Summary of Contents for Dodge 2005 Stratus Coupe

Page 1: Table Of Contents
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION LOCKING AND UNLOCKING SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS...
Page 3 CONTENTS Introduction ......4 How To Use This Manual ....4 INTRODUCTION Warnings, Cautions And Notes .
Page 4: Introduction
4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully.
Page 5: Introduction 5
WARNINGS, CAUTIONS AND NOTES This manual contains WARNINGS against operating procedures which could result in an accident or bodily injury. It also contains CAUTIONS against procedures which could result in damage to your vehicle. If you do not read this entire manual you may miss important information.
Page 6 6 INTRODUCTION Overview - Instruments and controls 1. Instrument cluster → p. 108 2. Ignition switch → p. 151 3. Supplemental restraint system-air bag (For driver’s seat) → p. 89 Horn switch → p. 134 4. Hazard warning flasher switch → p. 126 5.
Page 7 Interior 1. Seat belt → p. 68 Adjustable seat belt shoulder anchor (for front seats) → p. 73 2. Remote trunk lid release → p. 37 3. Power window switch → p. 44 4. Window lock switch → p. 45 5.
Page 8 8 INTRODUCTION Outside 1. Engine compartment → p. 259 Engine hood → p. 42 2. Windshield wiper and washer → p. 128 3. Sunroof (if so equipped) → p. 46 4. Outside rear-view mirrors → p. 190 5. Whip antenna → p. 221 6.
Page 9 INTRODUCTION 9 1. Inside emergency trunk release handle → p. 37 Trunk Area 2. Trunk light → p. 305 3. Jack → p. 267 4. Spare tire → p. 267 5. Tools → p. 266...
Page 10 10 INTRODUCTION QUICK INDEX If this warning light comes on… NOTE: These warning lights will illuminate for a few seconds for a bulb check when the ignition key is first turned on. Warning light Anti-lock braking system Brake warning light Oil pressure warning light Do this ·Park the vehicle in a safe place and turn off the engine.
Page 11 If this warning light comes on… Warning light Charging system warning light “N” indicator light in the instrument cluster flashes rapidly (twice per second) Do this ·Park the vehicle in a safe place and turn off the engine. Check the alternator belt. If the belt is loose, broken, missing, or if the light remains on when the ignition key is turned back on, call an authorized dealer for assistance.
Page 12 12 INTRODUCTION If this warning light comes on… Warning light “N” indicator light in the instruemnt cluster flashes slowly (once per second) Malfunction indicator light (“SERVICE ENGINE SOON”) Air bag warning light Traction control system warning light Do this ·Have the vehicle inspected at an authorized dealer as soon as possible.
Page 13 If you hear the sound… Sound If you hear a chime constantly when the driver’s door is opened. Do this “Key reminder chime” A chime will sound if the driver’s door is opened while the ignition key is in the “LOCK” or “ACC” position. Remove the key to stop the chime.
Page 14 14 INTRODUCTION If you hear the sound… Sound If you hear a metallic sound (squeal) when you depress the brake pedal while driving. If you hear a chime from the engine compartment continuously while the engine is on. Do this “Brake pad wear alarm”...
Page 15 If you hear the sound… Sound Warning light If you hear a chime while the engine is on, see the warning light in the instrument cluster. Do this “Seat belt reminder/warning chime” If the driver’s seat belt remains unfastened 1 minute later, the chime will sound intermittently (12 times) when the vehicle is driven.
Page 16 16 INTRODUCTION If this problem occurs… Problem Cannot turn the key Cannot shift the gear selector lever from the “P” (PARK) position The windows are fogged up. Do this (1)“LOCK” to “ACC” Turn the key while slightly turning the steering wheel right and left.
Page 17 If this problem occurs… Problem The engine does not start. The lights do not come on or dim. The horn does not honk or weak sound. The engine coolant temperature gauge indicator enters the “H” (hot) position. Steam comes out of the engine compartment.
Page 18 18 INTRODUCTION If this problem occurs… Problem The vehicle is stuck in sand, mud, or snow. The brakes are not functioning properly after crossing a puddle or stream. Do this 1. Carefully rock the vehicle by shifting the transmission from low to reverse. WARNING 1.When attempting to rock your vehicle out of a stuck position, be sure that no one is near the vehicle.
Page 19 If this problem occurs… Problem The automatic transaxle does not shift when accelerating and/or the vehicle does not easily begin to move. A tire is punctured. Do this There may be a problem in the automatic transaxle. Have the vehicle inspected by an authorized dealer. 1.Vehicles with automatic transaxle Shift the lever into “2”...
Page 21 LOCKING AND UNLOCKING CONTENTS Keys ....... . .23 Sentry Key ......23 Door locks (Manual) .
Page 22 22 LOCKING AND UNLOCKING Passenger switch ..... . .46 Sunroof (if so equipped) ....46 To tilt up.
Page 23: Locking And Unlocking 23
KEYS Two keys are provided. The keys fit all locks. Keep one in a safe place as a spare key. NOTE: The key number (A) is stamped on the plate as shown in the illustration. Make a record of the key number and store the key and key number plate in a separate place so that you can order a key from your authorized dealer if the original keys are lost.
Page 24 24 LOCKING AND UNLOCKING NOTE 1. In the following cases, the vehicle may not be able to receive the registered ID code from the key. This means the engine will not start even when the regis- tered key is turned to the START position: When the key comes into contact with a metallic or magnetic object.
Page 25 CAUTION! Do not make any alterations or additions to the sentry key system. Any alterations or additions could cause failure of the sentry key. Replacement keys NOTE: Only keys that have been programmed to the vehicle electronics can be used to start the vehicle. If you lose the key, you can order a key from your authorized dealer by referring to the key number.
Page 26: Door Locks (Manual)
26 LOCKING AND UNLOCKING If an error occurs, the indicator will flash 3 times. 5. Repeat step 4 if you want to register additional keys. Be sure to complete the entire registration process within 30 seconds after the theft-alarm indicator flashes in step General Information Your sentry key operates on a radio frequency subject to Federal Communications Commission (FCC) Rules.
Page 27: To Lock The Door With The Key
Key reminder chime After the ignition switch is off, if the driver’s door is opened while the ignition key is in the ignition, a chime will sound to remind you to remove the key. Forgotten-key prevention mechanism If the inside lock knobs on the doors are set to the locked position and the driver’s door or passenger’s door is closed while the key is still in the ignition switch, the lock will automatically be released.
Page 28: To Lock The Door From The Inside
28 LOCKING AND UNLOCKING To lock the door from the inside Move the inside lock knob to the locked position (so that the red mark cannot be seen) to lock the door. All doors should be kept locked while driving. The locked front driver’s side door can be opened by pulling its inside door handle without unlocking the inside lock knob.
Page 29: Keyless Entry System (If So Equipped)
KEYLESS ENTRY SYSTEM (IF SO EQUIPPED) UNLOCK button Press the keyless transmitter button(s), and all doors will be locked or unlocked as desired. The PANIC button can also help you signal for attention. To lock the doors Press the LOCK button, and all doors will be locked. When they are locked with the reading light in the “OFF”...
Page 30 30 LOCKING AND UNLOCKING Horn deactivation/reactivation The confirmation function can be set in the following three ways. Each time the confirmation function is set, a buzzer will sound to tell you the condition of the confirmation function. One buzzer: The horn will sound if the doors are locked with the keyless entry system.
Page 31: Using The Panic Alarm
Using the panic alarm If you are near your vehicle and feel threatened, you may activate the alarm to call attention. 1. Press the PANIC button. 2. The headlights will blink on and off and the horn will sound intermittently for about 3 minutes. 3.
Page 32: Procedure For Replacing Keyless Transmitter Battery
32 LOCKING AND UNLOCKING 7. If you wish to add another transmitter, contact an authorized dealer. A maximum of 4 keyless transmitters may be programmed for your vehicle. CAUTION! The keyless transmitter is a precision electronic device. Therefore; Avoid impact to the transmitter. Keep the transmitter dry.
Page 33 +side 2. Remove the discharged battery from the panic button side of the case half. 3. Install a new battery with its positive + side (2) down. Coin type battery CR2032 used 4. Close the transmitter case firmly and tighten the mounting screw.
Page 34: Power Door Locks
34 LOCKING AND UNLOCKING POWER DOOR LOCKS Locking and unlocking with the door lock switch Driver side switch Passenger side switch Lock Unlock All of the doors can be locked or unlocked by pressing the power door lock switch on the driver’s or the passenger’s door.
Page 35: Locking And Unlocking With Key Or Inside Lock Knob
Locking and unlocking with key or inside lock knob Lock Unlock Using the key to lock or unlock the driver’s or passen- ger’s (if so equipped) door will automatically lock or unlock all of the doors. Turn the key inserted in the driver’s door lock once in the unlocking direction, and the front driver’s door will be unlocked.
Page 36 36 LOCKING AND UNLOCKING CAUTION! Do not stand behind the exhaust pipe when loading and unloading luggage. Heat from the exhaust could lead to burns. To open the trunk lid Vehicles with keyless entry system Press the TRUNK button twice within five seconds. (Refer to ‘‘Keyless entry system’’...
Page 37: Remote Trunk Lid Release
Remote trunk lid release Pull the trunk lid release lever, located to the left of the driver’s seat, up to open the trunk lid. CAUTION! Do not operate the trunk lid release lever while the vehicle is moving. If the trunk lid opened, luggage could fall onto the road and cause an accident.
Page 38 38 LOCKING AND UNLOCKING The handle glows in the dark after exposure to sunlight. You and your family should familiarize yourselves with the location and operation of the emergency trunk release handle. Children should be taught not to play in or around vehicles.
Page 39: Fuel Filler
CAUTION! • When loading objects in the trunk, position them so that they will not contact the emergency trunk release handle when closing the trunk. This will prevent damage to the handle that could render it inoperable. • Always keep the handle in its holder when oper- ating the vehicle to prevent trunk cargo from moving the handle that might result in the open- ing of the trunk lid.
Page 40 40 LOCKING AND UNLOCKING WARNING! • Remove the fuel tank filler tube cap (gas cap) slowly to prevent fuel spray from the filler neck which may cause injury. • The volatility of some gasolines may cause a build up of pressure in the fuel tank that may increase while you drive.
Page 41 Low fuel warning chime If a chime sounds when the low fuel warning light is on, that means the fuel is low. NOTE: If the low fuel warning light goes off, then comes back on again, the chime will not sound. Fuel tank capacity 62 L (16.4 gal) CAUTION!
Page 42: Engine Hood Release
42 LOCKING AND UNLOCKING ENGINE HOOD RELEASE The engine hood release lever (located under the instru- ment panel near the driver’s door) is used to unlock the engine hood. Pull the lever toward you to release the engine hood latch. •...
Page 43 NOTE: Only open the engine hood when the wipers are at their parked position to prevent damage to the engine hood and wipers. Support the engine hood with the hood prop by inserting the hood prop securely in the opening in the hood marked with an arrow.
Page 44: Power Windows
44 LOCKING AND UNLOCKING CAUTION! Be careful that hands or fingers are not trapped when closing the engine hood. POWER WINDOWS Open NOTE 1. The windows can be operated when the ignition key is in the “ON ”position. The door windows can be opened or closed for a 30-second period even after the ignition switch is turned off.
Page 45: Driver Switch
Driver switch The main driver switch can be used to operate both door windows. Windows will move while the switch is being operated and stop when the switch is released. 1. Driver’s door window switch (To fully open the driver’s door window, it is not neces- sary to hold the switch down for the entire time the window is being lowered.) 2.
Page 46: Passenger Switch
46 LOCKING AND UNLOCKING Passenger switch The passenger switch can be used to operate the passen- ger door window. SUNROOF (IF SO EQUIPPED) F17A1610 The sunroof can be opened and closed with the ignition key in the “ON” position. To tilt up When the sunroof switch (1) is pressed, the back of the sunroof automatically goes up for inside ventilation.
Page 47: To Tilt Down
NOTE: Before tilting the sunroof, completely open the sunshade. Otherwise you will not have good ventilation. To tilt down Press the sunroof switch (2). To stop the sunroof partway, release the sunroof switch. To open When the sunroof switch (1) is pressed, the back of the sunroof automatically goes up.
Page 48: Sunshade
48 LOCKING AND UNLOCKING Sunshade The sunshade can be opened or closed manually while the sunroof is closed. NOTE: The sunshade will operate together with the sunroof only when the sunroof is opened. Do not attempt to close the sunshade when the sunroof is opened.
Page 49: Theft-Alarm System (If So Equipped)
3. Do not try to operate the sunroof if it is frozen closed (after snowfall or during extreme cold). 4. Do not sit on or place heavy luggage on the sunroof or roof opening edge. 5. Do not apply any force that may cause damage to the sunroof.
Page 50 50 LOCKING AND UNLOCKING 3. Lock the driver’s and the passenger’s door by using the key, power door lock switch, or the remote keyless transmitter (if equipped). After completion of the steps above, the theft-alarm indicator (located in the instrument cluster) will illumi- nate for approximately 20 seconds and then go out, indicating that the system is armed.
Page 51: Alarm Stage
7. The driver should not arm the system until first confirming that all passengers have left the vehicle. If the driver arms the system while a passenger(s) in the vehicle, the alarm may be activated when the passen- ger(s) leave the vehicle. Alarm stage The alarm will be activated if any of the following occur while the vehicle is parked and the system is armed.
Page 52: Disarmed Stage
52 LOCKING AND UNLOCKING Alarm deactivation The alarm can be deactivated in the following ways. 1. By turning the key (in the driver’s or passenger’s door) in either direction (toward lock or unlock). 2. By using the remote keyless transmitter (if equipped) to lock or unlock the door or trunk lid.
Page 53: Testing The Theft-Alarm System
3. If the UNLOCK button is pressed when all doors are closed and no door is opened within approximately 30 seconds, re-arming will automatically occur. NOTE: Once the system has been disarmed, it cannot be rearmed except by repeating the arming procedure. Testing the theft-alarm system Use the following procedure to test the system: 1.
Page 55 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS CONTENTS Front seats......57 To adjust seat forward or backward ..59 To recline the seatback .
Page 56 56 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS Tether anchors for the child restraint system ..85 Tether strap anchor installation ... . .86 Children who have outgrown child restraint systems.
Page 57: Front Seats
Your vehicle has seat belts and other features that help protect you and your passengers in an accident. Seat belts are the most important safety device. When worn properly, seat belts can reduce the chance of serious injury or death in various types of crashes. For added protection during a severe frontal collision, your vehicle has a Supplemental Restraint System (SRS) with air bags for the driver and front seat passenger.
Page 58 58 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS WARNING! • Do not attempt to adjust the seat while driving. This can be dangerous. • After adjusting the seat, make sure that the seat is securely locked into position. • Be sure to have the seat adjusted by an adult. If it is adjusted by a child, the seat may not be prop- erly locked into position.
Page 59: To Adjust Seat Forward Or Backward
To adjust seat forward or backward Type 1 (Manual) Pull the seat adjusting lever and slide the seat forward or backward to the desired position. Release the adjusting lever to lock the seat in position. SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 59 WARNING! To ensure the seat is locked securely, attempt to move the seat forward or backward without using...
Page 60: To Recline The Seatback
60 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS Push the switch to adjust the seat forward or backward to the desired position. Release the switch, and the seat will lock at that position. CAUTION! Operate the power seat with care not to have the hand or foot caught by the seat.
Page 61 Memory reclining knob When you fold down the seatback by using the memory reclining knob, the angle of the seatback will be memo- rized. Memory reclining knob Pull the memory reclining knob and fold the seatback down. SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 61 Just by pushing the seatback up into position will lock it in the memorized position.
Page 62 62 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS WARNING! To minimize risk of severe or fatal personal injury in the event of a collision or sudden stop, both the driver and passenger seatbacks should always re- main in a nearly upright position while the vehicle is in motion.
Page 63: To Adjust Seat Height (Driver's Side Only)
To adjust seat height (Driver’s side only) Type 1 (Manual) Turn the knob to raise or lower the whole seat cushion. 1. Raise 2. Lower SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 63 Type 2 (Power, driver’s side only-if so equipped) Front and/or rear parts of the seat cushion height can be adjusted.
Page 64 64 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS Rear part of the seat cushion Push the switch to raise or lower the rear part of the seat cushion. 1. Raise 2. Lower Whole seat cushion G22D0310 Push the center of the switch to raise or lower the whole seat cushion.
Page 65: To Adjust Lumbar Support (Driver's Side Only, If So Equipped)
To adjust lumbar support (Driver’s side only, if so equipped) Weak Strong A lumbar support is included in the seatback of the driver’s seat. The support has a three position adjust- ment. SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 65 For access to the rear seat (passenger side entry) G21E0230 To permit rear seat entry or exit, the front seatback will...
Page 66: Rear Seats
66 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS REAR SEATS Rear seat capacity WARNING! • The rear seating capacity of this vehicle is three people. • The rear seat occupants should always wear their seat belts when the vehicle is in motion. Fold down rear seatbacks The rear seatbacks can be folded forward to provide additional cargo area.
Page 67: Adjustment Of The Head Restraints
Adjustment of the head restraints Adjust the head restraint height so that the center of the restraint is as close as possible to your seated eye level. Any person too tall for the restraint to reach their seated eye level, should adjust the restraint as high as possible. To raise the restraint, push in the lock knob and pull it straight up.
Page 68: Seat Belts
68 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS SEAT BELTS Seat belts are installed in your vehicle for the protection of the driver and passengers. Always use the seat belts. In an accident, injury to the driver and passengers may be reduced if the seat belts are properly used.
Page 69: Unibelt Restraint System
WARNING! • To reduce the risk of severe or fatal injury from a deploying passenger air bag, make sure the pas- senger is also properly wearing their seat belt, remains sitting well back and upright in their seat and the seat is moved as far back as possible. Refer to “Supplemental Restraint System (SRS) - air bag”...
Page 70: Unibelt Instructions
70 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS UNIBELT instructions 1. Get in the vehicle and sit in a normal correct posture. To reduce the risk of severe or fatal injury caused by an inflating air bag, adjust the driver’s seat to the rear most position that still allows you to fully apply the pedals, easily control the steering wheel and safely operate the vehicle.
Page 71 2. Grasp the metal tongue and slide it up the webbing so that it becomes easy to pull across your body. After a couple of tries this will become an automatic one-handed motion. SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 71 G28A0220 3.
Page 72 72 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 4. Pull up on the shoulder portion of the belt to ensure that there is no slack in the lap belt. The belt will retain the small amount of slack necessary for comfort when you return to your normal seating position.
Page 73: Adjustable Seat Belt Shoulder Anchor (Front Seats)
5. The shoulder belt portion will allow regular move- ment under normal conditions. The belt will lock in the event of an abrupt change in vehicle motion. 6. To release the belt, push the button on the buckle. The belt retracts automatically, so hold the tongue when the belt is released and while it retracts.
Page 74: Enhanced Driver Seat Belt Use Reminder System (Beltalert™)
74 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS WARNING! To reduce risk of serious injury in a collision, adjust the anchor at a position so that the belt passes over your shoulder, but does not touch your neck. Always adjust the anchor when vehicle is not in motion.
Page 75: Seat Belt Extender
Turn the ignition key to the OFF position. A single chime will sound to signify that you have successfully completed the programming. The Enhanced Warning System (BeltAlert™) can be reac- tivated by repeating this procedure. NOTE: Although the Enhanced Warning System (BeltAlert™) has been deactivated, the Seat Belt Warning Light will continue to illuminate while the driver’s seat belt remains unfastened.
Page 76: Child Restraints
76 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS WARNING! • The extender should only be used if the existing belt is not long enough. Persons who can use the standard seat belt should not use an extender. Unnecessary use could result in serious personal injury in the event of a colli- sion.
Page 77 WARNING! • All children 12 years old and under should be seated in the rear seat, and properly restrained. Accident statistics indicate that children of all sizes and ages are safer when properly restrained in the rear seat rather than in the front seat. •...
Page 78 78 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS Air bag cover WARNING! Your vehicle is also equipped with a front passenger air bag. REAR-FACING CHILD RESTRAINTS or INFANT RESTRAINTS must NOT be used in the front passenger seat as it places an infant too close to the passenger air bag.
Page 79 WARNING! • It is important to use an approved rear facing infant restraint until the infant is one year old to allow the infant’s neck and spine to develop enough to support the weight of their head in the event of a collision. •...
Page 80 80 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS Installing a child restraint system to the lower anchorage (LATCH System) Your vehicle’s rear seat is equipped with lower anchor- ages for attaching a child restraint system that is compat- ible with the LATCH System. NOTE •...
Page 81 Installation 1. Open the gap a little between the seat cushion (A) and the seatback (B) with your hand to locate the lower anchorages (C). 2. Push the child restraint system’s lower anchor connec- tors into the lower anchorages (C) in accordance with the instructions provided by the child restraint system’s manufacturer.
Page 82: Installing A Child Restraint System To A Unibelt At The Rear Seat Positions Or The Front Passenger Seat (With Emergency/Automatic Locking Mechanism)
82 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS WARNING! • If there is any foreign material in or around the lower anchorage connectors, remove it before in- stalling the child restraint system. Also, make sure the seat belt is away from, not looped through or otherwise interfering with the child restraint sys- tem.
Page 83 Children 12 years old and under should be restrained in the rear seat only, whenever possible, although the front passenger seat belt can also be the converted to ALR mode. WARNING! • Before placing an infant or child in a child re- straint system, be absolutely certain you con- verted the retractor from the ELR mode to the ALR mode.
Page 84 84 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 3. To activate the ALR mode, slowly pull the shoulder part of the belt all the way out until it stops, then let the belt feed back into the retractor. 4. After the belt has retracted, tug on it. If the belt is locked, you will not be able to pull it out.
Page 85: Tether Anchors For The Child Restraint System
6. If your child restraint system requires the use of a top tether strap, refer to “Anchors for the child restraint system” on page 85. 7. Before putting the child in the restraint, push and pull the restraint in all directions to be sure it is firmly secure. Do this before each use.
Page 86: Tether Strap Anchor Installation
86 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS Tether strap anchor installation 1. Lift the cover from the tether anchor installation point by pulling it back with your hand as illustrated. 2. Latch the top tether strap hook (A) of the child seat onto the tether anchor bracket (B) and tighten the top tether strap hook so it is securely fastened.
Page 87: Seat Belts And Pregnant Women
WARNING! • Children who are not buckled up, with all the doors locked, can be thrown out of the vehicle or otherwise be seriously or fatally injured in the event of a collision. • A child should never be left unattended or unsu- pervised around the vehicle.
Page 88: Maintenance And Inspection Of Seat Belts
88 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS MAINTENANCE AND INSPECTION OF SEAT BELTS The seat belt webbing may be cleaned with mild soap or detergent solution. Allow the belts to dry in the shade. Do not allow them to retract until completely dry. Do not attempt to bleach or re-dye belts.
Page 89: Supplemental Restraint System (Srs) - Air Bag
WARNING! All seat belt assemblies, including retractors and attaching hardware, should be inspected by an au- thorized dealer after any collision. We recommend that all seat belt assemblies in use during a collision be replaced unless the collision was very minor and the belts show no damage and continue to operate properly.
Page 90 90 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS WARNING! • IT IS VERY IMPORTANT TO ALWAYS WEAR YOUR SEAT BELT PROPERLY EVEN WITH AN AIR BAG. • Seat belts help keep the driver and front pas- senger properly positioned. This reduces the risk of injury in all collisions, and reduces the risk of serious or fatal injuries when the air bags inflate.
Page 91 WARNING! • Do not sit on the edge of the seat or lean your head or chest close to the steering wheel or instrument panel. Do not put your feet or legs on or against the instrument panel. • Seat all infants and children 12 years of age and under in the rear seat properly restrained using an appropriate child restraint system.
Page 92 92 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS WARNING! Air bag cover • REAR- FACING CHILD RESTRAINTS or IN- FANT RESTRAINTS must NOT be used in the front passenger seat as it places an infant too close to the passenger air bag. The force of an inflating air bag could kill or cause serious injuries to the child.
Page 93 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 93 WARNING! • FRONT- FACING CHILD RESTRAINTS should be used in the rear seat whenever possible. If they must be used in the front passenger seat, move the seat to the full rear position. Failure to do so could kill or cause serious injuries to the child.
Page 94 94 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 1. Air bag module (Driver) 2. Air bag module (Passenger) 3. Air bag control unit (including the front impact sen- sors) 4. SRS warning light 5. Side air bag modules (if so equipped) 6.
Page 95: Event Data Recording
The air bags will operate only when the ignition switch is in the ‘‘ON’’ or ‘‘START’’ position. When an impact sensor detects a front or side impact of sufficient force, it automatically ignities materials in the module inflator which generate gas and inflates the appropriate air bags.
Page 96 96 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS Driver’s and passenger’s front air bag system Driver Front passenger WARNING! • Do not attach anything to the steering wheel’s padded cover, such as trim material, badges, etc. These could strike and injure an occupant if the air bag inflates.
Page 97 WARNING! • Do not set anything on, or attach anything to, the instrument panel above the glove compartment. Such items could strike and injure an occupant if the air bag inflates. • Do not mount or locate any aftermarket equipment on or behind the knee bolsters.
Page 98 98 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS A label is attached to the seatbacks in vehicles with side air bags. The side air bag is designed to inflate only on the side of the vehicle that is hit. Because the side air bags do not protect the occupants in all types of collisions, be sure to always wear your seat belts properly.
Page 99 WARNING! • The side air bag inflates with great force. In order to reduce the risk of serious or possibly fatal injury when the air bag is inflating, the driver and front passenger should not put their arms out in the windows or lean against the doors.
Page 100 100 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS WARNING! • Never install a rear-facing child restraint in the front passenger seat. Rear-facing child restraints MUST ONLY be used in the rear seat. Forward-facing child restraints should also be used in the rear seat. If a forward-facing child restraint must be used in the front passenger seat, move the seat as far back as possible, and make sure that the child stays in the child restraint...
Page 101: Srs Servicing
working properly. The SRS warning light is shared by the driver’s air bag, the front passenger’s air bag, and the optional side air bags. The air bags will operate only when the ignition switch is in the ‘‘ON’’ or ‘‘START’’ position WARNING! •...
Page 102 102 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS WARNING! • On vehicles with side air bags, do not modify your front seats, center pillar or center console. Such modifications can adversely affect SRS per- formance and may lead to possible injury. Also, if you discover any tear or open seam in the seat fabric near the side air bag, have the seat inspected by an authorized dealer.
Page 103: Transporting Pets
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 103 Transporting Pets Airbags deploying in the front seat could harm your pet. An unrestrained pet will be thrown about and possibly injured, or injure a passenger during panic braking or in a collision.
Page 105 INSTRUMENTS AND CONTROLS CONTENTS Instrument cluster ..... . 108 Meter cluster ......108 Indicator and warning light package .
Page 106 106 INSTRUMENTS AND CONTROLS Changing the setting for warning operation . . . 120 Automatic transaxle indicator (if so equipped) ..... . . 121 Traction Control System warning light (if so equipped) .
Page 107: Instruments And Controls 107
INSTRUMENTS AND CONTROLS 107 Canadian Programming/Gate Programming. . . 137 Reprogramming a Signal Button ... 139 Operation ......138...
Page 108: Instrument Cluster
108 INSTRUMENTS AND CONTROLS INSTRUMENT CLUSTER Meter cluster 1. Fuel gauge 2. Tachometer 3. Speedometer 4. Engine coolant temperature gauge 5. Odometer 6. Trip odometer 7. Trip odometer reset button D01A2700...
Page 109: Indicator And Warning Light Package
Indicator and warning light package 1. Washer fluid level indicator →P. 121 2. Anti-lock braking system warning light (if so equipped) →P. 115 3. Low-fuel warning light →P. 115 4. Brake warning light →P. 119 INSTRUMENTS AND CONTROLS 109 5. Supplemental Restraint System (SRS) - air bag warning light →P.
Page 110: Speedometer
110 INSTRUMENTS AND CONTROLS 11. High beam indicator →P. 114 12. Cruise control indicator →P. 115 13. Theft-alarm indicator →P. 114 14. Malfunction indicator light (SERVICE ENGINE SOON) →P. 117 15. Oil pressure warning light →P. 116 16. Charging system warning light →P. 116 17.
Page 111: Fuel Gauge
CAUTION! The red zone indicates an engine speed in excess of safe operation. Select the correct gear to control engine speed so the tachometer indicator does not enter the red zone. INSTRUMENTS AND CONTROLS 111 Fuel gauge The gauge shows the amount of fuel in the fuel tank when the ignition key is turned to the ‘‘on’’...
Page 112: Odometer/Trip Odometer
112 INSTRUMENTS AND CONTROLS Odometer/Trip odometer When the ignition switch is turned to the “ON” position, an “ODO” or “TRIP” indication is given. Every time the reset button (3) is pressed lightly (less than one second), the indicators will change from “ODO” to “Trip A”...
Page 113: Engine Coolant Temperature Gauge
since the current trip began and Trip measure the distance from an intermediate location. To return either Trip or Trip press the reset button (3) for more than one second. Only the currently displayed value will be reset. If Trip is displayed, for example, only Trip be reset.
Page 114: Turn Signal Indicators/Hazard Warning Lights
114 INSTRUMENTS AND CONTROLS CAUTION! While driving, care should always be taken to main- tain normal engine operating temperature. If the indicator enters the “H” (hot) position while driving, the engine is overheating. (Refer to “Engine over- heating” on page 279.) Turn signal indicators/hazard warning lights The arrow will flash in unison with the corresponding exterior turn signals when...
Page 115: Anti-Lock Braking System Warning Light (If So Equipped)
Trunk-ajar warning light and chime This light illuminates when the trunk lid is open or not completely closed. When the vehicle is moving at more than 5 mph (8 km/h) and the trunk lid is open or ajar, a chime will sound to inform the driver that the trunk lid is not properly shut.
Page 116: Front Fog Light Indicator (If So Equipped)
116 INSTRUMENTS AND CONTROLS CAUTION! Do not drive with an extremely low fuel level; running out of fuel could cause damage to the catalytic converter. Front fog light indicator (if so equipped) This indicator illuminates while the fog lights are on. NOTE: Fog lights will not be operational when high beam (headlights) are selected.
Page 117: Malfunction Indicator Light (Service Engine Soon)
CAUTION! • If this light illuminates and the engine oil level is not low, have your vehicle checked at an autho- rized dealer. • This warning light does not indicate the amount of oil in the crankcase. This must be determined by checking the oil level with the dipstick while the engine is turned off.
Page 118: Supplemental Restraint System (Srs)-Air Bag Warning Light
118 INSTRUMENTS AND CONTROLS CAUTION! • Prolonged driving with the malfunction indicator light on may result in further damage to the emission control system. Continued driving could also affect fuel economy and driveability. • If the light does not illuminate when the ignition key is turned to the “ON”...
Page 119: Brake Warning Light
driving, take your vehicle to your authorized dealer and have the system checked. [See “Supplemental Restraint System (SRS)” on page 118.] Brake warning light This light illuminates when the ignition key is turned to the “ON” position (engine off). When the engine is started, the light should go off. But when the parking brake is applied or the brake fluid falls below the prescribed level, the light illuminates.
Page 120: Seat Belt Reminder/Warning Light
120 INSTRUMENTS AND CONTROLS Seat belt reminder/warning light A chime and warning light are used to remind the driver to fasten the seat belt. When the ignition key is turned to the ‘‘ON’’ position, the warning light will illu- minate and a chime will sound for about 6 seconds.
Page 121: Automatic Transaxle Indicator (If So Equipped)
WARNING! In order to reduce risk of serious or fatal injury in an accident, always wear your own seat belt, and do not allow anyone to ride in your vehicle unless he or she is properly seated and wearing a seat belt. Children should be properly seated and restrained in an appropriate child restraint system.
Page 122: Combination Headlights, Dimmer And Turn Signal Lever
122 INSTRUMENTS AND CONTROLS COMBINATION HEADLIGHTS, DIMMER AND TURN SIGNAL LEVER Headlights Rotate the switch to operate the lights. OFF - All lights off - Parking, tail, front and rear side marker, license plate and instrument panel lights on - Headlights and other lights on NOTE: Do not leave the headlights and other lamps on for a long time while the engine is not running.
Page 123: Headlight Reminder Chime
1. Rotate the ignition key to “LOCK” or “ACC” position with the light switch in the ON “ ” position. 2. Turn light switch to “OFF” position within about 45 seconds of ignition key removal. 3. The headlights will stay on for about 60 seconds, then automatically turn off.
Page 124: Dimmer (High/Low Beam Change)
124 INSTRUMENTS AND CONTROLS NOTE: The headlights can also flash when the light switch is OFF. If you turn the lights off with the headlights set to high-beam illumination, the headlights are automati- cally returned to their low-beam setting when the light switch is next turned to the ON “...
Page 125: Fog Light Switch (If So Equipped)
There may be occasions when the lever does not return after cornering. This typically occurs when the steering wheel is turned only slightly. In this case, return the lever by hand. The instrument cluster indicator will flash to indicate proper operation of the front and rear turn signal lights. If the indicator light flashes faster than usual, check for a malfunctioning turn signal light bulb or faulty turn signal system.
Page 126: Hazard Warning Flasher Switch
126 INSTRUMENTS AND CONTROLS NOTE 1. If the headlights are switched to high beam, the fog lights will go out; they will illuminate again when the headlights are switched back to low beam. 2. If the light switch is rotated to OFF while the fog lights are illuminated, they will automatically turn off.
Page 127: Instrument Panel Light Dimmer Control
INSTRUMENT PANEL LIGHT DIMMER CONTROL Bright The brightness of the instrument panel lights can be adjusted by turning this knob while the light switch is in the ON “ ” or“ ” position. INSTRUMENTS AND CONTROLS 127 ELECTRIC REAR WINDOW DEFROSTER Indicator E15A0380 The electric rear window defogger can be operated when...
Page 128: Windshield Wipers
128 INSTRUMENTS AND CONTROLS It will turn off automatically in about 17 minutes. To turn off the defogger before 17 minutes has lapsed, push the switch again. CAUTION! • The rear window defroster is not designed to melt snow. Remove snow before use of the rear win- dow defroster.
Page 129: Intermittent Wipers
The intermittent intervals are adjustable from approxi- mately 3 to 18 seconds by rotating the adjusting knob at the end of the stalk. LO = Slow HI = Fast INTERMITTENT WIPERS Adjusting knob FAST SLOW Use the intermittent feature when weather conditions make a single wiping cycle, with a pause between cycles, desirable.
Page 130: Windshield Washer
130 INSTRUMENTS AND CONTROLS WINDSHIELD WASHER The windshield washer can be operated by pulling the lever toward you to spray fluid when the ignition key is in either the “ON” or “ACC” position. When washer fluid is sprayed, the wipers will automati- cally operate several times.
Page 131: Dome Light
vehicle in a safe place, turn off the ignition, and clean the deposits from the glass so that the wipers operate smoothly. 4. Avoid using the washer for more than 20 seconds at a time. To avoid pump damage, do not operate the washer when the fluid reservoir is empty.
Page 132: Lights (Dome Lights, Etc.) Auto-Cutout Function
132 INSTRUMENTS AND CONTROLS Push the light switch (A) to turn on the light, and push the light switch again to turn them off. LIGHTS (DOME LIGHTS, ETC.) AUTO-CUTOUT FUNCTION If any of the interior lights is left on with the ignition key in the ‘‘LOCK’’...
Page 133: Reading Lights
READING LIGHTS 1. Driver’s side 2. Passenger’s side Push the right or left reading light switch (lens) to turn on the light. This light produces a spot beam for convenient use as a map light at night. Push the reading light switch again to turn the light off. INSTRUMENTS AND CONTROLS 133 G08C0070 NOTE:...
Page 134: Rear Personal Lights
134 INSTRUMENTS AND CONTROLS REAR PERSONAL LIGHTS ON - The light illuminates OFF - The light illuminates when a door is opened and goes out when it is closed. HORN SWITCH E19A1270 Pressing on or around the causes the horn to honk. GARAGE DOOR OPENER (IF SO EQUIPPED) The HomeLink Universal Transceiver replaces up to...
Page 135: Training The Universal Transceiver
equipped). The transmitter operates off your vehicle’s battery and charging system; no batteries are needed. For additional information on HomeLink , call toll-free for customer assistance at 1–800–355–3515, or on the internet at www.homelink.com. WARNING! • A moving garage door can cause injury to people and pets in the path of the door.
Page 136 136 INSTRUMENTS AND CONTROLS Release the buttons when the light in the indicator (D) begins to flash after 20 seconds. A - Universal Transceiver button 1 B - Universal Transceiver button 2 C - Universal Transceiver button 3 D - Indicator light NOTE: •...
Page 137 NOTE: • Some entry gates and garage door openers may re- quire you to replace step 4 with the procedures listed under Canadian Programming. 5. The indicator light (D) will begin to flash, first slowly and then rapidly. The rapid flashing indicates successful programming.
Page 138 138 INSTRUMENTS AND CONTROLS Operation Press and hold the desired button (A, B or C) on the universal transceiver until the garage door or other device begins to operate. The indicator light (D) shows that the signal is being transmitted. The hand held transmitter (E) may also be used at any time.
Page 139 1. Locate the training button on the garage door motor head unit. The exact location and color of the training button may vary by garage door opener manufacturer. If you have difficulty in locating the training button, check your garage door opener manual, or call toll-free for customer assistance at 1-800-355-3515, or on the internet at www.homelink.jci.com.
Page 140 140 INSTRUMENTS AND CONTROLS 2. When the indicator light (D) begins to flash slowly (after 20 seconds) position the hand held transmitter (E) 1 to 3 inches away from the universal transceiver button to be trained. 3. Press and hold the hand held transmitter button. 4.
Page 141 This device complies with FCC rules part 15. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference that may be received including interference that may cause undes- ired operation.
Page 143 STARTING AND DRIVING CONTENTS Break-in recommendations....146 Fuel selection ......146 Gasoline additives .
Page 144 144 STARTING AND DRIVING Gear positions ......158 Driving speed (Vehicles with automatic transaxle) ..159 Holding on an upgrade .
Page 145 Cruise/speed control ....191 To activate......192 To deactivate .
Page 146: 146 Starting And Driving
146 STARTING AND DRIVING BREAK-IN RECOMMENDATIONS Advanced automobile manufacturing techniques permit you to operate your new vehicle without experiencing a long break-in period of low-speed driving. However, you can add to the future performance and economy of your vehicle by observing the following precautions during the first 300 miles (500 km).
Page 147: Gasoline Additives
CAUTION! Using leaded gasoline in your vehicle will damage the engine, catalytic converter, and the oxygen sen- sors. Further, using leaded gasoline is illegal, and will void warranty coverage of the engine, catalytic converter, and oxygen sensors. Gasoline additives Many fuel suppliers add detergents to their gasoline to minimize fuel injector fouling and to control intake valve deposits.
Page 148: Gasoline/Oxygenate Blends
148 STARTING AND DRIVING Gasoline/Oxygenate Blends Some fuel suppliers blend unleaded gasoline with mate- rials called oxygenates such as 10% ethanol, MTBE and ETBE. Oxygenates are required in some areas of the country during the winter months to reduce carbon monoxide emissions.
Page 149: Materials Added To Fuel
states adopting California emission standards, your ve- hicle will operate satisfactorily on fuels meeting Federal specifications, but emission control system performance may be adversely affected. Gasoline sold outside of California is permitted to have higher sulfur levels which may affect the performance of the vehicle’s catalytic converter.
Page 150 150 STARTING AND DRIVING NOTE: Tighten the gas cap until you hear a “clicking” sound. This is an indication that the gas cap is properly tightened. The Malfunction Indicator Light (“SERVICE ENGINE SOON”) will come on if the gas cap is not properly secured.
Page 151: Fuel Economy
FUEL ECONOMY Fuel economy is dependent on many factors. Your per- sonal driving habits can have a significant effect on your fuel economy. Several recommendations for achieving maximum fuel economy are listed below. 1. When pulling away from traffic lights or stop signs, accelerate slowly and smoothly.
Page 152: Key Reminder Chime
152 STARTING AND DRIVING NOTE: For vehicles with an automatic transaxle, the key cannot be removed unless the selector lever is set to the “P” (PARK) position. Allows operation of electrical accessories with the engine off. START Engages the starter. After the engine starts, release the key and it will return automatically to the “ON”...
Page 153: Theft Protection
THEFT PROTECTION CAUTION! Always remove the key from the ignition switch and lock all doors when leaving the vehicle unattended. Always try to park your vehicle in a well lighted area. The ignition key can only be removed in the “LOCK” position.
Page 154: Normal Conditions
154 STARTING AND DRIVING WARNING! Never run the engine in a closed or poorly ventilated area any longer than is needed to move your vehicle in or out of the area. Carbon monoxide gas, which is odorless, colorless and extremely poisonous, could build up, and cause serious injury or death.
Page 155: Flooded Engine
NOTE: Slight noises may be heard on engine start-up. These noises will disappear as you continue warming up the engine. Flooded engine If the engine has become flooded during starting, first operate the starter for 5 to 6 seconds while fully depress- ing the accelerator pedal (clear flood), then start the engine without depressing the accelerator pedal at all.
Page 156: Selector Lever Operation
156 STARTING AND DRIVING CAUTION! The electronically controlled transaxle system is strictly intended to provide supplementary func- tions. When driving downhill under certain condi- tions, or immediately after starting when the auto- matic transaxle is cold, no automatic shift-down may be made.
Page 157 The indicator panel, on the console located at the driver’s right, is illuminated for night driving. Button (A) must be pushed while the brake pedal is depressed to move the selector lever. Button need not be pushed to move the lever. Button must be pushed to move the lever.
Page 158: Gear Positions
158 STARTING AND DRIVING Gear positions “P” PARK The “P” (PARK) position supplements the parking brake by locking the transaxle while the vehicle is parked. The engine can be started in this position. Apply the parking brake before leaving the vehicle in this position.
Page 159: Driving Speed
“3” THIRD / “2” SECOND For driving slowly in heavy city traffic or on mountain roads where more precise speed control is desired. Also use it when climbing long grades, and for engine braking when descending moderately steep grades. Engine braking is automatically applied when necessary, depending on road conditions.
Page 160: Transaxle Reset Mode
160 STARTING AND DRIVING Transaxle Reset Mode The transaxle is monitored for abnormal conditions. If a condition is detected that could cause damage, the trans- axle automatically shifts into second gear. The transaxle remains in second gear despite the forward gear selected. Park (P), Reverse (R), and Neutral (N) will continue to operate.
Page 161: Selector Lever Operation
CAUTION! The electronically controlled transaxle system is strictly intended to provide supplementary func- tions. When driving downhill under certain condi- tions, or immediately after starting when the auto- matic transaxle is cold, no automatic shift-down may be made. The driver should shift down to a low gear (3rd gear or 2nd gear), which will permit the engine to exert a braking effect.
Page 162 162 STARTING AND DRIVING In the main gate, the selector lever has 4 positions and is equipped with a lock button (A) to prevent inad- vertent selection of the wrong gear. I04S1580 Button (A) must be pushed while the brake pedal is depressed to move the selector lever.
Page 163: Indicator Lights
WARNING! Always depress the brake pedal when shifting the selector lever into a gear from the “N” (NEUTRAL) position. When beginning to drive, do not shift the selector lever from the “N” (NEUTRAL) position while depressing the accelerator pedal; doing so may cause the vehicle to “jump”...
Page 164: Selector Positions (Main Gate)
164 STARTING AND DRIVING If the “N” indicator light in the instrument panel flashes, there could be a malfunction with the automatic transaxle system. Identify and take action in accordance with the following procedures: 1. The “N” indicator light flashes rapidly (twice per second) in the “D”...
Page 165: Selector Positions Manual Gate Autostick
“N” NEUTRAL The engine may be started in this position. WARNING! • Never move the lever to the “N” position while driving since you could accidentally move the lever into the P or R position, damaging the transaxle. • To prevent the vehicle from rolling when stopped on a slope, the engine should be started in the “P”...
Page 166 166 STARTING AND DRIVING + (UP) : Push the lever forward once to shift up one gear. – (DOWN) : Pull the lever backward once to shift down one gear. • Upward shifts do not take place automatically in Autostick. The driver must execute upward shifts in accordance with road conditions, make sure the engine rpm remains below the red zone on the tachometer.
Page 167: Holding On An Upgrade
3. In Autostick, downward shifts are made automatically when the vehicle slows down. When the vehicle stops, 1st gear is automatically selected. 4. When starting out on slippery roads, push the selector lever forward into the + (UP) position. This puts the transmission into 2nd gear and is better for starting out on slippery roads.
Page 168: Transaxle Reset Mode
168 STARTING AND DRIVING Transaxle Reset Mode The transaxle is monitored for abnormal conditions. If a condition is detected that could cause damage, the trans- axle automatically shifts into second gear. The transaxle remains in second gear despite the forward gear selected. Park (P), Reverse (R), and Neutral (N) will continue to operate.
Page 169: To Start
To start Depress the clutch pedal fully and shift into 1st. Then gradually release the clutch pedal while depressing the accelerator pedal. CAUTION! • Do not move the gearshift lever into the “R” (REVERSE) while the vehicle is moving forward; doing so will damage the transaxle.
Page 170 170 STARTING AND DRIVING At low altitude locations, shift at the vehicle speeds listed for acceleration. Earlier upshifts during cruise conditions (relatively steady speeds) will result in increased fuel economy. 2.4 liter engine Condition Upshift speeds mph (km/h) Acceleration 1st to 2nd 15 (25) 2nd to 3rd 23 (35)
Page 171: Recommended Downshifting Speed
Recommended downshifting speed Downshifting speed mph (km/h) Under 20 (30) 20 to 30 (30 to 45) Driving precautions 1. The table below indicates the driving speed ranges that may be driven in each gear without causing the engine to operate in excessive engine speeds. Possible driving speed Condition 2.4 liter engine Condition...
Page 172 172 STARTING AND DRIVING Before leaving the vehicle, make sure that the parking brake is set. To set the parking brake, pull up firmly on the lever. Also place the gear selector in the Park position (automatic transaxle) or Reverse (manual transaxle). To release the parking brake, apply the brake pedal and pull up on the parking brake lever.
Page 173: Brake Pedal
WARNING! • Leaving children in a vehicle unattended is dan- gerous for a number of reasons. A child or others could be injured. Children should be warned not to touch the parking brake or the gear selector. Don’t leave the keys in the ignition. A child could operate power windows, other controls, or move the vehicle.
Page 174: Power Brakes
174 STARTING AND DRIVING WARNING! Riding the brakes can lead to brake failure and possibly an accident. Driving with your foot resting or riding on the brake pedal can result in abnormally high brake temperatures, excessive lining wear, and possible brake damage. You wouldn’t have your full braking capacity in an emergency.
Page 175: Anti-Lock Braking (Abs) System (If So
WARNING! Driving on worn brake pads can reduce your ability to stop, and can result in an accident. ANTI-LOCK BRAKING (ABS) SYSTEM (IF SO EQUIPPED) The ABS gives increased vehicle stability and brake performance under most braking conditions. The system automatically “pumps”...
Page 176 176 STARTING AND DRIVING CAUTION! • Anti-lock braking system can not prevent acci- dents. It remains the driver’s task to exercise safety precautions and to drive prudently. • To prevent failure of the anti-lock braking system, be sure all 4-wheels and tires are the same size and type (space saver spare excluded).
Page 177: Steering Wheel Tilt Lock Lever
6 mph (10 km/h). It stops operating when the vehicle decelerates to a speed below approximately 3 mph (5 km/h). Wheel speed sensor 3. After driving on snow or icy roads, remove any snow and ice that may have adhered to the wheel areas. When doing this be careful not to damage the wheel speed sensors and cables located at each wheel on vehicles equipped with an anti-lock braking system.
Page 178: Power Steering
178 STARTING AND DRIVING WARNING! • After adjustment, to the desired height, check to be sure that the lever is locked. • Do not attempt to adjust the steering wheel while driving. This can be dangerous. POWER STEERING Your vehicle is equipped with power assisted steering as standard equipment.
Page 179: Inside Day/Night Rearview Mirrors
INSIDE DAY/NIGHT REARVIEW MIRRORS WARNING! • Do not attempt to adjust the rearview mirrors while driving. This can be dangerous. • Your passenger’s side mirror is convex. The ob- jects you see in the mirror will look smaller and farther away than they actually are. Do not use this mirror to estimate the distance of following vehicles when changing lanes.
Page 180: Electrochromic Inside Rearview Mirror
180 STARTING AND DRIVING I08A0630 I08A0640 Electrochromic inside rearview mirror (if so equipped) When the ignition key is in the “ACC” or “ON” position, the green indicator (A) should be illuminated. If not, press the display switch (C) for more than 6 seconds, less than 9 seconds, until the indicator illuminates.
Page 181: Electrochromic Mirror Operation (If So Equipped)
To turn off the function, press the display switch (C) more than 6 seconds, less than 9 seconds. When the green indicator (A) goes off, the automatic anti-glare will not function. To turn the function back on, press the display switch (C) more than 6 seconds, less than 9 seconds.
Page 182 182 STARTING AND DRIVING How to change the display mode The mode will change in order by pressing the display switch for the following seconds. 1. When the ignition key is “ACC” or “ON” position, automatic anti-glare operate and current outside tem- perature and compass are displayed.
Page 183 2. If you press the display switch less than 3 seconds, you can turn on/off the display. 3. If you press the display switch more than 3 seconds, less than 6 seconds, you can alternate the temperature reading between Fahrenheit and Celsius. → P. 186. I08A0660 STARTING AND DRIVING 183 I08A0590...
Page 184 184 STARTING AND DRIVING 4. If you press the display switch more than 6 seconds, less than 9 seconds, you can turn on/off the automatic anti-glare. → 181 5. If you press the display switch more than 9 seconds, less than 12 seconds, you can adjust for compass vari- ance.
Page 185 6. If you press the display switch more than 12 seconds, you can recalibrate compass variance. →190 Outside temperature (if so equipped) I08A0590 When the ignition key is in the “ACC” or “ON” position, the current outside temperature is displayed. STARTING AND DRIVING 185 I08A0600...
Page 186 186 STARTING AND DRIVING To alternate the temperature reading between Fahrenheit and Celsius Press the display switch above 3 seconds, less than 6 seconds until the display blinks °F and °C. Press the display switch to toggle between the Fahrenheit and Celsius readings within 5 seconds.
Page 187 Compass operation When the ignition key is in the “ACC” or “ON” position, the vehicle’s current directional heading (N, NE, E, SE, S, SW, W and NW) will be displayed. Magnetic variation of compass Under certain circumstances, as during a long distance cross-country trip, it will be necessary to adjust for magnetic variation of compass.
Page 188 188 STARTING AND DRIVING 2. Find your current location and variance zone number on the zone map. 3. Press the display switch until the new zone number appears in the display. After 5 seconds of inactivity, the original item (Outside temperature/Compass) displayed again.
Page 189 STARTING AND DRIVING 189 To calibrate the compass If the display reads “CAL” (A), there may be a strong magnetic field interfering with the compass. In this case, the compass may need calibration. I08A0650 D11C0110 If the “CAL” is displayed, drive the vehicle in a circle at about 5 mph (8km/h) or less until the “CAL”...
Page 190 190 STARTING AND DRIVING If the “CAL” is not displayed, but compass calibration is required, press and hold the display switch for 12 sec- onds, or until “CAL” is displayed. With “CAL” dis- played, drive the vehicle in a circle at less than 5mph (8km/h) or less until the “CAL”...
Page 191: Cruise/Speed Control
NOTE • After adjustment, return the lever to the centered position. Press the left, right, up or down switches (B) to adjust the mirrors as desired. 1. Up 2. Down 3. Right 4. Left STARTING AND DRIVING 191 CRUISE/SPEED CONTROL Cruise/speed control is an automatic speed control sys- tem.
Page 192: To Activate
192 STARTING AND DRIVING CAUTION! • For safety reasons, the main switch (A) should be set to the OFF position when you are not using the cruise/speed control system. • Cruise/speed control is not recommended when driving conditions will not allow you to stay at the same speed, such as in heavy traffic or on roads that are winding, icy, snow-covered, wet, or slip- pery, or on a steep downhill.
Page 193 2. When the main switch (A) is ON, the “CRUISE” control light on the instrument cluster will illuminate. 3. Pull the lever (B) down while driving at the desired speed. I10A1670 To increase the set speed There are 2 ways to increase the set speed. STARTING AND DRIVING 193 I10A1500...
Page 194 194 STARTING AND DRIVING Cruise/speed control lever Pull the cruise/speed control lever up and hold it. Your speed will then gradually increase. When you reach your desired speed, release the switch. Your cruising speed is now set. To increase your speed in small amounts, pull the cruise/ speed control lever up for less than 1 second and release it.
Page 195 Cruise/speed control lever Pull the cruise/speed control lever down and hold it while driving at the set speed, and you will slow down (coast) gradually. When your desired low speed is reached, release the lever. To slow down in small amounts, press the cruise/speed control lever down for less than 1 second and release it.
Page 196: To Deactivate
196 STARTING AND DRIVING To accelerate for passing Press the accelerator pedal as you would normally. When you release the pedal, the cruise/speed control will return to your set speed. To deactivate I10A1520 The cruise/speed control can be turned off as follows: 1.
Page 197: To Resume The Set Speed
3. By slightly tapping the brake pedal or pressing down on it to slow your speed. 4. By pressing the clutch pedal down (for vehicles with manual transaxle). 5. By moving the selector lever to “N” (for vehicles with automatic transaxle). 6.
Page 198: Traction Control (If So Equipped)
198 STARTING AND DRIVING procedure: (1) The ignition key is turned OFF. (2) The main switch is turned OFF. TRACTION CONTROL (IF SO EQUIPPED) On slippery surfaces, traction control system prevents the drive wheels (front wheels) from excessive spinning, during starting or while accelerating in turns on slippery roads.
Page 199: Catalytic Converter
Warning light When the ignition key is turned to “ON”, the warning light illuminate and go out after a few seconds. CAUTION • If the warning light illuminates, a malfunction may have occurred in the system. When this happens, have your vehicle checked at an authorized dealer.
Page 200 200 STARTING AND DRIVING CAUTION! Damage to the catalytic converter can result if your vehicle is not kept in proper operating condition. In the event of an engine malfunction, particularly one involving engine misfire or other apparent loss of performance, have your vehicle serviced promptly. Prolonged operation of your vehicle while it is overheated may result in damage to the converter and vehicle.
Page 201: Vehicle Preparation Before Driving
8. Stop driving the vehicle if you think the performance is noticeably less, or that there is unnecessary engine miss, or any other engine trouble, such as with the ignition, etc. If it is impractical to stop driving immedi- ately, reduce the speed and drive for only a short time. Have an inspection made by an authorized dealer as soon as possible.
Page 202: Lights
202 STARTING AND DRIVING Check wheel nuts for tightness and tires (including spare tire) for proper pressure. Maintain specified tire inflation pressures. Replace tires before they are excessively worn. Lights Have someone observe the operation of all exterior lights while you activate the controls. Check the turn signals and highbeam indicators on the instrument panel.
Page 203: Driving, Alcohol And Drugs
6. Always obey applicable laws and regulations. Be a courteous and alert driver. Always leave room for unexpected events, such as sud- den braking. 7. Never drive when you are sleepy or fatigued. Never drive under the influence of alcohol, drugs, or medica- tion.
Page 204: Operation During Cold Weather
204 STARTING AND DRIVING over curbs or parking stop blocks. Always use caution when traveling up or down sharp inclines as your bumper may contact the road surface. 2. Maintain specified tire inflation pressures. Replace tires before they are excessively worn. 3.
Page 205: Trailer Towing
WARNING! Never open the radiator cap when the radiator is hot. You could be seriously burned. TRAILER TOWING Warranty Requirements The Manufacturer’s Passenger Vehicle Warranty will apply to vehicles used to tow trailers for non-commercial use. However the following conditions must be met: •...
Page 206 206 STARTING AND DRIVING Weight limits I26A1290 Never exceed the maximum trailer weight (A), maximum tongue weight (B), Gross Vehicle Weight Rating (GVWR) and Gross Axle Weight Rating (GAWR).
Page 207 FOR PLEASANT DRIVING CONTENTS Sun visors ......211 To adjust the sun visor position ... 211 Vanity mirror .
Page 208 208 FOR PLEASANT DRIVING Fade ......222 Graphic Equalizer ..... 222 AM/FM Selection .
Page 209 Tuning ......228 Balance ......228 Fade .
Page 210 210 FOR PLEASANT DRIVING Vents....... . 237 Air flow rate and direction adjustments ..237 Air conditioning .
Page 211: For Pleasant Driving 211
SUN VISORS 1. To reduce front glare. 2. To reduce side glare. To adjust the sun visor position 1. Remove the holder (A) from the hook (B), then move the sunvisor to the window. 2. Slide the sun visor and adjust the position. G10A0260 FOR PLEASANT DRIVING 211 G10A0550...
Page 212: Vanity Mirror
212 FOR PLEASANT DRIVING Vanity mirror A vanity mirror is on the back of the sun visor. G10A0580 WARNING! G13A0850 • Do not attempt to adjust the sun visor while driving. This can be dangerous.
Page 213: Accessory Socket
Opening the lid of the vanity mirror will automatically turn on the mirror lights (C). CAUTION! If the lid of the lighted vanity mirror is kept open for prolonged periods of time, the battery may be dis- charged. ACCESSORY SOCKET G13A0840 Two accessory sockets are provided in the center console.
Page 214: Cup Holder
214 FOR PLEASANT DRIVING CAUTION! • Be sure to use a “plug-in” type accessory operat- ing on 12V and at 120W or less. Extended use of electronic equipment with the engine off may run down the battery. • When the accessory socket is not in use, be sure to close the socket cap.
Page 215: Accessory Boxes
CAUTION! Do not drink beverages while driving the vehicle; doing so could distract you and result in an accident. REAR SEAT Cup holders are provided at each side for the rear passengers. ACCESSORY BOXES Convenient storage space is located throughout the ve- hicle.
Page 216: Glove Compartment
216 FOR PLEASANT DRIVING Glove compartment To open the glove compartment, pull the lever. An open glove compartment door can result in serious injury to the front passenger in an accident, even if the passenger is wearing the seat belt. Al- ways keep the glove compartment door closed when driving.
Page 217: Center Console With Lid
Center console with lid Small articles can be stored in center console. To open the center console, pull up on the front of the lid. Trunk net (if so equipped) G14C0430 Attach the net to hooks according to the illustration. Keep the net stored in the trunk so it can be used at any time.
Page 218: Electronic Digital Clock
218 FOR PLEASANT DRIVING ELECTRONIC DIGITAL CLOCK The clock and radio each use the display panel built into the radio. A digital readout indicates the time in hours and minutes whenever the ignition switch is in the ON or ACC position. Clock setting procedure 1.
Page 219: Signal Transmission
Signal transmission FM signals do not follow the earth’s surface nor are they reflected by the upper atmosphere. For this reason, FM broadcasts cannot be received over long distances. AM signals follow the earth’s surface and are reflected by the upper atmosphere. For this reason, AM broadcasts can be received over longer distances.
Page 220: Cross Modulation
220 FOR PLEASANT DRIVING The direct signal from the broadcast station reaches the antenna slightly before the reflected signal. This time difference may cause some reception disturbance or flutter. This typically occurs in urban areas. Cross modulation If one listens to a weak station and is in the vicinity of another strong station, both stations might be received simultaneously.
Page 221: Whip Antenna
FM reception is not as sensitive to electrical disturbances as AM. AM reception is sensitive to electrical distur- bances such as power lines, lightning and other types of similar electrical phenomena. WHIP ANTENNA To remove the whip antenna, turn it counterclockwise. CAUTION! It is recommended to remove the whip antenna before going into an automatic vehicle wash or...
Page 222: Power Switch, Volume Control
222 FOR PLEASANT DRIVING Power Switch, Volume Control Press the ON/VOL control to turn the radio on. Turn the volume control clockwise to increase the volume. Seek Button (Radio Mode) Press and release the Seek button to search for the next station in either the AM or FM mode.
Page 223: To Set The Radio Pushbutton Memory
To stop the search, press SCAN a second time. To Set The Radio Pushbutton Memory When you are receiving a station that you wish to commit to push-button memory, press the SET button. SET 1 will show in the display window. Select the push-button you wish to lock onto this station and press and release that button.
Page 224: Seek Button
224 FOR PLEASANT DRIVING Seek Button Press the SEEK button up for the next selection on the tape and down to return to the beginning of the current selection. Press the SEEK button up or down to move the track number to skip forward or backward 1 to 6 selections.
Page 225: Noise Reduction
Noise Reduction The Dolby noise reduction system* is on whenever the tape player is on, but may be switched off. To turn off the Dolby noise reduction system: Press the NR button (button 2) after you insert the tape. The NR light in the display will go off when the Dolby NR System is off.
Page 226: Program Button 4 (Random Play)
226 FOR PLEASANT DRIVING released. Press the RW (Rewind) button and the CD player will reverse through the tracks until the button is released. Program Button 4 (Random Play) Press this button while the CD is playing to activate Random Play. This feature plays the selections on the compact disc in random order to provide an interesting change of pace.
Page 227: Am/Fm Stereo Radio With 4 Disc Cd Changer (If So Equipped)
Maintain your cassette tape player. The head and capstan shaft in the cassette player can pick up dirt or tape deposits each time a cassette is played. The result of deposits on the capstan shaft may cause the tape to wrap around and become lodged in the tape transport.
Page 228: Seek Button (Radio Mode)
228 FOR PLEASANT DRIVING Seek Button (Radio Mode) Press and release the Seek button to search for the next station in either the AM or FM mode. Press the top of the button to seek up and the bottom to seek down. The radio will remain tuned to the new station until you make another selection.
Page 229: To Set The Pushbutton Memory
To Set The Pushbutton Memory When you are receiving a station that you wish to commit to push-button memory, press the SET button. SET 1 will show in the display window. Select the push-button you wish to lock onto this station and press and release that button.
Page 230: Seek Button
230 FOR PLEASANT DRIVING will show the track number and index time in minutes and seconds. Play will begin at the start of track 1. Seek Button Press the top of the SEEK button for the next selection on the CD. Press the bottom of the button to return to the beginning of the current selection.
Page 231: Playing Discs
Playing Discs The radio display indicates the CD number (the slot where the CD is loaded), and the current track being played at the time. If more than one CD is loaded in the CD changer, it automatically plays the next CD after playing the last track of the current CD.
Page 232: How To Adjust The Volume
232 FOR PLEASANT DRIVING 5. Seek down / Rewind APS button / Track down button 6. Volume down button NOTE: • Do not push two or more of the steering wheel remote control switches at the same time. How to adjust the volume Volume up button - 2 The volume will increase when this button is pressed.
Page 233: To Listen To A Tape
To listen to a tape To operate the APS (Automatic Program Sensor) system The start of each song on a prerecorded music tape can be found by using the Fast forward APS button (1) or Rewind APS button (5). As many as 7 programs can be skipped over in this manner.
Page 234: Handling Of Compact Discs
234 FOR PLEASANT DRIVING Handling of Compact Discs (1) Use only the type of compact discs that have the mark shown in the illustration above. (Playback of CD-R discs may cause problems. CD-RW discs cannot be played.) (2) The use of special shaped, damaged compact discs (like cracked discs) or low-quality compact discs (like warped discs or burrs on the discs) such as those shown below will damage the CD player.
Page 235 (3) In the following circumstances, moisture can form on compact discs and inside the audio system, prevent- ing normal operation. • When there is high humidity (for example, when it is raining). • When the temperature suddenly rises, such as right after the heater is turned on in cold weather.
Page 236: Radio Operation And Cellular Phones
236 FOR PLEASANT DRIVING Do not wipe in a circle. Never use any chemicals such as benzine, paint thinner, a disc spray cleaner, or an anti-static agent on the disc. (8) Do not use a ball point pen, felt pen, pencil, etc. to write on the label surface of the disc.
Page 237: Vents
This condition is not harmful to the radio. If your radio performance does not satisfactorily “clear” by the repo- sitioning of the antenna, it is recommended that the radio volume be turned down or off during cellular phone operation. VENTS 1.
Page 238: Air Conditioning
238 FOR PLEASANT DRIVING Change the direction of the airflow from side to side by moving the knob (A). Change the vertical direction of the air flow up and down by pushing the top button edge of the vents. NOTE: On rare occasions, air from the vents of an air-conditioned vehicle may look like fog.
Page 239: Changing The Blower Speed
Changing the blower speed The blower may be operated (when the ignition key is in the ON position) at 4 different speeds. Select the best speed to fit your needs. When the blower switch is set to the ‘‘O’’ position, all air conditioning functions will stop. Changing the temperature H23A2860 Select the desired temperature level by turning the tem-...
Page 240: Changing Mode Selection
240 FOR PLEASANT DRIVING Changing mode selection To change air flow to the different outlets, turn the mode selection dial to the desired position. Face position H03I0670 Air flows exclusively to the upper part of the passenger compartment. H13D0543...
Page 241 Foot/face position Air flows to the upper part of the passenger compart- ment and flows to the leg area. NOTE: Air flows mostly to the upper part of the pas- senger compartment with the dial within position (1), and flows mostly to the leg area with the dial within position (2).
Page 242 242 FOR PLEASANT DRIVING Foot position Air flows mainly to the leg area. Foot/defroster position H13D0563 Air flows to the leg area, windshield, and door windows. H13D0573...
Page 243 NOTE: Air flows mostly to the leg area with the dial within position (1), and flows mostly to the windshield with the dial within position (2). FOR PLEASANT DRIVING 243 Defroster position Air flows exclusively to the windshield and door win- dows.
Page 244: Changing Air Selection
244 FOR PLEASANT DRIVING NOTE: When the mode selection dial is set to the “ or “ ” position, the air conditioning compressor will operate automatically. The outside air position will also be selected automatically. (In this case, the air condition- ing indicator will not change.) This is done for optimum performance.
Page 245: Air Conditioning Switch
Air conditioning switch The air conditioning can be operated while the engine is running. Push the switch, and the air conditioning (cooling/ dehumidifying function) will operate. When “ON”, the operation indicator lamp (A) will illuminate. Push the switch again and the air conditioning will stop. CAUTION! When using the air conditioning, the idle speed is slightly increased.
Page 246: How To Use The Controls
246 FOR PLEASANT DRIVING How to use the controls Heating Set the mode selection dial to the position shown in the illustration and set the air selection switch (A) to the “outside” position. Adjust the temperature by turning the temperature con- trol dial clockwise.
Page 247 To keep the windshield and door windows defogged, and to keep leg area heated (when driving in rain or snow). 1. Set the mode selection dial to the 2. Adjust the blower to the desired speed. 3. Set the desired temperature. For quick defrosting 1.
Page 248 248 FOR PLEASANT DRIVING Combination of unheated air and heated air Set the mode selection dial to the position shown in the illustration and set the air selection switch (A) to the outside position. The air will be directed to the leg area and the upper part of the passenger compartment.
Page 249: Important Operation Tips For Air Conditioning
Adjust the temperature by turning the temperature con- trol dial clockwise or counterclockwise. Select the desired blower speed. NOTE: If the outside air is dusty or otherwise contami- nated, or if maximum cooling performance is desired, set air selection switch (A) to the recirculation position and the temperature control dial all the way to the left.
Page 250: During A Long Period Of Disuse
250 FOR PLEASANT DRIVING CAUTION! The air conditioning system in your vehicle must be charged with the refrigerant HFC-134a and the lubri- cant SUN-PAG 56. Use of any other refrigerant or lubricant will cause severe damage which will result in the need to replace your vehicle’s entire air conditioning system.
Page 251 CONTENTS Cleaning the inside of your vehicle ..253 Plastic, vinyl leather, fabric, and flocked parts. . 253 Upholstery ......253 Genuine leather (if so equipped) .
Page 252 252 VEHICLE CARE In order to maintain the value and good looks of your vehicle, perform regular maintenance using proper ma- terials and procedures. Be sure to use only those materials and procedures that are in compliance with all local environmental pollution control regulations.
Page 253: Cleaning The Inside Of Your Vehicle
CLEANING THE INSIDE OF YOUR VEHICLE After cleaning the inside of your vehicle with cleaner, wipe it dry in a shady, well ventilated area. CAUTION! Do not use organic substances (solvents, kerosene, alcohol, gasoline, etc.) or alkaline or acidic solutions. These chemicals can cause discoloring, staining or cracking of the surface.
Page 254: Genuine Leather (If So Equipped)
CLEANING THE OUTSIDE OF YOUR VEHICLE To protect your vehicle’s outside finish, it is important that you wash it often and thoroughly. If desired, you may wax your vehicle by using an automobile wax. Foreign material Industrial fallout, road tar, bird droppings, tree sap, insect remains, sea water, and other foreign matter can damage the finish of your vehicle.
Page 255: Washing
Washing Chemicals contained in the dirt and dust picked up from air, rain, snow, or road surface can damage the paint coat and body of your vehicle if left in prolonged contact. Frequent washing and waxing is the best way to protect your vehicle from this damage.
Page 256: During Cold Weather
256 VEHICLE CARE CAUTION! • Some types of washers (including coin-operated washers) apply high temperature and high pres- sure to the vehicle, which may cause heat distor- tion and damage to the resin parts of the vehicle body, leakage of water into the vehicle, etc. There- fore, be sure to observe the following.
Page 257: Waxing Your Vehicle
Waxing your vehicle Wax your vehicle once or twice a year, or when painted surfaces do not shed water well. Apply a small amount of wax to painted surfaces with a soft cloth. After the wax has dried, polish with a dry soft cloth.
Page 258: Polishing Your Vehicle
258 VEHICLE CARE Polishing your vehicle If painted surfaces have been severely damaged and lost their original luster and color tone, polish the surface lightly with a fine polishing compound. Avoid limiting your polishing to the damaged surface only; polish a somewhat wider area, moving the polishing cloth in one direction.
Page 259: Chrome Parts
Chrome parts To prevent spots and corrosion of chrome parts, wash with water, dry thoroughly, and apply a nonabrasive automotive wax. If the chrome is severely damaged or pitted use a commercially available chrome polish. Aluminum wheels (if so equipped) A protective coating is provided over aluminum wheels.
Page 261 CONTENTS If the vehicle breaks down ....263 If the engine quits ..... 263 Operation under adverse driving conditions.
Page 262 262 EMERGENCIES Headlights ......295 Adjustment of headlight aim....297 Front turn signal and parking lights.
Page 263: If The Vehicle Breaks Down
IF THE VEHICLE BREAKS DOWN If the vehicle breaks down on the road, move to the shoulder and activate the hazard warning flashers. If there is no shoulder, or the shoulder is not safe, drive in the right lane, slowly, with the hazard flashers activated, until you reach a safe place to stop.
Page 264: On A Wet Road
264 EMERGENCIES WARNING! When attempting to rock your vehicle out of a stuck position, be sure that the area around the vehicle is clear of people. The rocking motion may cause the vehicle to suddenly lurch forward or backward, causing injury to by-standers. On a wet road CAUTION! •...
Page 265: On Snowy Or Icy Roads
CAUTION! • When driving in rain, a layer of water may form between the tires and the road surface (hydroplan- ing). This reduces a tire’s frictional resistance on the road, resulting in loss of steering stability and braking capability. When driving on a wet road, observe the following: (a) Drive your vehicle at a safe speed.
Page 266: Spare Tire, Jack And Tool Set Storage
266 EMERGENCIES SPARE TIRE, JACK AND TOOL SET STORAGE Jack Tool set The spare tire, jack and tool set are stowed in the trunk. Handling spare tire N01A1180 Remove the installation clamp to remove the spare tire. To install the spare tire, tighten the clamp firmly with your fingers until the spare tire has no more play.
Page 267: Jack
Jack Storage bracket To store To remove To remove Turn the shaft end so that the jack contracts and detach it from the storage bracket. To store Turn the shaft end by hand to expand the jack until it is secured firmly in position.
Page 268: Wheel Covers (If So Equipped)
268 EMERGENCIES CAUTION! • Avoid rapid starting and braking with a compact spare tire. • Avoid driving through automatic vehicle washes and over obstacles that could possibly damage the vehicle’s under-carriage. Because the tire is smaller than the original tire, vehicle ground clearance is slightly reduced.
Page 269 NOTE: The wheel cover is made of plastic; use caution when prying it off. NOTE: Some styles of wheels will have bolt-on type wheel covers. To remove this style, remove the bolts that hold the cover to the wheel. CAUTION! Trying to simply remove the wheel cover with your bare hands may severely injure your fingers.
Page 270: Jacking And Tire Changing
270 EMERGENCIES Before installing the wheel cover to the wheel, make sure that the opening with the symbol mark is correctly aligned with the air valve. JACKING AND TIRE CHANGING If a tire must be changed, do so only after making sure the vehicle is stopped in a safe, flat location.
Page 271 5. Place the jack under one of the jacking points shown in the illustration. Use the jacking point closest to the tire being changed. C = Jacking point WARNING! • Do not set the jack at any other position on the vehicle than those specified.
Page 272 272 EMERGENCIES 6. Rotate the jack by hand until the flange portion (D) fits in the groove at the top of the jack. N22A1450 NOTE: Before use, turn the top of jack and set it as shown in the illustration. N21C0280...
Page 273 7. Remove the wheel nut wrench and bar from the tool bag (located inside the trunk). N22A1830 8. Insert the bar (E) into the wheel nut wrench (F). Then attach the end of the bar to the jack end, as shown in the illustration.
Page 274 274 EMERGENCIES WARNING! • Before using the jack, chock or block the wheel that is tire diagonally opposite the jacking point. • Stop jacking up the vehicle when the tire is raised off the ground. It is dangerous to raise the vehicle any higher.
Page 275 9. Remove the wheel nuts with the wheel nut wrench, then take the wheel off. CAUTION! Handle the wheel cover carefully when replacing the flat tire, to avoid the wheel surface becoming scratched and causing premature corrosion. N24A0210 WARNING! Mount the spare wheel with the valve stem (G) on the side facing outward, not on the side facing the vehicle.
Page 276 276 EMERGENCIES Tapered nut Flange nut 10. Clear out any mud, etc. on the hub surface, hub bolts or in the installation holes in the wheel, and then mount the spare tire. 11. Install the spare wheel with the nut’s tapered end facing inward, then tighten by hand until the wheel is no longer loose.
Page 277 12. Lower the vehicle slowly and then tighten the nuts in the sequence shown in the illustration until each nut has been tightened to the specified torque. 88 to 108 N m (65 to 80 ft lb) CAUTION! Never use extra force with your foot on the wheel nut wrench or a pipe extension as you can over- tighten the nut.
Page 278 278 EMERGENCIES 14. Check tire inflation pressure. Tire inflation pressure specifications are shown on a placard located on the driver’s side ‘‘B’’-Pillar. • The emergency tire is to be used only temporarily when the standard tire is damaged. Repair the damaged tire as soon as possible.
Page 279: Engine Overheating
ENGINE OVERHEATING If the engine coolant temperature gauge indicator enters the “H” (hot) position, the engine may be overheated. In any of the following situations, you can reduce the potential for overheating by taking the appropriate ac- tion. • On the highways — Slow down. •...
Page 280: Jump-Starting The Engine
280 EMERGENCIES WARNING! • When working near the radiator cooling fan, dis- connect the fan motor lead or turn the ignition key to the OFF position. The fan is temperature con- trolled and can start at any time the ignition key is in the ON position.
Page 281 connection. You wouldn’t be able to start your vehicle, and the bad ground could damage the electrical systems. CAUTION! Check the other vehicle. It must have a 12-volt battery. If the other system isn’t 12-volts, both sys- tems can be damaged. 3.
Page 282 282 EMERGENCIES N29A0790 N29A1070 5. Connect one end of one booster cable to the positive (+) terminal of the discharged battery (A), and the other end to the positive (+) terminal of the booster battery (B). NOTE: Remove the terminal cover before connecting the booster cable to the positive terminal of the battery.
Page 283 6. Connect one end of the other jumper cable to the negative (-) terminal of the booster battery (B), and the other end to the engine block of the vehicle with the discharged battery (A) at the point farthest from the battery.
Page 284: If Your Vehicle Has Anti-Lock Brakes
284 EMERGENCIES WARNING! • Charging the battery installed in the vehicle might cause the battery to catch fire and explode. Or, damage to the vehicle could result. If it has to be charged in that condition for unavoidable reasons, disconnect the vehicle side negative lead. •...
Page 285 CAUTION! • Tie-down hooks should never be used for towing purposes. • This vehicle can NOT be towed by a tow truck using sling lift type equipment. This is to prevent the bumper from deformation. If this vehicle is towed, use wheel lift, dolly type or flat bed equipment.
Page 286: Fuses
286 EMERGENCIES CAUTION! • Towing should only be done by a professional tow service particularly if it will involve towing on winding roads, hills or heavy traffic. If you have any doubts, use a professional tow service. Towing—front wheel lift Place the gearshift lever (manual transaxle) to Neutral or the selector lever (automatic transaxle) in the “N”...
Page 287: Fuse Block
Fuse block To prevent damage to the electrical system due to short- circuiting or overloading, each individual circuit is pro- vided with a fuse. There are fuse blocks in the passenger compartment and in the engine compartment. The fuse block in the passenger compartment is located on the driver’s side at the position shown in the illustration.
Page 288: Fuse Load Capacities
288 EMERGENCIES Fuse load capacities The fuse cover lists the names of the electrical systems and the fuse capacities. Spare fuses are contained in the cover of the instrument panel (driver’s side). Always use a fuse of the same capacity for replacement. N29C0322...
Page 289 Passenger compartment fuse location Fuse location table Symbol Electrical system Audio — — Sunroof Accessory socket SOCKET Rear window defogger Heater — — — — Accessory socket SOCKET Door lock Rear window wiper — — Relay Electric remote-controlled outside R/C MIR mirror —...
Page 290 290 EMERGENCIES Engine compartment Fuse location table Engine compartment fuse location Symbol Electrical system Fuse (+B) Radiator fan motor Anti-lock braking system Ignition switch Electric window controls Fog lights — Horn Engine control Air conditioning Stop lights — Alternator Hazard warning flasher Automatic transaxle Headlights high beam (right) Headlights high beam (left)
Page 291 Symbol Electrical system Dome lights Audio Fuel pump Defroster • Some fuses may not be installed on your vehicle. Fuse application depends on the vehicle model, specifica- tions, or options. 7.5A BROWN LIGHT BLUE YELLOW GREEN GREEN YELLOW Fuse replacement Capacity 1.
Page 292 292 EMERGENCIES 4. There is a fuse puller in the cover of the instrument panel (driver’s side). Remove the fuse puller, clamp it on the fuse you wish to remove, and pull the fuse straight out from the fuse block. If the fuse is not blown, some- thing else must be causing the problem;...
Page 293: Replacement Of Light Bulbs
CAUTION! • Never use a fuse with a capacity larger than that specified or any substitute, such as wire, foil, etc. Doing so will cause the circuit wiring to heat up and could cause a fire. • If the newly inserted fuse blows again after a short time, have the electrical system checked by an authorized dealer to find and correct the cause.
Page 294 294 EMERGENCIES Wattage or Description Candela Power 5 - High-mounted stop light 6 - Stop and tail light 32/2cp 7 - Rear turn signal and tail 32/2cp light 8 - Rear side marker light 9 - License plate light 10 - Back up light 32cp Inside Description...
Page 295: Headlights
Headlights 1. Loosen the bolt (A), move the horn (B) (left side only). 2. Push the connector (C) to disconnect and remove the N10C1760 harness connector. EMERGENCIES 295 N10C1880...
Page 296 296 EMERGENCIES N10C1890 N10C1900 3. Remove the locking cap (D) by turning it counter- 4. Remove the bulb (E). clockwise.
Page 297: Adjustment Of Headlight Aim
CAUTION! • Never hold the halogen light bulb with a bare hand, dirty glove, etc. The oil from your hand could cause the bulb to break the next time the headlights are operated. If the glass surface is dirty, it should be cleaned with alcohol and installed after drying thor- oughly.
Page 298: Front Fog Lights (If So Equipped)
298 EMERGENCIES Front fog lights (if so equipped) 1. Insert a screwdriver as shown in the illustration and remove the screws. N10X1630 2. Slide the light unit outward to remove it. Turn the light socket counterclockwise and pull it out. N10X1460...
Page 299 3. Pull both clips (A) away from the center as shown and remove the bulb from the socket by pulling out. N10X1700 4. When mounting the light unit, align the pins (A) on the light unit with the holes in the body. EMERGENCIES 299 N10X1740...
Page 300: Front Side Marker Lights
300 EMERGENCIES CAUTION! • Never hold the halogen light bulb with a bare hand, dirty glove, etc. The oil from your hand could cause the bulb to break the next time the fog lights are operated. If the glass surface is dirty, it should be cleaned with alcohol and installed after drying thor- oughly.
Page 301: Rear Combination Lights
Rear combination lights 1. Turn the trim cover clip (A) counterclockwise and remove the trim cover clip. Partially remove the trim cover in the trunk. N20I0170 2. Remove the light case mounting nuts. Disconnect the connector. EMERGENCIES 301 N20I0160...
Page 302: High-Mounted Stop Light
302 EMERGENCIES 3. Slide the light unit outward to remove it. Remove each bulb socket assembly by turning it counterclockwise. Remove the bulb from the socket by turning it counter- clockwise while pressing it inward. High-mounted stop light A - Stop and tail light B - Rear turn signal and tail light C - Rear side marker light...
Page 303: License Plate Light
License plate light Remove the lens mounting screws, remove the socket assembly and the bulb together by turning it counter- clockwise. And remove the bulb by pulling out. Back up lights N10J0310 1. Remove the light mounting screw and pull the entire light bracket out.
Page 304 304 EMERGENCIES 2. Push the connector (A) to disconnect and remove the light bulb. N11H0150 3. Remove the entire socket and bulb assembly (B) by turning it counterclockwise. N11H0160...
Page 305 4. When mounting the light unit, align the pin (C) on the light unit with the hole in the body. Trunk light N11H0170 Pull both clips away from the center as shown and remove the light unit. Then remove the bulb by pulling out.
Page 306: Dome Light
306 EMERGENCIES Dome light 1. Insert a flat blade screwdriver into the notch of the light assembly and pry gently downward to remove it. N10M0410 2. Remove the light bulb from the light holder. N10M0380 NOTE: Wrap a cloth around the tip of the screwdriver to avoid scratching the light assembly.
Page 307 Reading lights Insert a straight blade screwdriver into the notch of the light assembly and pry gently to remove the lens. Remove the light bulb from the light holder. NOTE: Wrap a cloth around the tip of the straight blade screwdriver in order to avoid scratching the lens.
Page 309 CONTENTS View of engine compartment ....311 Service precautions ..... 312 Emission-control system maintenance .
Page 310 310 MAINTENANCE Disconnection and connection ... . . 327 Automatic transaxle..... 329 To check the fluid level.
Page 311: View Of Engine Compartment
VIEW OF ENGINE COMPARTMENT 2.4 liter engine 1. Power steering fluid reservoir 2. Engine coolant reservoir 3. Engine oil filler cap 4. Engine oil level dipstick 5. Battery 6. Clutch fluid reservoir (manual transaxle only) 7. Brake fluid reservoir 8. Windshield washer reservoir 9.
Page 312: Service Precautions
312 MAINTENANCE NOTE: The Scheduled Maintenance Charts are located in the rear of this maintenance section. Always refer to the schedules for proper service intervals. SERVICE PRECAUTIONS Adequate care of your vehicle at regular intervals serves to preserve the value and appearance as long as possible. Some maintenance items can be performed by the owner, while others should be done only by an authorized dealer.
Page 313: Emission-Control System Maintenance
WARNING! • The fan may turn on automatically even if the engine is not running; turn the ignition key to the “LOCK” position and remove the key to ensure safety while you work in the engine compartment. • Do not smoke, or allow open flames around fuel or the battery.
Page 314: Emissions Testing
314 MAINTENANCE EMISSIONS TESTING In some localities, it may be or will become a legal requirement to ensure that all emissions components and systems are functioning properly as a part of the test procedure. The test center accomplishes this by checking the On Board Diagnostic System system (OBD) with an electronic scan tool.
Page 315: Replacement Parts
If the light is flashing, severe catalytic converter damage and power loss will soon occur. Immediate service is required. If the gas cap is not tightened properly, the light may come on. Be sure the gas cap is tightened every time you add fuel.
Page 316: Air Cleaner Filter
316 MAINTENANCE Air cleaner filter The air cleaner filter will become dirty and loaded with dust during use, and the filtering effect will be substan- tially reduced. Replace it with a new filter in accordance with the schedule in this manual. 1.
Page 317: Spark Plugs
Spark plugs Spark plugs must fire properly to assure proper engine performance and emission-control. Do not reuse spark plugs by cleaning or regapping. Spark plugs should be replaced at the mileage specified on the scheduled maintenance chart. Your vehicle may be equipped with standard type spark plugs or iridium tipped ones.
Page 318: General Maintenance
318 MAINTENANCE GENERAL MAINTENANCE Engine oil and oil filter The following pages contain the maintenance service 2.4 liter engine recommended by the manufacturer. In addition to the general maintenance items for which fixed maintenance Good intervals have been specified, there are other items which are expected to operate satisfactorily without periodic maintenance.
Page 319 3.0 liter engine Good To check and refill engine oil It is normal for an engine to consume some oil. You may find it necessary to add oil between the recommended oil change intervals. Before starting the engine, check the engine oil level.
Page 320 320 MAINTENANCE To replace the oil filter The oil filter should be replaced at the time or mileage specified on the scheduled maintenance chart. You should be sure that any replacement filter used on this vehicle is a high quality filter. The manufacturer’s specifications for Genuine DaimlerChrysler oil filters require that the filter be capable of withstanding a pressure of 256 psi (1.8MPa).
Page 321 API service symbol If you are unable to find oils with the ILSAC certification mark (“Starburst” symbol), an API classification SL, SL/CF oil with the above label. This mark appears on the top of the oil containers and has two distinct areas for identifying various aspects of the oil. 1.
Page 322: Engine Coolant
322 MAINTENANCE ENGINE COOLANT To check the coolant level The coolant reserve system provides a quick visual method for determining the coolant level. When the engine is cold, the level of the coolant in the reserve tank should be between the FULL and LOW marks. The radiator normally remains completely full so there is no need to remove the radiator cap except for checking the coolant freeze point or replacing the antifreeze coolant.
Page 323: Brake Fluid
Radiator cap The radiator cap must be fully tightened to prevent loss of coolant and engine damage. WARNING! Make sure that the engine is thoroughly cooled down before removing the radiator cap, otherwise hot steam or boiling coolant may gush from the filler port and scald you.
Page 324: Clutch Fluid (Manual Transaxle)
324 MAINTENANCE CLUTCH FLUID (MANUAL TRANSAXLE) Good To check the clutch fluid The clutch fluid in the clutch master cylinder should be checked when performing other underhood services. In addition, the system should be checked for leakage at the same time. Check to make certain that the clutch fluid level is always between the MAX and MIN level mark- ings on the fluid reservoir and refill the fluid, if necessary.
Page 325: Battery
BATTERY The condition of the battery is very important for quick starting and to keep the vehicle’s electrical system work- ing properly. Check the battery regularly. If battery performance is suspect, have the battery and charging system tested by an authorized Mitsubishi dealer.
Page 326 326 MAINTENANCE Insert the tip of a screwdriver at the edge of the cap, pry gently to remove the cap. B = .31 in (8 mm) The inside of the battery is divided into several compart- ments. Check the electrolyte level (A) in each cell. The electrolyte level must be within the range (B) shown in the illustration.
Page 327: During Cold Weather
WARNING! • If the battery goes flat, be sure to check the battery electrolyte level before connecting booster cables. • After checking the battery electrolyte level, make sure the caps are fitted securely. • If any of the caps has a loose fit, replace the battery.
Page 328 328 MAINTENANCE WARNING! • Never disconnect the battery while the engine is running; doing so could damage the vehicle’s electrical components. • Never short-circuit the battery; doing so could cause it to overheat and be damaged. • Keep sparks, cigarettes and flames away from the battery because the battery may produce an explo- sion.
Page 329: Automatic Transaxle
NOTE 1. Check each battery terminal for corrosion. If necessary, neutralize corrosion by washing with a solution of bak- ing soda and water. Apply grease to posts and clamps after cleaning or tightening. 2. Before cleaning the battery, tighten all filler port caps to prevent foreign matter from entering the battery.
Page 330: To Check The Fluid Level
330 MAINTENANCE To check the fluid level The fluid level should be checked when the engine temperature gauge indicates a normal warmed up con- dition and the fluid in the transaxle is heated to its normal operating temperature. Operation with an im- proper fluid level will greatly reduce the life of the transaxle and the fluid.
Page 331: Manual Transaxle
Special additives DaimlerChrysler does not recommend the addition of any fluid additives to the transaxle. MANUAL TRANSAXLE Add oil to maintain the proper level. Refill or change oil according to the scheduled maintenance table. Lubricant Gear Oil Classification GL-4 Viscosity range SAE75W-90 or 75W-85W DISC BRAKE PADS, REAR DRUM BRAKE LININGS AND REAR WHEEL CYLINDERS...
Page 332: Hood Lock Release Mechanism And Safety Catch
332 MAINTENANCE HOOD LOCK RELEASE MECHANISM AND SAFETY CATCH The door hinges, trunk hinges, hood lock release mecha- nism and hood safety catch should be inspected, cleaned, and lubricated as required to maintain ease of operation and to provide protection against rust and wear. Apply Multipurpose Grease NLGI Grade 2 sparingly to all sliding contact areas of the hood latch and release lever.
Page 333: Windshield Wiper Blades
WINDSHIELD WIPER BLADES Check the wiper blades occasionally. Periodic cleaning of the wiper blades is suggested to remove the accumula- tion of salt and road film. The wiper blade arms and glass areas should be cleaned with a sponge or cloth and a mild detergent or non-abrasive cleaner.
Page 334: Parking Brake
334 MAINTENANCE PARKING BRAKE Check the parking brake lever travel occasionally. To check, pull the lever slowly and count the number of clicks of the ratchet. For vehicles with rear drum brakes: You should feel the parking brake take hold between 5 to 7 clicks.
Page 335: Drive Belt (For Generator, Water Pump, Power Steering Pump)
DRIVE BELT (FOR GENERATOR, WATER PUMP, POWER STEERING PUMP) 2.4 liter engine Water pump pulley Crank shaft pulley Check the tension of the drive belt. The deflection must be within specifications, when depressed at a point midway between the pulleys as shown in the illustrations with a force of about 100 N (22 lb.).
Page 336: Timing Belt
336 MAINTENANCE Amount of belt deflection Standard value Used belt .27 to .33 .29 to .33 (6.9 to 8.5) (7.4 to 8.5) .46 to .61 .50 to .57 (11.8 to 15.5) (12.6 to 14.4) .43 to .56 .46 to .52 (11.0 to 14.3) (11.7 to 13.3) .33 to .43...
Page 337 2. The outward facing sidewall of an asymmetrical tire that has a particular side that must always face out- ward when mounted on a vehicle. Rim : a metal support for a tire or a tire and tube assembly upon which the tire beads are seated. Tire Markings Size Designation EXAMPLE: P215/65R15...
Page 338 338 MAINTENANCE letters LT that are molded into the sidewall preceding the size designation. Example: LT235/85R16. • Temporary spare tires are high pressure compact spares designed for temporary emergency use only. Tires designed to this standard have the letter T molded into the sidewall preceding the size designa- tion.
Page 339 EXAMPLE : DOT MA L9 ABCD 1504 Department of Transportation This symbol certifies that the tire is in compli- ance with U.S. Department of Transportation tire safety standards, and is approved for highway use. Code representing the tire manufacturing loca- tion.
Page 340: Tire Inflation Pressures
340 MAINTENANCE Vehicle Safety Standard No. 109. Grades B and A repre- sent higher levels of performance on the laboratory test wheel than the minimum required by law. Tire inflation pressures Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 341: Radial Ply Tires
one mile (1.6 km) after being stationary for three hours. Cold inflation pressure must not exceed the maximum values molded into the tire sidewall. After driving several miles, tire inflation pressure may increase 2 to 6 psi (14 to 41 kPa) over the cold inflation pressure;...
Page 342: Tire Pressure For Sustained High-Speed Driving
342 MAINTENANCE Tire pressure for sustained high-speed driving For sustained high-speed driving, increase inflation pres- sure 4 psi (28 kPa) above the recommended pressure but do not exceed the maximum cold inflation pressure molded into the tire sidewall. Replacing tire and wheels CAUTION! •...
Page 343 • Vehicle normal load on the tire : load on an individual tire that is determined by distributing to each axle its share of the curb weight, accessory weight, and nor- mal occupant weight and dividing by two. • Maximum loaded vehicle weight : the sum of – (a) Curb weight;...
Page 344 344 MAINTENANCE 2. Determine the combined weight of the driver and passengers that will be riding in your vehicle. 3. Subtract the combined weight of the driver and pas- sengers from XXX kilograms or XXX pounds. 4. The resulting figure equals the available amount of cargo and luggage load capacity.
Page 345 MAINTENANCE 345...
Page 346: Cargo Loads
346 MAINTENANCE Cargo loads The load-carrying capacity of your vehicle is shown on the tire and loading information placard. DO NOT USE the weight rating data provided on the safety certification label for determining vehicle passen- ger and/or cargo load capacity. For determining the combined weight of occupants and cargo, use the specifications provided on the tire and loading information placard.
Page 347: Tire Rotation
When the indicators appear in two or more adjacent grooves, tire replacement is recommended. NOTE: The mark and the location of the tire wear indicator are different depending on tire manufacturers. Tire rotation Type 1 To equalize wear and help extend tire life, DaimlerChrysler recommends that you rotate your tires at the mileage speci- fied on the scheduled maintenance chart.
Page 348: Tire Chains
348 MAINTENANCE CAUTION! Do not use the compact spare tire for tire rotation. Tire chains CAUTION! Tire chains are not recommended for your vehicle. The clearance between the chains and the body is small, and the body might be damaged. Snow tires Some areas of the country require the use of snow tires during winter.
Page 349: Regular Maintenance Schedule
REGULAR MAINTENANCE SCHEDULE The content and mileage interval can vary depending on model. 6,000 Miles (10 000 km) or at 6 months Change engine oil and engine oil filter. Rotate tires. MILEAGE/ DEALERSHIP MONTHS NAME/CODE DATE 12,000 Miles (19 000 km) or at 12 months Check automatic transaxle fluid level.
Page 350 350 MAINTENANCE 24,000 Miles (38 000 km) or at 24 months Check automatic transaxle fluid level. Inspect disc brake pads, rotors and calipers for wear and leaks. Check brake hoses for deterioration or leaks. Inspect drive shaft boots for grease leaks and damage.
Page 351 30,000 Miles (48 000 km) or at 30 months Change engine oil and engine oil filter. Rotate tires. MILEAGE/ DEALERSHIP MONTHS NAME/CODE DATE 36,000 Miles (58 000 km) or at 36 months Check automatic transaxle fluid level. Inspect disc brake pads, rotors and calipers for wear and leaks.
Page 352 352 MAINTENANCE 54,000 Miles (86 000 km) or at 54 months Change engine oil and engine oil filter. Rotate tires. MILEAGE/ DEALERSHIP MONTHS NAME/CODE 60,000 Miles (96 000 km) or at 60 months Replace air cleaner filter. Replace spark plugs, standard type. Replace timing belt.* REPAIR : For California, Massachusetts and Vermont...
Page 353 60,000 Miles (96 000 km) or at 60 months Inspect suspension system for looseness and dam- age. Inspect ball joint and steering linkage seals for grease leaks and damage. Check and service exhaust system as required (connection portion of muffler, muffler pipes and converter heat shields).
Page 354 354 MAINTENANCE 78,000 Miles (125 000 km) or at 78 months Change engine oil and engine oil filter. Rotate tires. MILEAGE/ DEALERSHIP MONTHS NAME/CODE 84,000 Miles (134 000 km) or at 84 months Check automatic transaxle fluid level. Inspect disc brake pads, rotors and calipers for wear.
Page 355 90,000 Miles (144 000 km) or at 90 months Change engine oil and engine oil filter. Rotate tires. MILEAGE/ DEALERSHIP MONTHS NAME/CODE DATE 96,000 Miles (154 000 km) or at 96 months Check automatic transaxle fluid level. Inspect disc brake pads, rotors and calipers for wear and leaks.
Page 356 356 MAINTENANCE 114,000 Miles (183 000 km) or at 114 months Change engine oil and engine oil filter. Rotate tires. MILEAGE/ DEALERSHIP MONTHS NAME/CODE 120,000 Miles (192 000 km) or at 120 months Replace air cleaner filter. Replace spark plugs, standard type. Replace timing belt.* : For California, Massachusetts and Vermont this maintenance is recommended but not required.
Page 357: Severe Maintenance Schedule
120,000 Miles (192 000 km) or at 120 months Check fuel system for leak (tank, pipe line and connection, and fuel tank filler tube cap). Check evaporative emission control system for leaks and clogging (except evaporative emission canister). Check distributor cap and rotor. Change engine oil and engine oil filter.
Page 358 358 MAINTENANCE 9,000 Miles (14 000 km) or at 9 months Change engine oil and engine oil filter. Rotate tires. MILEAGE/ DEALERSHIP MONTHS NAME/CODE 12,000 Miles (19 000 km) or at 12 months Check automatic transaxle fluid level. Check brake hoses for deterioration or leaks. Inspect drive shaft boots for grease leaks and damage.
Page 359 18,000 Miles (29 000 km) or at 18 months Change engine oil and engine oil filter. Inspect disc brake pads, rotors and calipers for wear and leaks. Rotate tires. Inspect suspension system for looseness and dam- age. MILEAGE/ DEALERSHIP MONTHS NAME/CODE DATE 21,000 Miles (34 000 km) or at 21 months...
Page 360 360 MAINTENANCE 30,000 Miles (48 000 km) or at 30 months Replace air cleaner filter. Replace spark plugs, standard type. Check drive belts condition (for the generator, water pump, power steering pump). Change manual transaxle oil. Change automatic transaxle fluid. Check fuel hoses condition.
Page 361 36,000 Miles (58 000 km) or at 36 months Check automatic transaxle fluid level. Check brake hoses for deterioration or leaks. Inspect drive shaft boots for grease leaks and damage. Inspect suspension system for looseness and dam- age. Change engine oil and engine oil filter. Inspect disc brake pads, rotors and calipers for wear and leaks.
Page 362 362 MAINTENANCE 48,000 Miles (77 000 km) or at 48 months Change engine oil and engine oil filter. Inspect disc brake pads, rotors and calipers for wear and leaks. Rotate tires. Check automatic transaxle fluid level. Check brake hoses for deterioration or leaks. Inspect drive shaft boots for grease leaks and damage.
Page 363 60,000 Miles (96 000 km) Replace air cleaner filter. Replace spark plugs, standard type. Check drive belts condition (for the generator, water pump, power steering pump). Replace timing belt.* : For California, Massachusetts and Vermont this maintenance is recommended but not re- quired.
Page 364 364 MAINTENANCE 63,000 Miles (100 000 km) or at 63 months Change engine oil and engine oil filter. Rotate tires. MILEAGE/ DEALERSHIP MONTHS NAME/CODE 66,000 Miles (106 000 km) or at 66 months Change engine oil and engine oil filter. Inspect disc brake pads, rotors and calipers for wear and leaks.
Page 365 75,000 Miles (120 000 km) or at 75 months Replace air cleaner filter. Replace spark plugs, standard type. Inspect rear drum brake linings and rear wheel cylinders (except vehicles with disc brakes) for wear and leaks of all wheels. Check brake hoses for deterioration or leaks. Change engine oil and engine oil filter.
Page 366 366 MAINTENANCE 84,000 Miles (134 000 km) or at 84 months Change engine oil and engine oil filter. Inspect disc brake pads, rotors and calipers for wear and leaks. Rotate tires. Check automatic transaxle fluid level. Check brake hoses for deterioration or leaks. Inspect drive shaft boots for grease leaks and damage.
Page 367 90,000 Miles (144 000 km) or at 90 months Inspect suspension system for looseness and dam- age. Change engine oil and engine oil filter. Inspect disc brake pads, rotors and calipers for wear and leaks. Rotate tires. MILEAGE/ DEALERSHIP MONTHS NAME/CODE DATE 93,000 Miles (149 000 km) or at 93 months...
Page 368 368 MAINTENANCE 102,000 Miles (163 000 km) or at 102 months Replace spark plugs, platinum-tipped type. Change engine oil and engine oil filter. Inspect disc brake pads, rotors and calipers for wear and leaks. Rotate tires. Inspect suspension system for looseness and dam- age.
Page 369 111,000 Miles (178 000 km) or at 111 months Change engine oil and engine oil filter. Rotate tires. MILEAGE/ DEALERSHIP MONTHS NAME/CODE DATE 114,000 Miles (182 000 km) or at 114 months Change engine oil and engine oil filter. Rotate tires. Inspect disc brake pads, rotors and calipers for wear and leaks.
Page 370 370 MAINTENANCE 120,000 Miles (192 000 km) or at 120 months Change manual transaxle fluid. Change automatic transaxle fluid. Check fuel hoses condition. Flush and replace engine coolant. Check coolant hoses (radiator hose, heater hose). Inspect rear drum brake linings and rear wheel cylinders (except vehicles with disc brakes) for wear and leaks of all wheels.
Page 371 CONTENTS Vehicle labeling ......372 1 - Vehicle emission control information label . . 372 2 - Vehicle identification number plate ..372 3 - Vehicle information code plate .
Page 372: 372 Specifications
372 SPECIFICATIONS VEHICLE LABELING Keep a record of the vehicle identification number as such information will assist the police if your vehicle is stolen. 1 -Vehicle emission control information label The vehicle emission control information label is affixed on the underside panel of the engine hood. 2 -Vehicle identification number plate This is stamped on the number plate riveted to the left front corner of the instrument panel pad.
Page 373: Engine Serial Number
SPECIFICATIONS 373 5 - Engine serial number 4 Cylinder 6 Cylinder B02B0540 B02B0550 The engine serial number is stamped on the cylinder block as shown in the illustrations.
Page 374: Tire And Loading Information Placard
374 SPECIFICATIONS 6 - Tire and loading information placard The tire inflation pressure label is located on the inside sill of the driver’s door. 7 - Certification label The certification label is located on the inside sill of the driver’s door. BATTERY B02E0180 BCI Group NO.86...
Page 375: General Vehicle Data
GENERAL VEHICLE DATA Overall length 190.9in (4,850mm) Overall width 70.3in (1,785mm) Overall height 53.9in (1,370mm) Wheel base 103.7in (2,635mm) TIRES AND WHEELS Item 2.4 liter Type Radial, tubeless Tire Size P205/60R16 91H Spare tire T125/70D16 Type Steel/Aluminum* Size 16x6JJ Wheel 4.5 in.
Page 376 376 SPECIFICATIONS Cargo loads capacity: 150 lbs (68kg) time the des- ignated seating capacity, subtract from the vehicle capacity weight. CAUTION! Do not use the gross vehicle weight rating data provided in the chart or on the safety certification label for determining vehicle passenger and/or cargo load capacity.
Page 377: Engine Specifications
ENGINE SPECIFICATIONS Item Engine model Engine displacement No. of cylinders and cylinder arrangement Bore Stroke Compression ratio Controlled by-pass thermostat Spark plugs DENSO CHAMPION Spark plug gap Firing order Ignition timing idle speed and mixture NOTE 1. Your engine is equipped with intake and exhaust valve auto-lash adjusters that require no adjustment. 2.
Page 378: Capacities
378 SPECIFICATIONS CAPACITIES Item Fuel (approximate) Engine oil Oil pan Oil filter Power steering Automatic transaxle Manual transaxle Brakes and clutch Transaxle linkage, Parking brake cable mechanism, hood lock and hook, door latches, seat adjusters Engine coolant Refrigerant (air conditioning) Windshield washers *: Include 0.65 L (.69 qt.) in reserve tank.
Page 379: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ..... . . 380 Prepare For The Appointment ... . 380 Prepare A List .
Page 380: Suggestions For Obtaining Service For Your Vehicle
380 IF YOU NEED CONSUMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty, discuss additional charges with the service manager.
Page 381 • If for some reason you are still not satisfied, talk to the general manager or owner of the dealership. They want to know if you need assistance. • If your dealership is unable to resolve the concern, you may contact the DaimlerChrysler Motors Corporation Customer Center.
Page 382: Warranty Information
382 IF YOU NEED CONSUMER ASSISTANCE Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, DaimlerChrysler Motors Corporation has installed spe- cial TDD (Telecommunication Devices for the Deaf) equipment at its Customer Center. Any hearing or speech impaired customer who has access to a TDD or a conventional teletypewriter (TTY) in the United States can communicate with DaimlerChrysler Motors Corpo-...
Page 383: Mopar Parts
MOPAR PARTS Mopar fluids, lubricants, parts, and accessories are avail- able from your DaimlerChrysler Motors Corporation dealer. They will help you keep your vehicle operating at its best. CUSTOMER ARBITRATION BOARD In the 50 United States, and Washington, D.C., if a warranty dispute has not been resolved to your satisfac- tion, you may submit the issue to a DaimlerChrysler Motors Customer Arbitration Board.
Page 385: Publication Order Forms
PUBLICATION ORDER FORMS...
Page 387: Department Of Transportation Uniform Tire Quality Grades
DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following describes the tire grading categories estab- lished by the National highway Traffic Safety Adminis- tration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your car.
Page 388: Temperature A, B, C
388 IF YOU NEED CONSUMER ASSISTANCE Temperature A, B, C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 389: Index
INDEX...
Page 390 390 INDEX Accessory boxes ......215 Accessory (installation) ....250 Adding Fuel .
Page 391 Cassette Tape and Player Maintenance ..226 Cassette Tape Player ....221,223 CD Player ......221,229 Center console .
Page 392 392 INDEX Engine coolant ......322 Engine coolant level warning light ..109 Engine coolant temperature gauge .
Page 393 Headlight flasher (high/low beam) ..123 Switch ......122 Heater .
Page 394 394 INDEX Odometer ......108,112 Oil pressure gauge ..... . 108 Oil pressure warning light .
Page 395 Seats Front seats ......57 Rear seats ......66 SECURITY indicator .
Page 396 396 INDEX Tire chains ......348 Tread wear indicators ....346 Tools .

This manual is also suitable for:

25360 stratus coupe

Dodge 2005 Stratus Coupe Owner's Manual

Table of Contents

Locking and Unlocking

Seats, Seat Belts, Child Restraints and Air Bags

Instruments and Controls

Starting and Driving

For Pleasant Driving

Quick Links

TABLE OF CONTENTS

Chapters

Related Manuals for Dodge 2005 Stratus Coupe

Summary of Contents for Dodge 2005 Stratus Coupe
