Page 1: Introduction
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 3: Table Of Contents
CONTENTS Introduction ......4 Rollover Warning ......4 How To Use This Manual .
Page 4: Introduction
4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully.
Page 5: How To Use This Manual
Rollover Warning Label Failure to use driver and passenger seat belts provided is a major cause of severe or fatal injury. In fact, the U.S. government notes that the universal use of existing seat belts could cut the highway death toll by 10,000 or more each year, and could reduce disabling injuries by 2 million annually.
Page 6 6 INTRODUCTION...
Page 7: Warnings And Cautions
The vehicle identification number (VIN) is found on the left front corner of the instrument panel. The VIN is visible from outside of the vehicle through the wind- shield. This number also appears on the Automobile Vehicle Identification Number Information Disclosure Label affixed to a window on NOTE: It is illegal to remove the VIN.
Page 8: Vehicle Modifications/Alterations
8 INTRODUCTION VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 9: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key Removal ....12 Key-In-Ignition Reminder .
Page 10 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Programming Additional Transmitters ..24 Battery Replacement ....24 General Information .
Page 11 Driver And Front Passenger Supplemental Restraint Systems (SRS) ....49 Child Restraint ......66 Engine Break-In Recommendations .
Page 12: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS You can insert the double-sided keys into the locks with either side up. Vehicle Key The keys for your new vehicle are enclosed in a plastic bag with the key code number on it. If you received your keys without the bag, ask your dealer to give you the number.
Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 WARNING! Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons. A child or others could be seri- ously or fatally injured. Don’t leave the keys in the ignition.
Page 14: Key-In-Ignition Reminder
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Key-In-Ignition Reminder If you open the driver’s door and the key is in the ignition, a chime will sound to remind you to remove the key. NOTE: The Key-In-Ignition reminder only sounds when the ignition key is placed in the LOCK or ACC position.
Page 15: Replacement Keys
If the Vehicle Security Alarm Indicator Light turns on during normal vehicle operation (vehicle running for longer than 10 seconds), it indicates that there is a fault in the electronics. Should this occur, have the vehicle ser- viced as soon as possible. NOTE: •...
Page 16: Customer Key Programming
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE authorized dealer or by using the Customer Key Pro- gramming procedure. This procedure consists of pro- gramming a blank key to the vehicle electronics. A blank key is one, which has never been programmed. NOTE: When having the Sentry Key Immobilizer System serviced, bring all vehicle keys with you to the...
Page 17: General Information
The new Sentry Key is programmed. The Keyless Entry Transmitter will also be programmed during this pro- cedure. Repeat this procedure to program up to 8 keys. If you do not have a programmed sentry key, contact your dealer for details. NOTE: If a programmed key is lost, see your dealer to have all remaining keys erased from the systems memory.
Page 18: To Release The Steering Wheel Lock
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Release the Steering Wheel Lock Insert the key in the ignition and turn the wheel slightly to the right or left to disengage the lock. NOTE: If you turned the wheel to the right to engage the lock, you must turn the wheel slightly to the right to disengage it.
Page 19: To Disarm The System
To Disarm the System: Either press the Unlock button on the remote keyless entry transmitter or insert a valid sentry key into the ignition lock cylinder and turn the key to the ON position. The Security Alarm System is designed to protect your vehicle;...
Page 20: Remote Keyless Entry
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE REMOTE KEYLESS ENTRY This system allows you to lock or unlock the doors and liftgate or activate the panic alarm from distances up to 23 feet (7 meters) using your key fob. The key fob does not need to be pointed at the vehicle to activate the system.
Page 21: To Lock The Doors And Liftgate
On electronic vehicle information center (EVIC) equipped vehicles, refer to “Remote Key Unlock,” under “Personal Settings (Customer Programmable Features),” under “Electronic Vehicle Information Center (EVIC)” in Section 4 of this manual On non-EVIC equipped vehicles, perform the following steps: 1. Press and hold the “Lock” button on a programmed (i.e.
Page 22 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Features),” under “Electronic Vehicle Information Center (EVIC)” in Section 4 of this manual. • On non-EVIC equipped vehicles, perform the follow- ing steps: 1. Press the “Lock” button on a programmed (i.e. func- tional) key fob for at least 4 seconds, but not longer than 10 seconds.
Page 23: Using The Panic Alarm
1. Press and hold the “Unlock” button on a programmed (i.e. functional) key fob for at least 4 seconds, but not longer than 10 seconds. Then, press and hold the “Lock” button while still holding the “Unlock” button. 2. Release both buttons at the same time. 3.
Page 24: Programming Additional Transmitters
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE During the Panic Mode, the door locks and remote keyless entry systems will function normally. Panic mode will not disarm the security system on vehicles so equipped. Programming Additional Transmitters Refer to SENTRY KEY “Customer Key Programming.” in this section.
Page 25: General Information
2. Remove and replace the batteries. Avoid touching the new batteries with your fingers. Skin oils may cause battery deterioration. If you touch a battery, clean it with rubbing alcohol. 3. To assemble the key fob case, snap the two halves together.
Page 26 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To remote start your vehicle, press and release the “Remote Start” button on the key fob twice within three seconds. To indicate that the vehicle is about to start, the parking lights will flash and the horn will sound briefly (if programmed).
Page 27: Door Locks
The vehicle can be started remotely a maximum of two times consecutively. The vehicle is also allowed a maxi- mum of one failed start, where the remote start sequence was initiated but the engine stopped cranking without starting. Following either of these conditions, or if the Vehicle Security Alarm (if equipped) is alarming, or if the PANIC button was pressed, the system must be reset before remote starting the vehicle again.
Page 28: Manual Door Locks
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Manual Door Locks Use the manual door lock plunger to lock the doors from inside the vehicle. If the plunger is down when the door is closed, the door will lock. Therefore, make sure the keys are not inside the vehicle before closing the door.
Page 29: Power Door Locks
Power Door Locks A door lock switch is on each front door panel. Press this switch to lock or unlock the doors. Power Door Lock Switch If you press the power door lock switch while the key is in the ignition, and any front door is open, the power THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 locks will not operate.
Page 30: Automatic Unlock Doors On Exit
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Door Locks Programming The Automatic Door Locks feature can be enabled or disabled as follows: For vehicles equipped with a Electronic Vehicle Informa- tion Center (EVIC), refer to “Personal Settings (Customer Programmable Features)”...
Page 31 5. The doors were not previously unlocked. 6. The vehicle speed is 0 mph (0 km/h). Automatic Unlock Doors on Exit Programming The Automatic Unlock Doors On Exit feature can be enabled or disabled as follows: For vehicles equipped with a Electronic Vehicle Informa- tion Center (EVIC), refer to “Personal Settings (Customer Programmable Features)”...
Page 32: Child-Protection Door Lock System (Rear Doors)
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child-Protection Door Lock System (Rear Doors) Insert the tip of the ignition key into the lock and rotate to the lock or unlock position. Inserting Ignition Key WARNING! Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the child protection locks are engaged.
Page 33: Windows
WINDOWS Power Windows The power window controls are located on the driver’s door trim panel. There is a single switch on the front passenger door/rear doors which operates the front passenger/rear passenger door windows. The window controls will operate only when the ignition switch is in the ON or ACCESSORY position.
Page 34 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Off to Accessories Until Exit” in Section 4 of this manual. Opening a vehicle front door will cancel this feature. WARNING! Never leave children in a vehicle, with the keys in the ignition switch.
Page 35 Accessories Until Exit,” under “Personal Settings (Cus- tomer Programmable Features),” under “Electronic Ve- hicle Information Center (EVIC)” in Section 4 of this manual. Auto Up Feature with Anti-Pinch Protection — If Equipped On some models, the driver’s power window switch has an “Auto Up”...
Page 36 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • If the window runs into any obstacle during auto- closure, it will reverse direction and then stop. Remove the obstacle and use the window switch again to close the window. •...
Page 37: Wind Buffeting
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions.
Page 38: Liftgate
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LIFTGATE The vacuum fluorescent (VF) display located in the odometer area displays the word “GATE” as an indica- tion of when the liftgate is not completely closed. When the vehicle is not moving, and the liftgate is not com- pletely closed, the VF display will show the word “GATE.”...
Page 39: Occupant Restraints
WARNING! Driving with the liftgate open can allow poisonous exhaust gases into your vehicle. You and your pas- sengers could be injured by these fumes. Keep the liftgate closed when you are operating the vehicle. OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems.
Page 40: Lap/Shoulder Belts
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE and cause a collision which includes you. This can happen far away from home or on your own street. Research has shown that seat belts save lives, and they can reduce the seriousness of injuries in a collision. Some of the worst injuries happen when people are thrown from the vehicle.
Page 41: Lap/Shoulder Belt Operating Instructions
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is above the back of your seat. Grasp the latch plate and pull out the belt. Slide the latch plate up the webbing as far as necessary to make the belt go around your lap.
Page 42 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Latch Plate To Buckle WARNING! A belt that is buckled into the wrong buckle will not protect you properly.
Page 43 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap portion, pull up a bit on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug belt reduces the risk of sliding under the belt in a collision.
Page 44: Adjustable Upper Shoulder Belt Anchorage
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button marked PRESS on the buckle. The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to allow it to retract fully. WARNING! A frayed or torn belt could rip apart in a collision and leave you with no protection.
Page 45: Automatic Locking Mode - If Equipped
As a guide, if you are shorter than average, you will prefer a lower position, and if you are taller than average, you’ll prefer a higher position. When you release the anchorage, try to move it up or down to make sure that it is locked in position.
Page 46: Seat Belt Pretensioners
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • The belt and retractor assembly must be replaced if the seat belt assembly “automatic locking retrac- tor” feature or any other seat belt function is not working properly when checked according to the procedures in the Service Manual.
Page 47 chime and flash the Seat Belt Reminder Light for 96 seconds or until the driver’s or front passenger’s seat belt is buckled. The Enhanced Warning System (BeltAlert) will be reactivated if the driver’s or front passenger’s seat belt is unbuckled for more than 10 seconds and the vehicle speed is greater than 5 mph (8 km/h).
Page 48: Seat Belts And Pregnant Women
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belts and Pregnant Women We recommend that pregnant women use the seat belts throughout their pregnancy. Keeping the mother safe is the best way to keep the baby safe. Pregnant women should wear the lap part of the belt across the thighs and as snug across the hips as possible.
Page 49: Driver And Front Passenger Supplemental Restraint Systems (Srs)
Driver And Front Passenger Supplemental Restraint Systems (SRS) Front Airbag Components THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 This vehicle has airbags for both the driver and right front passenger as a supplement to the seat belt restraint systems. The driver’s front airbag is mounted in the steering wheel.
Page 50 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE This vehicle is equipped with window bags to protect the driver, front, and rear passengers sitting next to a win- dow. They are located above the side windows. Their covers are also labeled SRS/AIRBAG. Window Airbag Location NOTE: Airbag covers may not be obvious in the interior trim;...
Page 51 The front airbags have a multi stage inflator design. This allows the airbag to have different rates of inflation that are based on collision severity. Along with the seat belts, the front airbags provide improved protection for the driver and front passenger. Window bags also work with seat belts to improve occupant protection.
Page 52 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Children that are not big enough to properly wear the vehicle seat belt should be secured in the rear seat, in a child restraint or belt-positioning booster seat. Older children who do not use child restraints or belt- positioning booster seats should ride properly buckled up in the rear seat.
Page 53 WARNING! • Relying on the airbags alone could lead to more severe injuries in a collision. The airbags work with your seat belt to restrain you properly. In some collisions the airbags won’t deploy at all. Always wear your seat belts even though you have airbags.
Page 54 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Front Remote Acceleration Sensors • Seat Track Position Sensors (STPS) — If Present • Driver and Front Passenger Seat Belt Pretensioner • Driver and Front Passenger Seat Belt Retractors • Occupant Classification System (OCS) — Front Pas- senger Seat Only −...
Page 55 Also, the ORC turns on the “Airbag Warning Light” and “PAD Indicator Light” for 6 to 8 seconds for a self-check when the ignition is first turned on. After the self-check, the “Airbag Warning Light” will turn off. The “PAD Indicator Light”...
Page 56 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Children 12 years and under should always ride buckled up in a rear seat in an appropriate child restraint. • The Passenger Airbag Disable (PAD) Indicator Light (an amber light located in the center of the instrument panel) tells the driver and front passenger when the front passenger airbag is turned off.
Page 57 For occupants classified into the “child” size category, the “PAD Indicator Light” will be illuminated indicating that the front passenger airbag is turned off and will not inflate. If the “PAD Indicator Light” is not illuminated, DO NOT assume the airbag is turned off and move the child restraint to the rear seat.
Page 58 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the OCS has classified the occupant of the seat as an adult. An adult occupant needs to sit in a normal position (with their feet on or near the floor) in order to be properly classified.
Page 59 • The Driver and Passenger Airbag/Inflator Units are located in the center of the steering wheel and the right side of the instrument panel. When the ORC detects a collision requiring the airbags, it signals the inflator units. A large quantity of nontoxic gas is generated to inflate the front airbags.
Page 60 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE of nontoxic gas is generated to inflate the side curtain airbag. The inflating side curtain airbag pushes the outside edge of the headliner out of the way and covers the window. The airbag inflates in about 30 milliseconds (about one quarter of the time it takes to blink your eyes) with enough force to injure you if you are not belted and seated properly, or if items are...
Page 61 WARNING! Unapproved modifications or service procedures to the front passenger seat assembly, its related compo- nents, or seat cover may inadvertently change the airbag deployment in case of a frontal crash. This could result in death or serious injury to the front seat passenger if the vehicle is involved in an acci- dent.
Page 62 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE inflation. These airborne particles may irritate the skin, eyes, nose, or throat. If you have skin or eye irritation, rinse the area with cool water. For nose or throat irritation, move to fresh air. If the irritation continues, see your doctor.
Page 63: Airbag Warning Light
Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured if the airbag system is not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper right side of the instrument panel.
Page 64 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Event Data Recorder (EDR) In the event of an accident, your vehicle is designed to record up to 5-seconds of specific vehicle data parameters (see the following list) in an event data recorder prior to the moment of airbag deployment, or near deployment, and up to a quarter second of high-speed deceleration data during and/or after air bag deployment or near-...
Page 65 provided to the custodial entity upon request. General data that does not identify particular vehicles or crashes may be released for incorporation in aggregate crash databases, such as those maintained by the US govern- ment and various states. Data of a potentially sensitive nature, such as would identify a particular driver, ve- hicle, or crash, will be treated confidentially.
Page 66: Child Restraint
66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Cruise control status • Traction/stability control status • Tire pressure monitoring system status Child Restraint Everyone in your vehicle needs to be buckled up all the time — babies and children, too. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems.
Page 67 Infants and Child Restraints • Safety experts recommend that rearward-facing in the vehicle until they are at least one year old and weigh at least 20 lbs (9 kg). Two types of child restraints can be used rearward-facing: infant carriers and “convertible” child seats. •...
Page 68 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Here are some tips for getting the most out of your child restraint: • Before buying any restraint system, make sure that it has a label certifying that it meets all applicable Safety Standards.
Page 69 • In the rear seat, you may have trouble tightening the lap/shoulder belt on the child restraint because the buckle or latch plate is too close to the belt path opening on the restraint. Disconnect the latch plate from the buckle and twist the short buckle-end belt several times to shorten it.
Page 70 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The belt-positioning booster seat is for children weighing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly. If the child cannot sit with knees bent over the vehicle’s seat cushion while the child’s back is against the seat back, they should use a belt-positioning booster seat.
Page 71 having attachments for those anchorages will continue to also have features for installation using the vehicle’s seat belts. Child restraints having tether straps and hooks for connection to the top tether anchorages have been avail- able for some time. For some older child restraints, many child restraint manufacturers offer add-on tether strap kits or retro-fit kits.
Page 72 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE install the child restraint. You will easily feel them if you run your finger along the intersection of the seatback and seat cushion surfaces. Latch Anchorages In addition, there are tether strap anchorages behind each rear seating position located on the back of the seat.
Page 73 hook for attachment to the tether strap anchorage and a means of adjusting the tension of the strap. You will first loosen the adjusters on the lower straps and on the tether strap so that you can more easily attach the hooks or connectors to the vehicle anchorages.
Page 74 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE belt. However, any seat belt system may loosen with time, so check the belt occasionally and pull it tight if necessary. If the seat belt has a automatic locking retractor, it will have a distinctive label.
Page 75 Tether Strap Mounting THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor positions directly behind the child seat to secure a child restraint top tether strap.
Page 76: Engine Break-In Recommendations
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine in your new vehicle. Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable.
Page 77: Safety Checks You Should Make Inside The Vehicle
• Do not inhale exhaust gases. They contain carbon monoxide, a colorless and odorless gas which can kill. Never run the engine in a closed area, such as a garage, and never sit in a parked vehicle with the engine running for a extended period. If the vehicle is stopped in an open area with engine running for more than a short period, adjust the ventilation system to force fresh, outside air into the vehicle.
Page 78: Safety Checks You Should Make Outside The Vehicle
78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Defrosters Check operation by selecting the defrost mode and place the blower control on high speed. You should be able to feel the air directed against the windshield. See your authorized dealer for service if your defroster is inoper- able.
Page 79 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors .......83 Inside Day/Night Mirror ....83 Automatic Dimming Mirror —...
Page 80 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Seat Adjustment — Recline ..114 6–Way Driver’s Power Seat With Manual Recliner ......115 Fold Flat Front Passenger Seat .
Page 81 Electronic Speed Control Operation ..128 To Activate ......128 To Set At A Desired Speed .
Page 82 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Pinch Protect Feature ....145 Pinch Protect Override ....146 Venting Sunroof - Express .
Page 83: Mirrors
MIRRORS Inside Day/Night Mirror The mirror should be adjusted to center on the view through the rear window. Adjusting Rearview Mirror UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83 A two-point pivot system allows for horizontal and vertical adjustment of the mirror. Annoying headlight glare can be reduced by moving the small control under the mirror to the night position (toward rear of truck).
Page 84: Automatic Dimming Mirror - If Equipped
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped This mirror will automatically adjust for annoying head- light glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror.
Page 85: Exterior Mirrors Folding Feature
WARNING! Vehicles and other objects seen in the right side convex mirror will look smaller and farther away than they really are. Relying too much on your right side mirror could cause you to collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in the right side mirror.
Page 86: Illuminated Vanity Mirrors - If Equipped
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Illuminated Vanity Mirrors — If Equipped An illuminated vanity mirror is on each sun visor. To use the mirror, rotate the sun visor down and swing the mirror cover upward. The lights will turn on automati- cally.
Page 87: Hands-Free Communication (Uconnect ) - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 NOTE: For UConnect customer support, visit the following web sites: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect • or call 1–877–855–8400 UConnect allows you to transfer calls between the system and your cellular phone as you enter or exit your vehicle, and enables you to mute the system’s micro-...
Page 88 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE that enables different electronic devices to connect to each other without wires or a docking station, so UCon- nect works no matter where you stow your cellular phone (be it your purse, pocket, or briefcase), as long as your phone is turned on and has been paired to the vehicle’s UConnect system.
Page 89: Operation
The radio display will be used for visual prompts from the UConnect system such as CELL or caller ID on certain radios. Operation Voice commands can be used to operate the UConnect system and to navigate through the UConnect menu structure.
Page 90 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To activate the UConnect system from idle, simply press the “Phone” button and follow audible prompts for directions. All UConnect system sessions begin with a press of the “Phone” button on the radio control head. Cancel Command At any prompt, after the beep, you can say Cancel and you will be returned to the main menu.
Page 91 • You will then be asked to give your cellular phone a priority level between 1 and 7, 1 being the highest priority. You can pair up to seven cellular phones to your UConnect system. However, at any given time, only one cellular phone can be in use, connected to your UConnect System.
Page 92 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • System will prompt you to say the name of the person you want call. • After the Ready prompt and the following beep, say the name of the person you want to call. For example, you can say John Doe, where John Doe is a previ- ously stored name entry in the UConnect book.
Page 93 The UConnect system will allow you to enter up to 32 names in the phone book with each name having up to four associated phone numbers and designations. Each language has a separate 32-name phone book accessible only in that language. Phonebook Download UConnect allows the user to download entries from their phone via Bluetooth.
Page 94 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • You will then be asked for the name of the phone book entry that you wish to edit. • Next, choose the number designation (home, work, mobile, or pager) that you wish to edit. •...
Page 95 • After you enter the name, the UConnect system will ask you which designation you wish to delete, home, work, mobile, pager, or all. Say the designation you wish to delete. • Note that only the phone book entry in the current language is deleted.
Page 96: Phone Call Features
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phone Call Features The following features can be accessed through the UConnect system if the feature(s) are available on your cellular service plan. For example, if your cellular service plan provides three-way calling, this feature can be accessed through the UConnect your cellular service provider for the features that you have.
Page 97 the second call is in progress. To go back to the first call, refer to Toggling Between Calls. To combine two calls, refer to Conference Call. Place/Retrieve a Call from Hold To put a call on hold, press the Phone’ button until you hear a single beep.
Page 98 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE hold may not become active automatically. This is cell phone dependent. To bring the call back from hold, press and hold the “Phone” button until you hear a single beep. Redial • Press the “Phone” button to begin. •...
Page 99: Uconnect System Features
UConnect System Features Language Selection To change the language that the UConnect system is using, • Press the “Phone” button to begin. • After the Ready prompt and the following beep, say the name of the language you wish to switch to (English, Espanol, or Francais, if so equipped).
Page 100 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The UConnect system does slightly lower your chances of successfully making a phone call as to that for the cell phone directly. Your phone must be turned on and paired to the UCon- nect system to allow use of this vehicle feature in emergency situations when the cell phone has network...
Page 101 service or automated customer service. Some services require immediate response selection, in some instances, that may be too quick for use of UConnect system. When calling a number with your UConnect system that normally requires you to enter in a touch-tone sequence on your cellular phone keypad, you can push the “Voice Recognition”...
Page 102 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE a , you could press the “Voice Recognition” button and say Pair a Phone to select that option without having to listen to the rest of the voice prompt. Turning Confirmation Prompts On/Off Turning confirmation prompts off will stop the system from confirming your choices (e.g., the UConnect sys- tem will not repeat a phone number before you dial it).
Page 103: Advanced Phone Connectivity
may feel that the call did not go through even though the call is in progress. Once your call is answered, you will hear the audio. Mute/Un-Mute (Mute Off) When you mute the UConnect system, you will still be able to hear the conversation coming from the other party, but the other party will not be able to hear you.
Page 104 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE List Paired Cellular Phone Names • Press the “Phone” button to begin. • After the “Ready” prompt and the following beep, say “Setup Phone Pairing.” • When prompted, say List Phones. • The UConnect system will play the phone names of all paired cellular phones in order from the highest to the lowest priority.
Page 105: Things You Should Know About Your Uconnect System
• You can also press the “Voice Recognition” button anytime while the list is being played, and then choose the phone you wish to delete. Things You Should Know About Your UConnect System UConnect Tutorial To hear a brief tutorial of the system features, press the “Phone”...
Page 106 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Always wait for the beep before speaking. • Speak normally, without pausing, just as you would speak to a person sitting approximately eight (8) feet away from you. • Make sure that no one other than you is speaking during a voice recognition period.
Page 107 • Even though international dialing for most number combinations is supported, some shortcut dialing number combinations may not be supported. • In a convertible vehicle, system performance may be compromised with the convertible top down. Far End Audio Performance • Audio quality is maximized under: •...
Page 108 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109...
Page 110 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 111 Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Voice Commands Primary Alternate(s) call cancel confirmation prompts. continue delete dial download edit emergency English erase all Espanol...
Page 112 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again redial Voice Commands Primary Alternate(s) return to main menu return or main menu select phone...
Page 113: General Information
General Information This device complies with part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired op- eration.
Page 114: Front Seat Adjustment - Recline
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust any seat only while the vehicle is parked.
Page 115: 6-Way Driver's Power Seat With Manual Recliner
WARNING! Do not ride with the seatback reclined so that the seat belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or even fatally injured. Use the recliner only when the vehicle is parked.
Page 116: Fold Flat Front Passenger Seat
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fold Flat Front Passenger Seat The front passenger seat can be folded flat to allow for extended cargo space. Pull up on the lever to fold down the seat back. Fold Flat Passenger Seat Head Restraints Head restraints can reduce the risk of whiplash injury in the event of impact from the rear.
Page 117 indicate the level of heat in use. Two LEDs are illumi- nated for high, one for low, and none for off. Pressing the switch once will select high-level heating. Heated Seat Switches UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 Pressing the switch a second time will select low-level heating.
Page 118: 60/40 Split Folding Rear Seat With Fold Flat Feature
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaus- tion or other physical condition must exercise care when using the seat heater.
Page 119 Rear Seat Release Strap NOTE: Prior to folding the rear seat, it may be necessary to reposition the front seat to its mid-track position. Also, be sure that the front seats are fully upright and positioned forward. This will allow the rear seat to fold down easily.
Page 120 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Lower Rear Seat 1. Locate the release strap on the lower outboard side of each rear seatback. 2. Pull the release strap (toward the front of the vehicle). Rear Seat Release Strap 3.
Page 121: To Open And Close The Hood
TO OPEN AND CLOSE THE HOOD To open the hood, two latches must be released. First pull the hood release lever located under the left side of the instrument panel. Hood Release Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Then push the safety latch lever to the right.
Page 122: Lights
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To prevent possible damage, do not slam the hood to close it. Use a firm downward push at the center front edge of the hood to ensure that both latches engage. Never drive your vehicle unless the hood is fully closed, with both latches engaged.
Page 123: Multi-Function Control Lever
Multi-Function Control Lever The multi-function control lever controls the operation of the parking lights, headlights, headlight beam selection, passing light, fog lights, instrument panel light dimming, and turn signals. Multi-Function Control Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Parking Lights, Instrument Panel Lights, and Headlights Turn the end of the multi-function control lever to the first detent for parking lights and instrument panel...
Page 124: Lights-On Reminder
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To change the brightness of the instrument panel lights, rotate the center portion of the multi-function control lever up or down. NOTE: If the driver’s door is left open, and the head- lights or parking lights are left on, the “High Beam Indicator Light”...
Page 125: Turn Signals
Turn Signals Move the multi-function control lever up or down and the arrows on each side of the instrument cluster flash to show proper operation of the front and rear turn signal lights. You can signal a lane change by moving the lever partially up or down without moving beyond the detent.
Page 126: Intermittent Wiper System
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Intermittent Wiper System Use the intermittent wiper when weather conditions make a single wiping cycle, with a variable pause be- tween cycles, desirable. Move the lever to the DELAY position, then select the delay interval by turning the end of the lever.
Page 127: Mist Feature
If the lever is pulled while in the OFF position, the wipers will operate for as long as the lever is held plus two wipe cycles, then turn OFF. Mist Feature Push down on the wiper lever to activate a single wipe to clear off road mist or spray from a passing vehicle.
Page 128: Electronic Speed Control - If Equipped
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ELECTRONIC SPEED CONTROL — IF EQUIPPED When engaged, this device takes over the accelerator operation at speeds greater than 25 mph (40 km/h). Electronic Speed Control Operation The speed control lever is located on the right side of the steering wheel.
Page 129: To Set At A Desired Speed
To Set At A Desired Speed When the vehicle has reached the desired speed, press down on the lever and release. Release the accelerator and the vehicle will operate at the selected speed. NOTE: The vehicle should be traveling at a steady speed and on level ground before pressing the SET lever.
Page 130: Manual Transmission
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Tapping the “SET DECEL” button once will result in a 1 mph (2 km/h) speed decrease. Each time the button is tapped, speed decreases. NOTE: The Speed Control system has been designed to shut down if multiple speed control switch functions are operated simultaneously in order to ensure proper op- eration.
Page 131: Electronic Brake Control System
On steep hills a greater speed loss or gain may occur so it may be preferable to drive without speed control. ELECTRONIC BRAKE CONTROL SYSTEM Your vehicle is equipped with an advanced electronic brake control system that includes ABS (Anti-Lock Brake System), TCS (Traction Control System), BAS (Brake Assist System), ERM (Electronic Roll Mitigation) and ESP (Electronic Stability Program).
Page 132: Tcs (Traction Control System)
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TCS (Traction Control System) This system monitors the amount of wheel spin of each of the driven wheels. If wheel spin is detected, brake pressure is applied to the slipping wheel(s) and engine power is reduced to provide enhanced acceleration and stability.
Page 133: Erm (Electronic Roll Mitigation)
WARNING! BAS (Brake Assist System) cannot prevent the natu- ral laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. BAS cannot prevent accidents, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydroplaning.
Page 134: Esp (Electronic Stability Program)
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Many factors, such as vehicle loading, road condi- tions and driving conditions, influence the chance that wheel lift or rollover may occur. ERM can not prevent all wheel lift or rollovers, especially those that involve leaving the roadway or striking objects or other vehicles.
Page 135 • Oversteer - when the vehicle is turning more than appropriate for the steering wheel position. • Understeer - when the vehicle is turning less than appropriate for the steering wheel position. ESP/TCS Indicator Light The ESP/TCS Indicator Light located in the instrument cluster, starts to flash as soon as the tires lose traction and the ESP system becomes active.
Page 136 136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ESP On This is the normal operating mode for ESP in 2WD, 4WD Part Time, 4WD Full Time, and on 2WD vehicles. When- ever the vehicle is started, the ESP system will be in this mode.
Page 137: Esp/Bas Warning Lamp
situation requiring ESP to be switched to the “Partial Off” mode is overcome, turn ESP back on by momentarily depressing the “ESP OFF” switch. This may be done while the vehicle is in motion. ESP/BAS Warning Lamp The malfunction indicator lamp for the ESP is combined with BAS.
Page 138 138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The HomeLink buttons that are located in the headliner or sun visor designate the three different HomeLink channels. HomeLink Buttons NOTE: HomeLink is disabled when the Vehicle Secu- rity Alarm is active. WARNING! Your motorized door or gate will open and close while you are training the Universal Transceiver.
Page 139: Programming Homelink
WARNING! Vehicle exhaust contains carbon monoxide, a danger- ous gas. Do not run your vehicle in the garage while training the transceiver. Exhaust gas can cause seri- ous injury or death. Programming HomeLink Before You Begin If you have not trained any of the HomeLink buttons, erase all channels before you begin training.
Page 140 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: • Some gate operators and garage door openers may require you to replace Step #3 with procedures noted in the “Gate Operator/Canadian Programming” sec- tion. • After training a HomeLink channel, if the garage door does not operate with HomeLink and the ga- rage door opener was manufactured after 1995, the garage door opener may have rolling code.
Page 141: Gate Operator/Canadian Programming
1 — Garage Door Opener 2 — Training Button 6. Firmly press and release the “learn” or “training” button. The name and color of the button may vary by manufacturer. NOTE: There are 30 seconds in which to initiate the next step after the “Learn”...
Page 142: Using Homelink
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Similar to this Canadian law, some U.S. gate operators are designed to “time-out” in the same manner. It may be helpful to unplug the device during the cycling process to prevent possible overheating of the garage door or gate motor.
Page 143: Security
3. Without releasing the button, proceed with PRO- GRAMMING HOMELINK Step #2 and follow all re- maining steps. Security It is advised to erase all channels before you sell or turn in your vehicle. To do this, press and hold the two outside buttons for 20 seconds until the red indicator flashes.
Page 144: Power Sunroof - If Equipped
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 1. This device may not cause harmful interference 2. This device must accept any interference that may be received including interference that may cause undesired operation NOTE: The transmitter has been tested and it complies with FCC and IC rules.
Page 145: Opening Sunroof - Express
WARNING! • Never leave children in a vehicle, with the keys in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death. •...
Page 146: Pinch Protect Override
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE sunroof will automatically retract. Remove the obstruc- tion if this occurs. Next, press the switch forward and release to Express Close. Pinch Protect Override If a known obstruction (ice, debris, etc.) prevents closing, press the switch forward and hold.
Page 147: Sunroof Maintenance
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 Sunroof Maintenance Use only a non-abrasive cleaner and a soft cloth to clean the glass panel. ELECTRICAL POWER OUTLET This vehicle has two auxiliary power outlets that can provide up to 20 Amps of current for accessories de- signed for use with the standard power outlet adapters.
Page 148: Electrical Outlet Use With Engine Off
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The rear power outlet (if equipped) is located in the left rear cargo area. Rear Power Outlet Electrical Outlet Use With Engine Off WARNING! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e.
Page 149: Power Inverter
POWER INVERTER There is a 110–volt, 150–watt inverter outlet located on the back of the center console to convert DC current to AC current. This outlet can be used to power small appliances and electronics. 110 Volt AC (150 Watt maximum) power outlet UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 Press the switch located in the center stack lower switch bank to turn the power on to the outlet.
Page 150 150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Inverter Switch NOTE: Due to build in overload protection the inverter will shut down if the power rating is exceeded. WARNING! To Avoid Serious Injury or Death: • Do not use a 3—Prong Adaptor. •...
Page 151: Cup Holders
CUP HOLDERS In the center console there are two cup holders for the front seat passengers. Front Cup Holders UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 The rear passengers have cup holders at the rear of the center console. Rear Cup Holders...
Page 152: Storage
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE STORAGE Front Storage Compartment The front storage compartment (located on the left side of the instrument panel) can hold cell phones, PDA’s, and other small items. Front Storage Compartment Console Storage Compartment To open, press the latch and lift the cover. Center Console...
Page 153: Cargo Area Features
The center console has a removable storage tray, which can hold cell phones, PDA’s, and other small items. Removable Storage Tray UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 CARGO AREA FEATURES Cargo Light The cargo area light is activated by opening the liftgate, opening any door, or by rotating the dimmer control on the multi-function control lever to the extreme top posi- tion.
Page 154: Cargo Load Floor - If Equipped
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! The weight and position of cargo and passengers can change the vehicle center of gravity and vehicle handling. To avoid loss of control resulting in per- sonal injury, follow these guidelines for loading your vehicle: •...
Page 155 The cargo load floor is held by spring loaded latches. In order to use the cargo load floor, use the following procedure: 1. Push side mounted release handles (toward center of vehicle) to release cover. Floor Panel UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 2.
Page 156: Rear Cargo Slide Out System (Load N Go ) - If Equipped
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Cargo Slide Out System (LOAD N GO ) — If Equipped The sliding cargo load floor (LOAD N GO ) slides back and forth on steel tracks for convenience. The maximum load capacity is 400 lbs (181 kg). The floor panel can stop every 2 inches (50 mm) when the handle is released, to lock the panel in position.
Page 157: Rear Window Features
3. Pull out the sliding panel. Sliding Panel 4. Squeeze the right hand release handle to slide the panel back into the vehicle. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 REAR WINDOW FEATURES Rear Window Wiper/Washer — If Equipped A rotary ring switch on the control lever (located on the right side of the steering column), controls operation of the rear wiper/washer function.
Page 158 158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If the rear wiper is operating when the ignition is turned OFF, the wiper will automatically return to the “Park” position. When the vehicle is restarted, the wiper will resume function at whichever position the switch is set If the swing gate flip-up window is open or the swing gate is open, connection to the rear window wiper is interrupted preventing activation of the rear wiper blade.
Page 159: Rear Window Defroster - If Equipped
Adding Washer Fluid The fluid reservoir for the windshield washers and the rear window washer is shared. It is located in the front of the engine compartment, and should be checked for fluid level at regular intervals. Fill the reservoir with wind- shield washer solvent (not radiator antifreeze) and oper- ate the system for a few seconds to flush out the residual water.
Page 160: Roof Luggage Rack- Non Functional
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ROOF LUGGAGE RACK— NON FUNCTIONAL The tie loops provided in the Roof Ditch Applique can be used to help tie down cargo; however, metal rails/ crossbars should always be used whenever cargo is placed on the roof.
Page 161 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 WARNING! Cargo must be securely tied before driving your vehicle. Improperly secured loads can fly off the vehicle, particularly at high speeds, resulting in per- sonal injury or property damage. Follow the roof rack Cautions when carrying cargo on your roof rack.
Page 163 INSTRUMENT PANEL AND CONTROLS CONTENTS Instrument Panel And Controls ... . . 166 Instrument Cluster ..... . 167 Instrument Cluster Description .
Page 164 164 INSTRUMENT PANEL AND CONTROLS Two Types Of Signals ....196 Electrical Disturbances ....196 AM Reception .
Page 165 System Activation ..... 227 Electronic Serial Number/Sirius Identification Number (ENS/SID) ....228 Selecting Satellite Mode .
Page 166: Instrument Panel And Controls
166 INSTRUMENT PANEL AND CONTROLS INSTRUMENT PANEL AND CONTROLS 1 — Air Outlet 2 — Instrument Cluster 3 — Storage Tray 4 — Center Air Outlet 5 — Radio 6 — Glove Box 7 — Climate Control 8 — * Heated Seat Switch 9 —...
Page 167: Instrument Cluster
INSTRUMENT PANEL AND CONTROLS 167 INSTRUMENT CLUSTER...
Page 168: Instrument Cluster Description
168 INSTRUMENT PANEL AND CONTROLS INSTRUMENT CLUSTER DESCRIPTION 1. Fuel Gauge The fuel gauge shows level of fuel in tank when ignition switch is in the ON position. 2. Fuel Cap Indicator This symbol indicates the side of the vehicle where the fuel cap is located.
Page 169 5. Seat Belt Reminder Light This light comes on for several seconds after the ignition is turned ON as a reminder to “buckle up.” This light will remain on as long as the driver or passengers seat belt remains unbuckled. If the seat belt indicator remains on and/or flashes with belts buckled, this may indicate a fault in the seat belt reminder system.
Page 170 170 INSTRUMENT PANEL AND CONTROLS WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call a service center if your vehicle overheats. If you decide to look under the hood yourself, see Section 7 of this manual.
Page 171 after several ignition cycles, and the vehicle has been driven several miles at speeds greater than 30 mph (48 km/h), see your authorized dealer as soon as possible. NOTE: The ESP/TCS Indicator Light and the ESP/ BAS Warning Lamp come on momentarily each time the ignition switch is turned ON.
Page 172 172 INSTRUMENT PANEL AND CONTROLS bulb check. If the bulb does not come on during starting, see your authorized dealer for service. If the light stays on, it may be an indication that the parking brake has not been released, or there is a low brake fluid level. If the light remains on when the parking brake has been disengaged, and the fluid level is at the full mark on the master cylinder reservoir, it indicates a possible brake...
Page 173 16. Electronic Stability Program (ESP) Indicator Light/Traction Control System (TCS) Indicator Light The yellow ESP indicator light in the speedom- eter area illuminates with the key in the igni- tion switch turned to the ON/RUN position. It should go out with the engine running. The ESP/TCS Indicator Light starts to flash as soon as the tires lose traction and the ESP system becomes active.
Page 174 174 INSTRUMENT PANEL AND CONTROLS approximately 3 seconds. If this light remains on or comes on during driving, it indicates that the Anti-Lock portion of the brake system is not functioning and that service is required. See your authorized dealer immedi- ately.
Page 175 24. Transmission Range Indicator The electronic gear selector display is self-contained within the instrument cluster. It displays the position of the automatic transmission shift lever, and the relation of each position to all other positions. For a good signal the display will place a box around the selected transmission range (PRND21).
Page 176 176 INSTRUMENT PANEL AND CONTROLS maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale. Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly.
Page 177 26. Odometer/Trip Odometer The odometer shows the total distance the vehicle has been driven. The trip odometer shows individual trip mileage. To toggle between the odometer and the trip odometer, press the Odometer/Trip Odometer Button. To reset the Trip Odometer, press and hold the button while in trip mode, until the Trip Odometer resets.
Page 178 178 INSTRUMENT PANEL AND CONTROLS on the instrument cluster. To reset the oil change indica- tor system (after performing the scheduled maintenance) refer to the following procedure. 1. Turn the ignition switch to the ON position (Do not start the engine). 2.
Page 179 CAUTION! Prolonged driving with the MIL on could cause damage to the engine control system. It also could affect fuel economy and driveability. If the MIL is flashing, severe catalytic converter damage and power loss will soon occur. Immediate service is required. 28.
Page 180: Compass And Trip Computer - If Equipped
180 INSTRUMENT PANEL AND CONTROLS COMPASS AND TRIP COMPUTER — IF EQUIPPED The Compass/Trip Computer features a driver- interactive display (displays information on outside tem- perature, compass direction, and trip information). It is located on the lower left part of the cluster below the fuel and engine temperature gauge, and the tachometer.
Page 181: Control Buttons
INSTRUMENT PANEL AND CONTROLS 181 • Loose Fuel Cap (gASCAP) These messages can be manually turned off by pressing the right button (on the instrument cluster). Control Buttons Press and release the odometer/trip odometer reset but- ton (right side of the instrument cluster) to access the compass/trip computer displays.
Page 182: Trip Conditions
182 INSTRUMENT PANEL AND CONTROLS Trip Conditions Trip Odometer (ODO) This display shows the distance traveled since the last reset. Press and release the right button (on the instru- ment cluster) to switch from odometer, to trip A or trip B. Press and hold the right button while the odometer/trip odometer is displayed to reset.
Page 183 INSTRUMENT PANEL AND CONTROLS 183 NOTE: Magnetic materials should be kept away from the top of the right rear quarter window. This is where the compass sensor is located. To Set the Variance Start the engine, and leave the transmission in the P (Park) position.
Page 184: Electronic Vehicle Information Center (Evic) - If Equipped
184 INSTRUMENT PANEL AND CONTROLS To Manually Calibrate the Compass Start the engine, and leave the transmission in the P (Park) position. Press and hold (approximately 10 sec- onds) the odometer/trip odometer reset button until the current variance zone number is displayed. Release the odometer/trip odometer reset button, then press and hold again (approximately 10 seconds), until the direc- tion is displayed with the “CAL”...
Page 185 Vehicles equipped with steering wheel mounted buttons (described in this section) are also equipped with the EVIC. The EVIC consists of the following: • System Status • Vehicle information warning message displays • Tire Pressure Monitor System (If Equipped) • Personal Settings (Customer Programmable Features) •...
Page 186: Electronic Vehicle Information Center (Evic) Displays
186 INSTRUMENT PANEL AND CONTROLS Press and release the COMPASS/TEMPERATURE button to display one of eight compass readings and the outside temperature. Electronic Vehicle Information Center (EVIC) Displays When the appropriate conditions exist, the Electronic Vehicle Information Center (EVIC) displays the following messages: •...
Page 187: Oil Change Required
• Right Front Low Pressure (with a single chime). Refer to “Tire Pressure Monitoring System” in Section 5 of this manual. • Right Rear Low Pressure (with a single chime). Refer to “Tire Pressure Monitoring System” in Section 5 of this manual.
Page 188: Trip Functions
188 INSTRUMENT PANEL AND CONTROLS 3. Turn the ignition switch to the OFF/LOCK position. NOTE: If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary repeat this procedure. Trip Functions Press and release the MENU button until one of the following Trip Functions displays in the EVIC: •...
Page 189: Compass Display
• When the DTE value is less than 30 miles (48 km) estimated driving distance, the DTE display will change to a text display of LOW FUEL. This display will continue until the vehicle runs out of fuel. Adding a significant amount of fuel to the vehicle will turn off the LOW FUEL text and a new DTE value will display.
Page 190 190 INSTRUMENT PANEL AND CONTROLS objects) until the “CAL” indicator displayed in the EVIC turns off. The compass will now function normally. Manual Compass Calibration If the compass appears erratic and the “CAL” indicator does not appear in the EVIC display, you must put the compass into the Calibration Mode manually as follows: 1.
Page 191: Telephone - If Equipped
INSTRUMENT PANEL AND CONTROLS 191 1. Turn the ignition switch ON. 2. Press and hold the compass button for approximately 2 seconds. 3. Press the SCROLL button until “Compass Variance” message and the last variance zone number displays in the EVIC. 4.
Page 192 192 INSTRUMENT PANEL AND CONTROLS • Phone status: idle, voice mail, roaming, battery strength, and signal strength in increments of 20 percent. • Call status: Incoming call, connecting, connected, air time in minutes and seconds, call ended, call failed, roaming, and no phone connection. •...
Page 193: Personal Settings
The EVIC displays this symbol to indicate that you have voice mail. Voice Mail The EVIC displays this symbol to indicate a text message. Text Message The EVIC displays this symbol to indicate the battery strength of the UConnect™ phone. Battery Strength INSTRUMENT PANEL AND CONTROLS 193...
Page 194 194 INSTRUMENT PANEL AND CONTROLS Use the SCROLL button to display one of the following choices: Language When in this display you may select one of five lan- guages for all display nomenclature, including the trip functions and the navigation system (if equipped). Press the FUNCTION SELECT button while in this display to select English, Espanol, or Francais.
Page 195 Sound Horn with Remote Key Lock When ON is selected, a short horn sound will occur when the remote keyless entry “Lock” button is pressed. This feature may be selected with or without the flash lights on lock/unlock feature. To make your selection, press and release the FUNCTION SELECT button until “ON”...
Page 196: Radio General Information
196 INSTRUMENT PANEL AND CONTROLS Confirmation of Voice Commands — If Equipped When ON is selected, all voice commands from the UConnect™ system are confirmed. To make your selec- tion, press and release the FUNCTION SELECT button until “ON” or “OFF” appears. Display Units of Measure in The EVIC, odometer, and navigation system (if equipped) can be changed between English and Metric...
Page 197: Am Reception
AM Reception AM sound is based on wave amplitude, so AM reception can be disrupted by such things as lightning, power lines and neon signs. FM Reception Because FM transmission is based on frequency varia- tions, interference that consists of amplitude variations can be filtered out, leaving the reception relatively clear, which is the major feature of FM radio.
Page 198: Operating Instructions - Radio Mode
198 INSTRUMENT PANEL AND CONTROLS Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Press the ON/VOL control to turn the radio ON. Press the ON/VOL a second time to turn OFF the radio.
Page 199 Phone Button (UConnect™ Hands Free Phone) — If Equipped Press this button to operate the Hand Free Phone (UCon- nect™) feature (if equipped). Refer to “Hands-Free Com- munication (UConnect™)” in Section 3 for more informa- tion. If your vehicle is not equipped with or this feature is not available on your vehicle, a “UConnect™...
Page 200 200 INSTRUMENT PANEL AND CONTROLS RW/FF (Radio Mode) Pressing the rewind or fast forward button causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in either AM, FM or Satellite (if equipped) frequencies. TUNE Control (Radio Mode) Turn the right side rotary control clockwise to increase or counter-clockwise to decrease the frequency.
Page 201 allow the program format type to be selected. Many radio stations do not currently broadcast Music Type informa- tion. Toggle the Music Type button to select the following format types: Program Type 16 Digit-Character Display No program type or un- defined Adult Hits Classical...
Page 202 202 INSTRUMENT PANEL AND CONTROLS By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode.
Page 203 • Angle – Repeatedly Pressing SELECT will change the viewing angle if supported by the DVD disc (If Equipped). NOTE: The available selections for each of the above entries varies depending upon the disc. NOTE: These selections can only be made while playing a DVD.
Page 204 204 INSTRUMENT PANEL AND CONTROLS disc). If customer wishes to select a language not listed, then scroll down and select other. Enter the country code using the TUNE control knob to scroll up and down to select the # and then push to select. Subtitle Language —...
Page 205 a disc is loaded, changes will not be effective. Also, the defaults are effective only if the disc supports the customer-preferred settings. AM and FM Buttons (Radio Mode) Press the buttons to select AM or FM Modes. SET Button (Radio Mode) — To Set the Push-Button Memory When you are receiving a station that you wish to commit to push-button memory, press the SET button.
Page 206: Operation Instructions - (Disc Mode For Cd And Mp3/Wma Audio Play, Dvd-Video)
206 INSTRUMENT PANEL AND CONTROLS Operation Instructions - (DISC MODE for CD and MP3/WMA Audio Play, DVD-VIDEO) The radio DVD player and many DVD discs are coded by geographic region. These region codes must match in order for the disc to play. If the region code for the DVD disc does not match the region code for the radio DVD player, it will not play the disc.
Page 207 Eject Button — Ejecting Compact Disc(s) Press the eject button and the push-button with the corresponding number (1-6) where the CD was loaded and the disc will unload and move to the entrance for easy removal. Radio display will show EJECTING DISC when the disc is being ejected and prompt the user to remove the disc.
Page 208: Notes On Playing Mp3/Wma Files
208 INSTRUMENT PANEL AND CONTROLS Notes On Playing MP3/WMA Files The radio can play MP3/WMA files; however, acceptable MP3/WMA file recording media and formats are limited. When writing MP3/WMA files, pay attention to the following restrictions. Supported Media (Disc Types) The MP3/WMA file recording media supported by the radio are CDDA, CD-R, CD-RW, MP3,WMA, DVD Video, DVD-R, DVD-RW, DVD+R, DVD+RW, and CDDA+MP3.
Page 209 If a disc contains multi formats, such as CD audio and mp3/wma tracks, the radio will only play the mp3/wma tracks on that disc. Supported MP3/WMA File Formats The radio will recognize only files with the *.MP3/WMA extension as MP3/WMA files. Non-MP3/WMA files named with the *.MP3/WMA extension may cause play- back problems.
Page 210: List Button
210 INSTRUMENT PANEL AND CONTROLS Playback of MP3/WMA Files When a medium containing MP3/WMA data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3/WMA files.
Page 211 Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack, which allows the user to plug in a portable device such as an MP3/WMA player, cassette player, or microphone and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 212 212 INSTRUMENT PANEL AND CONTROLS For UConnect™ “Voice Recognition System (VR) — If Equipped ” refer to “Hands-Free Communication (UCon- nect™)” in section 3 of this manual for detailed operating instructions. Operating Instructions - Hands Free Phone (UConnect™) (If Equipped) Refer to “Hands-Free Communication (UConnect™)”...
Page 213: Sales Code Res - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
SALES CODE RES — AM/FM STEREO RADIO WITH CD PLAYER (MP3 AUX JACK) NOTE: The radio sales code is located on the lower right side of your radio faceplate. RES Radio (Non-Satellite Model Shown - With Satellite Similar) INSTRUMENT PANEL AND CONTROLS 213 Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
Page 214 214 INSTRUMENT PANEL AND CONTROLS SEEK Buttons Press and release the SEEK buttons to search for the next listenable station in AM/FM mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection.
Page 215 TIME Button Press the TIME button and the time of day will display. In AM or FM mode, pressing the TIME button will switch between the time and frequency displays. Clock Setting Procedure 1. Press and hold the TIME button, until the hours blink. 2.
Page 216 216 INSTRUMENT PANEL AND CONTROLS Setting the Tone, Balance, and Fade Press the rotary TUNE control knob and BASS will display. Turn the TUNE control knob to the right or left to increase or decrease the Bass tones. Press the rotary TUNE control knob a second time and MID will display.
Page 217 Program Type 16 Digit-Character Display No program type or un- defined Adult Hits Classical Classic Rock College Country Foreign Language Language Information Jazz News Nostalgia Oldies Personality Public Rhythm and Blues Program Type Religious Music None Religious Talk Adlt Hit Rock Classicl Soft...
Page 218 218 INSTRUMENT PANEL AND CONTROLS If a preset button is activated while in the Music Type (Program Type) mode, the Music Type mode will be exited and the radio will tune to the preset station. SETUP Button Pressing the SETUP button allows you to select between the following items: •...
Page 219: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
Buttons 1 - 6 These buttons tune the radio to the stations that you commit to push-button memory {12 AM and 12 FM stations}. DISC Button Pressing the DISC button will allow you to switch from AM/FM modes to Disc modes. Operation Instructions - CD MODE for CD and MP3 Audio Play NOTE: The ignition switch must be in the ON or ACC...
Page 220 220 INSTRUMENT PANEL AND CONTROLS CAUTION! • This CD player will accept 4 3/4 inch (12 cm) discs only. The use of other sized discs may damage the CD player mechanism. • Do not use adhesive labels. These labels can peel away and jam the player mechanism.
Page 221: Notes On Playing Mp3 Files
TIME Button Press this button to change the display from a large CD playing time display to a small CD playing time display. RW/FF Press the RW button to stop the CD at the beginning of the current CD track/title. Press and hold FF (Fast Forward) and the CD player will begin to fast forward until FF is released or RW or another CD button is pressed.
Page 222 222 INSTRUMENT PANEL AND CONTROLS files properly and may be unable to play the file nor- mally. UDF and Apple HFS formats are not supported. The radio uses the following limits for file systems: • Maximum number of folder levels: 8 •...
Page 223 rates (VBR) are also supported. The majority of MP3 files use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or VBR bit rates. MPEG Specifi- Sampling Fre- cation quency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio 24, 22.05, 16 Layer 3...
Page 224: List Button (Cd Mode For Mp3 Play)
224 INSTRUMENT PANEL AND CONTROLS LIST Button (CD Mode for MP3 Play) Pressing the LIST button will bring up a list of all folders on the disc. Scrolling up or down the list is done by turning the TUNE control knob. Selecting a folder by pressing the TUNE control knob will begin playing the files contained in that folder (or the next folder in sequence if the selection does not contain playable files).
Page 225: Sales Code Rer - Am/Fm/Cd/Dvd Radio With Navigation System - If Equipped
TIME Button (Auxiliary Mode) Press this button to change the display to time of day. The time of day will display for 5 seconds (when ignition is off). Operating Instructions - Hands Free Phone (UConnect™) (If Equipped) Refer to “Hands-Free Communication (UConnect™)” in Section 3 of this manual.
Page 226: Operating Instructions - Satellite Radio
226 INSTRUMENT PANEL AND CONTROLS Operating Instructions — Satellite Radio Refer to your “Navigation User’s Manual” for detailed operating instructions. Clock Setting Procedure The GPS receiver used in this system is synchronized to the time data being transmitted by the GPS satellite. The satellites’...
Page 227: Satellite Radio (Rsc) - If Equipped (Rer/Req/Ren Radios Only)
Changing Daylight Savings Time 1. Press the Time soft key on the lower left side of the face of the radio. 2. Press the Daylight Savings soft key when Daylight Savings Time is in effect. 3. Press the SAVE soft key on the face of the radio. Press the CANCEL soft key to exit from the clock setting mode.
Page 228: Electronic Serial Number/Sirius Identification Number (Ens/Sid)
228 INSTRUMENT PANEL AND CONTROLS Electronic Serial Number/Sirius Identification Number (ENS/SID) The Electronic Serial Number/Sirius Identification Num- ber is needed to activate your Sirius Satellite Radio system. To access the ESN/SID, refer to the following steps: ESN/SID Access With the ignition switch in the ON/RUN or ACCESSORY position and the radio ON, press the SETUP button and scroll using the TUNE control knob until Sirius ID is selected.
Page 229: Operating Instructions - Satellite Mode
• Dense tree coverage may interrupt reception in the form of short audio mutes. • Driving under wide bridges or along tall buildings can cause intermittent reception. • Placing objects over or too close to the antenna can cause signal blockage. Operating Instructions - Satellite Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
Page 230 230 INSTRUMENT PANEL AND CONTROLS TUNE Control (Rotary) Turn the right side rotary control clockwise to increase or counter-clockwise to decrease the channel. MUSIC TYPE Button Pressing this button once will turn on the Music Type mode for 5 seconds. Pressing the MUSIC TYPE button or turning the TUNE control knob within 5 seconds will allow the program format type to be selected.
Page 231: Operating Instructions - Hands Free Phone
You may add a second channel to each push-button by repeating the above procedure with this exception: Press the SET button twice and SET 2 will show in the display window. Each button can be set for SET 1 and SET 2. This allows a total of 12 Satellite channels to be stored into push-button memory.
Page 232 232 INSTRUMENT PANEL AND CONTROLS The LCD screen is located on the headliner behind the front seats. Press the release button and lower the screen. Remote Control Location Overhead Display Screen...
Page 233: Remote Sound System Controls - If Equipped
REMOTE SOUND SYSTEM CONTROLS — IF EQUIPPED The remote sound system controls are located on the rear surface of the steering wheel. Reach behind the wheel to access the switches. INSTRUMENT PANEL AND CONTROLS 233 The right hand control is a rocker type switch with a push button in the center.
Page 234: Cd Player
234 INSTRUMENT PANEL AND CONTROLS The button located in the center of the left hand control will tune to the next pre-set station that you have programmed in the radio pre-set push-buttons. CD Player Pressing the top of the switch once will go to the next track on the CD.
Page 235: Climate Controls
CLIMATE CONTROLS Manual Air Conditioning and Heating System The controls for the heating/air conditioning and venti- lation system in this vehicle consist of a series of rotary knobs. These comfort controls can be set to obtain desired interior conditions. Manual Air Conditioning and Heating Controls INSTRUMENT PANEL AND CONTROLS 235 The instrument panel features four airflow registers.
Page 236 236 INSTRUMENT PANEL AND CONTROLS Temperature Control Use this control to regulate the temperature of the air in- side the passenger compart- ment. The blue area of the scale indicates cooler tem- peratures while the red area indicates warmer tempera- tures.
Page 237 NOTE: There is a difference in temperature between the upper and lower outlets for added comfort. The warmer air goes to the floor outlets. This feature gives improved comfort during sunny but cool conditions. Floor Air is directed through the floor outlets and side window demist outlets with a small amount through the defrost outlet.
Page 238 238 INSTRUMENT PANEL AND CONTROLS Circulation Control Press the mode control knob to activate the recirculation mode. A lamp (in the knob) will illuminate when you are in recirculate mode. Press the knob again to deactivate the system. Only use the recircu- lation mode to temporarily block out any outside odors, smoke, or dust and to cool the...
Page 239: Operating Tips
Operating Tips Window Fogging Windows will fog on the inside when the humidity inside the vehicle is high. This often occurs in mild or cool temperatures when it’s rainy or humid. In most cases, turning on the air conditioning (pressing the snowflake button) will clear the fog.
Page 240 240 INSTRUMENT PANEL AND CONTROLS Your air conditioning system is also equipped with an automatic recirculation system. When the system senses a heavy load or high heat conditions, it may use partial Recirculation A/C mode to provide additional comfort. Winter Operation When operating the system during the winter months, make sure the air intake, located directly in front of the windshield, is free of ice, slush, snow, or other obstruc-...
Page 241 STARTING AND OPERATING CONTENTS Starting Procedures ..... 245 Manual Transmission ....245 Automatic Transmission .
Page 242 242 STARTING AND OPERATING Four-Wheel Drive Operation ....265 MP 143 Single-Speed Part-Time Transfer Case — If Equipped ......265 Shifting Procedure - Electronically Shifted Transfer Case .
Page 243 Tire Spinning ......290 Tread Wear Indicators ....291 Life Of Tire .
Page 244 244 STARTING AND OPERATING Trailer Towing ......315 Common Towing Definitions ... . . 315 Trailer Hitch Classification .
Page 245: Starting Procedures
STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belts. CAUTION! Long periods of engine idling, especially at high engine speeds can cause excessive exhaust tempera- tures which can damage your vehicle. Do not leave your vehicle unattended with the engine running.
Page 246: Extreme Cold Weather (Below -20°F Or -29°C)
246 STARTING AND OPERATING Tip Start Feature — Automatic Transmission Only Do not press the accelerator. Turn the ignition key briefly to START position, and release it. The starter motor will continue to run, but will automatically disengage itself when the engine is running. Ignition Key Positions Extreme Cold Weather (below –20°F or –29°C) To insure reliable starting at these temperatures, use of an...
Page 247 WARNING! Never pour fuel or other flammable liquids into the throttle body air inlet opening in an attempt to start the vehicle. This could result in a flash fire causing serious personal injury. STARTING AND OPERATING 247 WARNING! Do not attempt to push or tow your vehicle to get it started.
Page 248: After Starting
248 STARTING AND OPERATING released. If this occurs, continue cranking with the accel- erator pedal pushed all the way to the floor. Release the accelerator pedal and the key once the engine is running smoothly. If the engine shows no sign of starting after two 15 second periods of cranking with the accelerator pedal held to the floor, the “Normal Starting”...
Page 249: Manual Transmission - If Equipped
WARNING! Remember to disconnect the cord before driving. Damage to the 110-115 volt AC electrical cord could cause electrocution. Use the heater when temperatures below 0°F (-18°C) are expected to last for several days. MANUAL TRANSMISSION — IF EQUIPPED 6-Speed Manual Transmission WARNING! You or others could be injured if you leave the vehicle unattended without having the parking...
Page 250 250 STARTING AND OPERATING WARNING! When parking your vehicle, always leave a manual transmission in first gear and apply the parking brake fully to guard against vehicle movement and possible injury or damage. Never use any gear as a substitute for the parking brake. CAUTION! To drive as safely as possible and to prolong the life of your manual transmission, follow these tips:...
Page 251 • When “rocking” a stuck vehicle by shifting between a forward gear and reverse, do not spin wheels faster than 15 mph (24 km/h), or drivetrain damage may result. Recommended Manual Transmission Shifting Speeds The manufacturer recommends that you use the shift speeds listed in the chart below.
Page 252: Automatic Transmission
252 STARTING AND OPERATING CAUTION! Failure to follow the recommended downshifting speeds may cause the engine to over speed and/or damage the clutch disc even if the clutch pedal is depressed. AUTOMATIC TRANSMISSION CAUTION! Damage to the transmission may occur if the follow- ing precautions are not observed: •...
Page 253: Shift Lock Manual Override - If Equipped
WARNING! It is dangerous to shift the selector lever out of P (Park) or N (Neutral) if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in reverse.
Page 254: Brake/Transmission Interlock System
254 STARTING AND OPERATING 4. Using the screwdriver, reach into the manual override opening. Press and hold the shift lock lever down. 5. Move the shift lever into the N (Neutral) position. 6. The vehicle may then be started in N (Neutral). Have your vehicle inspected by your local authorized dealer, if the shift lock manual override has been used.
Page 255: 4-Speed Automatic Transmission (3.7L Engine)
4–Speed Automatic Transmission (3.7L Engine) Shifting from D (Drive) to P (Park) or R (Reverse) (or from P or R to D) should be done only after the accelerator pedal is released and the vehicle is stopped. Be sure to keep your foot on the brake when moving the shift lever between these gears.
Page 256 256 STARTING AND OPERATING WARNING! It is dangerous to shift the selector lever out of P (Park) or N (Neutral) if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in reverse.
Page 257 1 (First) For hard pulling at low speeds in mud, sand, snow, or on steep grades. Begins and stays in low gear with no upshift. Provides engine compression braking at low speeds. Overdrive Operation The overdrive automatic transmission contains an elec- tronically controlled fourth and fifth speed (Overdrive).
Page 258 258 STARTING AND OPERATING The transmission will downshift from Overdrive to Drive if the accelerator pedal is fully depressed at vehicle speeds above approximately 35 mph (56 km/h). When To Use “TOW/HAUL” Mode When driving in hilly areas, towing a trailer, carrying a heavy load, etc., and frequent transmission shifting oc- curs, press the “TOW/HAUL”...
Page 259 Transmission Limp Home Mode Transmission function is monitored for abnormal condi- tions. If a condition is detected that could result in transmission damage, the transmission limp home mode will be engaged. In this mode, the transmission will remain in the current gear until the vehicle is brought to a stop.
Page 260: 5-Speed Automatic Transmission (4.0L Engine)
260 STARTING AND OPERATING 5–Speed Automatic Transmission (4.0L Engine) The electronically controlled transmission provides a precise shift schedule. The transmission electronics are self-calibrating; therefore, the first few shifts on a new vehicle, may be somewhat abrupt. This is a normal condition, and precision shifts will develop within a few hundred miles.
Page 261 gear engagement may be delayed after restarting the engine if the key is not cycled to the LOCK position first. P (Park) This gear position supplements the parking brake by locking the transmission. The engine can be started in this range. Never use P (Park) while the vehicle is in motion.
Page 262 262 STARTING AND OPERATING N (Neutral) Shift into N (Neutral) when the vehicle is standing for prolonged periods with the engine running. The engine may be started in this range. Set the parking brake if you must leave the vehicle. NOTE: Towing the vehicle, coasting, or driving for any other reason with selector lever in N (Neutral) can result in severe transmission damage.
Page 263 Overdrive Operation The overdrive automatic transmission contains an elec- tronically controlled 5th speed (Overdrive). The trans- mission will automatically shift from 4th gear to Over- drive if the following conditions are present: • the transmission selector is in D (Drive); •...
Page 264 264 STARTING AND OPERATING 1. Stop the vehicle. 2. Move the shift lever to the P (Park) position. 3. Turn off the engine, be sure to turn the key to the LOCK position. 4. Wait approximately 10 seconds, then restart the en- gine.
Page 265: Four-Wheel Drive Operation
the transmission. This condition is normal and will not cause damage to the transmission. The torque converter will refill within five seconds of shifting from Park into any other gear position. FOUR-WHEEL DRIVE OPERATION MP 143 Single-Speed Part-Time Transfer Case — If Equipped Operating Information/Precautions This is an electric shift transfer case and is operated by...
Page 266: Shifting Procedure - Electronically Shifted Transfer Case
266 STARTING AND OPERATING wheels to rotate at the same speed. This is accomplished by rotating the 4WD Control Switch to the desired position - refer to “Shifting Procedure” for specific shift- ing instructions. The 4WD LOCK position is designed for loose, slippery road surfaces only.
Page 267: Mp 140 Single-Speed Full-Time Transfer Case - If Equipped
you momentarily release the accelerator pedal after turn- ing the control switch. If the vehicle is stopped, the ignition key must be in the ON position with the engine either RUNNING or OFF. This shift cannot be completed if the key is in the ACC (Accessory) position. NOTE: The 4 wheel drive system will not allow shifts between 2WD/4WD LOCK if the front and/or rear wheels are spinning (no traction).
Page 268: On-Road Driving Tips
268 STARTING AND OPERATING ON-ROAD DRIVING TIPS Utility vehicles have higher ground clearance and a narrower track to make them capable of performing in a wide variety of off-road applications. Specific design characteristics give them a higher center of gravity than ordinary cars.
Page 269 CAUTION! When driving through water, do not exceed 5 mph (8 km/h). Always check water depth before entering as a precaution, and check all fluids afterward. Driving through water may cause damage that may not be covered by the new vehicle limited warranty. Driving through water more than a few inches deep will require extra caution to ensure safety and prevent dam- age to your vehicle.
Page 270: Driving In Snow, Mud And Sand
270 STARTING AND OPERATING Driving In Snow, Mud and Sand In heavy snow, when pulling a load, or for additional control at slower speeds, shift the transmission to a low gear and shift the transfer case to 4L or 4LO if necessary. Refer to “Four-Wheel Drive Operation”...
Page 271: Traction Downhill
Remember, never drive diagonally across a hill-always drive straight up or down. If the wheels start to slip as you approach the crest of a hill, ease off the accelerator and maintain headway by turning the front wheels slowly left and right. This may provide a fresh “bite”...
Page 272: Parking Brake
272 STARTING AND OPERATING • After extended operation in mud, sand, water, or similar dirty conditions, have brake rotors, wheels, brake linings, and axle yokes inspected and cleaned as soon as possible. WARNING! Abrasive material in any part of the brakes may cause excessive wear or unpredictable braking.
Page 273 NOTE: The instrument cluster “Brake Warning Light” indicates only that the parking brake is applied. You must be sure the parking brake is fully applied before leaving the vehicle. Parking Brake STARTING AND OPERATING 273 Be sure the parking brake is firmly set when parked, and the gear selector lever is in the “P”...
Page 274: Anti-Lock Brake System
274 STARTING AND OPERATING WARNING! • Always apply the parking brake fully when leav- ing your vehicle or it may roll and cause damage or injury. Also, be certain to leave an automatic transmission in “P” (Park) or a manual transmis- sion in “R”...
Page 275 WARNING! Significant over or under inflation of tires or mixing sizes of tires or wheels on the vehicle can lead to loss of braking effectiveness. The Anti-Lock Brake System conducts a low-speed self- test at about 12 mph (20 km/h). If you have your foot lightly on the brake while this test is occurring, you may feel slight pedal movement.
Page 276 276 STARTING AND OPERATING WARNING! • The Anti-Lock Brake System (ABS) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking or steering efficiency beyond that afforded by the condition of the vehicle brakes and tires or the traction afforded.
Page 277: Power Steering
• Do not “ride” the brakes by resting your foot on the pedal. This could overheat the brakes and result in unpredictable braking action, longer stopping dis- tances, or brake damage. • When descending mountains or hills, repeated brak- ing can cause brake fade with loss of braking control. Avoid repeated heavy braking by downshifting the transmission or locking out overdrive whenever pos- sible.
Page 278 278 STARTING AND OPERATING NOTE: Increased noise levels at the end of the steering wheel travel are considered normal and do not indicate that there is a problem with the power steering system. Upon initial start-up in cold weather, the power steering pump may make noise for a short amount of time.
Page 279: Tire Safety Information
TIRE SAFETY INFORMATION Tire Markings NOTE: • P (Passenger)-Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Ex- ample: P215/65R15 95H. STARTING AND OPERATING 279 • European Metric tire sizing is based on European design standards.
Page 280 280 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary Spare tire 31 = Overall Diameter in Inches (in) 215 = Section Width in Millimeters (mm)
Page 281 Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry. H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions. —The maximum speed corresponding to the Speed Symbol should only be achieved un- der specified operating conditions (i.e.
Page 282: Tire Identification Number (Tin)
282 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side. Tires with white sidewalls will have the full TIN including date code DOT = Department of Transportation —This symbol certifies that the tire is in compliance with the U.S.
Page 283: Tire Loading And Tire Pressure
Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on either the face of the driver’s door or the driver’s side “B” pillar. Tire Placard Location STARTING AND OPERATING 283 Tire and Loading Information Placard Tire and Loading Information This placard tells you important information about the: 1) number of people that can be carried in the vehicle...
Page 284 284 STARTING AND OPERATING Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the “Tire and Loading Information”...
Page 285 5. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4. 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle.
Page 286 286 STARTING AND OPERATING...
Page 287: Tires - General Information
WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 288: Tire Inflation Pressures
288 STARTING AND OPERATING 2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Under inflation also increases tire rolling resistance and results in higher fuel consump- tion.
Page 289 check tire pressure. Do not make a visual judgement when determining proper inflation. Radial tires may look properly inflated even when they are under inflated. CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap (if equipped). This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem.
Page 290: Tire Pressures For High Speed Operation
290 STARTING AND OPERATING Tire Pressures for High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.
Page 291: Tread Wear Indicators
WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure some- one. Do not spin your vehicle’s wheels faster than 35 mph (55 km/h) when you are stuck, and do not let anyone near a spinning wheel no matter what the speed.
Page 292: Life Of Tire
292 STARTING AND OPERATING Life of Tire The service life of a tire is dependent upon varying factors including but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and spare tire should be replaced after six years, regardless of the remaining tread.
Page 293: Alignment And Balance
WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change suspension dimensions and performance characteristics, result- ing in changes to steering, handling, and braking of your vehicle.
Page 294: Tire Chains
294 STARTING AND OPERATING Improper alignment will not cause vehicle vibration. Vibration may be a result of tire and wheel out-of- balance. Proper balancing will reduce vibration and avoid tire cupping and spotty wear. TIRE CHAINS Use “Class S” chains or other traction aids that meet SAE Type “S”...
Page 295: Tire Rotation Recommendations
These cautions apply to all chain traction devices, includ- ing link and cable (radial) chains. Tire chain use is permitted only on the rear tires. NOTE: The use of class “S” chains is permitted with P235/65R17 tires. CAUTION! Do not use tire chains on vehicles equipped with tires other than P235/65R17 tires.
Page 296: Tire Pressure Monitor System (Tpms) - If Equipped
296 STARTING AND OPERATING NOTE: The Premium Tire Pressure Monitor System will automatically locate the pressure values displayed in the correct vehicle position following a tire rotation. The suggested rotation method is the “forward-cross” shown in the following diagram. TIRE PRESSURE MONITOR SYSTEM (TPMS) — IF EQUIPPED •...
Page 297 pressure will also increase as the vehicle is driven - this is normal and there should be no adjustment for this increased pressure. • The TPM System will warn the driver of a low tire pressure if the tire pressure falls below the low- pressure warning limit for any reason, including low temperature effects and natural pressure loss through the tire.
Page 298 298 STARTING AND OPERATING CAUTION! • The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle. Undesirable system operation or sensor damage may result when us- ing replacement equipment that is not of the same size, type, and/or style.
Page 299: Base System - If Equipped
• Seasonal temperature changes will affect tire pressure, and the TPMS will monitor the actual tire pressure in the tire. Base System — If Equipped The Tire Pressure Monitor System (TPMS) uses wireless technology with wheel rim mounted electronic sensors to monitor tire pressure levels.
Page 300 300 STARTING AND OPERATING vehicle may need to be driven for up to 10 minutes above 15 mph (25 km/h) in order for the TPMS to receive this information. Check TPMS Warning When a system fault is detected, the Tire Pressure Moni- toring Telltale Light will flash on and off for 75 seconds and then remain on solid.
Page 301: Premium System - If Equipped
NOTE: Vehicles with Compact Spare 1. The compact spare tire does not have a tire pressure monitoring sensor. Therefore, the TPMS will not monitor the pressure in the compact spare tire. 2. If you install the compact spare tire in place of a road tire that has a pressure below the low-pressure warning limit, upon the next ignition key cycle, a chime will sound and the TPM Telltale Light will turn ON.
Page 302 302 STARTING AND OPERATING • 3 Trigger Modules (mounted in three of the four wheel-wells) • Various Tire Pressure Monitoring System Messages, which display in the Electronic Vehicle Information Center (EVIC) • Tire Pressure Monitoring Telltale Light The matching full size spare wheel and tire assembly (if equipped) has a tire pressure monitoring sensor.
Page 303 the EVIC graphic) to the vehicle’s recommended cold placard pressure value. Once the system receives the updated tire pressures, the system will automatically update, the graphic display in the EVIC will stop flash- ing, and the Tire Pressure Monitoring Telltale Light will turn off.
Page 304 304 STARTING AND OPERATING 1. Jamming due to electronic devices or driving next to facilities emitting the same Radio Frequencies as the TPM sensors. 2. Installing some form of aftermarket window tinting that affects radio wave signals. 3. Lots of snow or ice around the wheels or wheel housings.
Page 305: General Information
2. If you install the compact spare tire in place of a road tire that has a pressure below the low-pressure warning limit, upon the next ignition key cycle, the TPM Telltale Light will remain ON and a chime will sound. In addition, the graphic in the EVIC will still display a flashing pressure value.
Page 306: Fuel Requirements
306 STARTING AND OPERATING The tire pressure sensors are covered under one of the following licenses: United States ..... KR5S120123 Canada .
Page 307: Reformulated Gasoline
Poor quality gasoline can cause problems such as hard starting, stalling and hesitations. If you experience these symptoms, try another brand of gasoline before consid- ering service for the vehicle. Over 40 auto manufacturer’s world wide have issued and endorsed consistent gasoline specifications (the World- wide Fuel Charter, WWFC) to define fuel properties necessary to deliver enhanced emissions, performance, and durability for your vehicle.
Page 308: Mmt In Gasoline
308 STARTING AND OPERATING Problems that result from using methanol/gasoline or E85 Ethanol blends are not the responsibility of the manufacturer. While MTBE is an oxygenate made from Methanol, it does not have the negative effects of Metha- nol. MMT In Gasoline MMT is a manganese containing metallic additive that is blended into some gasoline to increase octane.
Page 309: Carbon Monoxide Warnings
• The use of leaded gas is prohibited by Federal law. Using leaded gasoline can impair engine performance, damage the emission control system. • An out-of-tune engine, or certain fuel or ignition malfunctions, can cause the catalytic converter to overheat. If you notice a pungent burning odor or some light smoke, your engine may be out of tune or malfunctioning and may require immediate service.
Page 310: Adding Fuel
310 STARTING AND OPERATING • Guard against carbon monoxide with proper mainte- nance. Have the exhaust system inspected every time the vehicle is raised. Have any abnormal conditions repaired promptly. Until repaired, drive with all side windows fully open. • Keep the liftgate closed when driving your vehicle to prevent carbon monoxide and other poisonous ex- haust gases from entering the vehicle.
Page 311 CAUTION! Damage to the fuel system or emission control sys- tem could result from using an improper fuel cap (gas cap). A poorly fitting cap could let impurities into the fuel system. Also, a poorly fitting after- market cap can cause the MIL (Malfunction Indicator Light) to illuminate, due to fuel vapors escaping from the system.
Page 312: Loose Fuel Filler Cap Message
312 STARTING AND OPERATING NOTE: Tighten the gas cap about 1/4 turn until you hear one click. This is an indication that cap is properly tightened. If the gas cap is not tighten properly, the Malfunction Indicator Light will come on. Be sure the gas cap is tightened every time the vehicle is refueled.
Page 313: Vehicle Loading
WARNING! • Never add fuel when the engine is running. • Never have any smoking materials lit in or near the vehicle when the fuel cap is removed or the tank filled. VEHICLE LOADING Certification Label As required by National Highway Traffic Safety Admin- istration Regulations, your vehicle has a certification label affixed to the driver’s side door or pillar.
Page 314 314 STARTING AND OPERATING Each axle GAWR is determined by the components in the system with the lowest load carrying capacity (axle, springs, tires, or wheels). Heavier axles or suspension components sometimes specified by purchasers for in- creased durability does not necessarily increase the vehi- cle’s GVWR.
Page 315: Trailer Towing
or rear axles has been exceeded but the total load is within the specified GVWR. If so, weight must be shifted from front to rear or rear to front as appropriate until the specified weight limitations are met. Store the heavier items down low and be sure that the weight is distributed equally.
Page 316 316 STARTING AND OPERATING Gross Trailer Weight (GTW) The gross trailer weight (GTW) is the weight of the trailer plus the weight of all cargo, consumables and equipment (permanent or temporary) loaded in or on the trailer in its loaded and ready for operation condition. The recom- mended way to measure GTW is to put your fully loaded trailer on a vehicle scale.
Page 317 Tongue Weight (TW) The downward force exerted on the hitch ball by the trailer. In most cases it should not be less than 10% or more than 15% of the trailer load. You must consider this as part of the load on your vehicle. Frontal Area The maximum height and maximum width of the front of a trailer.
Page 318 318 STARTING AND OPERATING WARNING! An improperly adjusted Weight Distributing Hitch system may reduce handling, stability, braking per- formance, and could result in an accident. Weight Distributing Systems may not be compatible with Surge Brake Couplers. Consult with your hitch and trailer manufacturer or a reputable Recreational Vehicle dealer for additional information.
Page 319: Trailer Hitch Classification
Improper Adjustment of Weight Distributing System Trailer Hitch Classification Your vehicle is capable of towing trailers up to 2,000 lbs (907 kg) without added equipment or alterations to the standard equipment. Your vehicle may be factory equipped for safe towing of trailers weighing over 2,000 lbs (907 kg) with the optional Trailer Tow Prep Package.
Page 320: Trailer Towing Weights (Maximum Trailer Weight Ratings)
320 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/ Model Transmission 3.7L/6-Speed Manual 3.7L/6-Speed Manual 3.7L/ Automatic 3.7L/ Automatic 3.7L/ Automatic w/ Cooler 3.7L/ Automatic w/Cooler...
Page 321 4.0L/ 7,150 lbs (3 243 kg) Automatic 4.0L/ 7,400 lbs ( 3 356 kg) Automatic 4.0L/ 9,850 lbs (4 468 kg) Automatic w/ Cooler 4.0L/ 10,100 lbs (4 581 kg) Automatic w/ Cooler Refer to local laws for maximum trailer towing speeds. NOTE: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed the weight referenced on the Tire...
Page 322 322 STARTING AND OPERATING When Towing Trailers with Gross Trailer Weight (GTW) between 3,500 Lbs (1 588 kg) and 5,000 Lbs (2 268 kg) The following chart provides maximum trailer weight ratings towable for the following engine/transmission combinations, ONLY if using a weight distributing hitch. Engine/ Model Transmission...
Page 323: Trailer And Tongue Weight
NOTE: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed the weight referenced on the Tire and Loading Information placard. Refer to the Tire– Safety Information section in this manual. Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer.
Page 324: Towing Requirements
324 STARTING AND OPERATING NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory- installed options, or dealer-installed options, must be con- sidered as part of the total load on your vehicle. Refer to the Tire and Loading Information placard in the Tire Safety Information section of this manual for the maximum com- bined weight of occupants and cargo for your vehicle.
Page 325 • When hauling cargo or towing a trailer, do not over- load your vehicle or trailer. Overloading can cause a loss of control, poor performance or damage to brakes, axle, engine, transmission, steering, suspension, chas- sis structure or tires. • Safety chains must always be used between your vehicle and trailer.
Page 326 326 STARTING AND OPERATING − Also, check the trailer tires for proper tire inflation pressures before trailer usage. − Check for signs of tire wear or visible tire damage before towing a trailer. Refer to the Tires–General Information section of this manual on Tread Wear Indicators for the proper inspection procedure.
Page 327 WARNING! Do not connect trailer brakes to your vehicle’s hy- draulic brake lines. It can overload your brake sys- tem and cause it to fail. You might not have brakes when you need them and could have an accident. Towing any trailer will increase your stopping dis- tance.
Page 328 328 STARTING AND OPERATING The electrical connections are all complete to the vehicle but you must mate the harness to a trailer connector. Refer to the following illustrations. 7- Pin Connector 4 - Pin Connector...
Page 329: Towing Tips
Towing Tips Before setting out on a trip, practice turning, stopping and backing the trailer in an area away from heavy traffic. If using a manual transmission vehicle for trailer towing, all starts must be in FIRST gear to avoid excessive clutch slippage.
Page 330: Recreational Towing (Behind Motorhome, Etc.)
330 STARTING AND OPERATING − Use speed control in flat terrain and with light loads to maximize fuel efficiency. Towing Tips — Cooling System To reduce potential for engine and transmission over- heating, take the following actions: − City Driving When stopped for short periods of time, put transmission in neutral and increase engine idle speed.
Page 331: Towing - 4Wd Or All-Wheel Drive Models
Towing — 4WD or All-Wheel Drive Models CAUTION! Front or rear wheel lifts should not be used. Internal damage to the transmission or transfer case will occur if a front or rear wheel lift is used when recreational towing. STARTING AND OPERATING 331 Recreational towing (all four wheels on the ground) Recreational towing is NOT allowed.
Page 333: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flashers ....334 If Your Engine Overheats ....335 Jacking And Tire Changing .
Page 334: Hazard Warning Flashers
334 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHERS Your vehicle’s hazard warning flasher is an emergency warning system. When you activate it, all front and rear directional signals will flash intermittently. Use it when your vehicle is disabled on or near the road. It warns other drivers to steer clear of you and your vehicle.
Page 335: If Your Engine Overheats
IF YOUR ENGINE OVERHEATS In any of the following situations, you can reduce the potential for overheating by taking the appropriate ac- tion. • On the highways — Slow down. • In city traffic — While stopped, put transmission in N (Neutral), but do not increase engine idle speed.
Page 336: Jacking And Tire Changing
336 WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING WARNING! • Getting under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never get any part of your body under a vehicle that is on a jack.
Page 337: Spare Tire Stowage
WHAT TO DO IN EMERGENCIES 337 Spare Tire Stowage The spare tire is stowed underneath the rear of the vehicle and is held in place by a cable winch mechanism. Spare Tire Removal Fit the jack handle extension over the drive nut. Use the Lug Wrench to rotate the nut counter clockwise until the spare is on the ground with enough slack in the cable to allow you to pull the tire out from under the vehicle.
Page 338: Preparations For Jacking
338 WHAT TO DO IN EMERGENCIES CAUTION! The winch mechanism is designed for use with the jack extension tube only. Use of an air wrench or other power tools is not recommended and they can damage the winch. When the spare is clear, tilt the retainer at the end of the cable, and pull it through the center of the wheel.
Page 339: Jacking Instructions
WHAT TO DO IN EMERGENCIES 339 Jacking Instructions 1. Remove spare tire. 2. Loosen (but do not remove) the wheel lug nuts by turning them to the left one turn while the wheel is still on the ground. 3. Remove jack and tools from mounting bracket. As- semble the tools by connecting the driver to the exten- sion, and then to the lug wrench.
Page 340 340 WHAT TO DO IN EMERGENCIES Rear Jacking Location 5. Raise the vehicle by turning the jack screw to the right. Raise the vehicle only until the tire just clears the surface and enough clearance is obtained to install the spare tire. Minimum tire lift provides maximum stability.
Page 341: Jump Starting
9. Finish tightening the lug nuts. Push down on the wrench while tightening for increased leverage. Alternate nuts until each nut has been tightened twice. Correct wheel nut tightness is 130 N·m (95 ft. lbs). If in doubt about the correct tightness, have them checked with a torque wrench by your authorized dealer or at a service station.
Page 342 342 WHAT TO DO IN EMERGENCIES 1. Wear eye protection and remove all metal jewelry such as watch bands or bracelets which might make an unintended electrical contact. 2. Park the booster vehicle within cable reach but with- out letting the vehicles touch. Set the parking brake, place the automatic transmission in PARK and turn the ignition OFF on both vehicles.
Page 343: Towing A Disabled Vehicle
WARNING! Do not connect the cable to the negative post of the discharge battery. The resulting electrical spark could cause the battery to explode. During cold weather when temperatures are below freezing point, electrolyte in a discharged battery may freeze. Do not attempt jump starting because the battery could rupture or explode.
Page 344: Two-Wheel Drive Vehicles
344 WHAT TO DO IN EMERGENCIES NOTE: Transmission must be in “N” (Neutral) under any towing configuration. Two-Wheel Drive Vehicles Front Wheels Raised The speed must not exceed 30 mph (50 km/h) and the distance must not exceed 15 miles (25 km). This vehicle may be towed with the transmission in “N”, the ignition key in the LOCK position, the front wheels raised, and the rear wheels on the ground.
Page 345 MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment – 3.7L ....348 Engine Compartment – 4.0L ....349 Onboard Diagnostic System —...
Page 346 346 MAINTAINING YOUR VEHICLE Power Steering Fluid Check ....363 Driveline And Steering Component Lubrication ......364 Body Lubrication .
Page 347 Center High Mounted Stop Light (CHMSL) . . . 393 Fluid Capacities ......394 Fluids, Lubricants And Genuine Parts ..395 MAINTAINING YOUR VEHICLE 347 Engine .
Page 348: Engine Compartment - 3.7L
348 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT – 3.7L...
Page 349: Engine Compartment - 4.0L
MAINTAINING YOUR VEHICLE 349 ENGINE COMPARTMENT – 4.0L...
Page 350: Onboard Diagnostic System - Obd Ii
350 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 351: Loose Fuel Filler Cap Message
Loose Fuel Filler Cap Message After fuel is added, the vehicle diagnostic system can determine if the fuel filler cap is possibly loose, improp- erly installed, or damaged. A loose fuel filler cap message will be displayed in the instrument cluster. Tighten the gas cap until a clicking sound is heard.
Page 352 352 MAINTAINING YOUR VEHICLE Your vehicle has a simple ignition key actuated test, which you can use prior to going to the test station. To check if your vehicle’s OBD system is ready, you must do the following: 1. Insert your ignition key into the ignition switch. 2.
Page 353: Replacement Parts
Regardless of whether your vehicle’s OBD system is ready or not ready, if the MIL symbol is illuminated during normal vehicle operation, you should have your vehicle serviced before going to the I/M station. The I/M station can fail your vehicle because the MIL symbol is on with the engine running.
Page 354: Maintenance Procedures
354 MAINTAINING YOUR VEHICLE MAINTENANCE PROCEDURES The pages that follow contain the required maintenance services determined by the engineers who designed your vehicle. Besides the maintenance items for which there are fixed maintenance intervals, there are other items that should operate satisfactorily without periodic maintenance.
Page 355 CAUTION! Overfilling or underfilling the crankcase will cause aeration or loss of oil pressure. This could damage your engine. Change Engine Oil Road conditions as well as your kind of driving affect the interval at which your oil should be changed. Check the following to determine if any apply to you: •...
Page 356 356 MAINTAINING YOUR VEHICLE Engine Oil Selection For best performance and maximum protection for all engines under all types of operating conditions, the manufacturer recommends engine oils that are API Cer- tified and meet the requirements of DaimlerChrysler Material Standard MS-6395. American Petroleum Institute (API) Engine Oil Identification Symbol This symbol means that the oil has...
Page 357 SAE 10W-30 engine oil is preferred. SAE 5W-30 engine oil is allowed during cold weather only to improve cold weather starting. Lubricants which do not have both, the engine oil certi- fication mark and the correct SAE viscosity grade num- ber should not be used.
Page 358: Drive Belts - Check Condition And Tension
358 MAINTAINING YOUR VEHICLE Engine Oil Filter Selection All of the manufacturer’s engines have a full-flow type disposable oil filter. Use a filter of this type for replace- ment. The quality of replacement filters varies consider- ably. Only high quality filters should be used to assure most efficient service.
Page 359: Catalytic Converter
Catalytic Converter The catalytic converter requires the use of unleaded fuel only. Leaded gasoline will destroy the effectiveness of the converter as an emission control device. Under normal operating conditions, the catalytic con- verter will not require maintenance. However, it is im- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst damage.
Page 360 360 MAINTAINING YOUR VEHICLE WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming into contact with your exhaust system. Do not park or operate your vehicle in areas where your exhaust system can contact anything that can burn.
Page 361: Crankcase Emission Control System
Crankcase Emission Control System Proper operation of this system depends on freedom from sticking or plugging due to deposits. As vehicle mileage builds up, the PCV valve and passages may accumulate deposits. If a valve is not working properly, replace it with a new valve. DO NOT ATTEMPT TO CLEAN THE OLD PCV VALVE! Check ventilation hose for indication of damage or plugging deposits.
Page 362: Maintenance-Free Battery
362 MAINTAINING YOUR VEHICLE Maintenance-Free Battery Your vehicle is equipped with a maintenance-free battery. You will never have to add water, nor is periodic main- tenance required. WARNING! Battery posts, terminals, and related accessories con- tain lead and lead compounds. Always wash hands after handling the battery.
Page 363: Maintaining Your Vehicle 363
WARNING! • Use only refrigerants and compressor lubricants approved by the manufacturer for your air condi- tioning system. Some unapproved refrigerants are flammable and can explode, injuring you. Other unapproved refrigerants or lubricants can cause the system to fail, requiring costly repairs. Refer to Section 3 of the Warranty Information Book for additional warranty information.
Page 364: Driveline And Steering Component Lubrication
364 MAINTAINING YOUR VEHICLE WARNING! Fluid level should be checked on a level surface with the engine off to prevent injury from moving parts, and to insure accurate fluid level reading. Do not overfill. Use only the manufacturer’s recommended fluid. If necessary, add fluid to restore to the proper indicated level.
Page 365: Windshield Wiper Blades
amount of a high quality lubricant such as Mopar Lock Cylinder Lubricant directly into the lock cylinder. Windshield Wiper Blades Clean the rubber edges of the wiper blades and the windshield periodically with a sponge or soft cloth and a mild non-abrasive cleaner.
Page 366: Exhaust System
366 MAINTAINING YOUR VEHICLE Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system. If you notice a change in the sound of the exhaust system; or if the exhaust fumes can be detected inside the vehicle; or when the underside or rear of the vehicle is damaged;...
Page 367 garden hose vertically down the face of the A/C con- denser (if equipped) or the back of the radiator core. Check the engine cooling system hoses for brittle rubber, cracking, tears, cuts, and tightness of the connection at the coolant recovery bottle and radiator. Inspect the entire system for leaks.
Page 368 368 MAINTAINING YOUR VEHICLE CAUTION! • Mixing of antifreeze/coolant other than the speci- fied HOAT antifreeze/coolant may result in de- creased corrosion protection and engine damage. If a non-HOAT antifreeze/coolant is introduced into the cooling system in an emergency, it should be replaced with the specified antifreeze/coolant as soon as possible.
Page 369 Use only high purity water such as distilled or deionized water when mixing the water/antifreeze (coolant) solu- tion. The use of lower quality water will reduce the amount of corrosion protection in the engine cooling system. Please note that it is the owner’s responsibility to main- tain the proper level of protection against freezing ac- cording to the temperatures occurring in the area where the vehicle is operated.
Page 370 370 MAINTAINING YOUR VEHICLE children, do not store ethylene glycol based antifreeze/ coolant in open containers or allow it to remain in puddles on the ground. If ingested by a child, contact a physician immediately. Clean up any ground spills im- mediately.
Page 371: Hoses And Vacuum/Vapor Harnesses
• Check antifreeze/coolant freeze point in the radiator and in the coolant recovery bottle. If antifreeze/ coolant needs to be added, contents of coolant recov- ery bottle must also be protected against freezing. • If frequent antifreeze/coolant additions are required, or if the level in the recovery bottle does not drop when the engine cools, the cooling system should be pressure tested for leaks.
Page 372: Brake System
372 MAINTAINING YOUR VEHICLE are present. Components should be replaced immedi- ately if there is any evidence of degradation that could cause failure. Brake System In order to assure brake system performance, all brake system components should be inspected periodically. Refer to the appropriate “Maintenance Schedule”...
Page 373 WARNING! Worn brake hoses can burst and cause brake failure. You could have an accident. If you see any signs of cracking, scuffing, or worn spots, have the brake hoses replaced immediately. Brake Master Cylinder The fluid level in the master cylinder should be checked when performing under hood services, or immediately if the BRAKE warning light shows system failure Be sure to clean the top of the master cylinder area before...
Page 374: Automatic Transmission
374 MAINTAINING YOUR VEHICLE Use only brake fluid that has been in a tightly closed container to avoid contamination from foreign matter. Do not allow petroleum base fluid to contaminate the brake fluid as seal damage will result. Automatic Transmission Selection of Lubricant It is important that the proper lubricant is used in the transmission to assure optimum transmission perfor-...
Page 375: Hydraulic Clutch Fluid - Manual
Fluid Level Check — W5A580 (4.0L Engine) Your vehicle is equipped with a capped dipstick tube, it is sealed and should not be tampered with. Your autho- rized dealer has the proper tools to ensure that the fluid level is set properly. Special Additives The manufacturer strongly recommends against the ad- dition of any additives to the transmission.
Page 376: Transfer Case
376 MAINTAINING YOUR VEHICLE Transfer Case Fluid Level Check The fluid level should be to the bottom edge of the fill hole (A) when the vehicle is in a level position. Adding Fluid Fluid should be added only at filler hole until fluid begins to run out of the hole.
Page 377: Front/Rear Axle Fluid
Front/Rear Axle Fluid Fluid Level Check Lubricant should be at bottom edge of the oil fill hole. Adding Fluid Add lubricant only at the fill hole and only to the level specified above. Selection of Lubricant Use only manufacturer’s recommended fluid, refer to Fluids, Lubricants, and Genuine Parts for correct fluid type.
Page 378 378 MAINTAINING YOUR VEHICLE Washing • Wash your vehicle regularly. Always wash your ve- hicle in the shade using Mopar Car Wash or a mild car wash soap, and rinse the panels completely with clear water. • If insects, tar, or other similar deposits have accumu- lated on your vehicle, use Mopar Super Kleen Bug and Tar Remover to remove.
Page 379 • If you detect any stone chips or scratches in the paint, touch them up immediately. The cost of such repairs is considered the responsibility of the owner. • If your vehicle is damaged due to an accident or similar cause which destroys the paint and protective coating have your vehicle repaired as soon as possible.
Page 380 380 MAINTAINING YOUR VEHICLE • For tough stains, apply Mopar Total Clean or a mild soap solution to a clean, damp cloth and remove stain. Use a fresh, damp towel to remove soap residue. • For grease stains, apply Mopar Cleaner to a clean, damp cloth and remove stain.
Page 381: Fuses (Integrated Power Module)
Cleaning Plastic Instrument Cluster Lenses The lenses in front of the instruments in this vehicle are molded in clear plastic. When cleaning the lenses, care must be taken to avoid scratching the plastic. 1. Clean with a wet soft rag. A mild soap solution may be used, but do not use high alcohol content or abrasive cleaners.
Page 382 382 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 40 Amp Green 30 Amp Pink 40 Amp Green 25 Amp Natural 25 Amp Natural 40 Amp Green 30 Amp Pink 40 Amp Green Description Cavity Cartridge Power Folding Seat Transfer Case/Pwr Liftgate Module Rear Door Module (RR DOOR NODE)
Page 383 Cavity Cartridge Mini Fuse Fuse 20 Amp Powertrain Control Yellow Module (PCM) Trans Range 60 Amp Radiator Fan Yellow 30 Amp Front Wiper LO/HI Pink 20 Amp Front/Rear Washer Yellow 25 Amp Sunroof Module Natural 15 Amp Center High Mounted Blue Stop Light (CHMSL)/ Brake Switch...
Page 384 384 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 20 Amp Yellow 10 Amp Description Cavity Cartridge Ignition Off Draw — Vehicle Entertainment System (IOD-VES), Satellite Digital Audio Receiver (SDARS), DVD, Hands Free Module (HFM), RA- DIO, Antenna (ANT), Universal Garage Door Opener (UGDO), Vanity Lamp (VANITY LP)
Page 385 Cavity Cartridge Mini Fuse Fuse 20 Amp COL MOD, IR SNS, Yellow Heater Ventilation, Air Conditioning/ Automatic Tempera- ture Control (HVAC/ ATC), Rear View Mirror (RR VW MIR), Cabin Compartment Node (CCN), Transfer Case Switch (T-CASE SW), RUN/ST, Multi- Function Control Switch (MULTIFTCN SW), Tire Pressure Monitor (TPM), Glow...
Page 386 386 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 15 Amp Blue 20 Amp Yellow 10 Amp 10 Amp 25 Amp Natural Description Cavity Cartridge Cabin Compartment Node Interior Light (CCN INT LIGHT), Switch Bank (SW BANK), Steering Con- trol Module (SCM) Auto Shut Down (ASD #3) Right Horn (RT...
Page 387 Cavity Cartridge Mini Fuse Fuse 10 Amp Occupant Classifica- tion Module (OCM) 15 Amp Rear Wiper Module Blue (RR WIPER MOD), Power Folding Mirror (PWR FOLD MIR) 20 Amp Back-Up Lamps (B/U Yellow LAMPS) 10 Amp Occupant Restraint Controller (ORC), TT EUROPE 10 Amp Next Generation Con-...
Page 388 388 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 10 Amp 25 Amp Natural Description • When installing the Integrated Power Module Anti-Lock Brake Sys- tem (ABS), Electronic cover, it is important to ensure the cover is prop- Stability Program erly positioned and fully latched.
Page 389: Replacement Light Bulbs
REPLACEMENT LIGHT BULBS LIGHT BULBS — Interior Dome Light ......WL212–2 Liftgate Lamp ......567 Overhead Console Lights .
Page 390: Left Front Turn Signal
390 MAINTAINING YOUR VEHICLE 5. Disconnect the electrical connector and replace the bulb. Left Front Turn Signal 1. Turn the steering wheel all the way to the right (full right lock). 2. Remove the door in the left wheel liner by twisting counter clockwise.
Page 391: Right Front Turn Signal
Right Front Turn Signal 1. Open the hood. 2. Reach behind the headlamp unit in the engine com- partment to access the turn signal bulb. 3. Twist the bulb counter clockwise to remove. 4. Disconnect the electrical connector and replace the bulb.
Page 392: Rear Tail, Stop, Turn Signal, And Back-Up Lights
392 MAINTAINING YOUR VEHICLE CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with any oily surface, clean the bulb with rubbing alcohol. Rear Tail, Stop, Turn Signal, and Back-Up Lights 1.
Page 393: Center High Mounted Stop Light (Chmsl)
4. Remove the two screws attaching the backplate to the lamp assembly. 5. Pull the backplate straight back from the lamp hous- ing. 6. Disconnect the electrical connector. 7. Remove the bulb from the backplate. Center High Mounted Stop Light (CHMSL) 1.
Page 394: Fluid Capacities
394 MAINTAINING YOUR VEHICLE FLUID CAPACITIES Fuel (Approximate) Engine Oil with Filter 3.7 Liter Engine (SAE 5W-20, API Certified Engine Oil) 4.0 Liter Engine (SAE 10W-30, API Certified Engine Oil) Cooling System * 3.7 Liter Engine (Mopar Antifreeze/Engine Coolant 5 Year/ 100,000 Mile Formula) 4.0 Liter Engine (Mopar Antifreeze/Engine Coolant 5 Year/ 100,000 Mile Formula)
Page 395: Engine
FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Engine Coolant Engine Oil (3.7L Engine) Engine Oil (4.0L Engine) Engine Oil Filter Spark Plugs 3.7 Liter Spark Plugs 4.0 Liter Fuel Selection (3.7L Engines) Fuel Selection (4.0L Engines) Fluids, Lubricants and Genuine Parts Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or- ganic Additive Technology) or equivalent.
Page 396: Chassis
396 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transmission Manual Transmission Transfer Case Front Axle Rear Axle Brake Master Cylinder/Manual Transmission Clutch System Power Steering Reservoir Fluids, Lubricants and Genuine Parts. Mopar ATF+4, Automatic Transmission Fluid. Mopar Manual Transmission Lubricant or equivalent (meeting the re- quirements of DaimlerChrysler Material Standard MS-9224) Mopar ATF+4, Automatic Transmission Fluid.
Page 397 MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..398 Maintenance Schedule ....398 Required Maintenance Intervals ... 401...
Page 398 398 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The “Scheduled” maintenance services, listed in bold type must be done at the times or mileages specified to assure the continued proper functioning of the emission control system. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
Page 399 NOTE: • The oil change indicator message will not monitor the time since the last oil change. Change your vehicles oil if it has been 6 months since your last oil change even if the oil change indicator message is NOT illumi- nated.
Page 400 400 MAINTENANCE SCHEDULES Once a Month • Check tire pressure and look for unusual wear or damage. • Inspect the battery and clean and tighten the terminals as required. • Check the fluid levels of coolant reservoir, brake master cylinder, power steering and transmission and add as needed.
Page 401 Required Maintenance Intervals Maintenance Items Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter, replace if necessary. Inspect the brake linings, replace if necessary. Inspect the front &...
Page 402 402 MAINTENANCE SCHEDULES Maintenance Items Check the PCV valve, replace if necessary. Change the manual transmission fluid if using your vehicle for any of the following: trailer towing, snow plowing, heavy loading, taxi, police, delivery service (commercial service), off-road, desert operation or more then 50% of your driving is at sustained high speeds during hot weather, above 90°F (32°C).
Page 403 Maintenance Items Flush and replace the engine coolant. Replace the spark plugs (4.0L Only). Replace the timing belt (4.0L Only). Change the automatic transmission fluid & filter. Replace accessory drive belt(s) (3.7L and 4.0L). WARNING! You can be badly injured working on or around a motor vehicle.
Page 405: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......406 Prepare For The Appointment .
Page 406: Suggestions For Obtaining Service For Your Vehicle
We want you to be happy with our products and services. Warranty service must be done by an authorized Chrysler, Dodge, or Jeep dealer. We strongly recommend that you take your vehicle to your selling dealer. They know you and your vehicle best, and are most concerned that you get prompt and high quality service.
Page 407 technicians, special tools, and the latest information to assure your vehicle is fixed correctly and in a timely manner. This is why you should always talk to your dealer’s service manager first. Most matters can be resolved with this process. •...
Page 408 408 IF YOU NEED CONSUMER ASSISTANCE Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its Customer Center. Any hearing or speech impaired customer who has access to a TDD or a conventional teletypewriter (TTY) in the United States can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 409: Warranty Information (U.s. Vehicles Only)
WARNING! Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain prod- ucts of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 410: In Canada
410 IF YOU NEED CONSUMER ASSISTANCE To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1–888–327–4236 (TTY: 1–800–424– 9153), or go to http://www.safercar.gov; or write to: Administra- tor, NHTSA, 400 Seventh Street, SW., Washington, DC 20590.
Page 411 • Diagnostic Procedure Manuals. Filled with diagrams, charts and detailed illustrations, these practical manuals make it easy for students and technicians to find and fix problems on computer- controlled vehicle systems and features. They show exactly how to find and correct problems the first time, using step-by-step troubleshooting and driveability procedures, proven diagnostic tests and a complete list of all tools and equipment.
Page 412: Department Of Transportation Uniform Tire Quality Grades
412 IF YOU NEED CONSUMER ASSISTANCE DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following describes the tire grading categories estab- lished by the National highway Traffic Safety Adminis- tration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your car.
Page 413: Temperature Grades
Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure.
Page 415 INDEX...
Page 416 416 INDEX About Your Brakes ..... . . 272 ABS (Anti-Lock Brake System) ... . 173,274 Adding Fuel .
Page 417 Autostick ......262 Auxiliary Electrical Outlet (Power Outlet) ..147 Auxiliary Power Outlet .
Page 418 418 INDEX Light ....... 153 Cargo Light ......153 Cargo Load Floor .
Page 419 Drain, Flush, and Refill ....367 Inspection ......366 Points to Remember .
Page 420 420 INDEX Electronic Roll Mitigation ....133 Electronic Stability Program ....134 Traction Control System .
Page 421 Exhaust System ......366 Exterior Finish Care ..... . 378 Fabric Care .
Page 422 422 INDEX Octane Rating ..... . 306,395 Requirements ......394 Tank Capacity .
Page 423 Hitches Trailer Towing ......319 Holder, Coin ......152 Holder, Cup .
Page 424 424 INDEX Lane Change and Turn Signals ....171 Lap/Shoulder Belts ..... . . 40 LATCH (Lower Anchors and Tether for CHildren) .
Page 425 Side Marker ......392 Tire Pressure Monitoring (TPMS) ... 296 Traction Control .
Page 426 426 INDEX Vanity ....... 86 Modifications/Alterations, Vehicle ... . . 8 Monitor, Tire Pressure System .
Page 427 PCV Valve ......361 Personal Settings ......193 Pets .
Page 428 428 INDEX Refrigerant ......363 Release, Hood ......121 Reminder, Lights On .
Page 429 Shoulder Belt Anchorage ....44 Seats ....... . . 113 Adjustment .
Page 430 430 INDEX Cold Weather ......246 Emergency (Jump Starting) ....341 Engine Block Heater .
Page 431 General Information ....287 High Speed ......290 Inflation Pressures .
Page 432 432 INDEX Transmission ......255,260 Automatic ......255,260 Fluid .
Page 433 Warranty Information ..... 409 Washer, Adding Fluid ..... 159 Washers, Windshield .
Page 434 INTRODUCTION INTRODUCTION ROLLOVER WARNING HOW TO USE THIS MANUAL WARNINGS AND CAUTIONS VEHICLE IDENTIFICATION NUMBER VEHICLE MODIFICATIONS/ALTERATIONS THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Ignition Key RemovalKey-In-Ignition ReminderSENTRY KEY Replacement KeysCustomer Key ProgrammingGeneral InformationSTEERING WHEEL LOCK - IF EQUIPPED To Manually Lock the Steering WheelTo Release the Steering Wheel Lock SECURITY ALARM SYSTEM - IF EQUIPPED To Arm the SystemTo Disarm the SystemILLUMINATED ENTRY REMOTE KEYLESS ENTRY To Unlock the Doors and LiftgateTo Lock the Doors and LiftgateUsing the Panic AlarmProgramming Additional TransmittersBattery ReplacementGeneral InformationREMOTE STARTING SYSTEM - IF EQUIPPED DOOR LOCKS Manual Door LocksPower Door LocksAutomatic Door LocksAutomatic Unlock Doors on ExitChild-Protection Door Lock System (Rear Doors)WINDOWS Power WindowsWind BuffetingLIFTGATE OCCUPANT RESTRAINTS Lap/Shoulder BeltsLap/Shoulder Belt Operating InstructionsAdjustable Upper Shoulder Belt AnchorageAutomatic Locking Mode - If EquippedEnergy Management FeatureSeat Belt PretensionersEnhanced Seat Belt Use...

This manual is also suitable for:

2008 nitro 2011 dodge nitro

Dodge 2008 KA Nitro Owner's Manual

Introduction 1

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Instrument Panel and Controls

Starting and Operating

306 Starting and Operating

Starting and Operating

What to Do in Emergencies

Quick Links

INTRODUCTION

Chapters

Related Manuals for Dodge 2008 KA Nitro

Summary of Contents for Dodge 2008 KA Nitro
