16 Administering the security gateway

Navigating the user interface

To connect to the SGMI remotely
1
2
Navigating the user interface
Once you familiarize yourself with the basic structure of the user interface, you can create configurations,
view security gateway status, and access system event logs. The SGMI, shown in
following controls:
Online help is available for each tab when you click the blue circle with a question mark in the top right
corner of each screen.
The main menu items are located in the left pane of the window at all times.
Figure 2-1
Note: The wireless features do not appear in the SGMI until a compatible Symantec Gateway Security
WLAN (Wireless Local Area Network) Access Point option is properly installed and configured. See the
Symantec Gateway Security 300/400 Series Wireless Implementation Guide for more information.
Browse to the appliance's WAN port IP address followed by port 8088, for example:
http://206.7.7.14:8088
On your keyboard, press Enter.
The SGMI window displays (see
Wizard runs automatically.
Left pane main menu options
Right pane menu tabs
Right pane content
Command buttons (bottom)
Online Help button
SGMI controls
Left pane main menu options
Command buttons
Figure 2-1). If this is the first time you have connected, the Setup
Right pane menu tabs
Right pane content
Figure 2-1, includes the
Online help button
