- Page 1 GAS HOB MGH 701 Please read this instruction booklet before using the appliance...
-
Page 2: Important Safety Information
Important Safety Information You MUST read hese warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 08705 950950 Installation This appliance must be installed and serviced by a Never leave the hob unattended when cooking with competent person as stated in the Gas Safety oil and fats. -
Page 3: Table Of Contents
Contents For the Installer For the User Instructions for the Installer Important Safety Information Important safety requirements Description of the Hob Installation Operation Building In Maintenance and Cleaning Electrical connections Something Not Working? Wiring Diagram Service and Spare Parts Fault Finding Guarantee Conditions Commissioning European Guarantee... -
Page 4: Operation
Operation If you use a saucepan which is smaller than the recommended size, the flame will spread Hob burners beyond the bottom of the vessel, causing the handle to overheat. To light a burner: Take care when frying food in hot oil or fat, as push in the relevant control knob and turn it the overheated splashes could easily ignite. -
Page 5: The Burners
The Burners The burner caps and crowns can be removed for cleaning. Wash the burner caps and crowns using hot soapy water, and remove marks with a mild paste cleaner. A well moistened soap impregnated steel wool pad can be used with caution, if the marks are particularly difficult to remove. -
Page 6: Instructions For The Installer
Instructions for the Installer Engineers technical data OVERALL DIMENSIONS Rear Left Burner (rapid) Heat Input 2.8 kW Natural Gas Width: 680 mm. (10239 BTU/HR) Depth: 510 mm. 2.8 kW L.P.G. (9556 BTU/HR) CUT OUT DIMENSIONS Front Left Burner (auxiliary) Heat Input 1.0 kW (3413 BTU/HR) Width: 560 mm. -
Page 7: Important Safety Requirements
Important safety requirements This hob must be installed in accordance with the Gas FITTING THE GAS HOB WITHOUT A COOKER HOOD ABOVE Safety (Installation and Use) Regulations (Current Edition) and the IEE Wiring Regulations (Current Edition). Provision for ventilation Detailed recommendations are contained in the following 700 mm British Standards Codes Of Practice: B.S. -
Page 8: Installation
Installation IMPORTANT: This hob must be installed by a competent person to the relevant Gas Standards. Any gas installation must be carried out by a competent person. The manufacturer will not accept liability, should the above instructions or any of the other safety instructions incorporated in this book be ignored. -
Page 9: Fitting The Hob Into The Worktop
Building In Building over a cupboard or Building over a kitchen unit with drawer door Proper arrangements must be taken in designing the If the hob is to be installed above a cupboard or drawer it furniture unit, in order to avoid any contact with the bottom will be necessary to fit a heat resistant board below the of the hob which can be heated when it is operated. -
Page 10: Electrical Connections
Seal Electrical connections Permanent Connection Any electrical work required to install this hob In the case of a permanent connection, it is necessary should be carried out by a qualified electrician or that you install a double pole switch between the hob competent person, in accordance with the current and the electricity supply (mains), with a minimum gap regulations. -
Page 11: Wiring Diagram
Wiring Diagram 1. IGNITOR SWITCHES 2. IGNITOR UNIT Fault Finding Preliminary Electrical Systems PLUG (with cover SOCKET Check removed) (face view) Earth Wire Brown Blue Green/Yellow Green Yellow START Isolate appliance Neutral Wire and carry out: Blue A: Earth Continuity check. - Page 12 Ignition System / Gas Ignition Check gas supply at Ignitor does not spark burner Check plug top fuse Light burner manually replace if necessary Check polarity and Check by pass simmer earth continuity of adjusted supply point Check position of the Check earth continuity electrode of appliance...
-
Page 13: Commissioning
Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. Turn the gas tap to the MAX position and ignite. Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times. -
Page 14: Service And Spare Parts
* Appliances found to be in use within a commercial or similar environment, plus those which are the subject to rental agreements. * Products of Moffat manufacture which are not marketed by Moffat. CUSTOMER CARE For general enquiries concerning your Moffat appliance... - Page 16 www.electrolux.com 35689-8802 07/06...
