INSTRUCTION BOOKLET
GB
GAS HOB MODEL
MGH 620
Please read this instruction booklet before using the appliance

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MGH 620 and is the answer not in the manual?

Questions and answers

Related Manuals for Moffat MGH 620

Summary of Contents for Moffat MGH 620

  • Page 1 All manuals and user guides at all-guides.com INSTRUCTION BOOKLET GAS HOB MODEL MGH 620 Please read this instruction booklet before using the appliance...

  • Page 2: Important Safety Information

    All manuals and user guides at all-guides.com Important Safety Information You MUST read these warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 0 8705 950950 Service Installation Environmental Information Child Safety Keep this instruction book for future reference and ensure it is passed on to any new owner.

  • Page 3: Description Of The Hob

    All manuals and user guides at all-guides.com Contents For the User For the Installer Description of the Hob 1. Hob Top 2. Rapid Burner 3. Semi-rapid Burners 4. Auxiliary Burner 5. Control knobs 6. Electric Ignition Push Button...

  • Page 4: Operation

    All manuals and user guides at all-guides.com Operation Hob Burners Burner minimum maximum diameter diameter Fig. 1 FO 0204 Take care when frying food in hot oil or fat, as the overheated splashes could easily ignite. Maintenance and Cleaning DISCONNECT The Hob Top...

  • Page 5: Pan Supports

    All manuals and user guides at all-guides.com Pan Supports Ignition candle The Burners Something Not Working? IMPORTANT: SYMPTOM SOLUTION In-guarantee customers should ensure that the above checks have been made as the engineer will make a charge if the fault is not a mechanical or electrical breakdown.

  • Page 6: Service And Spare Parts

    All manuals and user guides at all-guides.com Service and Spare Parts Customer Care Department 0870 5 929929 MOFFAT * calls to this number may be recorded for training purposes. Guarantee Conditions Moffat Guarantee conditions European Guarantee 8.30am and 5.30pm premium Exclusions This guarantee does not cover:...
  • Page 7 All manuals and user guides at all-guides.com 08705 929 929 To contact your local Service Force Centre telephone NORTH EAST CHANNEL ISLANDS ISLE OF LEWIS GATESHEAD GUERNSEY KELSO JERSEY GRIMSBY HULL ORKNEY SCOTLAND LEEDS PERTH ABERDEEN (OWN SALES) AUCHTERMUCHTY NEWTON AYCLIFFE SHETLAND BLANTYRE (OWN SALES)
  • Page 8 All manuals and user guides at all-guides.com 08705 929 929 To contact your local Service Force Centre telephone LONDON & EAST ANGLIA SOUTH EAST MIDLANDS BECKENHAM ASHFORD BIRMINGHAM CHELMSFORD FLEET BOURNE BRIDGNORTH COLINDALE HAYWARDS HEATH GLOUCESTER ELTHAM TONBRIDGE HEREFORD ENFIELD HIGHAM FERRERS SOUTH WEST GRAVESEND...

  • Page 9: Instructions For The Installer

    All manuals and user guides at all-guides.com Instructions for the Installer Engineers technical data Overall dimensions Ignition HT Spark Rear Left Burner (semi-rapid) Cut out dimensions Front Left Burner (rapid) Rear Right Burner (semi-rapid) Supply connections Gas: Front Right Burner (auxiliary) Electric: BURNER RAPID...

  • Page 10: Installation

    All manuals and user guides at all-guides.com Important safety requirements FITTING THE GAS HOB WITHOUT A COOKER HOOD ABOVE 700 mm 400 mm 400 mm FO 0812 FITTING THE GAS HOB WITH A COOKER HOOD ABOVE Location 650 mm 400 mm 400 mm FO 0813 Installation...
  • Page 11 All manuals and user guides at all-guides.com Gas Connection FO 0814 FO 0264 Rectangular cut-out size for hob Cut Out Size FO 2098 Building In ON/OFF SWITCH Building over a cupboard or drawer FLEX OUTLET FO 0763 Building over a kitchen unit with door ON/OFF SWITCH FLEX...

  • Page 12: Fitting The Hob Into The Worktop

    All manuals and user guides at all-guides.com Fitting the Hob into the worktop FO 0199 a) Sealing gasket Electrical connections A cut off plug inserted into a 13 amp socket is a serious safety (shock) hazard. Ensure that the cut off plug is disposed of safely. Permanent Connection THIS HOB MUST BE EARTHED.

  • Page 13: Wiring Diagram

    All manuals and user guides at all-guides.com Wiring Diagram 220/240 A. IGNITOR SWITCH B. IGNITOR UNIT Fault Finding Preliminary Electrical Systems SOCKET PLUG (with cover (face view) removed) Check Earth Wire Green/Yellow Blue Brown Green START Yellow Isolate appliance and carry out: A: Earth Continuity Neutral Wire Blue...

  • Page 14: Ignition System / Gas Ignition

    All manuals and user guides at all-guides.com Ignition System / Gas Ignition Check gas supply at Ignitor does not spark burner Check plug top fuse Light burner manually and replace if necessary Check polarity and Check by pass simmer earth continuity of adjusted supply point Check position of the...

  • Page 15: Conversion From Natural Gas To Lpg

    All manuals and user guides at all-guides.com Commissioning Procedure: Minimum adjustment screw Pressure Testing Conversion from Natural Gas to LPG To adjust the gas rate Method IMPORTANT...
  • Page 16 All manuals and user guides at all-guides.com CUSTOMER CARE Moffat © From the Electrolux Group. The world’s No.1 choice. The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
