remote configurations
The 3000 system has an in-key 2-button remote control and a 3-button
remote control. Two additional Merlin remote controls can be added.
ARM/DISARM/PANIC
ARM/DISARM/PANIC
4
IN-KEY 2-BUTTON REMOTE CONTROL
FRONT
LED
3-BUTTON REMOTE CONTROL
LED
© 2 0 0 5 d i re c t e d e l e c t ro n i c s , a l l r i g h t s re s e r v e d
REAR
ACCESSORY
ACCESSORY
SILENT ARM/DISARM
