Charcoal filters:
• If the model is not vented to the outside, the
air will be recirculated through disposable
charcoal filters that help remove smoke
and odors.
• The charcoal filters cannot be cleaned,
they must be replaced regularly (depending
on range hood usage).
• NOTE: Do not rinse or put charcoal filters
in a dishwasher.
• NOTE: Charcoal filters are not included
with the range hood. Please call Frigidaire
at 1.800.944.9044 to order this kit. When
calling our customer service center, also
have this range hood's model number
ready.
IMPORTANT
Clean the filter every month to prevent risk of fire.
Maintenance
• User servicing – Do not repair or replace
any part of the appliance unless specifically
recommended in the manual. All other servicing
should be referred to a qualified technician.

Light bulb replacement

• Switch the appliance off and disconnect the
power supply.
• In order to replace the light bulb (8), the metallic
anti-grease filter should be detached first.
• Pull the spring lock downward (fig.
• Rotate and pull one or both of the light bulbs from
the holders and replace with new light bulb(s) of
the same type (GU10, 20W, 120V~) (fig.
• Replace the metallic anti-grease filter and make
sure it locks in place.

Troubleshooting

Technical data

Power supply
Power consumption
Bulb type
Power cable type
Troubleshooting
Problem
Excessive
vibration.
Light on, but
fan does not
work.
Both light and
fan do not
work.
).
).
/
Suction
performance
is not good.

Environmental protection

: 120V~, 60Hz
: 520W
: 4 x 20W, 120V~
(type: GU10)
: 18AWG
(Amer. Wire Gauge)
300V~, 105˚C
Cause Solution
The appliance Take down
is not fixed the appliance
properly on the and check it is
brackets. properly fixed.
The fan blade
is damaged.
Switch off the
The fan motor
appliance.
is not fixed
Repair to be
tightly.
carried out by
The fan blade
qualified service
is jammed.
personnel only.
The motor is
damaged.
Replace with
Light bulb
a bulb with
broken.
correct rating.
Check the
Problem with
electrical
electrical
connection with
connection
an electrician.
Distance
Readjust the
between the
appliance and distance (see
the cooking fig.
place too
page 6).
large.
Clean
Metallic anti-
filters (see
grease filter is
Cleaning and
dirty.
maintenance).
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check
with your Local Authority or retailer for
recycling advice.
13
