Intended Use; Parts Supplied - Frigidaire Fhpc3660Ls Use And Care Manual

IMPORTANT
Save installation instructions
inspector's use.
The range hood must be connected with copper
wire only.
The range hood should be connected directly
to the fused disconnect (or circuit breaker) box
through metal electrical conduit.
Wire sizes must conform to the requirements of
the National Electrical Code ANSI/NFPA 70 – latest
edition", or CSA Standards C22.1-94, Canadian
Electrical Code Part 1 and C22.2 No.0-M91 – latest
edition** and all local codes and ordinances.
A U.L.- or C.S.A.-listed conduit connector must be
provided at each end of the power supply conduit (at
the range hood and at the junction box).
Copies of the standards listed may be obtained from:
* National Fire Protection Association Batterymarch
Park Quincy, Massachusetts 02269
** CSA International 8501 East Pleasant Valley Road
Cleveland, Ohio 44131-5575
Power requirement:
120V~, 60Hz, 15 or 20A branch circuit

Intended use

• Your range hood is intended for exhaust operation
only. This range hood is not recommended to be
used over indoor grills. Do not use it to exhaust
hazardous or explosive materials or vapors.

Parts supplied

No. Part
1
2
3
Intended use / Parts supplied
for electrical
Qty.
Range hood 1
Glass cover 1
1
Upper and lower
+
chimney
1
4
5
6
Recirculation kit
7
8
9
10
(15/64" x 2-3/4")
11 (dia. 23/32" x 1/4"
Washer (dia. 5/32"
12
x 15/32" x 3/64")
M15/64" x 3/16"
13
14
15 (dia. 1/2" x 1/4" x
16
17
Assembly template
18
Template
(stencilled)
19
20
Upper bracket 1
Lower bracket 1
Collar 1
(optional
accessories) 1
Elux code:
FHPRKT60LS
Bulb
20W, 120V~,
4
GU10 (pre-
assembled)
Bolt, rubber 4
washer, washer sets
Long screw
4
Washer
4
x 5/64")
8
4
nut
Span washer
(dia. 7/16" x 4
11/32" x 1/64")
Washer
4
3/64")
Allen key 1
10' extension
chimney kit
(optional
1
accessories)
Elux code:
FHP10X60LS
1
(stencilled)
Short screw
14
9/64" x 15/32"
Short screw
2
1/8" x 15/32"
5
