MIW-SURGE
MAX IN-WALL
™
M
IW-SURGE delivers safe, protected AC power to
flat panel displays, ceiling mounted video projec-
tors and powered sub-woofers. Discreetly hides
behind electronic equipment for a neat, clean,
code compliant and professional installation.
MODEL: MIW-SURGE
Elegant, nickel plated
steel faceplate with
brushed metal finish.
Signal Bay provides a wide variety of
optional installation solutions by using:
Decora
®
Adapters
*MIW modules sold separately
SURGE PROTECTION SYSTEM
Pass-Through Inserts
NEW OPTIMIZED DESIGN
Now improves ease of installation!
Ultra thin profile
of flat plug lets
equipment hang
less than one inch
from the wall.
Keystone 2-Port Adapter
C
US
152908
L612-PFP REV. A
(See side 2)
MIW Signal Line Modules*
L612-PFP REV. E
