Summary of Contents for Directed Audio D2400

Page 1 OWNER’S MANUAL D1200 models D2400...
Page 2: Table Of Contents
Directed Audio power amplifiers will TABLE OF CONTENTS Limited Two-year Consumer Warranty ......3 Features .
Page 3: Limited Two-Year Consumer Warranty
LIMITED TWO-YEAR CONSUMER WARRANTY Directed Electronics, Inc. promises to the original purchaser, to replace this product should it prove to be defective in workman- ship or material under normal use, for a period of two years from the date of purchase by the dealer as indicated by the date code marking of the product PROVIDED the product was installed by an...
Page 4: Features
FEATURES Super-efficient Class D PWM design runs much cooler than conventional amps. High-speed MOSFET switching power supply. High-current complimentary Class D MOSFET outputs stable into one ohm loads. Thermal, DC offset, reverse polarity, and short circuit protection with status LED. Master/slave function supports two amps bridged to one load.
Page 5: Vehicle Servicing Note
VEHICLE SERVICING NOTE P P r r i i o o r r t t o o s s e e r r v v i i c c i i n n g g your vehicle ensure that the alarm system is d d i i s s a a r r m m e e d d . Due to the amplifier’s anti-theft feature (if enabled), amplifier operation is disabled when the main power to the amplifier is...
Page 6 guide. Minimum wire gauge recom- mendations for the individual ampli- fiers are listed on the specification page. Always use the same gauge wire for the amplifier ground that you use for the power wire. Be sure to examine the battery ground cable of the vehicle, and if neces- sary, upgrade it by adding an addi- tional ground wire that is the same...
Page 7: Front Panel Connections/Controls
FRONT PANEL CONNECTIONS/CONTROLS 1. R R C C A A I I n n p p u u t t J J a a c c k k s s - - Accepts line level outputs from head units or signal processors at voltages between 150mV and 7.5 volts.
Page 9: Rear Panel Connections
The D1200 uses 2-30A fuses, and the D2400 uses 3-40A fuses. 2. ( ( + + ) ) 1 1 2 2 V V o o l l t t P P o o w w e e r r - Connect this...
Page 10: Esp Features And Controls
FIGURE 2—AMPLIFIER CONNECTIONS - REAR D1200 D2400 40A x 3 FUSE FEATURES AND CONTROLS ® ® These amplifiers incorporate an on-board Directed ESP ® Engine. In addition to allowing menu-driven parameter adjust- ment*, operate with security products from Directed Electronics to incorporate advanced ESP2 features.
Page 11 to the other. Bitwriter commands can control para- ® meters such as Turn on Delay, Fan Control, Input Gain adjustment, and also place the amplifier into a monitoring state for commands from an ESP2 equipped alarm. 1. T T u u r r n n - - O O n n D D e e l l a a y y - - 0.75, 1.00, 1.25, 1.75, 2.25, 2.75, or 3.25 seconds.
Page 12 If selected while the remote power is on, the amplifier will continue playing until the remote power is turned off. To Clear Valet Mode, Disable Valet mode on the alarm, then cycle the remote power line off then on again. The amplifier will power up normally after the Turn On Delay time has expired.
Page 13 unlit, but still indicates service codes or faults using the top light. 9. L L e e a a r r n n T T X X I I D D s s D D e e f f a a u u l l t t O O f f f f . . Before the unit will respond to Arm/Disarm/Valet Commands from the alarm system, it needs to establish communica-...
Page 14 The ESP Status indicator flashes to ® indicate the current operational mode. This can be used in conjunc- Power/Protection LED Green Solid Red Green Flashing Flashing Slowly Flashing Rapidly Slow Flash (50% duty cycle) Overvoltage Slow Flash (mostly off) Flashing Flashing Rapidly Flashing N N o o t t e e : Remember that the Directed ESP...
Page 15: Speaker Wiring Diagrams
Two subwoofer connection (top view) N N O O T T E E : : The dual + and -- sub-out terminals of the D600/D800/D1200/D2400 are paralleled internally and the combined load impedance should be taken into consideration when connecting multiple subwoofers.
Page 16: Combining Amplifiers
A very small adjustment may not cause any audible change in level. The Directed D1200/D2400 subwoofer amplifiers have the capability of connecting two or more amplifiers of the same power rating together in a master/slave combination for increased power with accurate level matching.
Page 17: Parallel Synced Gain Connections/Settings
PARALLEL SYNCED GAIN CONNECTIONS/SETTINGS Refer to figure 5 for wiring details. 1. I I n n p p u u t t S S i i g g n n a a l l - Connect these RCA jacks as described in the Front Panel Connection section of this guide.
Page 18 FIGURE 5—PARALLEL SYNC GAINED D1200/D2400 Subwoofer Wiring (top view) 1 1 8 8 MASTER SLAVE N N O O T T E E : : The dual + and -- sub-out terminals are paralleled internally and the combined load impedance should be taken into consideration when connecting multiple subwoofers.
Page 19: External Synced Bridged Connections/Settings
EXTERNAL SYNCED BRIDGED CONNECTIONS/SETTINGS 1. I I n n p p u u t t S S i i g g n n a a l l - Connect these RCA jacks as described in the Front Panel Connection section of this guide.
Page 21: Multiple Amplifier Combinations
MULTIPLE AMPLIFIER COMBINATIONS The Directed D1200/D2400 subwoofer amplifiers can also be used in multiples of the master/slave combinations allowing for unlimited expansion to a systems subwoofer section. To use multiples of amplifier combinations the following directions must be adhered to for best results.
Page 22: Crossover Settings And Gain Adjustment
CROSSOVER SETTINGS AND GAIN ADJUSTMENT Your Directed Audio power amplifier needs to be adjusted carefully to achieve maximum performance. These are some guidelines to follow when fine-tuning the amplifier. Because this amplifier is only designed for subwoofer applications, the low-pass crossover is active at all times.
Page 23: Led Tube Installation (Optional)
LED TUBE INSTALLATION (OPTIONAL) This Directed Audio amplifier has been designed with a custom heat sink that can accommodate two (optional—not supplied) VARAD LED tubes. 1. Before installing the LED tubes, remove and discard the mounting feet from the VARAD LED tubes.
Page 24: Cea Specifications
CEA SPECIFICATIONS D D 1 1 2 2 0 0 0 0 Power Output: 300 Watts RMS x 1 at 4 ohms and < 1% THD+N Signal to Noise Ratio: -60 dBA (reference 1 Watt into 4 ohms) Additional Power: 600 Watts RMS x 1 at 1 ohm and < 1% THD+N D D 2 2 4 4 0 0 0 0 Power Output: 400 Watts RMS x 1 at 4 ohms and <...
Page 25: Specifications
SPECIFICATIONS Maximum Watts RMS continuous Power RMS continuous Power Frequency Response Damping Factor Variable Low Pass Crossover 12dB slope Subsonic Filter Bass Boost Input Impedance Input Sensitivity Output Load Fusing Illuminated LED Driver External Fan Driver Pass Through RCA Jacks 1.
Page 26 Directed Electronics, Inc. The company behind this system is Directed Electronics, Inc. its inception, Directed has had one purpose, to provide customers with the finest Vista, California 92081 vehicle security, car stereo products, rear seat entertainment, and accessories avail- www.directed.com able.
