- Page 1 MOUNTING LOCATION DIAGRAMS Model: GSK-3 SPILL SWITCH Mounting location on an MG-1 4” – 9” barometric draft control GSK-3 SPILL SWITCH SPECIFICATION Switching Voltage Millivolts Or 24VAC Switch Open Temperature 180°F Normally Closed Switch Type Manual Reset...
- Page 2 LOCATION FOR FASTEST RESPONSE – OPTIONAL LOCATION LOCATION FOR SLOWER RESPONSE Refer to GSK-3 Instruction Sheet for Mounting and Wiring Information P/N 46263200 Rev A 01/01...
