Dacor Discovery EO127 Planning Manual

Document # PG01-001
• Observe all governing codes and ordinances during planning
and installation. Contact your local building department for
further information.
• This appliance must be installed in accordance with the
accompanying installation instructions.
Dedicated Circuit
Required
240 Vac, 4-wire*,
60Hz, 30 Amp.
* Two 120 Vac hot (L1 and L2), one neutral, one ground.
Model A
EO127
27"
MOH127
(68.6 cm)
MOV127
EO130
30"
MOH130
(76.2 cm)
MOV130
Specifications subject to change without notice.
EO, MOH, MOV
27 and 30 Inch Wide, Single,
Discovery™ Wall Ovens
WARninG
Total Approximate
Connected Load Shipping Weight
4.6 kW (19.5 Amp.) 240 lbs.
22 11/16"
(57.6 cm)
B C D
27 15/16" 23 3/8" 2 5/16"
(71.0 cm) (59.4 cm) (5.9 cm)
Product tolerances: ±1/16" (±1.6 mm), unless otherwise stated.
1 1/4"
(3.2 cm)
L
Control panel
front
Chassis notch
side view
E F
7 3/8" 6 3/8"
(18.7 cm) (16.2 cm)
PRODUCT DIMENSIONS
www.dacor.com
PLANNING
®
EO - Epicure MOH/MOV - Millennia
3 11/16"
3 5/16"
(9.4 cm) (8.4 cm)
1 1/4"
(3.2 cm)
HANDLE DIMENSIONS - SIDE VIEW
C
B
J
A
K
Top of
chassis
G H J
25 3/8"
(64.4 cm)
27 3/8" 9/16"
(69.5 cm) (1.4 cm)
28 3/8"
(72.0 cm)
Revised 10/01/11 Page 1/2
GUIDE
®
1 1/4"
(3.2 cm)
Top of
chassis
H
E
D
F
G
Utility
cutout
66" (167.6 cm)
Flexible conduit
K L
1" 1 7/8"
(2.5 cm) (4.6 cm)
1.1
Phone: (800) 793-0093
