EN ORIGINAL INSTRUCTIONS

IMPORTANT - These instructions are for your safety.

Please read through them thoroughly prior to handling

the product and retain them for future reference.

V11024_5063022567604_MAND2_2324

5063022567604_MNL_EN_V03.indd 1

XX/XX/24

Impala Ref: PRJ32348

NAME

EAN: 5063022567604

Page Size: A5

EN Electric lawn mower

1200 W, 32 cm

MCB1136LWM

5063022567604

MCB1137LWM

5063022567635

10/22/2024 2:13:34 PM

Need help?

Do you have a question about the MCB1136LWM and is the answer not in the manual?

Questions and answers

Summary of Contents for Mac allister MCB1136LWM

Page 1 NAME EN Electric lawn mower 1200 W, 32 cm EN ORIGINAL INSTRUCTIONS IMPORTANT - These instructions are for your safety. MCB1136LWM Please read through them thoroughly prior to handling 5063022567604 the product and retain them for future reference. MCB1137LWM 5063022567635 V11024_5063022567604_MAND2_2324 5063022567604_MNL_EN_V03.indd 1...
Page 2 EN Parts 04. x2 01. x1 02. x1 03. x1 05 . x2 06 . x2 07 . x2 EN You will need EN Contents Product description Safety Guarantee Preparation Assembly Functions & Settings Care and maintenance Declaration of conformity 5063022567604_MNL_EN_V03.indd 2 5063022567604_MNL_EN_V03.indd 2 10/22/2024 2:13:34 PM...
Page 3 EN Product description 1. Safety switch button 9. Motor housing 15. Grass catcher 2. Start lever 10. Lever for cutting height a. Carry handle adjustment 3. Grip handle b. Hatch 11. Front wheel (x2) 4. Upper handle bar c. Rubber clip* (x3) 12.
Page 4 EN Safety General Machine Safety Warnings WARNING! READ ALL SAFETY WARNINGS, INSTRUCTIONS, ILLUSTRATIONS AND SPECIFICATIONS PROVIDED WITH THIS MACHINE. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/OR SERIOUS INJURY. SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE.
Page 5 Do not operate the lawnmower in rain or wet conditions. • This may increase the risk of electric shock. • Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the machine. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
Page 6 If devices are provided for the connection of dust • extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards. • Do not let familiarity gained from frequent use of machines allow you to become complacent and ignore machine safety principles.
Page 7 Use the machine, accessories and machine bits etc. in • accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the machine for operations different from those intended could result in a hazardous situation. • Keep handles and grasping surfaces dry, clean and free from oil and grease.
Page 8 Check the grass catcher frequently for wear or • deterioration. A worn or damaged grass catcher may increase the risk of personal injury. • Keep guards in place. Guards must be in working order and be properly mounted. A guard that is loose, damaged, or is not functioning correctly may result in personal injury.
Page 9 Do not touch blades and other hazardous moving parts • while they are still in motion. This reduces the risk of injury from moving parts. • When clearing jammed material or cleaning the lawnmower, make sure all power switches are off and the battery pack is disconnected.
Page 10 • Thoroughly inspect the area where the product is to be used and remove all objects which can be thrown by the product. • Before using, always visually inspect to see that the cutting blade, cutting blade bolts and cutting blade assembly are not worn or damaged.
Page 11 • Do not transport the product while the product is running. • Stop the product. Make sure that all moving parts have come to a complete stop: – whenever you leave the product, – before clearing blockages or unclogging chute, –...
Page 12 • If the replacement of the supply cord is necessary, this has to be done by the manufacturer or his agent in order to avoid a safety hazard. Health surveillance All employees should be part of an employer’s health surveillance scheme to help identity any vibration related diseases at an early stage, prevent disease progression and help employees stay in work.
Page 13 Emergency Familiarise yourself with the use of this product by means of this instruction manual. Memorise the safety directions and follow them to the letter. This will help to prevent risks and hazards. • Always be alert when using this product, so that you can recognise and handle risks early.
Page 14 Symbols On the product, the rating label and within these instructions you will find among others the following symbols and abbreviations. Familiarise yourself with them to reduce hazards like personal injuries and damage to property. Volt, (alternating voltage) Hertz Watt °C Degree Celsius No-load speed Litre Gram Kilogram /min or min Per minute Millimetre Centimeter Metre dB(A) Decibel (A-rated) Metres per seconds squared Lock / to tighten or secure.
Page 15 Inspect the area where the product is to be used and remove all objects which can be thrown by the product. If objects are hidden while operating stop the motor and remove the object. WARNING – Beware of thrown objects – keep bystanders away! Objects thrown by the product could hit the user or other bystanders.
Page 16 The product complies with the applicable European directives and an evaluation method of conformity for these directives was done. UK Conformity Assessed. Rating label explanation MCB1136LWM, MCB1137LWM = Model number MC = MAC Allister (brand name) B = Voltage (230-240 V~) 1136 / 1137 = Sequential Code...
Page 17 The declared vibration total values and the declared noise emission values have been measured in accordance with a standard test method (EN 62841-1, EN IEC 62841-4-3) and may be used for comparing one machine with another; they may also be used in a preliminary assessment of exposure. WARNING! THE VIBRATION AND NOISE EMISSION DURING ACTUAL USE OF THE MACHINE CAN DIFFER FROM THE DECLARED TOTAL VALUE DEPENDING ON THE WAYS IN WHICH THE MACHINE IS USED ESPECIALLY WHAT KIND OF WORKPIECE IS PROCESSED.
Page 18 • Accidental damage or modification • Failure to follow manufacturer’s guidelines • Loss of use of the goods If this product is defective, we will, within a reasonable time, repair, replace, refund, service, or provide spare parts. Rights under this guarantee are enforceable in the country in which you purchased this product. Guarantee related queries should be addressed to the store you purchased this product from.
Page 19 EN Assembly WARNING! THE PRODUCT MUST BE FULLY ASSEMBLED BEFORE OPERATION! DO NOT USE A PRODUCT THAT IS ONLY PARTLY ASSEMBLED OR ASSEMBLED WITH DAMAGED PARTS! WEAR PROTECTIVE GLOVES FOR THIS ASSEMBLY WORK AND ALWAYS LAY THE PRODUCT ON A FLAT AND STABLE SURFACE WHILE ASSEMBLING. FOLLOW THE ASSEMBLY INSTRUCTIONS STEP-BY-STEP AND USE THE PICTURES PROVIDED AS A VISUAL GUIDE TO EASILY ASSEMBLE THE PRODUCT!
Page 20 Upper handle bar 1. Guide the cord retainer (19) onto the upper handle bar (4) and slide it all the way until stop (Fig. 2). 2. Place the cord retainer (19) above the safety switch box (Fig. 3). 3. Hold the upper handle bar (4) with the safety switch button (1) facing upwards. Align the mounting holes of the upper handle bar (4) and the lower handle bars (6).
Page 21 Grass catcher 1. Insert the carry handle (15a) into the two assembling slots and make sure that the carry handle (15a) is firmly in place (Fig. 6, step 1). 2. Clip the three rubber clips (15c) onto the supporting rod (15d) of the grass catcher (15) (Fig. 6, step 2). 3.
Page 22 Connection to power supply NOTE: The machine is equipped with a power cord with the length of 10 m. If an additional extension cord is required for operation, observe the technical requirements for this product when purchasing an extension cord. Always use a residual current supply (RCD, ≤30 mA) protected supply.
Page 23 EN Functions & Settings Intended use This electric lawn mower MCB1136LWM / MCB1137LWM is designated with a rated power input of 1200 Watts. The product is intended for mowing grass in domestic gardens only. It must not be used to mow unusually high, dry or wet grass, e.g.
Page 24 Cutting height adjustment WARNING! SWITCH THE PRODUCT OFF AND DISCONNECT IT FROM THE POWER SUPPLY, WAIT THAT THE CUTTING BLADE (13B) HAD COME TO A COMPLETE STOP BEFORE ADJUSTING THE CUTTING HEIGHT! ENSURE THAT THE LEVER ENGAGES BETWEEN TWO OF THE PRONGS! FOR THE FIRST CUT OF THE SEASON, A SUITABLE CUTTING HEIGHT SHOULD BE CHOSEN.
Page 25 Indicator The grass catcher (15) is equipped with a hatch (15b) that indicates the filling during operation. 1. When the hatch (15b) is opened the grass catcher (15) has sufficient volume left to collect grass (Fig. 11). 2. When the hatch (15b) is closed, the grass catcher (15) is full and must be emptied (Fig. 12). Fig. 11 Fig. 12 Emptying Empty the grass catcher (15) frequently during use. Do not wait until it is completely full. We recommend emptying it when it is half full.
Page 26 EN Use General operation 1. Check the product, its power cord and plug as well as accessories for damage before each use. Do not use the product if it is damaged or shows wear. Take care of any problem you find or have the product checked by qualified specialist. 2. Double check that the accessories and attachments are properly secured. 3. Always push the product using the grip handle (3). Keep the handles dry to ensure safe support. 4.
Page 27 Stopping 1. Release the start lever (2) to stop the lawn mower (Fig. 14). Fig. 14 Mowing 1. Make sure that the lawn is clear of stones, sticks, wire or other objects that could damage the product or its product. 2.
Page 28 After use 1. Switch the product off, disconnect it from the power supply and let it cool down. 2. Check, clean and store the product as described below. Troubleshooting Suspected malfunctions are often due to causes that the users can fix themselves. Therefore check the product using this section. In most cases the problem can be solved quickly. WARNING! ONLY PERFORM THE STEPS DESCRIBED WITHIN THESE INSTRUCTIONS! ALL FURTHER INSPECTION, MAINTENANCE AND REPAIR WORK MUST BE PERFORMED BY AN AUTHORISED SERVICE CENTRE OR A SIMILARLY QUALIFIED SPECIALIST IF YOU CANNOT SOLVE THE PROBLEM YOURSELF!
Page 29 EN Care and maintenance The golden rules for care WARNING! ALWAYS SWITCH THE PRODUCT OFF, DISCONNECT IT FROM THE POWER SUPPLY AND LET THE PRODUCT COOL DOWN BEFORE PERFORMING INSPECTION, MAINTENANCE AND CLEANING WORK! ONLY PERFORM CARE AND MAINTENANCE WORK ACCORDING TO THESE INSTRUCTIONS! ALL FURTHER WORKS MUST BE PERFORMED BY A QUALIFIED SPECIALIST! 1.
Page 30 Underbody and cutting blade WARNING! WEAR SAFETY GLOVES WHEN WORKING ON THE CUTTING BLADE (13B) AND CLOSE TO IT! USE PROPER MACHINES TO REMOVE DEBRIS, E. G. A WOODEN STICK! NEVER USE YOUR BARE HANDS! ALWAYS USE ORIGINAL SPARE PARTS FOR REPLACEMENT. THE CUTTING BLADE MUST BE REPLACED BY AN IDENTIFICATION NO.
Page 31 6. Replace this cutting blade (13b) after 50 hours mowing or 2 years whichever is sooner regardless of condition. If the cutting blade (13b) is cracked or damaged, you must immediately replace it with a new one. 7. Lubricate the cutting blade (13b) after each use to prolong the life span of cutting blade (13b) and product.
Page 32 WARNING! NEVER CONNECT LIVE OR NEUTRAL WIRES TO THE EARTH TERMINAL OF THE PLUG, WHICH IS MARKED WITH E. Only fit an approved 13 Amp BS 1363 or BS 1363/A plug and correctly rated 13 Amp BS 1362 fuse. If in doubt, consult a qualified electrician. NOTE: If a moulded plug is fitted and has to be removed take great care in disposing of the plug and severed cable, it must be destroyed to prevent engaging into a socket. Storage 1.
Page 33 Customer care and technical helpline A better way to repair your tools Kingfisher takes special care in creating high-quality garden power tools that are designed to last. But if a fault develops with your garden power tool and you need to claim under the guarantee, the Customer Care and Technical Helpline can support with technical assistance or if required, arrange a free courier collection from your home, assess your garden power tool for fault, repair it, and return it.
Page 34 (UK) DECLARATION OF CONFORMITY Product • Lawnmower 1200 W 32 cm • MCB1137LWM • 0000001 - 999999 Name and address of the manufacturer or his authorised representative: Kingfisher International Products Limited 1 Paddington Square London W2 1GG United Kingdom This declaration of conformity is issued under the sole responsibility of the manufacturer. Object of the declaration Product Model...
Page 35 (EN) EU DECLARATION OF CONFORMITY (FR) DÉCLARATION UE DE CONFORMITÉ (PL) DEKLARACJA ZGODNOŚCI UE (RO) DECLARAȚIA DE CONFORMITATE UE (ES) DECLARACIÓN UE DE CONFORMIDAD (PT) DECLARAÇÃO DE CONFORMIDADE UE Product/ Produit/ Produkt/ Produsul/ Producto/ Produto • Lawnmower 1200 W 32 cm/ Tondeuse 1200 W 32 cm/ Kosiarka 1200 W 32 cm/ Mașină pentru tuns gazonul 1200 W 32 cm/ Cortacésped 1200 W 32 cm/ Corta-relva 1200 W 32 cm •...
Page 36 2006/42/EC as amended Machinery Directive 2014/30/EU as amended Directive Electromagnetic compatibility 2000/14/EC as amended Outdoor Noise Directive 2011/65/EU as amended Directive on the restriction of the use of certain hazardous substances in electrical and electronic equipment Directive 2006/42/CE relative aux machines 2014/30 / UE telle que modifiée Directive Compatibilité électromagnétique Directive 2000/14/CE relative aux émissions sonores extérieures Directive 2011/65/UE relative à...
Page 37 The notified body TÜV Rheinland LGA Products GmbH, Tillystraße 2, 90431 Nürnberg, Germany, 0197 performed Outdoor Noise Directive and issued the certificate: JO 60177871 0001. L’organisme notifié TÜV Rheinland LGA Products GmbH, Tillystraße 2, 90431 Nürnberg, Germany, 0197 a effectué Directive 2000/14/CE relative aux émissions sonores extérieures et a établi le certificate: JO 60177871 0001. W stosownych przypadkach jednostka TÜV Rheinland LGA Products GmbH, Tillystraße 2, 90431 Nürnberg, Germany, 0197 notyfikowana przeprowadziła 2000/14/WE w zmienionej dyrektywie w sprawie hałasu na zewnątrz i wydała certyfikat: JO 60177871 0001. Organismul notificat TÜV Rheinland LGA Products GmbH, Tillystraße 2, 90431 Nürnberg, Germany, 0197 a efectuat 2000/14/CE, astfel a fost modificată Directiva privind zgomotul în aer liber și a emis certificatul: JO 60177871 0001. El organismo notificado TÜV Rheinland LGA Products GmbH, Tillystraße 2, 90431 Nürnberg, Germany, 0197 ha efectuado 2000/14/CE modificada Directiva sobre ruido al aire libre y expide el certificado: JO 60177871 0001. O organismo notificado TÜV Rheinland LGA Products GmbH, Tillystraße 2, 90431 Nürnberg, Germany, 0197 efetuou 2000/14/CE como diretiva de ruído exterior alterada e emitiu o certificado: JO 60177871 0001. References to the relevant harmonised standards used or references to the other technical specifications in relation to which conformity is declared: Références des normes harmonisées pertinentes appliquées, y compris la date de celles-ci, ou des autres specifications techniques, y compris la date de celles-ci, par rapport auxquelles la conformité est déclarée: Odwołania do odnośnych norm zharmonizowanych, które zastosowano, wraz z datą normy, lub do innych...
Page 38 Manufacturer: EN www.diy.com www.screwfix.com UK Manufacturer: www.screwfix.ie Kingfisher International Products Limited, To view instruction manuals online, 1 Paddington Square, London, W2 1GG, visit www.kingfisher.com/products United Kingdom EU Manufacturer: Kingfisher International Products B.V., Rapenburgerstraat 175E, 1011 VM Amsterdam, The Netherlands 5063022567604_MNL_EN_V03.indd 38 5063022567604_MNL_EN_V03.indd 38 10/22/2024 2:13:39 PM 10/22/2024 2:13:39 PM...
