Summary of Contents for Tele System UP1
- Page 3 Index Product description ..........................................1 Package contents ........................................1 Rear panel and connections ....................................1 Front panel ..........................................2 Remote control ........................................2 1.4.1 Programming TV keys ....................................2 1.4.2 Bluetooth Pairing ......................................3 1.4.3 Inserting b a t t e r i e s ....................................3 First installation ..........................................
- Page 5 - 4K UHD HDR digital receiver - Voice search with Google Assistant To get the most out of your UP1, search for terrestrial channels, connect the box to the Internet, register your Google account and pair the remote control via Bluetooth.
- Page 6 1.4.1 Programming TV keys To make the UP1 remote control 2 in 1, some of its buttons can be reserved to control the main functions via infrared (IR), such as volume adjustment, on/off and input source, of an external device connected to the same receiver, such as a TV screen or an external audio amplifier/soundbar.
- Page 7 1.4.2 Bluetooth Pairing To use Google Assistant and voice search, you first need to pair the remote with UP1 via Bluetooth: 1. Start the Add accessory function from the Settings > Remotes and accessories menu. 2. Hold down simultaneously the keys BACK and HOME for 3-4 seconds.
- Page 8 2 First installation The first installation wizard is active the first time you turn on the device or after a factory reset from the Settings > Device preferences > Factory reset menu (section 5.4). After carrying out the initial installation procedure, you will have access to the full functionality of Android TV.
- Page 9 2.2 Digital terrestrial TV Once the first installation of the Android system has been completed, a few other simple steps will be shown on the screen to be able to watch digital terrestrial channels through the Live TV APP as indicated below. 2.2.1 Choose a PIN number The user must choose a PIN (Personal Identification Number) made up of 4 numeric digits of his choice to protect channels and some settings of the box itself.
- Page 10 3 Android TV All available contents can be reached from the Home screen, which can be called up by pressing the button . From here you access Android apps and games, Google Assistant and much more. Some suggestions: - To make the most of Android TV, connect the box to the Internet. - A Google account is required to use Google services.
- Page 11 3.1.3 Get more Apps and Games It is possible to install various APPs or games available in Google's official virtual store called Google Play Store: Apps Choose the item on the first line of the Home screen per visualize the apps and games installed on the box.
- Page 12 3.3 Chromecast built-in UP1 also integrates a Chromecast for sharing content from your phone, laptop or tablet. In particular, it is possible transmit multimedia content from Chromecast compatible APPs directly from your phone to the box connected to your TV screen to enjoy entertainment on a larger screen.
- Page 13 4 Live TV APP Within this APP you can watch the digital terrestrial channels receivable from your antenna. Channel change Use the keys / PROG to go to the next/previous channel or enter the channel number using the numeric keys for direct access to the desired channel.
- Page 14 NOTES AND WARNINGS • Compatible only with USB memory devices formatted with FAT32, exFAT and NTFS file systems. With future updates, Google may allow Timeshift recording only with one or some File Systems, excluding others. • Compatibility with all existing USB mass storage devices cannot be guaranteed. •...
- Page 15 4.1.3 Favourites To create favourite channel lists, from the main menu press the right arrow ► button until the Favourites submenu is selected. From here, for each favourite group, choose the channels to assign to the selected group. To recall the favourite channel lists created, from viewing mode access the channel list with the left arrow ◄...
- Page 16 NOTES AND WARNINGS • By law, parental controls are active and set with an age limit of 18 years. In this way, the box will ask for the PIN before showing on video any event reported by television broadcasters as suitable for an adult audience. •...
- Page 17 Internet and installed. The installation requires restarting the device. If necessary, it is also possible to install new software via USB which will be released at the discretion of TELE System. Install only official software from TELE System. Installing unofficial software could irreparably damage your device and void the product warranty.
- Page 18 6 Technical specifications Product code / Model 21005356 / TELE System UP1 Product type SmartBox DVB-T/T2, IP (Android TV Amlogic S905Y4 Internal memory / RAM 8GB eMMC / 2GB DDR4 1x RF IN DVB-T/T2 (IEC 169-2 type connector, 75Ω) Tuner...
- Page 19 7 Troubleshooting PROBLEM POSSIBLE CAUSE REMEDY Power supply not connected Check that the power supply is connected The box does not turn on Socket not working Connect the power supply to another power outlet The box is on standby Turn on the box The box is not connected correctly to the Check the physical connection of the audio-video HDMI or AV port...
- Page 20 ENG – Rev00_web 2025-01-10...
