The first option is typically used when the purpose of the secondary site is primarily testing by the
IT department. The second option is typically used in a company that has more than one large site of
operations.
Two Site Business Continuity Cluster
Figure 1-3
Building A
Ethernet Switch
Server Server Server
1A 2A 3A
Fibre Channel
Switch
Fibre Channel
Disk Arrays
Cluster Site 1
Multiple-Site Business Continuity Cluster Solution
This is a large Business Continuity Cluster solution capable of supporting up to 32 nodes per site
and more than two sites. Services and applications can do fan-out failover between sites. Replication
of data blocks is typically done by SAN vendors, but can be done by host-based mirroring for
Two independent clusters at
geographically separate sites
WAN
eDirectory
DirXML
Server
4A
SAN
Disk blocks
Building B
Ethernet Switch
Server Server Server
1B 2B 3B
Fibre Channel
Switch
Fibre Channel
Disk Arrays
Cluster Site 2
Server
4B
Overview 15
