Joie Pact Pro Manual

Introduction

We are so excited to be part of your journey with your little one. While traveling with the Joie Pact™ Pro, you are using a high quality, fully certified stroller, approved to European safety standards EN 1888-2:2018+A1:2022. This product is suitable for children up to 22kg or 4 years whichever comes first. Please carefully read this manual and follow each step to ensure a comfortable ride and best protection for your child.

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.

Emergency
In case of emergency or accident, it is most important to have your child taken care of with first aid and medical treatment immediately.

Parts List

Make sure all parts are available before assembly. If any part is missing, please contact local retailer. No tools are required for assembly.

1. Stroller Frame
2. Front Wheel
3. Rear Wheel
4. Arm bar
5. Canopy
6. Shoulder Harness Cover
7. Arm bar
8. Calf Support
9. Swivel Lock
10. Front Wheel

11. Buckle
12. Secondary Lock
13. One-Hand-Fold Handle
14. Backrest Adjuster Buckle
15. Storage Basket
16. Brake Lever
17. Rear Wheel
18. Carry Strap
19. Carry Bag

Accessories (May not be included)

1. Rain cover (on certain models)
   Accessories may be sold separately or may not be available depending on region.


WARNING

1. Always use the restraint system.
2. Ensure that all the locking devices are engaged before use.
3. Do not let the child play with this product.
4. Check that the car seat attachment devices are correctly engaged before use.
5. Adult assembly required.
6. This product is suitable for children up to 22kg or 4 years whichever comes first.
7. To prevent a hazardous, unstable condition, do not place more than 4.5kg in the storage basket.
8. Never leave the child unattended.
9. Use the stroller with only one child at a time. Never place purses, shopping bags, parcels or accessory items on the handle or canopy.
10. Accessories which are not approved by the manufacturer shall not be used.
11. Only replacement parts supplied or recommended by the manufacturer shall be used.
12. To avoid injury ensure that the child is kept away when unfolding and folding this product.
13. This product is not suitable for running or skating.
14. Pushchair designed to be used from birth shall recommend the use of the most reclined position for new born babies.
15. The parking device shall be engaged when placing and removing the children.
16. For car seats used in conjunction with a chassis, this vehicle does not replace a cot or a bed. Should your child need to sleep, then it should be placed in a suitable pram body, cot or bed.
17. Any load attached to the handle and/or on the back of the backrest and/or on the sides of the vehicle will affect the stability of the vehicle.

Stroller Assembly

Please read all the instructions in this manual before assembling and using this product.

Open Stroller
see images -

• Check that the stroller is completely latched before continuing to use.

Assemble & Detach Front Wheel
see images -

Assemble & Detach Rear Wheel
see images -

Assemble & Detach Arm bar
see images -
Arm bar can be opened one side for easy seating and unseating of child.

• Always secure the child with the harness. The arm bar is not a restraint device.

The completely assembled stroller is shown as

Stroller Operation

Use Buckle
see images -
Release Buckle
Press the center button to release the buckle.
Lock Buckle
Match the waist belt buckle with the shoulder buckle - 1, and click into the center buckle. - 2
A "click" sound means the buckle is locked completely. - 3

1. Always secure the child with the harness. The arm bar is not a restraint device.
2. Make sure your child is snugly secured. The space between the child and the shoulder harness is about the thickness of one hand.
3. Do not cross the shoulder belts. This will cause pressure on a child's neck.

Use Shoulder & Waist Harnesses
see images -

• In order to protect your child from falling out, after your child is placed into the seat, check whether the shoulder and waist harnesses are at proper height and length.

- 1 Shoulder harness anchor A
- 2 Shoulder harness anchor B
- 3 Slide adjuster

For larger child, use shoulder harness anchor A and the highest shoulder slots. For smaller child, use shoulder harness anchor B and the lowest shoulder slots.
To adjust the position of the shoulder harness anchor, turn the anchor to be level with the side facing forward. Thread it through the shoulder harness slot from back to front.
Rethread it through the slot that is closest to child's shoulder height.
Use slide adjuster to change the harness length. - 1
Press the button - 2, while pulling the waist harness to proper length. - 3

Adjust Backrest
see images -
Recline Backrest
Press backrest adjuster buckle to adjust the backrest downwards.
Raise Backrest
To raise the backrest, push up.

• Make sure the recline is set properly for use.

Adjust Calf Support
see images -
The calf support has 3 positions.
To raise the calf support, push it upwards. A "click" sound means the calf is locked completely.
To lower calf support, press the adjustment buttons on both sides of the calf support - 1, and rotate the calf support downwards. - 2

Use Front Swivel Lock
see images
Push up the front swivel locks to maintain the moving direction.
Tip It is recommended to use swivel locks on uneven surfaces.

Use Brake
see images -
To lock the rear wheels, step down on the brake lever.
To unlock the rear wheels, step down the brake lever again.
Tip Always apply the brake when the stroller is stopped. Push the stroller slightly to ensure the brake is engaged.

Use Canopy
see images -
The canopy can be opened or folded, pull it toward front or back.
There is a window on the canopy, through which you can view your baby.
It is convenient to see the baby when flipping up the canopy rear panel.

Use Shoulder Harness Cover and Crotch Harness Cover
see images -
The shoulder harness cover or crotch harness cover can be removed from the webbing. To assemble shoulder harness cover and crotch harness cover in reverse steps.

Fold Stroller
see images -

• Please fold the canopy before folding the stroller.
  Push secondary lock - 1 and squeeze one-hand-fold button - 2. Push the stroller forward to fold.
• Grab the carry bag, the stroller will follow you.

Use Accessories

Accessories may be sold separately or may not be available depending on region.

Use with Infant Child Restraint
see images -
When using with Joie child restraint i-Jemini, i-Snug 2, gemm or i-Gemm 3 please refer to the following instructions.

• Adjust the backrest to the lowest position and fold the canopy.
  Release the infant child restraint lock.
  Place the infant child restraint on the stroller so it sits over the armbar.
  Close the infant child restraint lock to secure the infant child restraint on the stroller.
• If you have any problems about using the infant child restraint, please refer to their own instruction manuals.
• Remove the infant child restraint before folding the stroller.

Use Rain Cover
see image
To assemble the rain cover, place it over the stroller, and then attach the seaps and hook and loop fasteners on the rain cover.

• Before using the rain cover, please make sure the backrest has been adjusted to the lowest position and the infant child restraint has been fastened.
• When using the rain cover, please always check its ventilation.
• When not in use, please check that the rain cover has been cleaned and dried before folding.
• Do not fold the stroller after assembling the rain cover.
• Do not place your child into the stroller assembled with rain cover during hot weather.

Detach & Assemble Soft Goods
see images -
Remove arm bar shown as .
To re-assemble seat soft goods, follow the steps abovein reverse -

Care and Maintenance

see image

• Removable seat pad may be washed in cold water and drip-dried. No bleach. Please refer to the care label for instructions on cleaning the fabric parts of the stroller.
• To clean stroller frame, use only household soap and warm water. No bleach or detergent. Periodically wipe clean plastic parts with a soft damp cloth. Always dry the metal parts to prevent the formation of rust if the stroller has come into contact with water.
• From time to time, check your stroller for loose screws, worn parts, torn material or stitching. Replace or repair the parts as needed.
• Excessive exposure to sun or heat could cause fading or warping of parts.
• If stroller becomes wet, open hood and allow to dry thoroughly before storing.
• If wheels squeak, use a light oil (e.g., Silicon Spray, antirust oil, or sewing machine oil). It is important to get the oil into the axle and wheel assembly.
• When using your stroller at the beach, completely clean your stroller after use to remove sand and salt from mechanisms and wheel assemblies.
