REFRIGERATOR 3-DOOR F6FBM36S1 - F6FBM36S2
REVISION HISTORY
NO
REVISION
00
First publication
TND eklendi
01
02
03
04
05
06
07
36'' 3 DOORS WARDROBE TYPE REFRIGERATOR
SERVICE MANUAL
1
NO: 01
DATE
10.10.2015
18.10.2018
/ REV

Advertisement

loading
Need help?

Need help?

Do you have a question about the F6FBM36S1 and is the answer not in the manual?

Questions and answers

Related Manuals for Fulgor Milano F6FBM36S1

Summary of Contents for Fulgor Milano F6FBM36S1

  • Page 1 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 01 REFRIGERATOR 3-DOOR F6FBM36S1 - F6FBM36S2 SERVICE MANUAL REVISION HISTORY REVISION DATE First publication 10.10.2015 TND eklendi 18.10.2018...
  • Page 2 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 1. GENERAL SAFETY WARNINGS 1.1.HCA warning 1.2.For products with water dispenser 1.3.Intended use 1.4.Child safety 1.5.Compliance with the WEEE directive and disposal of the waste product 1.6.Packaging information 1.7.Disposal of the waste product 2.General appearance of the product 2.1.General Dimensions of the Product 2.2.Opened View of Product at 90°...
  • Page 3 10.13.Water cannot be dispensed from the water dispenser 10.14.Condensation in the form of drops on the water dispenser area 11.MOUNTING/DEMOUNTING PROCESSES OF THE PARTS 11.1.FULGOR MILANO door handle 11.2.FULGOR MILANO lower drawer handle 11.3.Rear cover 11.4.Service hatch 11.5.Card cover 11.6.Electronic Card 11.7.Front leg plate group and the lid...
  • Page 4 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.23.Water system connection 11.24.Crisper rails 11.25.Telescopic rail and rail gripper 11.26.Cooler rear illumination glass group 11.27.Cooler ceiling illumination glass 11.28.Fridge illumination glass and LED card 11.29.Filter cover group 11.30.Bypass cover / water filter 11.31.Filter head 11.32.Cooler evaporator cover screw plug 11.33.Cooler evaporator cover...
  • Page 5 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.56.Thermal fuse 11.57.Heated pipe group 11.58.Discharge groups 11.59.Middle hinge group and pin 11.60.The metal door puller mechanism 11.61.The condenser fan motor 11.62. Sound damper 11.63. Service hatch 12. Service equipment 13.
  • Page 6 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 1. GENERAL SAFETY WARNINGS Children must not play with the device. Cleaning and user maintenance must not be performed by the children unless they are supervised by an adult. If the product is out of order, it must not be operated before being repaired by the authorised service! Risk of electric shock! Connect the product to a grounded socket which is being protected by a fuse conforming to the values on the Type Label.
  • Page 7 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 1.1.HCA warning If the product has a refrigeration system containing R600a gas, make sure that the refrigeration system and piping are not damaged during usage and transportation. This gas is flammable. If the refrigeration system is damaged, keep the product away from potential fire sources that may cause it to catch fire and immediately ventilate the room where the unit is placed.
  • Page 8 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 2.General appearance of the product The figure given is for schematic purposes and may not be exactly the same with the product. If the relevant parts are not available in the product, it applies to other models.
  • Page 9 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 2.1.General Dimensions of the Product...
  • Page 10 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00...
  • Page 11 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 2.2.Opened View of Product at 90°...
  • Page 12 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 2.3.Maximum Opened View of the Product...
  • Page 13 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 3. INSTALLATION 3.1.Handling Instructions 1. This appliance must be transported only in upright position. Shipping package must not be damaged during transportation. 2. If the appliance is to be transported in horizontal position, it must only be leaned towards right-hand side when you are facing the front of the appliance.
  • Page 14 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 3.3.Appropriate place for installation WARNING: If the door of the room where the refrigerator will be placed is too narrow to let the product to pass through, the doors of the unit must be dismantled and the appliance must be passed in a horizontal position.
  • Page 15 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 3.5.Electrical Connection Connect the product to a grounded socket which is protected by a fuse conforming to the values on the Type Label. Our company shall not be liable for any damages which may arise if the machine is used without a proper grounding which conforms to the local regulations.
  • Page 16 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 4.PRODUCT USE For air circulation in the place where the refrigerator is located, necessary clearance must be allocated under, top, right and left of the unit. As the water inlet is at the rear side of the refrigerator for products equipped with water dispenser, make sure that the hose is not kinked or squeezed.
  • Page 17 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 6.Gas Flow Diagram and Parts Cooling system parts 1- Compressor / KMP.MTS200MT 2- Coil Condenser 3- Freezer heating pipe 4- Dryer 5- Capillary (Capillary pipe) 6- Freezer evaporator group 7- Cooler evaporator group 8- Return Pipe Welding Points A- Compressor - Coil Condenser...
  • Page 18 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 7.ELECTRONIC AND CONTROLLING SYSTEM 7.1.Component List and Operating Principles Component Compressor Defrosting heater DC Speed Freezer fan DC Speed Condenser fan Sensors (Frz Eva, Frz Air, FF Eva, FF Air, Icematic) DC Fresh Food Fan Flange Heater FF Eva heater...
  • Page 19 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 FF Eva sensor (Fridge Compartment Eva Sensor): It is used to detect the tail Evaporator temperature of the Fridge compartment. Defrost sensor: It is located on the evaporator at the capillary outlet. It detects the temperature on the evaporator and transmits it to the microprocessor.
  • Page 20 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 8.ELECTRONIC CONTROL SYSTEM 8.1.U4 CONTROL CARD FOREVER DISPLAY DEALER MODE DEALER MODE ACTIVATION The display board we use in the refrigerator has a six-key system. Set values are shown on the display. The figure given is for schematic purposes and may not be exactly the same with the product.
  • Page 21 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 If the key configuration is pressed correctly, dealer mode is enabled with a buzzer sound. Alarm icon lights continuously. Related icons light as the display button is pressed; no cooling is made. If the door is opened, "door open"...
  • Page 22 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 8.2.U4 CONTROL CARD FOREVER DISPLAY SERVICE TEST ACTIVATION OF SERVICE TEST The display board we use in the refrigerator has a six-key system. Set values are shown on the display. *(pressing for 3 seconds) Step 1: Press and hold On/Off and Alarm Off buttons for 3 sec anytime after energizing to switch to password entry screen.
  • Page 23 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 8.3.U4 CONTROL CARD FOREVER DISPLAY SERVICE TEST VERSION NUMBER DISPLAY Once entered in the service test, icons work for ON for 0.5 sec. and OFF for 0.5 sec. Once any button is pressed, Step 1 is terminated. Step 2: Firstly, the display software version info is shown on the FF compartment and the revision info is shown on the FRZ compartment.
  • Page 24 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 8.4.U4 CONTROL CARD FOREVER DISPLAY SERVICE TEST SENSOR TEMPERATURES DISPLAY Step 3: When any button is pressed, sensor display step is entered. Sensor display is as follows. View (Value-Sensor) : Sensor value at FRZ compartment, at FF compartment:...
  • Page 25 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 View (Value-Cabin Code) : Sensor value and cabinet code CA: 0 Fridge CA: 1 Freezer Switch between sensors can be made by pressing Fridge Set button in forward direction and Quick Fridge button in backward direction.
  • Page 26 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 8.5.U4 CONTROL CARD FOREVER DISPLAY SERVICE TEST COMPONENT DRIVE STEP Step 5: Product ON/OFF and Alarm Off buttons are shortly pressed simultaneously to switch to the component drive step. Component Selection Component Selection Component On/Off...
  • Page 27 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 to OFF-22-14-OFF... with FRZ setting button. Fan speed could be different for different products. Fan off Fan speed When Icematic 'Ir' is selected, Icematic is rotated in pouring direction by selecting '1' using FRZ Set button and in the correction direction when '2' is selected.
  • Page 28 TPM Single Point Lesson LESSON NO: U4 CONTROL BOARD FOUREVER 3 DOOR TOP TRIM DISPLAY SUBJECT SERVICE TEST ACTIVATION The fourever top trim display board we use in the refrigerator has an six-key system. Set values are shown on the display. On / Off Quick Fridge Fridge Set...
  • Page 29 TPM Single Point Lesson LESSON NO: U4 CONTROL BOARD FOUREVER 3 DOOR TOP TRIM DISPLAY SUBJECT SERVICE TEST ACTIVATION The Fridge set button is pressed once. Press one times The buzzer mode is activated with the buzzer sound. The display shows the set values and the warning icon does not illuminate.
  • Page 30 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 If the following states occur, service test is aborted. Power failure Product on-off and Alarm Off buttons are pressed simultaneously Operating in service test for 30 minutes 8.7.PRODUCTION TEST OF THE CONTROL CARD (4934262300) When the refrigerator is energised, it starts with production test as long as it is not switched to service test or dealer mode.
  • Page 31 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 14.2 16.0 2 Water pipe heaters - HAB Heater 16.2 Compressor 8.9.CONTROL CARD GR U4 G91629NE FOUREVER V0b (4934262300) I/O type I/O name Connector name INPUT Fridge Air Sensor KN6-1,2 INPUT Fridge Eva Sensor KN6-3,4...
  • Page 32 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 FF/FRZ Light KN10-13 KN10-14 KN10-15 INPUT DC FF Door KN9-1,2 Analogue (LV) INPUT DC FRZ Door KN9-4,5 VALVE B - KN11-6 VALVE A - KN11-7 12V DC OUTPUT KN11 12 VDC KN11-8 VALVE B + KN11-9...
  • Page 33 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 8.10.CONTROL CARD GR U4 G91629NE V0b A+ TR (4934262800) I/O type I/O name Connector name INPUT Fridge Air Sensor KN6-1,2 INPUT Fridge Eva Sensor KN6-3,4 Analogue (LV) INPUT Freezer Air Sensor KN6-5,6 INPUT Freezer Eva Sensor...
  • Page 34 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 INPUT DC FF Door KN9-1,2 Analogue (LV) INPUT DC FRZ Door KN9-4,5 VALVE B - KN11-6 VALVE A - KN11-7 12V DC OUTPUT KN11 12 VDC KN11-8 VALVE B + KN11-9 VALVE A + KN11-10...
  • Page 35 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 8.11. Electric Circuit Diagram...
  • Page 36 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 9.U4 MALFUNCTION ERROR CODES ERROR ERROR DEFINITION CODE Freezer Compartment Air Sensor Error Freezer Compartment Evaporator Sensor Error Fridge Compartment Evaporator Sensor Error Fridge Compartment Air Sensor Error Freezer Compartment Defrost Heater Error Icematic Air Sensor Error Icematic Failure Speed Frz Fan Error...
  • Page 37 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 9.1.E0 Freezer Air Sensor Error Freezer E0 Error flashes Sensor Error Check cables connected to control card sensor socket (KN6) pins 5 and 6 If cables are disconnected, re-connect them, turn on the refrigerator and check Any errors on display? Remove KN6 socket from control card.
  • Page 38 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 9.2.E1 Freezer Evaporator Sensor Error Freezer E1 Error flashes Evaporator Sensor Error Check cables connected to control card sensor socket (KN6) pins 7 and 8 If cables are disconnected, re-connect them, turn on the refrigerator and check Any errors on display?
  • Page 39 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 9.3.E2 Fridge evaporator sensor error Fridge E2 Error flashes Evaporator Sensor Error Check cables connected to control card sensor socket (KN6) pins 3 and 4 If cables are disconnected, re-connect them, turn on the refrigerator and check Any errors on display?
  • Page 40 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 9.4.E3 Fridge Air Sensor Error Fridge Air E3 Error flashes Sensor Error Check cables connected to control card sensor socket (KN6) pins 1 and 2 If cables are disconnected, re-connect them, turn on the refrigerator and check Any errors on display?
  • Page 41 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 9.5.E4 Freezer Defrost Heater Error Freezer E4 Error flashes Defrost Heater Error Plug the refrigerator to wattmeter and operate freezer defrost heater in service test. Check if the value read from wattmeter conforms to the total power of defrost heater+drain heater Is the value suitable?
  • Page 42 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 9.6.E8 Icematic Air Sensor Error Icematic E8 Error flashes Sensor Error Check cables connected to control board sensor socket (KN4) pins 14 and If cables are disconnected, re-connect them, turn on the refrigerator and check Any errors on display? Use a multimeter to measure sensor...
  • Page 43 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 9.7.E9 Icematic Motor Error Icematic E9 Error flashes Motor Error In service test, rotate icematic motor in In service test, rotate icematic motor in pouring direction. Check if there is 12V correcting direction.
  • Page 44 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 9.8.E13 Cyclic freezer fan error E13: Speed E13 Error flashes Frz Fan Error Check cables connected to control card DC Input-Output socket (KN10) pins 1, 2 and 3 If cables are disconnected, re-connect them, turn on the refrigerator and check Any errors on display?
  • Page 45 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 9.9.E15 Speed Condenser Fan Error E15: Speed E15 Error flashes Condenser Fan Error Check cables connected to control card DC Input-Output socket (KN10) pins 4, 5 and 6 If cables are disconnected, re-connect them, turn on the refrigerator and check Any errors on display?
  • Page 46 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 9.10.Cooling failure due to electrical issues Cooling failure due Refrigerator does not cool to electrical issues Enter service test and operate Step-3 compressor. Check if it is running. Remove the connector of the cables entering the body from the Is compressor compressor’s side.
  • Page 47 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 9.11.Freezing error due to electrical issues Freezing error due to Refrigerator freezes the foods electrical issues Plug the refrigerator to wattmeter and operate freshfood heater in service test. Check if the value read from wattmeter conforms to the power of freshfood heater.
  • Page 48 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 10.TROUBLESHOOTING 10.1.The refrigerator is not operating refrigerator is not operating. Is the fuse of the socket to Is the refrigerator which your refrigerator is connected or the main correctly plugged in? fuse blown out? Insert the plug Check the...
  • Page 49 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 10.2.Condensation in the Fridge Compartment Condensation on the side wall of the fridge compartment (MULTIZONE or COOL SELECT). REASONS OF THINGS TO TAKE INTO CONDENSATION ACCOUNT Very cold Switching the set ambient position to a colder conditions.
  • Page 50 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 10.3.Compressor is not running Compresso r is not running. THINGS TO TAKE REASONS INTO ACCOUNT Protective thermal of the compressor will blow on the sudden power interruptions or while The refrigerator will start running plugging the appliance in and out as the approximately after 6 refrigerant pressure in the cooling system of the...
  • Page 51 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 10.4.Refrigerator runs either frequently or for a long time The fridge is running frequently or for a long time. This is normal. Operation times of the Volume of the refrigerators may vary refrigerator may be depending on their volumes.
  • Page 52 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 10.5.Temperatures are too low temperature s are too low The temperature of the The temperature of the fresh food compartment freezer compartment is is very low but that of the very low but that of the freezer compartment is fresh food compartment is...
  • Page 53 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 10.6.The refrigerator operates tumultuously The refrigerator operates tumultuously The operation sound There is a ticking Shake or changes when the noise from the noise sound is refrigerator is running. heard. refrigerator.
  • Page 54 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 10.7.Noise from the evaporator fan motor Noise comes from evaporator fan motor Open the eva cover and check the fan, replace if it is Fan motor blade may skewed and there is a risk of be skewed.
  • Page 55 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 10.8.Noise from the condenser fan motor Noise from the condenser fan motor. Open the compressor area rear cover and check the fan; replace if Fan motor blade may it is skewed and there is a risk of be skewed.
  • Page 56 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 10.9.Noise from the refrigerator Noise from the refrigerator Compressor pipes may be Check the pipes. contacting somewhere. As the capillary pipe is long, it may contact the eva cover or Check it.
  • Page 57 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 10.10.Condensation on the inner walls of the refrigerator Condensation on the inner walls of refrigerator. The doors are ajar. Hot and humid weather Make sure that the increases frosting and doors are fully closed.
  • Page 58 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 10.11.Condensation on the outer side of the refrigerator Water/condensatio n/ice on the outer side of the refrigerator. Humidity occurs on the outer Stinky smell inside of the refrigerator. side of the refrigerator or between the doors.
  • Page 59 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 10.12.The doors cannot be closed The door(s) is (are) not closing. The refrigerator is probably not standing completely upright on the floor and it might be rocking when slightly moved. Door seals may Adjust the elevation be failed.
  • Page 60 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 10.13.Water cannot be dispensed from the water dispenser Water cannot be dispensed from the water dispenser Remove the water pipe from the water valve and discharge the System may have take water to a container for 1-2 air inside.
  • Page 61 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 10.14.Condensation in the form of drops on the water dispenser area Condensation in the form of drops on the water dispenser area Set the display to ice supply and press and hold the trigger.
  • Page 62 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.MOUNTING/DEMOUNTING PROCESSES OF THE PARTS 11.1.FULGOR MLANO door handle Handle kit is used on the product. To dismount the handles loosen the two allen screws. Then pull out the handle.
  • Page 63 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.2.FULGOR MLANO lower drawer handle Handle kit is used on the product. To dismount the handles loosen the two allen screws. Then pull out the handle.
  • Page 64 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.3.Rear cover As the waterspouts are on transition point, do not tighten a screw. Rear cover and rears are fixed by 5 screws and insertion at the bottom. Remove the screws to take the cover out. 11.4.Service hatch The service hatch used on the rear wall section of the product is fixed to the rear wall by insertion to plate and 1 screw.
  • Page 65 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.5.Card cover The electronic card board used on the top plate is fixed by insertion and 1 screw. Screw is removed off and the board is detached according to the arrow direction. 11.6.Electronic Card Electronic card is fixed in the housing with bench stops.
  • Page 66 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.7.Front leg plate group and the lid Front leg plate group is fixed by overlapping to the product and 1 screw. Remove the screws to take the group out. 11.8.Rear leg plate group It is fixed with 4 screws.
  • Page 67 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.9.Door shelf 70 mm 70-Gallon Door Shelf is used on the upper section of cooling left and right doors. Detached by moving onto the arrow direction. *Optional 11.10.TPK shelf Gallon Door Shelf is used on the upper section of cooling left and right doors. Detached by moving onto the arrow direction.
  • Page 68 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.12.Sliding door shelf Gallon Door Shelf is used on the upper section of cooling left and right doors. Can be moved up and down by arrow directed motions. The buttons located on the inner section of the shelf are pressed simultaneously in movement is required.
  • Page 69 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.14.Aluminium adjustable glass shelf profiles The aluminium profiles on which the adjustable glass shelf profiles are grouped are fixed by 2 screws. Profiles are detached by removing off the screws. 11.15.Fridge crisper-top glass shelf The glass shelf on the crisper is slightly lifted upwards and detached by pulling.
  • Page 70 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.16.Crispers Crisper are pulled from their rails and removed. 11.17.Chiller compartment Chiller compartment is pulled, got free from the pins on the telescopic rail, slightly lifted upwards and detached.
  • Page 71 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.18.Water dispenser trigger group socket Plastic Clamp Water dispenser trigger group is located on the inner left section. Remove by getting free from bench stops using a thin-edged apparatus. The led socket connection is detachable, plastic clamps are cut off and the water pipe is removed.
  • Page 72 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.19.Crisper sheathing group and water container middle rail group The water container pipes through water valve and water dispenser are detached. Crisper cover group is fixed to the body by a screw on the rear wall. Screw is removed off, crisper cover and medium rail group are detached by pulling.
  • Page 73 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.20.Waterspout closer lids They are comprised of two parts. Removed by removing 2 screws starting with the longer one. Then the other covering part is removed which is fixed to the rear wall by 3 screws.
  • Page 74 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.21.Middle rail group and water container The rails on the right and the left of the middle rail group chassis are fixed by clamps. Rails are detached by removing the screws and getting loose from the clamps. 5 screws are removed off from the chassis holding water container.
  • Page 75 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.22.Water valve and waterspouts The pipes towards water valve and trigger group Water reservoir IMAGE 1 IMAGE 2 IMAGE 4 IMAGE 5 IMAGE 3 IMAGE 6 IMAGE 7 IMAGE 8 The pipes towards water valve and trigger group are shown in image 1.
  • Page 76 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.23.Water system connection From water reservoir to valve From filter to valve From ice machine to valve From filter to valve 1) The 1900 mm long black and white hoses are transmitted from inner body's upper left corner, pulled out from rear wall and grouped in valve and filter head in assembly.
  • Page 77 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 Dragon filter Stream from valve to filter Stream from filter to valve Stream to water dispenser Stream from valve to water reservoir Double stream from valve to ice machine Mains input...
  • Page 78 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 Dragon filter Water dispenser group Stream to water dispenser from water container Icematic group socket...
  • Page 79 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 Mains input To filter Stream from valve to ice machine Stream from filter to valve Stream from valve to water reservoir 11.24.Crisper rails Remove by getting free from bench stops using a thin-edged apparatus.
  • Page 80 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.25.Telescopic rail and rail gripper Telescopic rails used in chiller, ice drawer and freezer upper drawer are fixed to rail gripper with 3 screws. Firstly, the telescopic ray is opened totally ajar for the screws to be completely seen and then they are removed off.
  • Page 81 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.26.Cooler rear illumination glass group The cooling compartment is used in both right and left. This group is fixed on the body by means of clamps. Can be removed by using a thin-edged apparatus. Socket connection is removed from its housing by disassembling.
  • Page 82 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.28.Fridge illumination glass and LED card Used in cooling chiller compartment's right and left sides. Illumination glass can be removed by using a thin-edged apparatus. The led card which is grouped in angled situation can be detached by needle nose pliers. When placing the mew led card, firstly the socket part is mounted and then the card is grouped in assembly by the clamps.
  • Page 83 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.30.Bypass cover / water filter Bypass cover grouped in assembly within the filter head is detached. Water filter is inserted instead upon preference. 11.31.Filter head It is fixed with 1 screw. Remove the screws and pipe connections to take the cover out.
  • Page 84 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.32.Cooler evaporator cover screw plug Two units of eva cover screw plugs are used, one at the right and one at the left side. Remove the pipe holders by using a flat-tipped screwdriver. 11.33.Cooler evaporator cover The cooling eva cover is grouped in assembly with the clamps by 2 screws.
  • Page 85 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.34.Square fan group Four tabs around the fan fixing frame are removed with a flat-tip screwdriver. After the fan and the protective silicon are removed, remove the fan. 11.35.Ioniser group Ioniser cooler is used behind the fridge eva cover.
  • Page 86 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.37. Ioniser illumination cover (Ion fresh) Ioniser illumination cover is fixed at the bottom and top by two clamps. Can be detached by slightly pulling with hands. 11.38.Sensor cover Sensor cover is mounted with tabs. Remove the pipe holders by using a flat-tipped screwdriver.
  • Page 87 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.39.Moving middle compartment group SOCKET CONNECTION UPPER HINGE LOWER HINGE GROUP SLIDING LOWER HINGE GROUP Movable middle section group ıt is used in the fridge’s left door. It is affixed by 2 screws each in lower hinge and the skid on the lower hinge. The skid is removed by slightly sliding on the direction of the arrow after the screws are removed off.
  • Page 88 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.41.Hand plate display group The hand plate display group is grouped as to cover the hinges on the upper plate. 6 screws are removed off from the upper section and get loosened from the clamps on the hinge.
  • Page 89 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.42.Display group It is fixed with 3 screws on the hinge cover. Remove the screws and socket connection to detach from housing.
  • Page 90 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.43.Freezer compartment lower drawer / Separator / Separator wire The freezer compartment is removed by holding from rear handles. Separator is used on 2 wires. Separator wires are click-fit to right and left with silicones. 11.44.Freezer compartment upper drawer Freezer compartment upper drawer is grouped in assembly by means of telescopic rails in right and left sides.
  • Page 91 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.45.Ice compartment Freezer compartment upper drawer is grouped in assembly by means of telescopic rails in right and left sides. Can be detached by lifting slightly up and pulling. 11.46.Freezer door The door is opened by pulling the freezer door, the lower drawer is removed and the reinforcement connecting the telescopic rails with the door comes forth.
  • Page 92 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.47.Freezer group Regularity of the silicone outputs must be assured. Attention must be paid to prevent heating cables to be placed in front of the silicone. Icematic group is used in the upper left corner in freezer compartment. Can be detached by slightly pulling with hands.
  • Page 93 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.48.Freezer separator wire Wire is removed by pulling. 11.49.Freezer middle rail group The freezer compartment is in the chassis holding the telescopic rails supporting ice drawer and upper drawer as an assembly. Among the freezer middle rail group, the icebox group must be removed at first.
  • Page 94 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.50.Ice drawer and freezer drawer rails There are 4 rails used for freezer drawers. Can be detached by removing 2 screws placed on each. Rail grippers can be detached by bare hands as they are only inserted.
  • Page 95 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.51.Freezer door rail Freezer door rails are used with synchronization wire in an assembly group. Rails are affixed with 7 screws on each side. The rails are pulled after the screws are removed off and rail group is detached after the screws at the bottom section are removed off.
  • Page 96 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.52.Freezer evaporator sockets service cover Service hatch The freezer eva is affixed by 1 screw and clamps on the cover. The screws are removed off using a thin-edged apparatus and the sockets are reached.
  • Page 97 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.53.Freezer evaporator cover Fixed with the freezer evaporator cover using 1 screw. Remove the screws to take the cover out as shown in related images. 11.54.Wired fan shield Removed by turning left on the eva cover.
  • Page 98 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.55.Freezer fan group Firstly, remove the Freezer eva cover. Remove the 2 screws off fixing the fan group. Socket connection is removed from its housing by disassembling. NOTE: Make sure that it is not possible that the cable touches the propeller and the evaporator. 11.56.Thermal fuse It is assembled on the return pipe.
  • Page 99 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.57.Heated pipe group Once the service hatch is opened, 4 screws on the silicones are removed off and the heating pipe group is pulled as to detach. 11.58.Discharge groups Freezer draining group Fridge water drain group Freezer draining group is used in between compressor and coil condenser.
  • Page 100 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.59.Middle hinge group and pin It is fixed with 3 screws. Remove the screws to take the cover out. Middle hinge pin is detached by pliers. 11.60.The metal door puller mechanism It is used under the lower covers of the fridge and freezer doors.
  • Page 101 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 11.61.The condenser fan motor It is grouped onto the right side of the coil condenser in the compressor area. It is fixed to steam container with two screws. The screws and socket connection are removed, the fan group is dismantled from the housing.
  • Page 102 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 12. Service equipment 1. Blade 2. Different bit set 3. Star bit 4. Torque bit 5. Chargeable gun 6. Flat-tipped screwdriver 7. Phillips screwdriver 8. Side cutter 9. Long nose pliers 10.
  • Page 103 36’’ 3 DOORS WARDROBE TYPE REFRIGERATOR / REV NO: 00 13. MAINTENANCE AND CLEANING Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular intervals. WARNING: Before cleaning the unit, unplug it. •...
