- Page 1 FM4BM30FBI FM4BM30IFBI INSTALLATION GUIDE FRIDGE...
-
Page 3: Table Of Contents
TABLE OF CONTENTS PAGE TABLE OF CONTENTS PAGE Cabinet Installation 1. Important Instructions 7.1 Removing fridge from the wooden pallet 1.1 Important safety instructions 7.2 Putting unit into cabinet niche 1.2 Children safety 7.3 Adjusting the height of the refrigerator in the niche 2. -
Page 4: Important Instructions
1 - Important Instructions 1.1 Important safety instructions 1.2 Children safety Symbols used in the Guide: NOTE Tips for the correct use of the appliance IMPORTANT Directions to avoid appliance damage WARNING Directions to prevent injury DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer: •... -
Page 5: Technical Requirements
2 - Technical Requirements 2.1 Appliance features and installation requirements Appliance dimensions Overlay Built-In Series Voltage AC 110 - 120V 60Hz Series 30” w: 29-11/16” (754mm) Power supply cable 90° Nema 5-15P h: 83-1/4” (2115mm) d: 23-5/8” (600mm) Water supply between 25psi to 80psi pressure (1.7 Bar - 5.5 Bar) -
Page 6: Preparing The Installation
3. Preparing for the Installation 3.1 Transport to installation site and unpacking • Dimensions of the cabinet niche must meet the WARNING necessary dimensions given in the manual. • It is recommended the installation area not be located The product can present a tip hazard if not secured to in proximity to heat sources, ovens, radiators etc. -
Page 7: Water Connection
3.7 Water Connection (where applicable) • Location of the water supply (refer to niche diagram). • Water system of the refrigerator must be connected to the potable water main in the house with a valve that is accessible in an adjacent cabinet, so that it is accessible after installation. -
Page 8: Niche Dimensions
4. Niche Dimensions 4.1 Niche Dimensions and Installation: Dimensions Images • Cabinet niche dimensions should always be confimerd before starting the installation • Confirm that the floor where the refrigerator is to be installed is level with a Bubble Level Tool •... - Page 9 • Distances between the cabinet doors and the kitchen cabinet must be 1/8" (3 mm) minimum. • Height of the Kitchen Toe kick Based on the Min./Max. Height of the Cabin.
-
Page 10: Unpacking
5. Unpacking 5.1 Unpacking and removing the 5.3 Removing the lower and upper connectors on the side wall of unit vent grill cover 1. Side furniture connection bracket closing parts • Required for water connection or repair work to 2. Seals between the Furniture, Door and Inner Door for condenser sealed system the Fridge (Already attached in products with clad •... -
Page 11: Installation
6. Installation IMPORTANT The following instruction for installation apply to all models. Continue to install the product according to the WARNING instructions below. Additionally, consider national and local instructions regarding installation. Always ensure the area to be drilled into is free of any waterlines or electrical circuits which could cause, Please observe the following: damage, injury or death. -
Page 12: Alternative Anti-Tip Method
IMPORTANT 6.3 Preparing the Water Hose If you are not comfortable the supplied connection and • Inspect all water connections for leaks. Water anti tip brackets are fit to the wall as securely as they leaks can cause excessive damage over time. It is should be, you can use alternative anti-tip methods. -
Page 13: Cabinet Installation
7. Cabinet Installation 7.2 Putting unit into cabinet niche 7.1 Removing fridge from the wooden pallet • Insert the water hose through the channel opening at • Remove brackets which secure the fridge to pallet back of unit and pull through to the front of the unit to as shown below. -
Page 14: Adjusting The Height Of The Refrigerator In The Niche
7.3 Adjusting the height of the 7.4 Adjusting the refrigerator according refrigerator in the niche to the cabinet niche • For products with supplied stainless panel doors, the • Use the adjustable leg mechanism to raise, lower and level the unit in the niche as per the diagram below position of the unit is adjusted so that the door and the furniture surface are flush and ensuring a min 1/8”... -
Page 15: Screwing The Side Brackets
7.6 Securing the upper bracket IMPORTANT • Attach the upper bracket to the furniture with 4 The depth of the niche must also be designed to screws (Item #16). accommodate the minimum depth requirement plus the • Preparing a pilot reference hole in the side gable thicker door panel if desired. -
Page 16: Bottom Cabinet Installation
8. Bottom Cabinet Installation 8.1 Complete the water connection 8.3 Attaching the lower vent hole assembly Use 2 screws to attach the lower vent hole part. Allow sufficient slack in waterline to ensure an easy bend and clear connection with no tension or potential kinks in the supply line to the connector The lower grill can be adjusted to accommodate the cabinet toe kick. -
Page 17: Hinge Adjustment And Reversing The Door Swing
9. Hinge Adjustment and Reversing the Door Swing • 9.1 Adjusting the spring tension of the hinge Set the tension level of the hinge to "0”. WARNING IMPORTANT Failure to set the hinge to "0" and continuing the • The door must be fully open during this adjustment. •... -
Page 18: Replacing The Hinges
9.3 Installing the Upper Door 9.2 Replacing the hinges • Remove the hinge pocket cover located at the other • Place the upper inner door to the refrigerator side where you will affix the hinges. using the door gasket to help hold door in •... -
Page 19: Overlay Panel Installation And Preparation
10. Overlay Panel Installation and Preparation This section contains information about preparing the 10.2 Removing the overlay panel mechanism cabinet doors and mounting them to the product. covers Maximum weights of the cabinetry to be mounted to A magnet is located in the cover of the door hanger bracket. the product are as follows. -
Page 20: Preparing The Overlay Panels
• Remove the panel adjustment mechanism covers and IMPORTANT panel afixing brackets from the lower part of the freezer Door. • Use screws suitable for the door thickness to avoid damage to the finished surface of the panel • Install the panel brackets using screws (#23). You can also use the template (#24) provided with the product to align these parts. -
Page 21: Installing The Upper Door Panel
Install the lower panel bracket using the panel screws (#23). 10.6 Installing the upper door panel You can also use the template (#24) provided with the • Attach the cabinet door to the fridge door product to align these parts. It is recommended to keep this template for future reference. -
Page 22: Re-Installing The Freezer Drawer Front
• Remove screws from mounting bracket to affix the • Adjust from lower part of the door with 2 screws upper/lower mounting bracket cover. removed from bracket (shown below) together with 2 slotted screws. • Use the bracket（#21）to secure the upper door panel to the upper door, use 2 screws (#20) and 1 screw (#22) to fix. -
Page 23: Panel Adjustments
• Reinstall the main freezer bin onto the rail and secure the bin onto the rails with the provided thumb screws image #1 image #2 • If an adjustment is needed for the upper door panel please follow the illustrations below using the adjustment mechanisim 10.8 Panel Adjustments Panel-adjustment for upper door –... - Page 24 If an adjustment is needed for the freezer door panel please follow the illustrations below using the adjustment mechanisim Panel-adjustment for freezer door panel - upper 1. Use the freezer cabinet door adjustment washer to align the door panel top part. 2.
-
Page 25: Warranty
(ie. removing handles to fit through doors) prior to or during product delivery / installation. The remedies described herein are the only ones which Fulgor Milano will provide, either under these warranties or under any warranty arising by operation of law. Fulgor Milano will not be responsible for content loss due to spoilage, freezing or burning nor for consequential damages to surrounding cabinetry, construction materials or finishing materials such as but not limited to flooring.
