ATTENTION:
INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THE CONSUMER.
CONSUMER: PLEASE READ & RETAIN THESE INSTRUCTIONS FOR FUTURE
REFERENCE AND BEFORE INSTALLING OR OPERATING.
If you smell gas:
•
•
•
•
•
•
This appliance is designed as an "ATTENDED APPLIANCE".
121324
Power Burner Pro User Manual
Models: PB2PRO
DANGER
Shut OFF gas supply to the appliance.
Extinguish any open flame.
Open lid.
If odor continues, keep away from the appliance
and immediately call your gas supplier or your fire
department.
WARNING
Do not store or use gasoline or other flamable liquids or
vapors in the vicinity of this or any other appliance.
An LP cylinder not connected for use shall not be stored
in the vicinity of this or any other appliance.
DO NOT leave this appliance burning when unattended.
1
SUMMERSET GRILLS
Advertisement
Related Manuals for Summerset PB2PRO
Summary of Contents for Summerset PB2PRO
- Page 1 Power Burner Pro User Manual Models: PB2PRO ATTENTION: INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THE CONSUMER. CONSUMER: PLEASE READ & RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE AND BEFORE INSTALLING OR OPERATING. DANGER If you smell gas: • Shut OFF gas supply to the appliance.
- Page 2 Always confirm burner ignition by observing the burner flame directly. • If you do not see a flame, turn the burner off, wait five minutes, and try reigniting. • Never leave the power burner unattended while in use. * Pertains to SB2PRO model only SUMMERSET GRILLS 121324...
- Page 3 Care & Cleaning THANK YOU PART #: SB2 Thank you for your purchase. We’d like to welcome you to the Summerset Grills family of luxury outdoor kitchen prod- SB2L ucts and look forward to being a part your home for years SB2PRO to come.
- Page 4 Power burners operating with natural gas must be installed with the NG regulator supplied with the unit and set to 4.0” of water column pressure • Power burners operating with Liquid Propane must be installed with an LP regulator and set to 11” of water column pressure SUMMERSET GRILLS 121324...
- Page 5 This should be done within (5) days of the delivery date. Be caustic chemicals including chlorine and pool cleaning sure to hold on to the box/carton for inspection. We cannot products away from stainless steel at all times. assume responsibility for damage or loss incurred in transit. SUMMERSET GRILLS 121324...
- Page 6 INSTALLATION MINIMUM POWER BURNER CLEARANCES: The Summerset Grills power burner can be used as a built- Minimum clearances between the power burner and any in unit. For installation as a built-in, it requires a non-com- side wall or rear wall must fall within one (or more) of the bustible island or enclosure.
- Page 7 ( 4” non-combustible material clearance, plus round, a an additional 10” clearance between the power burner and Summerset Grills insulating jacket/grill liner must be used. protected wall.) A minimum five (5) foot clearance is required between the countertop and the overhead construction.
- Page 8 GAS REQUIREMENTS NATURAL GAS REQUIREMENTS WARNING • Summerset Grills recommends that only qualified professionals perform the required plumbing on this GAS LINES product. Never connect a gas line directly to the power • Check the Rating Plate to make sure the gas burner.
- Page 9 IF THE INFORMATION IN SECTIONS “a” AND “b” IS NOT FOLLOWED EXACTLY, A FIRE CAUSING DEATH OR SERIOUS INJURY MY OCCUR. For proper ventilation and enclosure requirements, see the Enclosure Installation and Ventilation Requirements on pages 6 and 11. Figure 7 SUMMERSET GRILLS 121324...
- Page 10 LP gas dealer. Repeat the leak test to ensure that no leaks are present. Do not use the appliance until the leak is corrected. SUMMERSET GRILLS 121324...
- Page 11 The sidewalls may be paral- lel, as in a breezeway, or at right angles to each other; all openings must be permanently open; sliding doors, garage doors, windows, or screened openings are not SUMMERSET GRILLS 121324...
- Page 12 This appliance is designed as an “ATTENDED APPLIANCE”. DO NOT leave this appliance burning when unattended. Check and clean burner/venturi tubes for insects and insect nests. A clogged tube can lead to a fire beneath the power burner. SUMMERSET GRILLS 121324...
- Page 13 When stain is removed, wash entire surface with the • Rinse completely with clean water. soap solution mentioned above. For grease build up, • Dry with a microfiber towel. use Zep on the exterior surface to remove. SUMMERSET GRILLS 121324...
- Page 14 After your first use, certain areas of the power burner may discolor from the intense heat given off by the burners; this is normal and cannot be cleaned off. For light and heavy food stains there are many differ- ent stainless; steel cleaners available. SUMMERSET GRILLS 121324...
- Page 15 LINE DRAWINGS SUMMERSET GRILLS 121324...
- Page 16 FLEX TUBE 360mm LIGHT SWITCH (WHITE) LIGHT WIRE TRANSFORMER VALVE MANIFOLD INLET FITTING (LP MODEL ONLY) LP MODEL INLET FITTING (NG MODEL ONLY) NG MODEL 1/2” ELBOW (NG MODEL ONLY) NG MODEL LP REGULATOR WITH HOSE (LP MODEL ONLY) SUMMERSET GRILLS 121324...
- Page 17 ILLUSTRATED PARTS SUMMERSET GRILLS 121324...
- Page 18 • Warranty is valid only if regular maintenance is exercised. Due to the nature of commercial applications (multiple users, lack of control of use, etc.) regular maintenance is mandatory. 14520 DELTA LANE SUITE 105 HUNTINGTON BEACH, CA 92647 800.966.8126 AMDDIRECT.COM SUMMERSET GRILLS 121324...
- Page 19 This chart is for reference only, we recommend you consult with a Licensed Plumber/Gas Fitter or NFPA54 (National Fuel Gas Code - current edition) for more details. SUMMERSET GRILLS 121324...
- Page 20 8" SPACER BRACKET FOR 36" VENT HOOD FOR 42" VENT HOOD FOR 48" VENT HOOD FOR 36" VENT HOOD VH48-2 COMPATIBILE WITH: VH36-2 VH42-2 VH60-2 LINE DRAWING: 18½ 21¾ 24½ 30¼ VENT DUCT TRANSITION: VH42-2-WDF VH48-2-WDF VH60-2-WDF SUMMERSET GRILLS 082724 121324...
- Page 21 • Black Exterior & Interior Cabinet • 32° - 50° Temperature Range • Right to Left Opening Door Model • Triple-Glazed, Tinted Glass Door • Self-Closing #304 Stainless Steel Door, (RFR-24S-AR) Body & Handle • Left & Right Doors Available SUMMERSET GRILLS 121324...
- Page 22 Using Bar Keeper’s Friend, Zep, or other quality stain- less steel cleaners helps to protect the porous stainless steel surface from discoloration. • Covering the power burner with a power burner cover when not in use is a great way to protect the exterior. SUMMERSET GRILLS 121324...
- Page 23 Page intentionally left blank SUMMERSET GRILLS 121324...
- Page 24 SUMMERSET GRILLS For more information visit: SUMMERSETGRILLS.COM AMD Direct, Inc. 14520 DELTA LANE SUITE 105 HUNTINGTON BEACH, CA 92647 800.966.8126 SUMMERSET GRILLS 121324...
