ATTENTION:
INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THE CONSUMER.
CONSUMER: PLEASE READ & RETAIN THESE INSTRUCTIONS FOR FUTURE
REFERENCE AND BEFORE INSTALLING OR OPERATING.
If you smell gas:
•
•
•
•
•
•
This appliance is designed as an "ATTENDED APPLIANCE".
121324
Double Side Burner &
Double Side Burner Pro User Manual
Models: SB2
DANGER
Shut OFF gas supply to the appliance.
Extinguish any open flame.
Open lid.
If odor continues, keep away from the appliance
and immediately call your gas supplier or your fire
department.
WARNING
Do not store or use gasoline or other flamable liquids or
vapors in the vicinity of this or any other appliance.
An LP cylinder not connected for use shall not be stored
in the vicinity of this or any other appliance.
DO NOT leave this appliance burning when unattended.
SB2L
SB2PRO
SB2PROL
1
SUMMERSET GRILLS
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Summerset SB2
Summary of Contents for Summerset SB2
- Page 1 Double Side Burner & Double Side Burner Pro User Manual Models: SB2 SB2L SB2PRO SB2PROL ATTENTION: INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THE CONSUMER. CONSUMER: PLEASE READ & RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE AND BEFORE INSTALLING OR OPERATING. DANGER If you smell gas: •...
- Page 2 Always confirm burner ignition by observing the burner flame directly. • If you do not see a flame, turn the burner off, wait five minutes, and try reigniting. • Never leave the side burner unattended while in use. * Pertains to SB2PRO model only SUMMERSET GRILLS 121324...
- Page 3 THANK YOU PART #: SB2 Thank you for your purchase. We’d like to welcome you to SB2L the Summerset Side burners family of luxury outdoor kitch- SB2PRO en products and look forward to being a part your home for SB2PROL years to come.
- Page 4 Side burners operating with natural gas must be installed with the NG regulator supplied with the unit and set to 4.0” of water column pressure • Side burners operating with Liquid Propane must be installed with an LP regulator and set to 11” of water column pressure SUMMERSET GRILLS 121324...
- Page 5 Main Burners: SB2(2), SB2PRO(2) while side burnering with all burners on high and the hood Side Burner Cover: SB2(1), SB2PRO(1) closed, then be careful. If wind keeps the heat from exit- ing the rear of the side burner, then the control panel and Set of orifices knobs could become extremely hot.
- Page 6 (back) of the side 12-5/8” 25-1/2” 9-5/8” burner from a protected combustible wall. Refer to Figure 3. SB2PRO 12-5/8” 25-1/2” 9-5/8” Table 2 Note: Refer to page 10 for Custom Built-In Enclosures/ Islands when building. SUMMERSET GRILLS 121324...
- Page 7 When installing this side burner in a combustible surround, bustible wall. ( 4” non-combustible material clearance, plus an additional 10” clearance between the side burner and Summerset Side burners insulating jacket/side burner liner protected wall.) must be used. A minimum five (5) foot clearance is required between the countertop and the overhead construction.
- Page 8 GAS REQUIREMENTS NATURAL GAS REQUIREMENTS WARNING • Summerset Side burners recommends that only qual- ified professionals perform the required plumbing on GAS LINES this product. Never connect a gas line directly to the side • Check the Rating Plate to make sure the gas burner.
- Page 9 IF THE INFORMATION IN SECTIONS “a” AND “b” IS NOT FOLLOWED EXACTLY, A FIRE CAUSING DEATH OR SERIOUS INJURY MY OCCUR. For proper ventilation and enclosure requirements, see the Enclosure Installation and Ventilation Requirements on pages 6 and 11. Figure 7 SUMMERSET GRILLS 121324...
- Page 10 LP gas dealer. Repeat the leak test to ensure that no leaks are present. Do not use the appliance until the leak is corrected. SUMMERSET GRILLS 121324...
- Page 11 The sidewalls may be paral- lel, as in a breezeway, or at right angles to each other; all openings must be permanently open; sliding doors, garage doors, windows, or screened openings are not SUMMERSET GRILLS 121324...
- Page 12 This appliance is designed as an “ATTENDED APPLIANCE”. DO NOT leave this appliance burning when unattended. Check and clean burner/venturi tubes for insects and insect nests. A clogged tube can lead to a fire beneath the side burner. SUMMERSET GRILLS 121324...
- Page 13 When stain is removed, wash entire surface with the • Rinse completely with clean water. soap solution mentioned above. For grease build up, • Dry with a microfiber towel. use Zep on the exterior surface to remove. SUMMERSET GRILLS 121324...
- Page 14 After your first use, certain areas of the side burner may discolor from the intense heat given off by the burners; this is normal and cannot be cleaned off. For light and heavy food stains there are many differ- ent stainless; steel cleaners available. SUMMERSET GRILLS 121324...
- Page 15 LINE DRAWINGS SB2PRO SUMMERSET GRILLS 121324...
- Page 16 REPLACEMENT PARTS SB2PRO ITEM ITEM DESCRIPTION SB2 QTY. QTY. LID HANDLE GRATE IGNITER BURNER LP ORIFICE 1.05mm NG ORIFICE 1.6mm BURNER BASE BURNER PLATE BODY IGNITER WIRE 330mm IGNITER WIRE 480mm FLEX TUBE 200mm FLEX TUBE 420mm LED WIRE (SB2PRO Model Only)
- Page 17 ILLUSTRATED PARTS SB2PRO shown SUMMERSET GRILLS 121324...
- Page 18 • Warranty is valid only if regular maintenance is exercised. Due to the nature of commercial applications (multiple users, lack of control of use, etc.) regular maintenance is mandatory. 14520 DELTA LANE SUITE 105 HUNTINGTON BEACH, CA 92647 800.966.8126 AMDDIRECT.COM SUMMERSET GRILLS 121324...
- Page 19 This chart is for reference only, we recommend you consult with a Licensed Plumber/Gas Fitter or NFPA54 (National Fuel Gas Code - current edition) for more details. SUMMERSET GRILLS 121324...
- Page 20 8" SPACER BRACKET FOR 36" VENT HOOD FOR 42" VENT HOOD FOR 48" VENT HOOD FOR 36" VENT HOOD VH48-2 COMPATIBILE WITH: VH36-2 VH42-2 VH60-2 LINE DRAWING: 18½ 21¾ 24½ 30¼ VENT DUCT TRANSITION: VH42-2-WDF VH48-2-WDF VH60-2-WDF SUMMERSET GRILLS 082724 121324...
- Page 21 • Black Exterior & Interior Cabinet • 32° - 50° Temperature Range • Right to Left Opening Door Model • Triple-Glazed, Tinted Glass Door • Self-Closing #304 Stainless Steel Door, (RFR-24S-AR) Body & Handle • Left & Right Doors Available SUMMERSET GRILLS 121324...
- Page 22 Using Bar Keeper’s Friend, Zep, or other quality stain- less steel cleaners helps to protect the porous stainless steel surface from discoloration. • Covering the side burner with a side burner cover when not in use is a great way to protect the exterior. SUMMERSET GRILLS 121324...
- Page 23 Page intentionally left blank SUMMERSET GRILLS 121324...
- Page 24 SUMMERSET GRILLS For more information visit: SUMMERSETGRILLS.COM AMD Direct, Inc. 14520 DELTA LANE SUITE 105 HUNTINGTON BEACH, CA 92647 800.966.8126 SUMMERSET GRILLS 121324...
