ATTENTION:
INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THE CONSUMER.
CONSUMER: PLEASE READ & RETAIN THESE INSTRUCTIONS FOR FUTURE
REFERENCE AND BEFORE INSTALLING OR OPERATING.
If you smell gas:
•
•
•
•
•
•
This appliance is designed as an "ATTENDED APPLIANCE".
121224
TRL PRO Gas Grill User Manual
Models:
DANGER
Shut OFF gas supply to the appliance.
Extinguish any open flame.
Open lid.
If odor continues, keep away from the appliance
and immediately call your gas supplier or your fire
department.
WARNING
Do not store or use gasoline or other flamable liquids or
vapors in the vicinity of this or any other appliance.
An LP cylinder not connected for use shall not be stored
in the vicinity of this or any other appliance.
DO NOT leave this appliance burning when unattended.
TRLPRO32
TRLPRO32L
TRLPRO40
TRLPRO40L
1
SUMMERSET GRILLS
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Summerset TRL PRO Series
Summary of Contents for Summerset TRL PRO Series
- Page 1 • An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance. This appliance is designed as an “ATTENDED APPLIANCE”. DO NOT leave this appliance burning when unattended. SUMMERSET GRILLS 121224...
-
Page 2: Explosion Hazard
Always confirm burner ignition by observing the burner flame directly. • If you do not see a flame, turn the burner off, wait five minutes, and try reigniting. • Never leave the grill unattended while in use. SUMMERSET GRILLS 121224... -
Page 3: For Your Records
TRLPRO32L Thank you for your purchase. We’d like to welcome you TRLPRO40 to the Summerset Grills family of luxury outdoor kitchen TRLPRO40L products and look forward to being a part of your home for years to come. As a family business with over 20 years of industry experience, we aim to deliver exceptional quality and personal service. -
Page 4: Safety And Installation Warnings
Grills operating with natural gas must be installed with the NG regulator supplied with the unit and set to 4.0” of water column pressure • Grills operating with Liquid Propane must be installed with an LP regulator and set to 11” of water column pressure SUMMERSET GRILLS 121224... -
Page 5: Before Grilling
Construction debris such as (but not limited to) stone dust, stucco, and lime dust could damage or permanently discolor stainless steel products. Keep all caustic chemicals including chlorine and pool cleaning products away from stainless steel at all times. SUMMERSET GRILLS 121224... -
Page 6: Installation
A: WIDTH B: DEPTH C: HEIGHT protected combustible wall. Refer to Figure 3 (page 7). TRLPRO32 31-7/8” 25-1/2” 22-3/8” TRLPRO40 39-7/8” 25-1/2” 22-3/8” Table 2 Note: Refer to page 11 for Custom Built-In Enclosures/ Islands when building. SUMMERSET GRILLS 121224... -
Page 7: Overhead Construction And Exhaust Hood Requirements
8” clearance between the grill and protected wall.) When installing this grill in a combustible surround, a Summerset Grills insulating jacket/grill liner must be used. A minimum five (5) foot clearance is required between the countertop and the overhead construction. -
Page 8: Gas Requirements
GAS REQUIREMENTS NATURAL GAS REQUIREMENTS WARNING • Summerset Grills recommends that only qualified professionals perform the required plumbing on this GAS LINES product. Never connect a gas line directly to the grill. A • Check the Rating Plate to make sure the gas... - Page 9 IF THE INFORMATION IN SECTIONS “a” AND “b” IS NOT FOLLOWED EXACTLY, A FIRE CAUSING DEATH OR SERIOUS INJURY MY OCCUR. For proper ventilation and enclosure requirements, see the Enclosure Installation and Ventilation Requirements on pages 6 and 11. Figure 7 SUMMERSET GRILLS 121224...
- Page 10 LP gas dealer. Repeat the leak test to ensure that no leaks are present. Do not use the appliance until the leak is corrected. SUMMERSET GRILLS 121224...
- Page 11 The sidewalls may be paral- lel, as in a breezeway, or at right angles to each other; all openings must be permanently open; sliding doors, garage doors, windows, or screened openings are not SUMMERSET GRILLS 121224...
- Page 12 This appliance is designed as an “ATTENDED APPLIANCE”. DO NOT leave this appliance burning when unattended. Check and clean burner/venturi tubes for insects and insect nests. A clogged tube can lead to a fire beneath the grill. SUMMERSET GRILLS 121224...
- Page 13 • Using Bar Keepers Friend, Zep or other quality stainless steel cleaners helps to protect the porous stainless-steel soap solution mentioned above. For grease build up, surface from discoloration. use Zep on the exterior surface to remove. SUMMERSET GRILLS 121224...
-
Page 14: Maintenance Tips
After your first use, certain areas of the grill may discolor from the intense heat given off by the burners; this is normal and cannot be cleaned off. For light and heavy food stains there are many different stainless steel cleaners available. SUMMERSET GRILLS 121224... -
Page 15: Care And Cleaning
Using Bar Keeper’s Friend, Zep, or other quality stain- less steel cleaners helps to protect the porous stainless steel surface from discoloration. • Covering the grill with a grill cover when not in use is a great way to protect the exterior. SUMMERSET GRILLS 121224... -
Page 16: Rotisserie Installation
You will hear the one time clicking sound of the spark ignition. 7. After ignition, set the knob to the desired setting. 8. Using the main burner sear zone can cause extreme damage. 100% attendance to this style of cooking is required. SUMMERSET GRILLS 121224... -
Page 17: Line Drawings
LINE DRAWINGS TRLPRO32 TRLPRO40 SUMMERSET GRILLS 121224... -
Page 18: Replacement Parts
TUBE BURNER FLAME TAMER 32" BASIN 40" BASIN FLASH TUBE 32" LED WIRE KIT 40" LED WIRE KIT LED LIGHT (WHITE) 32" BACK-LIT KNOB WIRE KIT 40" BACK-LIT KNOB WIRE KIT 32" CONTROL PANEL 40" CONTROL PANEL SUMMERSET GRILLS 121224... -
Page 19: Illustrated Parts
ILLUSTRATED PARTS 32” grill shown 61 62 SUMMERSET GRILLS 121224... -
Page 20: Warranty
Warranty is Valid Only if Regular Maintenance is Exercised. 14520 DELTA LANE SUITE 105 Due to the Nature of Commercial Applications (Multiple HUNTINGTON BEACH, CA 92647 Users, Lack of Control of Use, etc.) Regular Maintenance Is 800.966.8126 Mandatory AMDDIRECT.COM SUMMERSET GRILLS 121224... -
Page 21: Gas Pipe Sizing Chart
This chart is for reference only, we recommend you consult with a Licensed Plumber/Gas Fitter or NFPA54 (National Fuel Gas Code - current edition) for more details. SUMMERSET GRILLS 121224... - Page 22 8" SPACER BRACKET FOR 36" VENT HOOD FOR 42" VENT HOOD FOR 48" VENT HOOD FOR 36" VENT HOOD VH48-2 COMPATIBILE WITH: VH36-2 VH42-2 VH60-2 LINE DRAWING: 18½ 21¾ 24½ 30¼ VENT DUCT TRANSITION: VH42-2-WDF VH48-2-WDF VH60-2-WDF SUMMERSET GRILLS 082724 121224...
- Page 23 • Black Exterior & Interior Cabinet • 32° - 50° Temperature Range • Right to Left Opening Door Model • Triple-Glazed, Tinted Glass Door • Self-Closing #304 Stainless Steel Door, (RFR-24S-AR) Body & Handle • Left & Right Doors Available SUMMERSET GRILLS 121224...
