ARTERY AT32F415CCT6 Technical Manual

®
ARM -based 32-bit Cortex
Flash Memory, USB, CAN, 18 Timers, 3 ADCs, 16 Communication Interfaces
Function

®
Core: ARM 32-bit Cortex
− Operating rate up to 200 MHz, with
Memory Protection Unit (MPU),
embedded single cycle multiplication
and hardware division
− Embedded Floating Point Unit (FPU)
− DSP instruction set provided

Memory
− From 256 Kbyte to 1024 Kbyte internal
Flash program/data memory
− SPIM interface: Additional external SPI
Flash program/data memory interface up
to 16 Mbytes
− Up to 96 + 128 Kbyte SRAM
− W ith 4 chip-select external controllers
(XMC). Supports CF Card, SRAM,
PSRAM, NOR, and NAND memory
− Parallel LCD interface, compatible with
8080/6800 mode

Clock, Reset, and Power Management
− 2.6 V ~ 3.6 V and I/O pins
− Power-on/Power-down Reset (POR/PDR),
Programmable Voltage Detector (PVD)
− 4 to 16 MHz crystal oscillator
− Embedded 8 MHz RC oscillator calibrated
in factory (25 ° C 1% precision, overall
temperature 2.5% precision)
− Embedded 40 kHz RC oscillator with
calibration
− RTC function 32 kHz oscillator with
calibration

Low Power Consumption
− Sleep, Stop, and Standby mode
− VBAT support for RTC and backup
register
3 12-bit A/D converters, 0.5 μs converting

time (Up to 21 input channels)
− Converting range: 0 V ~ 3.6 V
− 3 sample and hold functions
− Temparature sensor

2 12-bit D/A Converters

DMA: DMA controller with 12 channels
− Peripherals supported: Timer, ADC,
DAC, SDIO, I

Debug Mode
− Serial Wire Debug (SWD) and JTAG interface
2020.06.28
®
-M4F MCU + FPU, with 256 Kbyte ~ 1024 Kbyte Internal
®
-M4F CPU with FPU
2 2
S, SPI, I C, and USART
AT32F415 Series Technical Manual
− Cortex
®
-M4F Embedded Trace Macrocel (ETM

Up to 112 Fast I/O Interfaces
− 36/51/80/112 multifunctional and
bidirectional I/O ports, all of which can
be mapped to 16 external interrupts ;
almost every port is tolerant to 5 V input
signal.

Up to 18 Timers
− Up to 8 16-bit timers + 2 32-bit timers;
each timer has up to 4 channels used for
input capture/output compare/PW M or
pulse counting and incremental encoder
input.
− Up to 3 16-bit advanced-control timers
with dead-time control and emergency
break, PW M used for motor control
− 2 W atchdog timers (independent and
window)
− System timer: 24-bit decremental counter
− 2 16-bit basic timers driving DAC

Up to 16 Communication Interfaces
− Up to 3 I
2
C interfaces
(Support SMBus/PMBus)
− Up to 5 USART interfaces (Supports
ISO7816, LIN, IrDA interface, and modem
control)
− Up to 4 SPI interfaces (50 Mbit/sec.), all 4
interfaces can be muxed as I
− CAN interface (2.0B active)
− USB2.0 full-speed interface
− Up to 2 SDIO interfaces

CRC Calculation Unit, 96-bit Chip-only Code

Packaging
− LQFP144 20x20 mm
− LQFP100 14x14 mm
− LQFP64 10x10 mm
− LQFP48 7x7 mm

List of Models
Internal Flash
Memory
256 Kbytes
512 Kbytes
1024 Kbytes
Page 1
2
S interfaces.
Model
AT32F415CCT6, AT32F415RCT6,
AT32F415VCT6, AT32F415ZCT6
AT32F415CET6, AT32F415RET6,
AT32F415VET6, AT32F415ZET6
AT32F415CGT6, AT32F415RGT6,
AT32F415VGT6, AT32F415ZGT6
