Ingersoll-Rand 6661A-C Series Operator's Manual

OPERATOR'S MANUAL
INCLUDING: OPERATION, INSTALLATION & MAINTENANCE
It is the responsibility of the employer to place this information in the hands of the operator. Keep for future reference.
SERVICE KITS
Refer to the Model Description Chart to match the pump material options.
637118 C for Air Section repair (see page 6).
637161 XX C for Fluid Section repair (ee page 4).
PUMP DATA
Models . . . See Model Description Chart for  XXX".
Pump Type Non Metallic, Air Operated, Double Diaphragm
Material . . . See Model Description Chart.
Weight . . . . 6661A3 3XX C
6661A4 4XX C
6661B3 3XX C
6661B4 4XX C
Maximum Air Inlet Pressure
Maximum Material Inlet Pressure
Maximum Outlet Pressure . . . . . . . . . . .
Maximum Flow Rate
(Flooded Inlet)
Displacement / Cycle Gal. @ 100 Psig
Maximum Particle Size (semi solids)
Maximum Temp. Limits
Polypropylene . . . . . .
PVDF (Kynar) . . . . . .
Dimensional Data . . . . . . . . . . . . . . . . .
Noise Level @ 70 p.s.i. 60 c.p.m.¬
¬ Tested with 93110 muffler installed.
­ The pump sound pressure levels published here have been updated to an Equivalent
Continuous Sound Level (L ) to meet the intent of ANSI S1.13 1971, CAGI PNEUROP
Aeq
S5.1 using four microphone locations.
NOTICE: All possible options are shown in the chart, however, certain
combinations may not be recommended, consult a representative or the
factory if you have questions concerning availability.
GENERAL DESCRIPTION
The ARO Diaphragm Pump offers high volume delivery even at low air
pressure and a broad range of material compatibility options available.
Refer to the model and option chart. ARO pumps feature stall resistant
design, modular air motor / fluid sections.
Air operated double diaphragm pumps utilize a pressure differential in
the air chambers to alternately create suction and positive fluid pres
sure in the fluid chambers, ball checks insure a positive flow of fluid.
Pump cycling will begin as air pressure is applied and it will continue to
pump and keep up with the demand. It will build and maintain line pres
sure and will stop cycling once maximum line pressure is reached (dis
pensing device closed) and will resume pumping as needed.
INGERSOLL-RAND COMPANY
P.O. BOX 151 ONE ARO CENTER
D
&
D
(419) 636-4242 FAX (419) 633-1674
1" DIAPHRAGM PUMP
1:1 RATIO (NON-METALLIC)
READ THIS MANUAL CAREFULLY BEFORE INSTALLING,
OPERATING OR SERVICING THIS EQUIPMENT.
. . . . . . . . . 20.25 lbs (9.19 kgs)
. . . . . . . . . 28.5 lbs (12.93 kgs)
. . . . . . . . . 28.8 lbs (13.06 kgs)
. . . . . . . . . 37 lbs (16.78 kgs)
. . . . . . . . . 120 p.s.i. (8.3 bar)
. . . . . 10 p.s.i. (.69 bar)
120 p.s.i. (8.3 bar)
. . . . . 47 g.p.m. (177.9 lpm)
. . 0.17 (.64 l)
. . . . . 1/8" dia. (3.2 mm)
35_ to 150_F (2_ to 66_C)
10_ to 200_F ( 12_ to 93_C)
See page 8.
. . . . 64.5 db (A)­
BRYAN, OHIO 43506 0151
D
E
2000 D PRINTED IN U.S.A.
6661AX-X-C
6661A3 XXX C
MODEL DESCRIPTION CHART
CENTER BODY MATERIAL
A - Aluminum
B - Cast Iron
FLUID CAP / MANIFOLD MATERIAL
3 - Polypropylene
4 - PVDF (Kynar )
R
SEAT MATERIAL
3 - Polypropylene
4 - PVDF (Kynar)
8 - Hard 440 Stainless Steel
BALL MATERIAL
1 - Neoprene 5 - E.P.R.
2 - Nitrile 8 - Polyurethane
3 - Viton E - Santoprene
R
4 - T.F.E. (Teflon )
R
DIAPHRAGM MATERIAL
1 - Neoprene 3 - Viton
2 - Nitrile 5 - E.P.R.
4 - T.F.E. (Teflon) / Santoprene
FLUID SECTION SERVICE KIT SELECTION
EXAMPLE: MODEL # 6661A3 311 C
FLUID SECTION SERVICE KIT # 637161 11 C
RELEASED: 9-11-89
REVISED: 12-14-00
(REV. P)
6661 X X X X X C
R
9 - Hytrel
R
B - Santoprene
6661XX X X X C
637161 X X C
BALL DIAPHRAGM
