Intel AN430TX - Motherboard - ATX Technical Product Specification page 66

AN430TX Motherboard Technical Product Specification
3.2.4.8.3 Keyboard Auto-repeat Rate
Selects the key repeat rate. The options are:
30/sec (default)
26.7/sec
21.8/sec
18.5/sec
13.3/sec
10/sec
6/sec
2/sec
3.2.4.8.4 Keyboard Auto-repeat Delay
Selects the delay before key repeat. The options are:
¼ sec
½ sec (default)
¾ sec
1 sec
3.2.4.9 Video Configuration Subscreen
3.2.4.9.1 Palette Snooping
Controls the ability of a primary PCI graphics controller to share a common palette with an ISA
add-in video card. The options are:
Disabled (default)
Enabled
3.2.4.9.2 Video Monitor Type
Selects the type of video monitor being used. (Available only with the ATI-ImpacTV option.) The
options are:
VGA
VGA and TV Out (default)
3.2.4.9.3 TV Out Signal Type
Selects the type of TV Out signal to be used. (Available only with the ATI -ImpacTV option.) The
options are:
NTSC (North America) (default)
PAL (Europe)
PAL-M (South America)
66
