- Page 1 INSTALLATION AND USER’S MANUAL...
- Page 3 CONTENTS Safety------------------------------------------------------------3-5 Specifications---------------------------------------------------6 Components-----------------------------------------------------6 Installation---------------------------------------------------7-14 Prepare for Installation---------------------------------7 Recommended Tools for Installation---------------8 Install the Hood--------------------------------------9-13 Activated Carbon Filter Installation----------------14 Operation----------------------------------------------------15-16 Cleaning and Maintenance----------------------------17-19 Motor Grease Filter Fan Blade Activated Carbon Filter Stainless Steel Cleaning Painted Finish Cleaning Bulb Replacement Troubleshooting ----------------------------------------------20 Environmental Protection----------------------------------21...
- Page 4 Due to continuous development, we reserve the right to make technical changes including errors or other aberrations without notice. This is particularly true for measurements and cut-out dimensions respectively. Scan the QR code to get access to contact CIARRA Amazon Service if you have any question.
- Page 5 Safety READ AND SAVE THESE INSTRUCTIONS WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: ◼ Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer at the address or telephone number listed in the warranty.
- Page 6 Safety WARNING TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE: 1) Never leave surface units unattended at high settings. Boil overs cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium settings. 2) Always turn hood ON when cooking at high heat or when flambeing food.
- Page 7 Safety CAUTION ◼ For indoor use only. ◼ For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors. ◼ To avoid motor bearing damage and noisy and/or unbalanced fan blade, keep drywall spray, construction dust, etc. off range hood. ◼...
- Page 8 Specifications Voltage 120V/60Hz Power of Motor 1 x 200W Power of lamps 2 x 1.5W Cable length 1.5M 29.53*19.69*26.69-41.34(inch) Appliance Dimension (W x D x H) Note: The manufacturer reserves the right to change any technological improvement or modification without prior notice. Components...
- Page 9 Installation Prepare for installation: a) If you have an outlet to the outside, your cooker hood can be connected as below picture by means of an extraction duct (enamel, aluminum, flexible pipe or inflammable material with an interior diameter of 4.72"). Choose a straight, short duct run to allow the hood to perform most efficiently.
- Page 10 Installation Recommended Tools for Installation • Measuring tape • Phillips screwdriver no. 2 • Flat blade screwdriver (to open knockout holes) • Drill, 1/8” drill bit and 1½” hole saw (to mark holes for ducting and cut electrical access hole) •...
- Page 11 Installation Install the Hood（VENT OUTSIDE）: 1) If present, remove all protective poly film from the hood and/or parts. 2) Below is the 1:1 installation diagram: 3) According to the 1:1 installation diagram, Drill 3*Ø0.31" holes to accommodate the bracket. Screw and tighten the bracket onto the wall with the Wall plugs &...
- Page 12 Installation 4) Hang the cooker hood onto the wall bracket. 5) Take out the grease filter, find the two positioning holes inside the case in the figure, mark with pen respectively, and then take down the cooker hood. 6) Drill two 0.32” holes in the marked position on the wall with an electric drill, and then put the Wall plug in.
- Page 13 Installation 7) Hang the cooker hood on the wall bracket again. After that, use two 0.16"x1.18" screws to lock the corresponding positioning in the figure. 8) Put the Aluminum Flex Pipe on the air outlet of the cooker hood and fix the tube with the Cable Ties.
- Page 14 Installation 10) Put the Lower Decorative Chimney on the cooker hood. Use a pen to mark the orifice of the Lower Bracket on the wall, and then take down the Lower Decorative Chimney. Drill 2*Ø0.32" holes in the marked position on the wall with an electric drill, and then put the wall plug in.
- Page 15 Installation 13) Put the Upper Decorative Chimney into the Lower Decorative Chimney, Fix the Upper Decorative Chimney on the Upper Chimney Bracket by 2 screws (0.16"x0.32"). NOTE: ➢ Connect ductwork to hood and use Cable Ties to make joints secure and air-tight.
- Page 16 Installation Activated Carbon Filter Installation（VENT INSIDE）: If you do not have an outlet to the outside, exhaust pipe is not required and the installation is similar to the one shown in section “Installation (Vent outside)” 1. Activated carbon filter can be used to trap odors. In order to install the activated carbon filter, the grease filter should be detached first.
- Page 17 Operation Always turn your hood on before you begin cooking to establish an air flow in the kitchen. Let the blower run for a few minutes to clear the air after you turn off the range. This will help keep the whole kitchen cleaner and fresher. Touch control Operate the hood as follows: Power key:...
- Page 18 Operation Delay function: When cooker hood working, could set delay function. Push first time and indicator show1, for delaying 5 minutes; Push second time and indicator show 2, for delaying 10 minutes; Push third time and indicator show 3, for delaying 15 minutes; Push fourth time and indicator show 4, for delaying 20 minutes;...
- Page 19 Cleaning and Maintenance Proper maintenance of the Range Hood will assure proper performance of the unit. MOTOR The motor is permanently lubricated and never needs oiling. If the motor bearings make excessive or unusual noise, replace the motor with the exact service motor.
- Page 20 Cleaning and Maintenance Don't: ⚫ Use any steel or stainless steel wool or any other scrapers to remove stubborn dirt. ⚫ Use any harsh or abrasive cleansers. ⚫ Allow dirt to accumulate. ⚫ Let plaster dust or any other construction residues reach the hood. During construction/ renovation, cover the range hood to make sure no dust sticks to the stainless steel surface.
- Page 21 Cleaning and Maintenance 1. If need to replacement the LED lamp, the grease filter should be detached first. Press the lock and pull it downward. 2. Push the LED lamp holder out from the cabinet by hand, pull out the LED lamp and the wire together, open the power protection cover, pull out the plug and replace the LED lamp of the corresponding model.
- Page 22 Customer Care Service Replace the damaged Light bars are blown out light Lights are not working Light bar connection are Reset the connection loose If problem persists after the above checks, please contact CIARRA Customer Care Centre for assistance.
- Page 23 Environmental protection Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
