- Page 1 INSTALLATION AND USER’S MANUAL...
-
Page 2: Table Of Contents
CONTENTS Safety------------------------------------------------------------3-5 Specifications---------------------------------------------------6 Components-----------------------------------------------------6 Installation---------------------------------------------------7-13 Prepare For Installation---------------------------------7 Recommended Tools For Installation---------------8 Install The Hood--------------------------------------9-12 Activated Carbon Filter Installation-----------------13 Operation--------------------------------------------------------14 Cleaning and Maintenance----------------------------15-17 Motor Grease Filter Fan Blade Activated Carbon Filter Stainless Steel Cleaning Painted Finish Cleaning Bulb Replacement Troubleshooting ----------------------------------------------18 Environmental Protection----------------------------------19... - Page 3 Due to continuous development, we reserve the right to make technical changes including errors or other aberrations without notice. This is particularly true for measurements and cut-out dimensions respectively. Scan the QR code to get access to contact CIARRA Amazon Service if you have any question.
-
Page 4: Safety
Safety READ AND SAVE THESE INSTRUCTIONS WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: ◼ Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer at the address or telephone number listed in the warranty. - Page 5 Safety WARNING TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE: 1) Never leave surface units unattended at high settings. Boil overs cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium settings. 2) Always turn hood ON when cooking at high heat or when flambeing food.
- Page 6 Safety CAUTION ◼ For indoor use only. ◼ For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors. ◼ To avoid motor bearing damage and noisy and/or unbalanced fan blade, keep drywall spray, construction dust, etc. off range hood. ◼...
-
Page 7: Specifications
Specifications Voltage 110-120V~60Hz Power of Motor 1 x 200W 2 x 3W Power of lamps Cable length 1.2M 29.76*22.44*11.02(inch) Appliance Dimension (W x D x H) Note: The manufacturer reserves the right to change any technological improvement or modification without prior notice. Components... -
Page 8: Installation
Installation Prepare for installation: a) If you have an outlet to the outside, your cooker hood can be connected as below picture by means of an extraction duct (enamel, aluminum, flexible pipe or inflammable material with an interior diameter of 150mm). Choose a straight, short duct run to allow the hood to perform most efficiently. -
Page 9: Recommended Tools For Installation
Installation Recommended Tools for Installation • Measuring tape • Phillips screwdriver no. 2 • Flat blade screwdriver (to open knockout holes) • Drill, 1/8” drill bit and 1½” hole saw (to mark holes for ducting and cut electrical access hole) •... -
Page 10: Install The Hood
Installation Attention: Observe the warning in the instruction sheet concerning the operation of the appliance when air is discharged from the room. When the range hood and appliance supplied with energy other than electricity are simultaneously in operation, the negative pressure in the room must be not exceed 4 Pa (4×10 Bar). - Page 11 Installation 2) Install the wall plug, insert the upper two wall plugs with 0.24"*1.57" screws, do not lock too tight them first, and leave a gap of no less than 0.39" ; 3) Put the cooker hood onto the top two screws, and lock the screws tight; 4) Lock the lower two holes with 0.24"*1.57"...
- Page 12 Installation Way 2: 1) According to the 1:1 hole drawing of Way 2, mark the following positions with pencil under the cabinet, and use the drilling tool to open the air pipe hole and power cord hole in turn; 2) Align the air ventilation port of the cook hood with the cabinet ventilation hole at the bottom, pass the power cord through the power hole, and then use four 0.24"*1.57"...
- Page 13 Installation 3) Put the cooker hood onto the four screws, and lock the screws tight; 4) Lock the lower two holes with 0.24"*1.57" screws; 5) Put the Aluminum Flex Pipe on the air outlet of the cooker hood and fix the tube with the Cable Ties.
-
Page 14: Activated Carbon Filter Installation
Installation Activated Carbon Filter Installation（VENT INSIDE）: If you do not have an outlet to the outside, exhaust pipe is not required and the installation is similar to the one shown in section “Installation (Vent outside)” 1. Activated carbon filter can be used to trap odors. In order to install the activated carbon filter, the grease filter should be detached first. -
Page 15: Operation
Operation Always turn your hood on before you begin cooking to establish an air flow in the kitchen. Let the blower run for a few minutes to clear the air after you turn off the range. This will help keep the whole kitchen cleaner and fresher. Push button/Electronic button Operate the hood as follows: Off button... -
Page 16: Cleaning And Maintenance
Cleaning and Maintenance Proper maintenance of the Range Hood will assure proper performance of the unit. MOTOR The motor is permanently lubricated and never needs oiling. If the motor bearings make excessive or unusual noise, replace the motor with the exact service motor. -
Page 17: Painted Finish Cleaning
Cleaning and Maintenance Don't: ⚫ Use any steel or stainless steel wool or any other scrapers to remove stubborn dirt. ⚫ Use any harsh or abrasive cleansers. ⚫ Allow dirt to accumulate. ⚫ Let plaster dust or any other construction residues reach the hood. During construction/ renovation, cover the range hood to make sure no dust sticks to the stainless steel surface. - Page 18 Cleaning and Maintenance 1. If need to replacement the LED lamp, the grease filter should be detached first. Press the lock and pull it downward. 2. Push the LED lamp holder out from the cabinet by hand, pull out the LED lamp and the wire together, open the power protection cover, pull out the plug and replace the LED lamp of the corresponding model.
-
Page 19: Troubleshooting
Customer Care Service Replace the damaged Light bars are blown out light Lights are not working Light bar connection are Reset the connection loose If problem persists after the above checks, please contact CIARRA Customer Care Centre for assistance. -
Page 20: Environmental Protection
Environmental protection Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
