Yolink Valve Controller 2 Installation & User Manual

Hide thumbs

page of 53

/ 53
Bookmarks

Quick Links

Download this manual

Valve Controller 2

YS5003(S)-UC

KITS:

YS5003(S)-UC & BULLDOG

YS5003(S)-UC & DN##

Installation & User Guide

Revision Mar. 15, 2023

Need help?

Do you have a question about the Valve Controller 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Yolink Valve Controller 2

Page 1 Valve Controller 2 YS5003(S)-UC KITS: YS5003(S)-UC & BULLDOG YS5003(S)-UC & DN## Installation & User Guide Revision Mar. 15, 2023...
Page 2 . Get to Know Your Valve Controller 2 . Power Up . Install the App . Add Your Valve Controller 2 to the App . Install the Valve Controller 2 . Get to Know Your Bulldog Valve Robot . Install the Bulldog Valve Robot .
Page 3 Welcome! Thank you for purchasing YoLink products! We appreciate you trusting YoLink for your smart home & automation needs. Your 100% satisfaction is our goal. If you experience any problems with your installation, with our products or if you have any questions that this manual does not answer, please contact us right away.
Page 4 Before You Begin Visit our Valve Controller 2 support page on our website, for the latest installation guides, additional resources, information and videos by visiting: www.shop.yosmart.com/pages/valve- controller-2-product-support Or by scanning the QR code: Download the most current version of the user...
Page 5 What's Included YS5003(S) Items: Valve Controller 2 Plug-in Power Supply Phillips Head Screws(3) 4 x AA Batteries (Pre-Installed) Quick Start Guide...
Page 6 What's Included, Continued Bulldog Valve Robot Kit Items: 24-36x50 36-52x54 Bulldog Valve Robot Large & Small Brackets Motorized Valve Kit Items: Motorized Valve...
Page 7 Required Items These tools or items may be required: Wall Anchors Drill with Drill Bits Medium Phillips Screwdriver These items will be required to install the Bulldog Valve Robot: Medium Phillips Screwdriver...
Page 8 Required Items, Continued These items may be required to install the motorized valve: Pipe Wrench Locking Pliers Copper Pipe Cutting Tool Pipe Fittings/Adapters Thread Seal Tape Sandpaper Marker or Pencil...
Page 9 Get to Know Your Valve Controller 2 Keyhole Mounting Slot Status LED (See LED Behaviors, Below) SET Button Battery Housing Cover Mounting Hole 12VDC Input Cable Valve Status Cable (YS5003S, Only) Valve Control Cable LED Behaviors Blinking Red Once, Slow Blinking Green Then Green Once Twice Device Start-Up...
Page 10 Power Up Power up the Valve Controller 2 by briefly pressing the SET button, until the LED flashes (red, then green). SET button...
Page 11 Install the App If you are new to YoLink, please install the app on your phone or tablet, if you have not already. Otherwise, please proceed to the next section. Scan the appropriate QR code below or ﬁnd the “YoLink app” on the appropriate app store.
Page 12 Add Your Valve Controller 2 to the App 1. Tap Add Device (if shown) or tap the scanner icon: Scanner icon 2. Approve access to your phone’s camera, if requested. A viewﬁnder will be shown on the app. 3. Hold the phone over the QR code so that the code appears in the viewﬁnder.
Page 13 Add Your Valve Controller 2 to the App, Continued 4. You can change the device name and assign it to a room later. Tap Bind device. 5. If successful, the screen will appear as shown. Tap Done.
Page 14 The Valve Controller 2 was designed to be wall-mounted, at an indoor or outdoor location. If installing your Valve Controller 2 and/or valve device at an outdoor location, please ﬁrst refer to the environmental range speciﬁcations, found on the Valve Controller 2 product support page of our website.
Page 15 Install the Valve Controller 2, Continued With the use of optional extension cables, the valve controller can be installed remotely from the Bulldog or motorized valve. In some cases this may allow placing the controller at a more convenient or more accessible location (for battery replacement, etc.).
Page 16 Install the Valve Controller 2, Continued 3. Insert a screw in the top mounting hole location, but do not screw it flush with the wall; leave space on the end of the screw for the valve controller. 4. Hang the valve controller on this screw, and it should be level on the wall.
Page 17 Get to Know Your Bulldog Valve Robot Clutch Pin Handle and Position Indicator Mounting Tab Rocker Arm Handle-Supporting Bolt Output Shaft of Bulldog Brackets Valve Control Cable Valve Status Cable (YS5003S Only) Please note: the existing ball valve must be in good working order.
Page 18 Install the Bulldog Valve Robot 1. Select the appropriate bracket for your application. The appropriate bracket ﬁts over the ball valve (where it is connected to the pipe) and can subsequently be tightened securely to the ball valve. If the bracket does not ﬁt over the ball valve, or seems to be too loose, try the other bracket.
Page 19 Install the Bulldog Valve Robot, Continued 3. Place the upper bracket and lower bracket on the valve, as shown, and loosely tighten the screws. Important! The bracket must be mounted to the ball valve, not to the pipe. The ball valve should have at least one side shaped like a nut or bolt head.
Page 20 Install the Bulldog Valve Robot, Continued 4. Position the bracket so that it is aligned with the pivot point of the ball valve, by visualizing a line between the tab slot and the pivot point, as shown. Tab Slot Pivot Point 5.
Page 21 Install the Bulldog Valve Robot, Continued 6. Keeping the center axis of the Valve Robot’s motor shaft aligned with the ball valve shaft, as indicated by the red dashed line, reinsert and tighten the tab slot screw. If it is not possible to align the parts as shown, or if the bracket can not be secured to the ball valve, consider rotating the ball valve handle 180°.
Page 22 Install the Bulldog Valve Robot, Continued 7. Securely tighten the two screws on the brack- et. Gently tug on the Bulldog, and tighten the screws until the Bulldog is ﬁrmly held in place by the bracket and tab screw. 8. Remove the nuts and collars from the two handle supporting bolts, as shown.
Page 23 Install the Bulldog Valve Robot, Continued 9. Place the bolts in the slot on the rocker arm, with one on each side of the valve handle, as shown. 10. Put the collars back on the bolts. Holding them in place with one hand, insert the bottom supporting bracket over the end of each bolt, as shown.
Page 24 Final Connections 1. Connect the valve controller’s valve control cable (2-pin) to the control cable of the Bulldog Valve Robot. Ensure the arrow of the cable connector aligns with the arrow of the other cable connector. Twist the collar of the connector tight.
Page 25 Manual Operation It is recommended to always use the app or the valve controller SET button to operate the Bulldog Valve Robot. If you need to manually operate the Bulldog without using the app, you can press the SET button on the valve controller. If you need to operate the Bulldog Valve Robot without using the valve controller, you can do so by depressing the clutch pin as shown below.
Page 26 Testing 1. Test the Valve Controller 2 and Bulldog Valve Robot by pressing the SET button on the controller, and by watching the closing or opening action of the Bulldog and the ball valve. The valve should open and close completely (verify no water is flowing through the valve while closed).
Page 27 Troubleshooting Problem: The valve controller is offline Possible Solutions: Ensure the Valve Controller 2 is on. Repeat the Power Up section steps, if needed Replace the batteries Problem: The valve controller does not respond to the SET button being pressed and/or the Bulldog Valve...
Page 28 Troubleshooting, Continued Problem: The Bulldog Valve Robot moves or slides off of the ball valve while in operation Possible Solution: Ensure the Bulldog’s bracket is mounted to the correct (non-round) part of the ball valve, and is tightly secured to the ball valve. Return to the installation section, if needed Problem: The Bulldog Valve Robot does not close the...
Page 29 Troubleshooting, Continued Problem: The valve is indicated as closed in the app, but it is actually open (or vice versa) Possible Solution: Non-valve-status controllers only: disconnect the valve controller from the Bulldog. Manually operate the Bulldog, moving it to the open position if it was closed, and to the closed position if it was open.
Page 30 Get to Know Your Motorized Valve The valve included in this kit is a 12V DC non-smart motorized valve. Use only this valve or YoLink-approved valve control products, such as the Bulldog Valve Robot. Do not use with non-YoLink valve products. Manual Control Knob...
Page 31 This location must be within reach of the cables of the Valve Controller 2 (see Install the Valve Controller 2 section, on page 12. Ensure that there is physical room for the...
Page 32 Install the Motorized Valve, Continued 1. Shut-off the water serving the pipe where the valve is to be installed. Drain the water from the pipe, by turning on a faucet, or by other method as required. 2. Depending on the adapter ﬁtting used, measure the length of pipe that must be cut, and mark the cut lines on the pipe, as shown below.
Page 33 Install the Motorized Valve, Continued 3. Cut the water pipe through the mark using a pipe cutting tool, then remove the cut section of pipe, as shown below. 4. Sand both ends of cut pipe, removing any burrs or rough edges. Use care handling the cut edges, which may be sharp! Wipe off the cut section of pipe with a clean cloth.
Page 34 Install the Motorized Valve, Continued 6. Wrap each adapter’s threaded end with thread seal tape, per the tape manufacturer’s instruc- tions, as shown below. 7. Install the Motorized Valve on the adapter ﬁttings, ensuring a secure connection at each ﬁtting, as shown below. 8.
Page 35 Final Connections 1. Connect the valve controller’s valve control cable (2-pin) to the control cable of the motorized valve. Ensure the arrow of the cable connector aligns with the arrow of the other cable connector. Twist the collar of the connector tight.
Page 36 Manual Operation It is recommended to always use the app or the valve controller’s SET button to operate your motorized valve. Lift the knob on the top of the motorized valve and turn it by hand, until it can not be turned. Check the valve position indicator.
Page 37 (the water flowing through the valve may make an audible sound). Check that no water flows from an open faucet served by this valve. 2. Test the operation of the Valve Controller 2 from the app. From the Rooms Favorite...
Page 38 Troubleshooting Problem: The valve controller is offline Possible Solutions: Ensure the Valve Controller 2 is on. Repeat the Power Up section steps, if needed Replace the batteries Problem: The valve controller does not respond to the SET button being pressed and/or the Motorized Valve...
Page 39 Troubleshooting, Continued Problem: The valve is indicated as closed in the app, but it is actually open (or vice versa) Possible Solution: Non-valve-status controllers only: disconnect the valve controller from the Motorized Valve. Manually operate the Motorized Valve, moving it to the open position if it was closed, and to the closed position if it was open.
Page 40 YoLink Control-D2D is our unique device-to-device control technology. Using Control-D2D, compatible YoLink devices can control or be controlled by other YoLink devices, without a hub or internet connection. One device can control another device, directly. A device that controls or sends out commands is called the controller.
Page 41 SET Button (5-10 seconds) 2. To conﬁgure the Valve Controller 2 as a responder, ﬁrst ensure that the valve or Bulldog is in the closed position. Press and hold the controller’s SET button for 5-10 seconds until the LED quickly blinks green, then release the button.
Page 42 SET button for 10-15 seconds, until the LED quickly blinks green then red, then release the button. 2. At the Valve Controller 2, press and hold the SET button for 10-15 seconds, until the LED quickly blinks green then red, then release the button.
Page 43 Using the App & 3rd-Party Services Please visit our website’s Support page for the YoLink app guide and for product-speciﬁc app settings and instructions: www.yosmart.com/support-and-service Factory Reset Factory reset will erase device settings and restore it to factory default settings. Doing a...
Page 44 Firmware Update Your YoLink products are constantly being improved, with new features added. It is periodically necessary to make changes to your device's ﬁrmware. For optimal performance of your system, and to give you access to all available features for your devices, these ﬁrmware updates should be installed when they...
Page 45 Battery Replacement 1. Using a Phillips screwdriver, loosen the four battery cover screws, and remove the battery compartment cover. 2. Remove all four batteries.
Page 46 AA batteries 4. Replace the battery compartment cover and tighten the screws. 5. In the app, verify the Valve Controller 2 is online and the batteries are indicated as good. The Valve Controller 2 can be powered by alka- line or lithium-ion batteries.
Page 47 Warnings Please install, operate and maintain the Valve Controller 2 (and Motorized Valve or Bulldog Valve Robot) only as outlined in this manual. Improper installation or use may damage the unit and/or void the warranty. Do not install or use the device outside of the temperature and humidity range listed in the environmental speciﬁcations.
Page 48 Warnings, Continued Power the controller only with new AA alkaline or lithium-ion batteries. Do not use rechargeable batteries, do not use other type batteries (e.g. zinc blend). Do not mix old and new batteries. If storing the controller for extended periods, remove the batteries.
Page 49 1 year from the date of purchase for motorized valves and the Bulldog Valve Robot and for 2 years from the date of purchase for the Valve Controller 2. The warranty does not cover abuse or misused products, nor does this warranty apply to products that have been improperly installed, were modiﬁed, or put to a use other than...
Page 50 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 51 FCC Statement, Continued PRODUCT NAME: Valve Controller 2 PARTY: YOSMART, INC. TELEPHONE: 831-292-4831 MODEL NUMBER: YS-5003-UC ADDRESS: 15375 BARRANCA PKWY SUITE J-107, IRVINE, CA 92618 USA EMAIL: SERVICE@YOSMART.COM...
Page 52 IC Caution -English: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
Page 53 Contact Us We are here for you, if you ever need any assis- tance installing, setting up or using a YoLink app or product! Need help? For fastest service, please email us 24/7 at service@yosmart.com Or call us at 831-292-4831 (US phone support hours: Monday - Friday, 9AM to 5PM Paciﬁc)
