Reference Manual

BOX Computer

BX-T5000-G Series

CONTENTS

Introduction .................................................................. 4

Safety Precautions .................................................... 11

Product Nomenclature and Function ............... 18

Hardware Setup ........................................................ 32

BIOS Setup .................................................................. 43

Appendix ...................................................................... 87

List of Optional Products .................................... 105

Customer Support And Inquiry ........................ 107

Need help?

Do you have a question about the BX-T5000-G Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Contec BX-T5000-G Series

Page 1 Reference Manual BOX Computer BX-T5000-G Series CONTENTS Introduction ..............4 Safety Precautions ............ 11 Product Nomenclature and Function ....18 Hardware Setup ............32 BIOS Setup ..............43 Appendix ..............87 List of Optional Products ........105 Customer Support And Inquiry ......107...
Page 2 Table of Contents Introduction ..............4 1. Related Manuals ..............................5 2. About The Product ..............................6 3. Product Lineup ................................7 4. Features ..................................8 5. Supported OS ................................9 6. Product Configuration List ..........................10 Safety Precautions ............11 1. Safety Information ............................... 12 2.
Page 3 Table of Contents 4. Attaching The Antennas ..........................37 5. Fastening The Cable ............................. 38 6. Attaching The VESA Mount Parts ......................39 7. Installation Requirements .......................... 41 BIOS Setup ..............43 1. Before Configuring BIOS Settings ......................... 44 1. Using Aptio Setup Utility ..........................45 2.
Page 4 Introduction This section provides necessary information of the product such as the outline, bundled items and manuals before actual use. - 4 -...
Page 5 Read this when operating This describes the hardware Reference Manual Download from the product. aspects such as functions and the CONTEC settings. website (PDF) ◆ Download Manuals Download the manuals accordingly from the following URL. https://www.contec.com/download/ Download - 5 -...
Page 6 IoT gateway devices for connecting to peripherals. Embedded-type CPU has been adopted. The use of readily available parts ensures the product to be applied easily. In addition, CONTEC-customized BIOS allows support to be provided at the BIOS level.
Page 7 — — Introduction BX-T5000 Series Reference Manual 3. Product Lineup The product has Two models. Model Memory Storage device BX-T5000-G3200000 Core i5-1345URE DDR5 8GB None *1 None *2 BX-T5000-G2200000 Core i3-1315URE DDR5 8GB *1: Operating system provided: Windows 11 IoT Enterprise LTSC 2024 (Japanese / English / Chinese / Korean) For more detailed requirements, please contact the regional agent *2: For storage device and operating system configuration service needs, please contact the regional agent - 7 -...
Page 8 *2 It is the actual measured value when Windows 11 and HORM function are enabled at the factory. Time may vary depending on configuration. Note that ME, TPM, Network Stack, and SMART Self Test are not supported when the CONTEC Fast Boot is enabled.
Page 9 — — Introduction BX-T5000 Series Reference Manual 5. Supported OS Windows11 IoT Enterprise LTSC 2024 (Japanese / English / Chinese / Korean) - 9 -...
Page 10 — — Introduction BX-T5000 Series Reference Manual 6. Product Configuration List The product consists of the items listed below. Check, with the following list, that your package is complete. If you discover damaged or missing items, contact your retailer. BX-T5000-GX200000 [Base Model] Name Pcs.
Page 11 Safety Precautions Understand the following definitions and precautions to use the product safely. Never fail to read them before using the product. - 11 -...
Page 12 — — Safety Precaution BX-T5000 Series Reference Manual 1. Safety Information This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely. Signal word used to indicate an imminently hazardous situation which, DANGER if not avoided, will result in death or serious injury.
Page 13 To prevent corruption of files, always shut down the OS before turning off this product. ⚫ CONTEC reserves the right to refuse to service a product modified by the user. ⚫ - 13 -...
Page 14 — — Safety Precaution BX-T5000 Series Reference Manual In the event of failure or abnormality (foul smells or excessive heat generation), unplug the ⚫ power cord immediately and contact your retailer. To connect with peripherals, use a grounded, shielded cable. ⚫...
Page 15 — — Safety Precaution BX-T5000 Series Reference Manual 1. FCC PART 15 Class A Notice NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 16 — — Safety Precaution BX-T5000 Series Reference Manual 3. Display Marking Display of power (Input Rating Display of functional earth Display of Hot surface Label) terminal DC power supply Functional earth terminal Hot surface - 16 -...
Page 17 — — Safety Precaution BX-T5000 Series Reference Manual 3. Security Warning When connecting to the network, be aware of security-related problems. See the examples of Security measures below and set up the product properly along with the network devices. 1. Information Security Risks Unauthorized access from the outside through a network could cause the system to halt data ⚫...
Page 18 Product Nomenclature and Function This section describes product component names and their functions, pin assignment of each connector. - 18 -...
Page 19 — — Product Nomenclature and Function BX-T5000 Series Reference Manual 1. Nomenclature Of Product Components Component names of the product are shown in the figure below. ◆ Front ◆ Side Name Function Front MIC IN & LINE OUT Mic in, Line out (3.5φ PHONE JACK) POWER LED Power ON display LED HDMI...
Page 20 — — Product Nomenclature and Function BX-T5000 Series Reference Manual 2. Description Of Product Components Components such as connectors, switches are described. 1. DC Power Input Connector: DC-IN The DC power input connector is provided. Rated input voltage : 12 - 24VDC Input voltage range: 10.8 –...
Page 21 FLASHING, ON (Red) LED operation can also be controlled from user applications. *1 *1 CONTEC Manager that controls STATUS LED is available. (It is already installed for the product OS pre-installed type when shipped from the factory) CONTEC Manager can be downloaded through the CONTEC's Web site. For more detailed information, contact your retailer.
Page 22 — — Product Nomenclature and Function BX-T5000 Series Reference Manual 6. USB 3.2 Gen2 Ports: USB3.2 Gen2(USB3.1) This product is equipped with 4 ports for USB 3.2 Gen2(USB3.1) TYPE-A interface. USB3.2 Gen2 Connector Pin No. Signal Name USB_VCC DATA- DATA+ USB_GND SSRX- SSRX+...
Page 23 — — Product Nomenclature and Function BX-T5000 Series Reference Manual 8. CFast Card Connector: CFast The CF Card (Type I : dedicated to the memory card) can be connected. CFast Card Connector Connector used on the product CFast Card Connector Pin No.
Page 24 — — Product Nomenclature and Function BX-T5000 Series Reference Manual 9. DisplayPort Interface: Display port The product is equipped with a connector for a DisplayPort interface. DisplayPort connector Connector used on the product Display Port 20-pin Pin No. Signal name Pin No.
Page 25 — — Product Nomenclature and Function BX-T5000 Series Reference Manual 10. DisplayPort Interface: HDMI The product is equipped with a connector for HDMI connections. DisplayPort connector Connector used on the product HDMI 19Pin Pin No. Signal name Pin No. Signal name HDMI DATA2(+) HDMI DATA2(-) HDMI DATA1(+)
Page 26 — — Product Nomenclature and Function BX-T5000 Series Reference Manual 11. Giga Bit-Ethernet: LAN A, B, C This product is equipped with 3 ports for giga bit-Ethernet. Network type 2.5GBASE-T/1000BASE-T/100BASE-TX/10BASE-T ⚫ Transmission speed * 2.5G/1000M/100M/10M bps ⚫ Max. network path length : 100m/segment ⚫...
Page 27 — — Product Nomenclature and Function BX-T5000 Series Reference Manual 12. Serial Port Interface: SERIAL A, B This product has 2 ports of RS-232C compliant serial ports supporting up to a baud rate of 115,200bps with a 16-byte transmission-dedicated data buffer and a 16-byte reception-dedicated data buffer.
Page 28 — — Product Nomenclature and Function BX-T5000 Series Reference Manual Serial A port connector Connector used on the product 9-pin D-SUB (Male) Pin No. RS-232C RS-422 RS-485 DATA- DATA+ RTS- RTS+ CTS+ CTS- Serial B port connector Connector used on the product 9-pin D-SUB (Male) Pin No.
Page 29 This product is equipped with a remote power switch and 6 ports for non-isolated general I/O. * CONTEC Manager is necessary to use the General I/O. (It is already installed for the product OS pre-installed type when shipped from the factory.) CONTEC Manager can be downloaded through the CONTEC's Web site.
Page 30 — — Product Nomenclature and Function BX-T5000 Series Reference Manual ◆ Equivalent circuit ◆ When selecting inputs (an example of connecting the product to a switch) When the switch is “ON”, the relevant bit indicates “0”. When the switch is “OFF”, the relevant bit indicates “1”. ◆...
Page 31 — — Product Nomenclature and Function BX-T5000 Series Reference Manual 14. Antenna Connector: ANT1, ANT2 The product is equipped with two connectors for antennas. Even with one antenna connection, the wireless LAN communication can be performed. See the following table for the specification. Setting a terminator is not necessary if you do not use antennas.
Page 32 Hardware Setup This section describes how to install, connect, and set up the product. - 32 -...
Page 33 — — Hardware Setup BX-T5000 Series Reference Manual 1. Before Using The Product For The First Time Follow the next steps to set up this product: STEP1 By referring to the information in this section, install, connect and set up this product. STEP2 Connect cables.
Page 34 — — Hardware Setup BX-T5000 Series Reference Manual 2. Hardware Setup Before you start, be sure that the power is turned off. ⚫ Remove only those screws that are explained. Do not move any other screws. ⚫ 1. Attaching The Attachment Fittings Use supplied screws to attach the bundled attachment fittings.
Page 35 — — Hardware Setup BX-T5000 Series Reference Manual 2. Attaching The FG Use screws to attach the FG. CAUTION The FG pin of this product is connected to the GND signal. Note that the connection cannot be cut off. Screw holes may be damaged if screws are tightened with a torque greater than the specified torque.
Page 36 — — Hardware Setup BX-T5000 Series Reference Manual 3. Attaching The CFast Attachment Fittings After inserting a CFast Card, fasten the CFast attachment fittings with a screw. CAUTION Insert the CFast Card face up. ⚫ Screw holes may be damaged if screws are tightened with a torque greater than the specified ⚫...
Page 37 — — Hardware Setup BX-T5000 Series Reference Manual 4. Attaching The Antennas Insert the included antennas into the antenna connectors (ANT1, ANT2) on the side of the product, and turn the antennas in the directions indicated below to attach. CAUTION Make sure the antennas are securely attached.
Page 38 — — Hardware Setup BX-T5000 Series Reference Manual 5. Fastening The Cable This product comes with clamps for fixing cables and USB removal prevention fitting. Fastening the Audio, USB Cable Using a cable clamp and USB removal prevention fitting for a cable with lock-less connector, such as the Audio and USB Cable, prevents the connector from being unplugged.
Page 39 — — Hardware Setup BX-T5000 Series Reference Manual 6. Attaching The VESA Mount Parts This product conforms to the VESA standard. To attach the VESA PLATE and the VESA mount parts "BX-BKT-VESA02" (optional accessory), see the images below and follow the instruction. *1: The length of the screws for VESA mounting should be shorter than (VESA PLATE thickness + 5mm).
Page 40 — — Hardware Setup BX-T5000 Series Reference Manual Use the screws (M3×6) included with the product. If using screws other than those included, be sure to limit the penetration length L (from the enclosure surface to the tip of the screw) to 4 mm or less.
Page 41 — — Hardware Setup BX-T5000 Series Reference Manual 7. Installation Requirements Increase the distance from devices that generate heat or exhaust air or take other measures to ensure the ambient temperature falls within the range specified in the environment requirements. Installation direction for ambient operating temperatures of -20°C to +60°C ⚫...
Page 42 — — Hardware Setup BX-T5000 Series Reference Manual Distances between the BOX-PC and its vicinity (Exemplar) Ambient temperature In this product, the ambient temperature is decided from the multiple measurement points as shown below. When making use of the product, the air current should be adjusted to prevent that all the temperatures measured at the measurement points exceed the specified temperature.
Page 43 BIOS Setup This section describes how to configure, change, and check BIOS settings used to manage basic computer information. - 43 -...
Page 44 — — BIOS Setup BX-T5000 Series Reference Manual 1. Before Configuring BIOS Settings The BIOS software controls the hardware required for booting the system. The default BIOS settings are configured for optimal performance under normal use. These default settings are recommended under the following circumstances.
Page 45 — — BIOS Setup BX-T5000 Series Reference Manual 1. Using Aptio Setup Utility This section explains how to use Aptio Setup Utility. ◆ Starting the Setup Utility While the BIOS is in control, the Setup program can be activated in one of two ways: By pressing <Del>...
Page 46 — — BIOS Setup BX-T5000 Series Reference Manual ◆ Key Operations Use the following keys to operate the setup utility. Function Up Arrow Move to the previous item Down Arrow Move to the next item Left Arrow Move to the item on the left (menu bar) Right Arrow Move to the item on the right (menu bar) Main Menu: Quit without saving changes...
Page 47 — — BIOS Setup BX-T5000 Series Reference Manual Discard Changes and Exit Exit Aptio Setup Utility without saving the changed settings Press the <Esc> key or select “Discard Changes and Exit” in the “Save & Exit” menu screen. The following message will be displayed. Select [Yes] and press the <Enter>...
Page 48 — — BIOS Setup BX-T5000 Series Reference Manual 2. Setup Utility Menu Once you enter the Aptio Setup Utility, the Main Menu will appear on the screen. By pressing the left or right arrow keys, you will be able to move the tab of each item. (Actual display may differ) 1.
Page 49 — — BIOS Setup BX-T5000 Series Reference Manual Save & Exit Use this menu to load or save the setup item and to exit the setup menu. - 49 -...
Page 50 — — BIOS Setup BX-T5000 Series Reference Manual 2. Main Menu Use the Main menu to configure basic system settings. The setting items are shown below. (Actual display may differ) You can configure the following settings. Main Menu Selections Item Options Description System Date...
Page 51 — — BIOS Setup BX-T5000 Series Reference Manual 3. Advanced Menu Use the Advanced menu to configure the settings for the CPU and other devices on the motherboard. The setting items are shown below. Power & Performance CPU-Power Management Control Options PCH-FW Configuration Use this menu to check the Intel®...
Page 52 — — BIOS Setup BX-T5000 Series Reference Manual Hardware Monitor Use this to check information such as the CPU temperature. RTC Wake Settings The system wakes up on alarm event settings USB Configuration USB Configuration Parameters Network Stack Configuration Use this menu to configure the network stack settings. NVMe Configuration This device is not equipped with NVMe.
Page 53 — — BIOS Setup BX-T5000 Series Reference Manual ◆ Power & Performance Configure the CPU settings. CPU - Power Management Control Use this menu to check the CPU settings GT - Power Management Control Use this menu to check the GPU settings. - 53 -...
Page 54 — — BIOS Setup BX-T5000 Series Reference Manual CPU - Power Management Control Item Options Description Turbo Performance Boot performance mode Do not change this setting. Race To Halt (RTH) Disabled / Enabled Do not change this setting. Intel(R) Speed Shift Technology Disabled / Enabled Do not change this setting.
Page 55 — — BIOS Setup BX-T5000 Series Reference Manual GT - Power Management Control Item Options Description RC6(Render Standby) Disabled / Enabled Do not change this setting. Default Max Frequency / 100Mhz / 150Mhz / Maximum GT frequency Do not change this setting. 200Mhz …...
Page 56 — — BIOS Setup BX-T5000 Series Reference Manual ◆ PCH-FW Configuration Use this menu to check the Intel® Management Engine (ME) settings. PCH-FW Configuration Item Options Description ME State Disabled / Enabled Do not change this setting. - 56 -...
Page 57 — — BIOS Setup BX-T5000 Series Reference Manual ◆ Trusted Computing Use this menu to configure the Trusted Computing. Trusted Computing Item Options Description Enables or Disables BIOS support for security Security Device Support Disabled / Enabled device SHA256 PCR Bank Disabled / Enabled Enable or Disable SHA256 PCR Bank.
Page 58 — — BIOS Setup BX-T5000 Series Reference Manual ◆ ACPI Settings Set the ACPI power management. ACPI Settings Item Options Description Disabled / Enabled Configure the Enable Hibernation function settings. Enable Hibernation Suspend Disabled Selecting the highest ACPI sleep state the system will ACPI Sleep State / S3 (Suspend to RAM) enter when the SUSPEND button is pressed.
Page 59 — — BIOS Setup BX-T5000 Series Reference Manual ◆ RAS Configuration RAS Configuration Settings. RAS Configuration Item Options Description Set the auto-recovery function for resetting WDT during boot of BIOS Disabled / Enabled the system if it freezes during BIOS startup. Normally set this to Enabled Enabled or disabled WDT function during WDT during boot of OS...
Page 60 — — BIOS Setup BX-T5000 Series Reference Manual ◆ SMART Settings Use this menu to check the SMART settings. SMART Settings Item Options Description Perform a SMART Self Test on SATA devices during SMART Self Test Disabled / Enabled POST. - 60 -...
Page 61 — — BIOS Setup BX-T5000 Series Reference Manual ◆ NCT6216D Super IO Configuration Use this menu to configure the operation settings for Super IO. Super IO Configuration Item Description Serial Port A Configuration Configure the operation settings for serial port A. Serial Port B Configuration Configure the operation settings for serial port B.
Page 62 — — BIOS Setup BX-T5000 Series Reference Manual Item Options Description RS-485 is a half-duplex communication system, so transmission and reception are assigned to the same pins and must be controlled by RTS high/low. Set to Enabled to allow the hardware to automatically control the device without RS485 Auto Flow Control Disabled / Enabled...
Page 63 — — BIOS Setup BX-T5000 Series Reference Manual ◆ H/W Monitor Use this to check information such as the CPU temperature. (Actual display may differ) - 63 -...
Page 64 — — BIOS Setup BX-T5000 Series Reference Manual ◆ RTC Wake Settings Enable system to wake from S5 using RTC alarm. RTC Wake Settings Item Options Description Disabled / Fixed Configure the automatic power ON function, including Wake On RTC Time /Dynamic the automatic ON date/time.
Page 65 — — BIOS Setup BX-T5000 Series Reference Manual ◆ USB Configuration Settings Use this menu to configure the USB setting USB Configuration Item Options Description USB Mass Storage Driver Disabled / Enabled Configure the USB storage support settings. Support Set the USB power (5 V) status when entering the S5 state after shutting down the OS.
Page 66 Disabled / Enabled Enable IPv6 HTTP boot. Ipv4 PXE/HTTP Support (Only Available When "Enabled" Is Selected) Item Options Description Set the IPv4 access address when starting CONTEC Ipv4 Address 0 - 3 192.168.1.1 tools using network boot. - 66 -...
Page 67 — — BIOS Setup BX-T5000 Series Reference Manual ◆ NVMe Configuration ( When NVMe device is installed) NVMe Configuration Item Options Description Apply hardware write protection to the NVMe. This Write Protect setting is available only when using a supported Disabled / Enabled NVMe.
Page 68 — — BIOS Setup BX-T5000 Series Reference Manual ◆ Intel(R) Ethernet Controller I226-IT Use this menu to view the MAC address of the Ethernet controller and similar settings (Actual display may differ) - 68 -...
Page 69 — — BIOS Setup BX-T5000 Series Reference Manual 5. Chipset Menu Specify the detailed chipset functions. The following items are available. System Agent(SA) Configuration Use this menu to check the System Agent Configuration settings. PCH-IO Configuration Use this menu to specify the PCH-IO settings. - 69 -...
Page 70 — — BIOS Setup BX-T5000 Series Reference Manual ◆ System Agent (SA) Configuration Use this menu to configure the System Agent settings. System Agent (SA) Configuration Item Options Description Graphics Configuration Support the virtualization of the I/O VT-d Disabled / Enabled device.
Page 71 — — BIOS Setup BX-T5000 Series Reference Manual ◆ PCH-IO Configuration Use this menu to configure the PCH-IO settings. SATA Configuration Item Options Description SATA Controller(s) Disabled / Enabled Configure the SATA settings. SATA Mode Selection Disabled / Enabled Enable each port. Apply hardware and write protection to each Write Protect Disabled / Enabled...
Page 72 — — BIOS Setup BX-T5000 Series Reference Manual Item Options Description Wake on RI (COM2) Configure the Wake on RI (COMB) function Disabled / Enabled settings. BIOS Lock Enable or disable BIOS rewriting. Disabled / Enabled Set whether to start the system at the same time the power supply starts.
Page 73 — — BIOS Setup BX-T5000 Series Reference Manual 6. Security Menu Configure the security of the system settings. The following items are available. Administrator Password Set the Administrator Password. Press Enter to display the following screen for entering the password. Administrator Password Create New Password [****...
Page 74 — — BIOS Setup BX-T5000 Series Reference Manual CAUTION Be careful not to forget the password. If you forget the password, the product will have to be repaired at an extra cost. - 74 -...
Page 75 Enable this setting to prevent the startup and execution of anything Secure Boot other than UEFI apps authenticated by Disabled / Enabled Windows and Contec for construction of a more secure system. Secure Boot Mode Standard This setting cannot be changed.
Page 76 — — BIOS Setup BX-T5000 Series Reference Manual ◆ Logging Boot Configure the Logging Boot settings. Use these settings to save self-diagnosis logs to a USB memory device at startup. The USB memory device must be in FAT32 format. The log will be saved as a .csv file. Select whether to save the data at every startup, at the first startup of the day, or monthly on a specified day.
Page 77 — — BIOS Setup BX-T5000 Series Reference Manual Use the Log List menu to view the values stored in NVRAM. (Actual display may differ) The data will be saved to the USB memory device as a .csv file as shown below. (Actual display may differ) - 77 -...
Page 78 Disabled Link / Enabled Do not change this setting. Configure this setting for faster startup times. When this function is enabled, ME, TPM, CONTEC Fast Boot Disabled Link / Enabled Network Stack, and SMART Self Test cannot be used. Fast Boot Disabled Link / Enabled Do not change this setting.
Page 79 — — BIOS Setup BX-T5000 Series Reference Manual Item Options Description connected disk when the OS fails to start. XXXXXXXX Boot Option #x (Specify the arbitrary Set the start order of the connected devices. device) - 79 -...
Page 80 — — BIOS Setup BX-T5000 Series Reference Manual 8. Save & Exit Use this menu to save/restore BIOS settings and exit the setup utility. The setting items are shown below. (Actual display may differ) Save Changes and Exit Save the changed settings and exit. The system restarts if this is changed to a setting that requires restarting.
Page 81 Specify this setting when you want to temporarily start the system from a connected device other than those that have been set with the Boot Configuration menu. The bootable connecting devices are displayed. CONTEC Utility Use utilities that operate in the UEFI environment. See the next section for details and usage methods. - 81 -...
Page 82 — — BIOS Setup BX-T5000 Series Reference Manual ◆ CONTEC Utility Utility that runs on the UEFI environment can be used. The following items are available. Disk Copy Copy the disk and perform such functions as backup and restore. Memory Test Execute the Memory Test of the PASSMARK.
Page 83 — — BIOS Setup BX-T5000 Series Reference Manual Disk Copy Item Options Description Select Source Disk USBx: xxx Displays the names of the connected USB and M.2: xxx SATA devices. Select the copy source disk. CFast: xxx When Erase is selected, the entire disk selected as Erase the copy destination is filled with 0x00.
Page 84 — — BIOS Setup BX-T5000 Series Reference Manual Item Options Description every time a unit block is copied. If a mismatch occurs, the operation ends with an error. This option is not available when the copy mode is [Disk to Cab] or [Cab to Disk]. CAUTION Because copying is performed according to the capacity of the smaller disk with [Disk to ⚫...
Page 85 — — BIOS Setup BX-T5000 Series Reference Manual Self Inspection Use this menu item to perform self-inspection. (Actual display may differ) Self Inspection Item Option Description PCI Device Activity PASS Checks whether the expected PCI devices are FAIL present. [PASS] is displayed if all devices are present.
Page 86 Check whether the LAN EEPROM data is correct. FAIL Checking will not be possible if no LAN device is found. CONTEC MAC PASS Check whether the MAC data from CONTEC has FAIL been written. Unique MAC PASS Check whether the MAC data is unique in the FAIL actual device.
Page 87 Appendix This section lists the specifications and the physical dimensions of the product, and the details of model name. - 87 -...
Page 88 — — Appendix BX-T5000 Series Reference Manual 1. System Reference 1. Specifications Function Specifications Item Description BX-T5000-G3200000 Intel® Core™ i5-1345URE Processor 1.4GHz BX-T5000-G2200000 Intel® Core™ i3-1315URE Processor 1.2GHz BIOS BIOS (mfd. by AMI) Memory 1x DDR5 5600MHz SO-DIMM socket, up to 32GB (In-band ECC) Graphics Controller BX-T5000-G3200000 Intel...
Page 89 — — Appendix BX-T5000 Series Reference Manual Item Description Watchdog timer (WDT) Software programmable, 255 level (1sec - 255sec), Time up allows reset. Real Time Clock Lithium backup battery life: 10 years or more The real-time clock is accurate within ±3 minutes (at 25°C) per month (CPU built-in RTC).
Page 90 — — Appendix BX-T5000 Series Reference Manual Environment Requirements Item Description Operating Temperature *1 *2 -20 - +50°C no airflow -20 - +60°C airflow 0.7m/s Non-operating Ambient -20 - +60°C Temperature *1 Humidity 10 - 90%RH (No condensation) Floating Dust Particles Not to be excessive Corrosive Gases None...
Page 91 — — Appendix BX-T5000 Series Reference Manual 2. Physical Dimensions BX-T5000-Gxxxxxxxxx - 91 -...
Page 92 — — Appendix BX-T5000 Series Reference Manual 3. POST Codes POST (hex) Description < Security (SEC) phase > Power on. Reset type detection (software / hardware) AP initialization before microcode loading North Bridge initialization before microcode loading South Bridge initialization before microcode loading OEM initialization before microcode loading Microcode load AP initialization after microcode loading...
Page 93 — — Appendix BX-T5000 Series Reference Manual POST (hex) Description 3Ch - 3Eh Post-memory, South Bridge initialization (South Bridge module specific) 3Fh - 4Eh OEM post memory initialization codes DXE IPL is started < Driver Execution Environment (DXE) phase > DXE Core start is started NVRAM initialization Installation of the South Bridge Runtime Services...
Page 94 — — Appendix BX-T5000 Series Reference Manual POST (hex) Description SCSI initialization is started SCSI Reset SCSI Detect SCSI Enable Setup Verifying Password Start of Setup Reserved for ASL (see ASL Status Codes section below) Setup Input Wait Reserved for ASL (see ASL Status Codes section below) Ready To Boot event Legacy Boot event Exit Boot Services event...
Page 95 — — Appendix BX-T5000 Series Reference Manual 4. SERIAL I/O Address and Register Function ◆ I/O Port Addresses The following table lists the I/O addresses in case of SERIAL A. I/O address DLAB Read/Write Register Transmitter holding register 03F8H Receive buffer register Divisor latch register (LSB) Divisor latch register (MSB) 03F9H...
Page 96 — — Appendix BX-T5000 Series Reference Manual I/O address Description 03F9H 03FAH - 96 -...
Page 97 — — Appendix BX-T5000 Series Reference Manual I/O address Description 03FBH 03FCH - 97 -...
Page 98 — — Appendix BX-T5000 Series Reference Manual I/O address Description 03FDH 03FEH 03FFH SCR: Scratchpad Register This is an 8-bit, readable/writable register which is available to the user to allow data to be saved temporarily. - 98 -...
Page 99 — — Appendix BX-T5000 Series Reference Manual Baud Rate Settings A baud rate is set by software by dividing the clock input (1.8432MHz). The baud rate in terms of hardware can be set to a maximum of 115,200 bps for SERIAL A and B. The baud rates available in practice depend on the operating environment (cable, software, etc.).
Page 100 * It is also possible not to perform [WDT Stop] instead of performing [WDT Stop] to [WDT Start], but to perform [WDT Start] continuously at the time of a re-start. CONTEC Manager is necessary to use the watch-dog-timer. (It is already installed for the product OS pre-installed type when shipped from the factory.)
Page 101 — — Appendix BX-T5000 Series Reference Manual CONTEC Manager can be downloaded through the CONTEC's Web site. For more detailed information, contact your retailer. CAUTION The timer’s intervals have a tolerance of ±2 seconds. - 101 -...
Page 102 — — Appendix BX-T5000 Series Reference Manual 6. Battery Disposal 1. Battery Specification The product contains one battery, and the details are as follows: Item Description Type Lithium primary battery Model BR-2032/BN Maker Panasonic Nominal Voltage Nominal capacity 200mAh Lithium content 1gram or less - 102 -...
Page 103 — — Appendix BX-T5000 Series Reference Manual 2. Dispose Of The Battery WARNING For battery replacement, contact your retailer as it must be performed as a process of repair. ⚫ Do not attempt to replace the battery as inappropriate battery replacement poses a risk of ⚫...
Page 104 — — Appendix BX-T5000 Series Reference Manual 7. Life of SSD 1. About Write Endurance M.2 card (TLC) contained in the product has a write endurance which limits the number of times each memory may be written, due to the characteristic of the memory that is used. Write endurance can be calculated by the following formula as a reference value: Write endurance (years) = Total capacity (cycles) / (The number of annual consumed blocks / The total number of blocks)
Page 105 List of Optional Products This section lists optional items that can be used along with the product. - 105 -...
Page 106 Bracket for VESA (“75 x 75”, “100 x 100”) CAUTION If a product other than our optional one is used, the normal operation may be impaired or the functions may be limited. Visit the CONTEC website for the latest optional products. https://www.contec.com/ Download - 106 -...
Page 107 Customer Support And Inquiry CONTEC provides the following support services for you to use CONTEC products more efficiently and comfortably. - 107 -...
Page 108 — — Customer Support and Inquiry BX-T5000 Series Reference Manual 1. Services CONTEC offers the useful information including product manuals that can be downloaded through the CONTEC website. Download https://www.contec.com/download/ You can download updated driver software, firmware, and differential manuals in several languages. Membership registration (myCONTEC) is required to use the services.
Page 109 No part of this document may be copied or reproduced in any form by any means without ⚫ prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained ⚫ in this document.
Page 110 CONTEC CO., LTD. 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan https://www.contec.com/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. BX-T5000 Series Reference Manual NA10418 (LXEA851) [04152025]...
