- Page 1 EAP Start Guide © 2025 TP-Link 1910013944 REV1.0.0...
- Page 2 CONTENTS About This Guide ........................01 Related Documentation ............................01 More Resources ..............................01 Hardware Overview ......................02 Ceiling Mount Access Point ..........................02 Front Panel ..............................02 Rear Panel ............................... 03 Indoor/Outdoor Access Point ........................05 LED Explanation ............................07 Buttons & Ports ............................. 08 Wall Plate Access Point ............................09 LED Explanation ............................
- Page 3 About This Guide Omada offers scenario-based access points (hereinafter referred to as EAPs) for different kinds of environments. This document offers startup guidance for an EAP, including a detailed hardware overview and quick references for hardware installation and software configuration. Related Documentation The Quick Installation Guide can be found in the product packaging and on the Product Support page:...
- Page 4 Hardware Overview This chapter provides a detailed hardware overview of the EAP. Ceiling Mount Access Point Front Panel The EAP is equipped with a system LED that indicates the system status on the front panel. LED Status Indication • For EAPs with single-color LED: Working normally/Initializing.
- Page 5 Rear Panel The ports, buttons, and other parts are located on the rear panel and may vary by model. L-Key Slot Bracket Aligning Mark Bracket Aligning Mark RESET RESET Bracket Aligning Mark Cable Compartment Cover Cable Compartment Cover Removable Block Bracket Aligning Mark Note: For an AP with a Cable Compartment Cover, to avoid device damage, do not insert any objects into the holes for attaching the cover!
- Page 6 Removable Block (Only for certain models) Remove the block to route a cable if needed. Note: For EAPs with a 10 Gbps port, using a CAT5e cable limits the Ethernet port's 10 Gbps link to less than 55 meters. To achieve longer transmission distances, use a shielded CAT6A cable.
- Page 7 Indoor/Outdoor Access Point EAP603-Outdoor EAP610-Outdoor RESET Ethernet Grounding Port Terminal...
- Page 8 EAP668-Outdoor HD External Antennas External Antenna Connectors Grounding RESET ETH0 ETH1 SFP+ Terminal Button (PoE IN) (PoE OUT) Port EAP725-Outdoor External Antennas System LED Signal LEDs Grounding Terminal...
- Page 9 EAP772-Outdoor RESET Ethernet Grounding Button Port Terminal LED Explanation The EAP is equipped with a system LED that indicates the system status on the front or side panel. Some models may have signal LEDs at the side panel. • System LED LED Status Indication Flashes twice...
- Page 10 • Signal LEDs (Only for certain models) LED Status Indication The device works as the root AP. The device works as the mesh AP. More lit LEDs indicates better wireless signal strength. Buttons & Ports The ports and buttons are located on the bottom and may vary by model. Item Description RESET...
- Page 11 Wall Plate Access Point The EAP is equipped with a system LED that indicates the system status on the front panel. The port and button locations may vary by model. EAP230-Wall LED & LED Button Uplink Ethernet Port Downlink Ethernet Port RESET Button Faceplate...
- Page 12 EAP655-Wall RESET Button Button Uplink Ethernet Port Downlink Ethernet Port Faceplate Body Rear Panel EAP720-Wall RESET Button Button Uplink Ethernet Port Downlink Ethernet Port Faceplate Body Rear Panel EAP725-Wall RESET Button Button Uplink Ethernet Port Downlink Ethernet Port Faceplate Body Rear Panel...
- Page 13 LED Explanation LED Status Indication • For EAPs with single-color LED: Working normally/Initializing. • For EAPs with dual-color LED: White: Normal power supply Orange: Low power supply Working abnormally/Power off/LED is turned off. Flashes twice Initialization is complete. Flashing quickly The EAP is resetting, or the Omada controller is locating the device.* Flashing once per The EAP is updating the firmware.
- Page 14 GPON Access Point The GPON AP is equipped with a system LED and a GPON LED on the front panel. The ports and buttons are located on the side and rear panels and may vary by model. LED Button FXS LED Reset Button FXS Port GPON Port...
- Page 15 * When the Locate feature is activated in the Omada Controller, the LED will flash quickly for 10 minutes to help you locate and identify the device. You can disable this feature manually to stop the device from flashing. Buttons & Ports Button Description RESET...
- Page 16 Hardware Installation Omada offers scenario-based EAPs for different kinds of environments. This chapter provides quick references for hardware installation. Ceiling Mount Access Point The Ceiling Mount Access Point can be mounted to a ceiling, wall, or junction box. You can follow the Quick Installation Guide to install the EAP using the accessories in the product packaging.
- Page 17 Software Configuration Omada EAPs offer wireless coverage solutions for small to medium-sized businesses and households. They can work independently as standalone APs or be centrally managed via an Omada Controller, delivering a flexible, feature-rich, and easy-to-configure wireless network. Get Started Choose a method to set up your EAPs: •...
- Page 18 GPON AP Gateway SIP Server Switch Optical Splitter Clients Phone GPON AP • Method 2: Controller Mode Configure and manage EAPs (and other Omada devices) centrally with an Omada Controller. For instructions on how to get started with an Omada Controller, refer to https://www.
- Page 19 SIP Server Phone GPON AP Omada App With the TP-Link Omada app, you can access and manage your Omada devices at a local site or remotely with a tap of your phone. Scan for Omada App Omada App More Configurations...
