Summary of Contents for TP-Link Omada EAP
- Page 1 EAP Start Guide © 2025 TP-Link 1910013944 REV1.0.0...
- Page 2 CONTENTS About This Guide ........................01 Related Documentation ............................01 More Resources ..............................01 Hardware Overview ......................02 Ceiling Mount Access Point ..........................02 Front Panel ..............................02 Rear Panel ............................... 03 Indoor/Outdoor Access Point ........................04 LED Explanation ............................04 Buttons & Ports ............................. 05 Wall Plate Access Point ............................05 LED Explanation ............................
- Page 3 About This Guide Omada offers scenario-based access points (hereinafter referred to as EAPs) for different kinds of environments. This document offers startup guidance for an EAP, including a detailed hardware overview and quick references for hardware installation and software configuration. Related Documentation The Quick Installation Guide can be found in the product packaging and on the Product Support page:...
- Page 4 Hardware Overview This chapter provides a detailed hardware overview of the EAP. Ceiling Mount Access Point Front Panel The EAP is equipped with a system LED that indicates the system status on the front panel. LED Status Indication • For EAPs with single-color LED: Working normally/Initializing.
- Page 5 Rear Panel The ports, buttons, and other parts are located on the rear panel and may vary by model. L-Key Slot Bracket Aligning Mark RESET Removable Block Bracket Aligning Mark Bracket Aligning Mark Cable Compartment Cover Note: For an AP with a Cable Compartment Cover, to avoid device damage, do not insert any objects into the holes for attaching the cover! Item Description...
- Page 6 Indoor/Outdoor Access Point The EAP is equipped with a system LED that indicates the system status on the front or side panel. The ports and buttons are located on the bottom and may vary by model. LED Explanation The EAP is equipped with a system LED that indicates the system status of the access point. LED Status Indication Flashes green...
- Page 7 Buttons & Ports Item Description RESET Press and hold for about 5 seconds to reset the AP to its factory Button default settings. Ethernet Port Connect to a PSE (Power Sourcing Equipment), such as a PoE switch, for both data transmission and power supply. Grounding Connect to grounding facilities for lightning and ESD protection.
- Page 8 LED Explanation The EAP is equipped with a system LED that indicates the system status of the access point. LED Status Indication • For EAPs with single-color LED: Working normally/Initializing. • For EAPs with dual-color LED: White: Normal power supply Orange: Low power supply Working abnormally/Power off/LED is turned off.
- Page 9 Hardware Installation Omada offers scenario-based EAPs for different kinds of environments. This chapter provides quick references for hardware installation. Ceiling Mount Access Point The Ceiling Mount Access Point can be mounted to a ceiling, wall, or junction box. You can follow the Quick Installation Guide to install the EAP using the accessories in the product packaging.
- Page 10 Software Configuration Omada EAPs offer wireless coverage solutions for small to medium-sized businesses and households. They can work independently as standalone APs or be centrally managed via an Omada Controller, delivering a flexible, feature-rich, and easy-to-configure wireless network. Get Started Choose a method to set up your EAPs: •...
- Page 11 For instructions on how to get started with an Omada Controller, refer to https://www. omadanetworks.com/support/faq/4096/. Omada App With the TP-Link Omada app, you can access and manage your Omada devices at a local site or remotely with a tap of your phone. Scan for Omada App Omada App...
