13/2/25, 14:23
Package Contents
Power adapter (12V, 1A)
Installation requirements
Drill with a 6mm drill bit (for wall mounting)
Phillips screwdriver
For indoor applications, use Category 5 (or higher) UTP cabling certified for indoor
use.
For outdoor applications, Category 5 (or higher) shielded cabling must be used for all
Ethernet connections and must be connected to the AC ground of the power supply.
We recommend that you protect your networks from harmful outdoor environments
and electrostatic discharge phenomena with Ubiquiti's industrial-grade Ethernet
shielded cable. For more details, please visit:
Hardware Overview
Green
Disabled
https://dl.ubnt.com/qsg/ERLite-3/ERLite-3_ES.html#_idTextAnchor007
ERLite-3 Quick Start Guide
EdgeRouter Lite
Note:
Although cabling can be routed outside, the EdgeRouter must be stored
inside a protective enclosure.
Power LED
RJ45 Speed/Link/Activity LED (ports eth0, eth2)
ERLite-3 Quick Start Guide
Screws (qty: 2)
ui.com/toughcable
EdgeRouter on
Not connected
Screw anchors (qty.: 2)
1/7
Advertisement
Related Manuals for Ubiquiti EdgeRouter Lite
Summary of Contents for Ubiquiti EdgeRouter Lite
- Page 1 Ethernet connections and must be connected to the AC ground of the power supply. We recommend that you protect your networks from harmful outdoor environments and electrostatic discharge phenomena with Ubiquiti's industrial-grade Ethernet shielded cable. For more details, please visit: ui.com/toughcable...
- Page 2 13/2/25, 14:23 ERLite-3 Quick Start Guide ERLite-3 Quick Start Guide Link established at 10/100 Mbps Amber Blinking indicates activity Link established at 1000 Mbps Green Blinking indicates activity Console port RJ45 serial console port for command line interface (CLI) management. RJ45 (ports eth0, eth2) The RJ45 ports support 10/100/1000 Ethernet connections.
- Page 3 13/2/25, 14:23 ERLite-3 Quick Start Guide ERLite-3 Quick Start Guide Grounding (recommended) The power adapter grounds the device; however, you can add an optional ESD ground cable to enhance ESD protection (ground cable not included). https://dl.ubnt.com/qsg/ERLite-3/ERLite-3_ES.html#_idTextAnchor007...
- Page 4 3. Launch your web browser. Enter the correct IP address in the address field. Press Enter (PC) or Return (Mac). 4. Enter ubnt in the username and password fields . Read the Ubiquiti license agreement and check the box next to I agree to the terms of this License Agreement to accept it.
- Page 5 3. Launch your web browser. Type https://192.168.1.1 in the address bar. Press Enter (PC) or Return (Mac). 4. Enter ubnt in the username and password fields . Read the Ubiquiti license agreement and check the box next to I agree to the terms of this License Agreement to accept it.
- Page 6 13/2/25, 14:23 ERLite-3 Quick Start Guide 1. Please read, follow and retain these instructions. ERLite-3 Quick Start Guide 2. Heed all warnings. 3. Only use devices or accessories specified by the manufacturer. WARNING: Lack of proper ventilation may result in a risk of fire. Maintain at least 20 mm clearance next to the ventilation holes for proper ventilation.
- Page 7 13/2/25, 14:23 ERLite-3 Quick Start Guide The CE marking on this product indicates that the product complies with all applicable directives. ERLite-3 Quick Start Guide WEEE Compliance Statement Declaration of conformity Online Resources © 2025 Ubiquiti Inc. All rights reserved. https://dl.ubnt.com/qsg/ERLite-3/ERLite-3_ES.html#_idTextAnchor007...
