Installation Instructions for Ice and Beverage Dispensers

D414AS, E414AS

Order parts online

www.follettice.com

Maestro Plus ice machines with RIDE technology

fit most countertop dispensers manufactured by

Maestro Plus

™

Cornelius • Lancer • SerVend

801 Church Lane • Easton, PA 18040, USA

Toll free (877) 612-5086 • +1 (610) 252-7301

www.follettice.com

Ice Machine with RIDE

Technology

™

self-contained

01571322R00

Need help?

Do you have a question about the Maestro Plus D414AS and is the answer not in the manual?

Questions and answers

Summary of Contents for Follett Maestro Plus D414AS

Page 1 Maestro Plus Ice Machine with RIDE Technology ™ ™ Installation Instructions for Ice and Beverage Dispensers D414AS, E414AS Order parts online www.follettice.com self-contained Maestro Plus ice machines with RIDE technology fit most countertop dispensers manufactured by Cornelius • Lancer • SerVend 801 Church Lane •...
Page 2 § This appliance must not be cleaned by a water jet. § User maintence should not be done by children. § Follett recommends a Follett water filter system be installed in the ice machine inlet water line (standard capacity, high capacity, carbonless high capacity).
Page 3 Contents Unpack ...................................4 Unpack Ice Machine ..............................4 Site Preparation ................................5 Installation site requirements ............................5 Dispenser Top Preparation ............................6 Top Preparation ................................6 Mount thermostat box ...............................6 Install shuttle actuator and bracket ...........................7 Route thermostat ..............................7 Mount Ice Machine ................................8 Ice machine in cabinet ..............................8 External Connections ..............................10 Air-cooled ice machines only ..........................10 Water-cooled ice machines only ..........................10...
Page 4 Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack Ice Machine Beverage Dispenser • RIDE Technology Maestro Plus...
Page 5 Site Preparation Provide drainage, potable water supply and electrical power to within 6 feet (2m) of ice machine in accordance with local and national codes. Outdoor installation is not recommended and will void warranty. Installation site requirements 115 V NEMA 5-15 ➊...
Page 6 Dispenser Top Preparation Prepare the dispenser. Note: The instructions below only apply to 22” & 30” wide dispensers. 44” wide dispenser instructions may be found with the top kit. Top Preparation - Thermostat (if applicable) Standard (Cornelius, Lancer, or Servend) Lancer Sensation and Touchpoint 9.00"...
Page 7 3.1.2 3.1.3 Install shuttle actuator and bracket Route thermostat SHUTTLE ➌ SHUTTLE ACTUATOR ACTUATOR ➋ ➊ THERMOSTAT 3/4" RADIUS GROMMET ➍ (APPROX.) THERMOSTAT BRACKET 2" ➋ 1" APPROX ➎ § Route thermostat through grommet and into bin ➊ § Install thermostat grommet ➊...
Page 8 Top Preparation - Shuttle Actuator (if applicable) Standard (Cornelius, Lancer, or Servend) Lancer Sensation and Touchpoint 9.00" 5" Back of Top (127 mm) 10.00" 3.0" ∅ (77,2 mm) 3.0" ∅ Front of Top Locate hole position 5" (127 mm) from Locate hole position 10"...
Page 9 Mount Ice Machine Mounting options: Cabinet, Wall, Stand In cabinet Wall bracket Stand 18.125" (46.0 cm) 6.80" (17.27 cm) 26.25" 20.125" (66.7 cm) (51.1 cm) A - 15.125" (38.4 cm), C - 13.25" (33.6 cm) B - 18.625" (47.3 cm) D - 20.75"...
Page 10 Completed installation with air intake gasket gasket and door in place cabinet door Side View door & gasket must mate directly 22.75" (57.8 cm) 29" Front (74 cm) minimum cutout for supplied air intake grille 12"W x 12"H (30 cm x 30 cm) supplied air drain tube intake grille...
Page 11 1/4" per foot (6,4 mm/0,3 m) pitch. ➋ § Install ice machine potable water supply 3/8" FPT) Note: Follett recommends a Follett water filter system be installed in the ice machine inlet water line (standard capacity, high capacity, carbonless high capacity).
Page 12 Dispenser Agitation Adjustment - CORNELIUS Agitation adjustments Cornelius models ED, DB, DF, IDC and Flavor Fusion § Adjust the agitation tier located on the Cornelius PC board to 1 second on, 1 hour off. Note: see Cornelius manual for more information. Agitation adjustments –...
Page 13 Agitation adjustments – LANCER FS SERIES Initialization Screen (Boot Up Only) Lancer FS-16 Ver. 0.200 Main Menu Sub-Catagory FS-16 Setup Brands Per Side Major/Minor V:1 L:2 R:1 FS-16 Setup Bonus Key Setup Enter Cancel Config Bonus Key V:1 T:F M:S B:W FS-16 Setup Soda/Plain Water Soda/Plain Water...
Page 14 Single Agitator P/N 307277 — Diverter plate (single agitator Cornelius dispensers and left-hand dispense chute on dual-agitator Cornelius dispensers) Dual Agitator P/N 307277 — Diverter plate (single agitator Cornelius dispensers and left-hand dispense chute on dual-agitator Cornelius dispensers) P/N 00996207 — Diverter plate (right-hand dispense chute on dual-agitator dispensers) Beverage Dispenser •...
Page 15 Dispenser diverter plate installation – CORNELIUS, ED, DF AND DB SERIES GATE MOUNTING PLATE STORAGE HOPPER FLANGE EXTENDS INTO STORAGE HOPPER THROUGH GATE OPENING ICE DIVERTER ICE CHUTE COVER APPLY RTV TO THIS SURFACE TO SEAL TO HOPPER GATE MOUNTING PLATE 10-32 WASHER GASKET ICE CHUTE...
Page 16 Transport tube installation Incorrect ice transport tube installation can result in wet ice and dispensing problems. Follow guidelines below to ensure correct installation. Call factory for assistance if you are unable to meet these requirements. General requirements § Maximum length of tube run – 20 ft (6 m). Factory approval required for longer runs. §...
Page 17 RIDE model ice machine start up procedure The start-up procedure below is intended to ensure that ice machine is operating properly after installation has been made. Check each item listed and call factory immediately for assistance if you experience problems with unit.
Page 18 Beverage Dispenser • RIDE Technology Maestro Plus...
Page 19 Beverage Dispenser • RIDE Technology Maestro Plus...
Page 20 Maestro Plus is a trademark of Follett Products, LLC. Follett, Chewblet and RIDE are registered trademarks of Follett Products, LLC, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01571322R00 www.follettice.com...
