Gigabyte GSmart G1345 Quick Manual

Quick guide - gsmart g1345 english version
Hide thumbs Also See for GSmart G1345:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, User Manual
Your Phone
This section introduces you to the hardware of the device.
No.
1 Earphone jack
2
3
Earpiece
4
Touch screen Display screen.
5
6
P-sensor
7
Light sensor
G1345│ 1
Items
Functions
Use a headset for hands-free
conversation or listening to
music.
• Press and hold for several
seconds to turn the phone
on or off.
Power
• To set your phone to the
sleep mode, press the
power button briefly. Press
again to turn on the display.
The source of music and
voice.
• Power status notification.
LED
• Other notification. (New
message / Missed call).
The screen will turn off
automatically when taking the
device close to face on call.
Adjust the brightness of the
screen according to the
environment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GSmart G1345 and is the answer not in the manual?

Questions and answers

Related Manuals for Gigabyte GSmart G1345

Summary of Contents for Gigabyte GSmart G1345

  • Page 1 Your Phone Items Functions This section introduces you to the hardware of the device. Use a headset for hands-free 1 Earphone jack conversation or listening to music. • Press and hold for several seconds to turn the phone on or off. Power •...
  • Page 2 Items Functions • Go back to Home Screen. Home • Press and hold to bring up recent activities. Press to view the options of Menu the menu. Connect to the website or find Search features in the phone. Return Return to the previous page. Sound Receiver.
  • Page 3 Items Functions Press upwards or downwards to increase or decrease the Volume volume. Slide down the key fully to enter vibrate mode. You can insert your Micro 15 Micro SD Slot SD card. • Tap to activate the camera. • In Camera/Camcorder Camera key mode, press to take a photo or video.

  • Page 4: Installing Or Uninstalling The Sim Card, Battery, And Memory Card

    2. Please move your fingertip into the slot . Installing or uninstalling the SIM Card, Battery, and Memory Card To remove the back cover 1. Please turn over your phone with the back cover facing up. G1345│ 4...
  • Page 5 3. Then pull the back cover with your fingertip to remove SIM card The SIM card contains your phone number, memory storage, and the details of the network service. To install the SIM card Insert the SIM card. Make sure the gold contacts are facing down and the cut-off corner is facing towards the battery slot.
  • Page 6 To remove the SIM card To remove the battery 1. Remove battery. Use your fingertip to lift the battery, and then, remove it. 2. Use your finger to slide the SIM card from the card slot. Battery Your phone comes with a rechargeable battery. Battery life varies depending on the network, used applications, and the type of connections attached to your phone.
  • Page 7 To replace the back cover 2. Then, press the bottom of the back cover until click into 1. Please insert the hook on the top of the place. back cover into the slot of the phone. G1345│ 7...

  • Page 8: Charging The Battery

    Memory card To remove the memory card You will need a microSD card to store photos, music, 1. For safe removal, tap Application Drawer > videos, and other data. Settings >Storage > Unmount SD card. 2. Push the memory card down to eject it from the To install the memory card slot.

  • Page 9: Turning The Phone On Or Off

    To turn off your phone 1. Press and hold the power button for several seconds. 2. A pop-up window appears, and then, tap Power off. 3. Select OK to confirm. To set your phone to the sleep mode To set your phone to the sleep mode, press the power button briefly.

  • Page 10: Using Headset

    Using Headset music, press twice quickly to next music. For hands-free conversation or listening to music, plug a • If you are having a call headset to the headset jack. conversation, press and NOTE: hold the button to end the •...
  • Page 11 Status Bar Icons Battery is low. The icons of the status bar indicate different types of information. Tap the status bar and scroll down to view Battery is very low. notifications or view system information. Network status icons will turn green while you login your Battery is charging.
  • Page 12 Airplane mode. New e-mail. Call is in progress. Alarm. Your call is on Notification Event notification. hold. Portable Wi-Fi Missed call. hotspot is activated. USB debugging is USB tethering is connected. activated. Data is Syncing. Both USB tethering and Portable General hotspot are notification.

  • Page 13: Android Manager

    Use Android Manager on your PC Android Manager Contacts: Allows you to back up contacts, as well as You can use Android Manager on your PC to synchronize organize your contacts. data in your device. Please download Android Manager Messages: Allows you to edit and send messages. from GSmart’s official website and install it in your PC.

  • Page 14: Install Usb Driver

    Data Storage on your phone. Your PC will pop-up a Specifications message to ask if you want to use data storage. It can System Information help you save the files. Platform Android 2.3 2. PC Sync: Tap PC Sync on your phone, your Qualcomm device will connect and access Android Processor...
  • Page 15 External Memory Up to 115 hours (It may vary depending on the MicroSD supports up to Memory Card Standby time availability of local 32GB networks and the Temperature individual usage.) Operating -15°C to 55°C Up to 4.5 hours (It may SIM Card Slot vary depending on the Dual SIM card slot.
