Summary of Contents for Gigabyte g-Smart

  • Page 2: Safety Information

    Safety Information This chapter contains important information on safe and efficient operation. Please read this information before using the device. Exposure To Radio Frequency (RF) Energy The device contains a transmitter and a receiver. When it is ON, it receives and transmits RF energy. Please use the device appropriately.

  • Page 3: General Information

    General Information This chapter contains important information on safe and efficient operation. Please read this information before using the device. Ignorance of the following notices may lead to violations of the law. Before using the device, please make sure you have fully charged the battery. Do NOT remove the battery from the device during charging.

  • Page 4: Table Of Contents

    2.1 Today Screen..........................17 2.2 Start Menu List..........................18 2.3 Applications...........................18 2.4 Settings............................19 2.5 Input Method..........................21...

  • Page 7: Led Indicator

    This chapter introduces you to the hardware of the device and its function keys. 1.Power On / Off: Press and hold the power button for a few seconds to turn on / off your device. 2.Stereo speaker: You may play music / voice through speaker. 3.LED Indicator: The LED Indicator indicates the status of your device by showing different colors.

  • Page 8: Navigation Key

    8.Flag Key: Press the flag key to open “ Start ” menu options. 9.Right Function Key: Perform the function of menu or program command displayed on the down-right corner screen. 10.End Key: Press this key to end a call or to switch between Today & 3D Quick Menu. 11.OK Key: Press this key to execute or terminate a selected function or application.

  • Page 9: Camera Key

    18.Camera Key: Press camera key to launch camera function. 19.Volume Key Slide this key upwards or downwards to adjust volume. Press this key to launch Voice Commander. 20.Stereo Speaker: 21.Flash: Support Auto Flash / Forced Flash On / Forced Flash Off mode. 22.Stylus : Use the stylus to touch the screen panel.
  • Page 10 Function 5-Way Navigation Key - Up Move cursor up 5-Way Navigation Key - Down Move cursor down 5-Way Navigation Key - Left Move cursor to the left 5-Way Navigation Key - Right Move cursor to the right 5-Way Navigation Key - Center Execution Call key Press: enter phone function.
  • Page 11 3.It takes 3 hours to fully charge your battery for the first time. After the first time, the charging process will be completed by around 2.5 hours. 4.When the LED indicator flashes in blue, it means the battery is charging. 5.When the LED indicator goes out, it means the charging is complete.

  • Page 12: Standby Mode

    You can also choose your screen display in Portrait or Landscape. 1.Press and hold OK any time when the device is on to switch your screen display between Portrait and Landscape. You can also change the default screen display by following the steps below: 1.Tap“Start”>...

  • Page 13: Sleep Mode

    off, and the device enters Standby mode. 2.Touch the screen under standby mode, the screen will light up again. You may start performing normal operations. Sleep Mode 1.Sleep Mode is a power saving mode designed to reserve battery power. You may enter Sleep mode by pressing power On / Off key shortly.
  • Page 14 tab, and check both “ Identification Information ”and “ Note ”. 6.Select “ OK ” to finish setup and save it. You can set your own password to prevent unauthorized use of your device. 1.Tap “ Start ” > Settings >...

  • Page 15: System Reset

    Reboot System: When you reboot the device, all running programs will stop and you will lose all unsaved information. Please make sure that all information has been saved before performing system reboot. 1.Reset key is located on the bottom right side of your device. 2.Use the stylus to softly poke the reset key on the lower right side of the device to reboot your system.
  • Page 16 4.Place the device in the case when you are not using it. Please follow the suggestions below when you are traveling with the device: 1. Back up your data. 2.Copy your data in a mini SD card. 4.Remove all other connected device. 5.Bring your charger.

  • Page 17: Today Screen

    1.Start Menu : Tap to open the start menu list. 2.Battery Status : Shows the current battery status. 3.Connection Status : Shows the connection status of the device. 4.SIM Card Status : Shows SIM card status. 5.Volume : Tap to adjust the speaker or phone volume. 6.Time : Shows time and the latest appointment.

  • Page 18: Applications

    Mobile phone is off (Flight mode). Mobile phone is on. GPRS is available. GPRS is disconnected. GPRS is connected. Bluetooth is activated. 1.The applications in this block are fi xed for some Microsoft applications. 2.The applications in this block are the last 5 programs that you have used. 3.Tap on Programs, to enter the programs screen.
  • Page 19 Block List , Modem Link , SIM Contacts , Phone Manager Download Agent Games Bubble Breaker , Solitaire Transmit data between your computer and the ActiveSync device. Pocket MSN Perform MSN functions. Excel Mobile Execute Excel files. PowerPoint Mobile Execute PowerPoint files. Word Mobile Execute Word files.
  • Page 20 Sounds & Notifications Settings for alarm sound and notification. Today Settings for screen appearance and display items. > System Tab Select “ Start ” > Settings Program Description About Contains information of the device. Backlight Settings for backlight. Identifies the device to others to prevent unauthorized Certificates access.

  • Page 21: Letter Recognizer

    Screen Keyboard You can input data by using screen keyboard. Tap on the keyboard icon on your screen to open the screen keyboard. Follow the following steps below to input your data: 1.On your screen keyboard, tap Shift key to input a Capitalized letter or some common symbols.

  • Page 22: Speed Dial

    Press key, or select “ Start ” > Phone to enter phone function. Please insert a SIM card before using phone. 1.Before inserting / removing a SIM card, please make sure that the device is turned off and is not connected to any power supply by the USB cable or charger. 2.Remove the battery from the battery slot.

  • Page 23: Smart Dial

    Smart Dial Use this function to search a contact or a specific number quickly. 1.On the phone screen, slide down the keypad to enter smart dial. 2.The smart dial screen will display all contacts in this device and history calls. 3.After inputting the fi...
  • Page 24 1.Press the volume adjustment key on the side manually or tap > to adjust incoming call volume. 2.If you press the volume adjustment key on the side of this device or tap > icons during a call, you may adjust the in - call volume of the phone. You can only adjust it when during a call.
  • Page 25 In Contacts, Tap { New } on the bottom left of screen. A blank record will appear. 1.You may set photos in photo field for this contact, by which the contact’s photo will display as an incoming call photo ID. 2.You may also tap ringtone field to set different incoming call ringtones for your contacts.
  • Page 26 3.You can set keypad tone for dialing. 4.You can set personal password to prevent unauthorized use from others. Use this function to copy the contacts in SIM card to this device. 1.Select “ Start ” > Programs > Phone Manager >...
  • Page 27 Select “ Start ” > Programs > Phone Manager > Block List 1.Check “ Block all unknown calls ” or tap { Menu } and select { Add Block List } to add a number you would like to block. 2.Select “...

  • Page 28: Answer Machine

    You may set your personalized settings by preference 1.Select “ Start ” > Settings > Personal Tab > Shutdown Animation 2.Select your preferred Animation File, Sound File, Show Time. Tap User Define in “ Animation File ” to set your own file as shutdown animation. 3.Select “...
  • Page 29 4.Select“Activate Time”to set how many seconds that your answer machine will wait before answering an incoming call. 5.Select { Greeting Setup } to set greeting screen. 6.Tap “ OK ” to save setup and return to System tab screen. You will find callers’ messages in “ My Answer Machine ” folder. Greeting Setup: Tap { Greeting Setup } to set default answer machine greeting or record your own greeting.
  • Page 30 5.Press “ OK ” to validate the settings and exit. You may also use the files you have recorded as background effects. To do so, save the files under My Background Sounds in My Documents, then repeat step 1 to 5. After activating background effects, when an incoming call rings, tap { Answer } to answer with the background sound you have selected, or tap on the icon and choose “...
  • Page 31 ˙ “ Password ” : restrict access to your data. ˙ “ Power ” : extend battery lifetime. ˙ “ Today ” : personalize “T oday Screen ” appearance and information. When you change your Today theme in Today > Theme tab, your Today background, phone skin, and theme color, will all change accordingly.
  • Page 32 2. Battery Power tab: set the turn on method and turn off time for backlight when using battery power. 3. External Power tab: set the turn on method and turn off time for backlight when using external power. 4. Extended tab: adjust the brightness of backlight. “...
  • Page 33 You may set certain keys as the activation keys for your most common used programs. 1. Select “ Start ” > Settings > Personal tab > Buttons > Program Buttons tab. 2. Under Program Buttons tab screen, select desired function key. 3.

  • Page 34: Settings

    Services: 1.Select “ Start ” > Settings > Personal tab > Phone > Services tab. 2.Check the items you want to select. 3.Tap “ OK ” to save settings and return to Personal tab screen. Note: All services in Services are provided by operators. Please contact your operator for enquiries regarding these services.

  • Page 35: Application Tab

    Contacts tab: 1.Select “ Start ” > Settings > System tab > Voice Commander Settings > Contacts tab. 2.Select a contact from contacts list. 3.Press key to play system pronunciation method. 4.Press voice tag to record your own pronunciation method. 5.Press delete key to delete voice tag.
  • Page 36 Advanced Settings tab: 1.Select “ Start ” > Settings > System tab > Voice Commander Settings > Advanced Settings tab. 2.Select the desired sensitivity. 3.Select the length of phone number. Press ” OK ” to save Settings and return to System tab screen. You may use Microsoft ActiveSync to synchronize data in this device with personal computer.

  • Page 37: Hardware Installation

    Note: Before installing ActiveSync, do not connect your device to the computer. You may only connect the device to the computer by using the USB cable AFTER ActiveSync is installed. 1.ActiveSync Installation: use the enclosed CD to install Microsoft ActiveSync in your personal computer. This device already has built-in ActiveSync.
  • Page 38 When using GPRS and Internet connection, you will not be able to answer a call. If you want to make a call, your device will automatically disconnect to the Internet and reconnect to the Internet at the end of conversation. Before using GPRS to connect to the Internet, please confirm with your system provider whether this service is enabled and supported on your SIM card.
  • Page 39 Connections. After completing connection, you may go Internet surfing or send and receive email. GPRS Wizard helps you to manually select your GPRS network with more ease. 1.Tap “ Start ” > Settings > Connections tab > GPRS Wizard 2.Choose the regional name of your location. 3.Choose the desirable network, or tap “...
  • Page 40 Wi-Fi allows this device to connect with detected network through WI-FI. 1. Select “ Start ” > Settings > Connections tab > Wireless Manager. 2. Tap {Wi-Fi}. 3. Tap“OK”to activate wireless network and exit. After activating WI-FI, a new window, “ New Network Detected ”, will appear. Select Connect and enter your password to the local network.Press Connect to connect this device with local network.You may use WI-FI for up to 2 hours.
  • Page 41 Before receiving and sending your email or message, please make sure that this device has connected to a network. When you are connected to a network, you may go to Messaging to receive and send your email or message. You may: 1.Use this device to directly connect with email server and receive or send letter.
  • Page 42 If you select not to perform synchronization, you may manually copy or move email messages between this device and the computer. 2.Only the mail in “ Inbox ” of your computer will be synchronized. 3.Only the mail in Exchange or Outlook can be synchronized. 4.The mail from “...
  • Page 43 ˙ SMTP server name for outgoing mail 2.Establish Email Services: Select Messaging > { Menu } > Tool > New Account, and then follow the instructions on the screen to set up a new email account. 3.See “ 6.1 Internet Access ” to connect this device to a network and start receiving and sending email and messages.
  • Page 44 6.Select { Menu } to open menu. Under new mail screen, select and hold to activate related Menu. Read and reply mail: Select Messaging > { Menu }, and then select Send and Receive from { Menu } to start sending and receiving new mail.
  • Page 45 5. Set the Peak times to “As items arrive” and the Off-peak times sync time to “As items arrive”. Tap “OK”. Now you have established a cooperative relationship for the device and the Exchange Server. The next time when you select “Start” > ActiveSync > Sync, you may synchronize with Exchange Server using Wi-Fi or GPRS.

  • Page 46: Switch Accounts

    8.Select { Menu } to open menu. In { Menu }, you may insert voice and video clip, add page, and change background color of MMS. Read and Reply Messages: Select Messaging > { Menu } > Inbox to view all received MMS messages.Select { Menu } > { Send / Receive } to receive new MMS.Select any unread mail in Inbox to view content.

  • Page 47: Msn Messenger

    MSN Messenger 1.Select “ Start ” > Programs > Pocket MSN > MSN Messenger 2.Tap { Tap here to sign in }. 3.Enter your MSN or Hotmail email address and password. 4.Select { Sign In }. MSN Hotmail 1. Select “ Start ” > Programs > Pocket MSN > MSN Hotmail 2.
  • Page 48 When you want to form connection through Bluetooth, please make sure the device you would like to make connections with is also equipped with Bluetooth. When Bluetooth is activated, tap icon on Today screen, and you will see icon in the pop-up window.
  • Page 49 1.Select { New Incoming Port } to enter setup screen. 2.Select a port to be set. 3.Select { Finish }.
  • Page 50 Watch full screen analog TV on this device and be the fi rst to get the news! Depending on the power status of the battery, you may watch TV for up to 2 hours. Please plug in the device headset before watching TV in this device. The headset is also an antenna. You ca adjust the headset lines for better signals.
  • Page 51 8.Tap for TV Help. When watching TV, you may use keypad to enter the number of the channel you would like to watch. TV Volume Control Method: You may use volume control key on the side to adjust volume. When watching TV, the volume adjustment bar will appear on the bottom of the screen after you press volume control key.
  • Page 52 7.Tap to start recording the FM radio broadcast of the channel you are currently listening to. The recording time will be displayed on the top of screen. Tap “STOP” to stop recording. 8.Number key on screen: You can enter a channel frequency and the frequency you entered will appear on the display.

  • Page 53: Camera Menu

    Camera Menu Video Mode: Tap on this icon to switch to video mode. Pictures & Videos: view your photos here. Camera Settings: to open the menu for camera settings. Settings: 1.Shooting Mode: you may select different shooting modes to fit the shooting environment.

  • Page 54: Video Menu

    Video Menu: Camera Mode: Tap on this icon to switch to camera mode. Pictures & Videos: view your photos here. Video Settings: to open the menu for video recorder settings. Settings: 1.Shooting Mode: you may select different shooting modes to fit the shooting environment.

  • Page 55: For Example

    Note: 1.If there is incoming call during recording, answering the call will automatically terminate recording. If you want to continue recording after ending call,you need to reactivate recording function. 2.When TV or FM radio is activated on this device, recorder will record the only the sound of the broadcasting programs.
  • Page 56 ˙Play Music / Pause / Resume to play / pause / resume music in My Music. ˙Next / Previous to play the next/previous music file in My Music. ˙Play + (Music File) to play the music file you have chosen. ˙Start + (Application) to launch an application.

  • Page 57: Create An Appointment

    Appointments and Meetings: You may use Calendar to arrange appointments, meetings, and other events. You may view your appointments in different display modes. You may select preferred display mode by tapping on the bottom left of screen to switch between day, week, month, year. 1.Select a date to go to the desired date.

  • Page 58: Phone Book

    Send Meeting Notice: You may use Calendar to set meeting notice by combining with the information on Outlook or Pocket Outlook. When you synchronize messages or connect this device with E-mail server, meeting reminders will be generated automatically. Select Calendar > { Menu } >...

  • Page 59: Searching Contacts

    6.Tap “ OK ” to save and return to contacts. To save a contact from phone to SIM, tap on that contact in the contacts list and then select “Save to SIM” in { Menu }. Searching Contacts: There are four contact search methods provided in this system. ˙...

  • Page 60: Input Method

    Add a New Task: 1.On “ Tasks ” screen, select New 2.Select a field to input data. 3.Select “ Starts ” and “ Ends ” field to set first and last day of task. 4.You may select Occurs to select whether this task has periodicity. 5.You may select “...
  • Page 61 ˙ Tap on {Menu} to for options. ˙ Tap on “ OK ” to save memo and return to memo screen. You may use Word Mobile in this device with Microsoft Word in your computer to easily copy and move document between this device and your computer.Through computer synchronization, you may keep updated contents in both this device and your computer.
  • Page 62 You may use Excel Mobile in this device with Microsoft Excel in your computer to easily copy or move files between this device and your computer. Through computer synchronization, you can keep updated content in both this device and your computer. You may use Excel Mobile to create documents like Statement of Income and Expenditure.
  • Page 63 You may use PowerPoint Mobile in this device with Microsoft PowerPoint in your computer to easily copy or move document between this device and your computer. Through computer synchronization, you may keep the fi les in both this device and your computer updated.

  • Page 64: View Favorites

    1.Select library folder 2.{ Menu } : select < Open File > to open files not in the library. Select { Update Library } to update library list. 3.Select and hold the file or folder for playing, and then select { Play } or { Queue Up }. You may use synchronization to copy sound and image files from your computer to this device.
  • Page 65 2.On Favorites screen, select the website you want to view. ˙ Select the website you would like to go to. ˙ You may add or delete folders or URL links. Mobile Favorites Folder: After installing ActiveSync to your computer, “ Mobile Favorites ” folder will be added to “...
  • Page 66 You can save storage space and increase efficiency of the device by compressing some of your files with this ZIP tool. Zipping Files: 1.To zip a file, select “ Start ” > File Manager . 2.Tap and hold on a file you would like to zip. A pop-up menu will appear. 3.Select Zip File in the pop-up menu.
  • Page 67 1.Select “ Start ” > Programs > Game 2.Select Bubble Breaker or Solitary to launch a game.

  • Page 68: Main Tab

    Select “ Start ” > Settings > System tab > Memory Main tab: Display current memory status of this device. Storage Card tab: Display the memory status of storage card in this device. Running Program tab: Display all current running programs in this device. Select any program from “...
  • Page 69 All programs pre-installed in the device will be saved in ROM (Read Only Memory) and are not removable. Data saved in ROM will not be lost by accident. All programs that you installed will be saved in RAM (Random Access Memory).As long as there is sufficient space in this device, you may install suitable programs by preference.
  • Page 70 2.Directly download programs to this device by using Internet Explorer in this device. (Please select programs designed for Pocket PC and this device) 3.Read installation instructions, ‘Readme’ file, or accompanied programs provided to you. 4.Run installation executive file in your computer. Add Programs to ”Start”...
  • Page 71 Item Specifications System Information Operating System Windows Mobile 5.0 Processor Intel PXA272 416 MHz Memory 64 MB ROM, 64MB RAM Size Dimensions (mm) 109×53.5×24mm Weight (in grams) 153g Batteries Battery Capacity 840mAh Li-Ion Battery Standby time 110 hours Talk time 3 hours Power Duration for Video Playback 12 hours...
  • Page 72 Video Format 3GPP, MPEG4, WMV Max Size Depends on available RAM Phonebook Size Depends on available RAM PAL or NTSC or SECAM PAL or NTSC or SECAM (Depends on country of purchase) Ringtone Type MP3, WMA, AMR Polyphone 192 polyphonic mid file Type JPEG Pixels...
  • Page 73 Why can’t I turn on the device? Please make sure that the device has sufficient power, and that the battery is secured in the device. Plug the device to an outlet using the travel charger. Check whether the LED light on the device has lighted up, and then press the power key on the device to turn on the device.
  • Page 74 When I open a file or a program, a “Insufficient Memory” message pops up. The device memory is shared by both storage and programs. You can follow the steps below to free up some memory. Remove some of the rarely used programs you installed. Remove rarely used files.
  • Page 75 If the connection still fails, remove ActiveSync on your computer and reinstall. How do I take out the mini SD card from the SD adapter? The card slot on this device is designed for mini SD cards. To remove the mini SD card from the SD card adapter, please hold the SD card adapter with one hand, slightly lift the end of the mini SD card and pull.
