User Manual
Your Phone
This section introduces you to the hardware of the device.
5
1
2
7
6
3
4
11
8
9
10
No.
1 Earphone jack
2
3
Receiver
4
Touch screen Display screen.
5
P-sensor /
6
Light sensor
G1355│ 1
Items
Functions
Use a headset for hands-free
conversation or listening to
music.
• Press and hold for several
seconds to turn the phone
on or off.
Power
• To set your phone to the
sleep mode, press the
power button briefly. Press
again to turn on the display.
The source of voice.
• Power status notification.
• Other notification. (New
LED
message / New email /
Missed call).
• P-Sensor: The screen will
turn off automatically when
the device is close to the
face during a phone call.
• Light Sensor: Adjust the
brightness of the screen
according to the
environment.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Gigabyte GSmart G1355
Summary of Contents for Gigabyte GSmart G1355
-
Page 1: Your Phone
Your Phone Items Functions This section introduces you to the hardware of the device. Use a headset for hands-free 1 Earphone jack conversation or listening to music. • Press and hold for several seconds to turn the phone on or off. Power •... - Page 2 Items Functions Press to view the options of Menu the menu. • Go back to Home Screen. Home • Press and hold to bring up recent activities. Sound Receiver. Connect to the website or find Search features in the phone. Return Return to the previous page.
- Page 3 Items Functions The camera on the back of the 5 Megapixels device supports 5-mega-pixel Camera photo and high-quality video. You need to open the cover to Back cover install or uninstall the battery and the SIM card. Speaker The source of music and voice. NOTE: The battery can also be charged while connecting to a computer.
- Page 4 2. Please remove the back cover from the top. Installing or uninstalling SIM Card, Battery, and Memory Card To remove the back cover 1. Please turn over your phone with the back cover facing G1355│ 4...
- Page 5 3. Pull the back cover with your fingertip and remove it. SIM card The SIM card contains your phone number, memory storage, and details of network service. To install the SIM card Make sure the gold contacts are facing down and the cut-off corner is facing toward the SIM card slot.
- Page 6 To remove the SIM card To remove the battery 1. First, remove battery. Use your fingertip to lift the battery, then remove it. 2. Use your finger to slide the SIM card out of card slot. NOTE: Battery To ensure battery performance and avoid risk from fire: Your phone comes with a rechargeable battery.
- Page 7 To replace the back cover 2. Then, press four points of back cover fully until hear 1. Please insert the hook on the bottom of back cover into clicks. the slot. G1355│ 7...
-
Page 8: Charging The Battery
Memory card To remove the memory card You may need a microSD card to store photos, music, 1. For safe removal, tap Application Drawer > videos and other data. Settings > Storage > Unmount SD card. 2. Push the memory card to eject it from the slot. To install the memory card 1. -
Page 9: Turning The Phone On Or Off
NOTE: Notification LED • The battery can also be charged when you connect Types Descriptions your phone to a computer. Solid red light Battery is charging. • To ensure safety, do not remove the battery from the phone while the AC adapter is connected or Solid green light Battery is full. -
Page 10: The Home Screen
The following instructions are only provided with the The Home Screen original headset of the original manufacturer: On Home screen, you can quickly access common Types Descriptions features and view notifications of missed calls, • When you receive an incoming received messages, battery, and the status of the call, press the button to answer connection. - Page 11 Battery is full. 3G is in progress. Battery is low. HSDPA is in Battery progress. Battery is very low. Airplane mode. Battery is charging. Call is in progress. No network signal / Your call is on No SIM card hold. inserted.
-
Page 12: Android Manager
The device is Downloading an connected to PC application. via the USB cable. Android Manager New text message. You can use Android Manager on your PC to synchronize New e-mail. data in your device. Please download Android Manager from GSmart’s official website and install it in your PC. Alarm. -
Page 13: Usb Manager
USB Manager : Connection between PC and your device is There are 4 modes of USB Manager after your device disconnected. connects to PC with the USB cable: Use Android Manager on your PC 1. Data Storage: Insert the memory card, and then, tap Contacts: Allows you to back up contacts, as well as Data Storage on your phone. -
Page 14: Specifications
NOTE: Up to 105 hours (It may Only Windows XP Service Pack 3 and higher versions vary depending on the support the installation. Standby time availability of local networks and the individual usage.) Specifications Up to 6 hours (It may System Information vary depending on the Platform... - Page 15 External Memory microSD supports up to Memory Card 32GB Temperature Operating -15°C to 55°C SIM Card Slot Dual SIM card slot. NOTE: Specifications are subject to change without the prior If this document is modified, please download the latest notice. They may vary in some regions also. version on GSmart’s official website.
