Fisher & Paykel 7 Series Quick Reference Manual

QUICK REFERENCE GUIDE > RGV3-486GD-L
48" Series 7 Professional 6
Burner Griddle Gas Range,
LPG
Series 7 | Professional
Stainless Steel | LPG
With Professional styling, this large range has six burners
delivering powerful high heat, a griddle and two gas ovens.
Griddle with burners that deliver up to 17,000 BTU heat per
burner, for seriously fast boiling
Expansive 7.7 cu ft total oven capacity across two oven cavities
Non-tip full-extension shelves in main cavity for safe removal of
hot dishes
Made from quality materials and real stainless steel
DIMENSIONS
Height
Width
Depth
FEATURES & BENEFITS
Generous Capacity
Featuring a generous total capacity of 7.7 cu ft, with enough
room to fit a 32 lb turkey. The griddle plate allows you to cook
several foods at once.
Cooktop Power
Sealed Dual Flow Burners™ deliver cooktop power up to
17,000 BTU for seriously fast boiling right down to a precise
140°F full surface simmer with the gentlest of flames.
Cooking Flexibility
The cooktop is designed for easy access to any burner with
grates you can smoothly slide pots across. The oven is large
enough to hold full size baking sheets.
Design Quality
This range has craftsmanship in every detail, with real stainless
steel, cast-iron trivets, and titanium coated dials. Each cavity
features incandescent lights and full extension telescopic
racks. From the robust legs to the powerful legs to the
powerful cooktop, the Range is built to last.
Easy To Clean
Cleaning up spills is effortless with the continuous, porcelain
basepan. Your cooktop simply needs a quick wipe to keep it
looking good as new.
Total Control
Precise control across high and low settings is delivered
35 3/4 - 36 3/4 "
through the halo-illuminated cooktop dials.
47 7/8 "
Total Control
29 1/8 "
Precise control across high and low settings is delivered
through the halo-illuminated cooktop dials.
SPECIFICATIONS
Burner ratings
Maximum burner power
Power back centre
Power back left
Power back right
Power front centre
Power front left
Power front right
Power griddle
Total cooktop power
Capacity
Shelf positions (main oven)
Total capacity (main oven)
Total capacity second oven
Usable capacity (main oven)
Cleaning
Date: 17.12.2024 > 1
17000 BTU
13000BTU
13000BTU
13000BTU
15000BTU
17000BTU
15000BTU
15000BTU
101000 BTU
5
5.3 cu ft
2.4 cu ft
3.9 cu ft
