OWNER'S MANUAL
Model: PD600-TAM3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PD600-TAM3 and is the answer not in the manual?

Questions and answers

Related Manuals for Frizzlife PD600-TAM3

Summary of Contents for Frizzlife PD600-TAM3

  • Page 1 OWNER'S MANUAL Model: PD600-TAM3...

  • Page 2: Table Of Contents

    CONTENT 2. PRODUCT INTRODUCTION 3. SAMPLE CONNECTION 4. INSTALLATION TIPS 5. INSTALLATION STEPS 6. FIRST TIME USAGE 7. USER INTERFACE 8. REPLACEMENT OF FILTER CARTRIDGE 9. FILTER REPLACEMENT INSTRUCTION 10.HOOK UP TO YOUR REFRIGERATOR/ICE MAKER 11.MINI TANK AVAILABLE NOW 12. MAINTENANCE 13.

  • Page 3: Installation Instruction

    Model: PD600-TAM3 Thank you for purchasing Frizzlife PD600-TAM3 reverse osmosis undersink filter system with 600G RO membrane. If you have any questions or need any assistance, please contact: support@frizzlife.com Find the installation video Video Scan the QR code to direct to video page Search "Frizzlife PD600-TAM3 installation"...

  • Page 4: Product Introduction

    Model: PD600-TAM3 2. Product Introduction Front Back Accessories: ASR211 Dedicated Faucet (CP filter) Drain Saddle Feed Water Valve PD600-Tam3 Converter Set ASR212 1/4” White Tubing (RO filter) 1/4” Red Tubing Power supply 3/8” White Tubing OUT TDS Blade Filter life...

  • Page 5: Installation Tips

    Model: PD600-TAM3 4. Installation Tips Please cut the tubing into two sections in proper length, make sure cut them squarely and cleanly. How to connect/disconnect the tubing? To connect: please push the tubing into the fitting and make sure it is fully inserted.
  • Page 6 Step 1: Cut and Soften the 3/8" tubing Please cut the 3/8" tubing in proper length, make sure cut them squarely and cleanly. (Fig.1) Put one end of tubing into boiled water for 5 seconds to soften itself.(Fig.2) Fig.1 Fig.2 Step 2: Connect three-way feed water valve (3/8"...
  • Page 7 Step 3: Connect the water supply (COLD WATER ONLY) Shut off the water supply. (Fig.7) Disconnect the cold water pipe from angle valve. Twist the feed water valve onto the angle valve and make sure the O ring is loaded. (Fig.8) Connect cold water pipe onto the feed water valve.
  • Page 8 Step 5: Install the drain saddle Disassemble the drain saddle, and peal off the black sticker and stick to saddle valve (Fig.13) Choose a spot on the drain pipe that is convenient for installing the drain saddle. It is recommended to install the drain saddle on the vertical drain pipe. (Fig.14) Drill a 1/4”...
  • Page 9 Step 7: Connect the "FILTERED" water tubing Cut another 1/4" tubing in proper length. Insert one end into the “Filtered” port on the back of the system and connect the other end to the TAM3 filter. (Fig.20) Fig.20 Note: Please make sure the tubings are fully inserted, otherwise may result in water leakage.
  • Page 10 Fig. 24 Fig. 25 Fig. 26 Fig. 27 Fig. 28 Step 11: Connect the power cord Turn on the angle valve and 3-way feed water valve. Check for leaks. (Fig.33) Insert the DC head of the power adapter into the "POWER" port on the back of the system.

  • Page 11: First Time Usage

    6. First time usage plugged Note: For the first time usage,TDS result will not show up until the system has kept producing water for 1 minute. Note: When the system keeps producing water continuously for 30 minutes, the system will enter into protection status and all the components stop working.
  • Page 12 Model: PD600-TAM3 Power-on When the system is powered on, you will hear a beep. All indicators will be on for 3 seconds, and then the system will automatically flush for 30 seconds. After flushing, if there is no water production, it will turn into standby status.

  • Page 13: Manual Flushing

    Model: PD600-TAM3 C. Flushing when constant water production: if the system constantly keeps producing water for 10 minutes, it will be automatically flushed for 15 seconds. D.Flushing when in standby status: When the system is in standby status, it will automatically flushed for 18 seconds every 6 hours.

  • Page 14: Filter Replacement Instruction

    Model: PD600-TAM3 9. Filter Replacement Instruction Step 1：Cut off the power and turn on the water faucet to release water pressure Cut off the water supply and power when start to replace the filter. （Fig.38, Fig.39) Remove the front cover Fig.40...

  • Page 15: Hook Up To Your Refrigerator/Ice Maker

    10.Hook Up to Your Refrigerator/Ice Maker The PD600 system can be connected with your refrigerator/Ice-maker by utilizing an extra IMC-1 ice maker connection kit (not included). Simply search “Frizzlife IMC-1” or Asin# “B07R7NH55L” on Amazon, or scan the QR code to purchase.

  • Page 16: Mini Tank Available Now

    1.If you consider the lagging outflow to be undesirable. 2.If you are encountering the constant on and off issue of the system pump due to unstable/lack of water pressure. Simply search “Frizzlife MWT3” on Amazon, or frizzlife.com, or scan the QR code to purchase.

  • Page 17: Maintenance

    Output Faucet Frizzlife RO System The mini water tank is not included in the package.If you consider the initial lag of the water outflow to be undesirable, please search "Frizzlife MWT3" on Amazon or frizzlife.com to purchase. Feed Water TAM3 Adapter...

  • Page 18: Trouble Shooting

    Model: PD600-TAM3 Please replace the filter cartridge regularly according to the filter life indicator. The testing was performed under standard laboratory conditions, acual performance may vary depending on the source water quality and water usage. In case of premature blockage and failure of the filters, it is recommended to replace the filter in accordance with actual usage.
  • Page 19 Model: PD600-TAM3 Lifetime of the filter Please replace the filter according to the cartridge is expired. instruction. The system has been off Please discharge water for 5 minutes Fltered water work for more than 2 days. before usage. in poor quality...

  • Page 20: Frequently Asked Questions

    Model: PD600-TAM3 The system is not connected Please check if the adapter is connected tothe power adapter or the properly. connection is loose. Indicators on user interface disappear The panel is damaged orit' s Please contact customer service team. cable is loose.

  • Page 21: Limited Product Warranty

    To be free of defects in material and workmanship by Frizzlife INC, Frizzlife will replace or repair components of the unit that Frizzlife has deemed to be broken within the limits of the warranty without charge. The customer is not responsible for any freight involved with shipping the item back for inspection and shipment of replacement items.
  • Page 22 Model: PD600-TAM3 1. Frizzlife is not liable for anything that we deem as abuse of the units, including but not limited to, misuse of product outside of intended use, equipment modifications, unauthorized repairs, improper installation, damage from freezing, hot water, fire or other acts of God outside of Frizzlife control.
