- Page 1 PX600 OWNER'S MANUAL REVERSE OSMOSIS Water Filtration System Follow Frizzlife www.frizzlife.com...
-
Page 2: Table Of Contents
CONTENT 1. Before Installation 2. Packing List 3. Product Introduction 4. Sample Connection 5. Installation Tips 6. Installation Steps 7. First Time Usage 8. User Interface 9. Replacement of Filter Cartridge 10. Filter Replacement Instruction 11. Hook Up to Your Refrigerator/Ice Maker 12. -
Page 3: Before Installation
Thank you for purchasing Frizzlife PX600 reverse osmosis undersink filter system, with 600G RO membrane. If you have any questions or need any assistance, please contact: support@frizzlife.com Find the installation video Search "Frizzlife PX600 installation" on www.youtube.com Register to get 150% warranty 1. -
Page 4: Packing List
2. Packing List Preinstalled System Housing PPC Filter(ASR711) RO Filter(ASR712-600G) TC Filter(ASR713) X 1 Set RO Faucet White 1/4” Tubing White 3/8” Tubing Red 1/4” Tubing X 1 Set Feed Water Valve 1/2”-3/8” Converter Drain Saddle Power Adapter X 1 Set Blade X 1 Plumber Tape 1/4”... -
Page 5: Product Introduction
3. Product Introduction Front Back ASR712-600G Power supply (RO filter) PX600 Connect to drinking faucet ASR711 (PPC Filter) Connect to drain pipe Do not use this plug ASR713 (TC Filter) Connect to water supply OUT TDS Filter life Filter life reset Flush button 4. -
Page 6: Installation Tips
5. Installation Tips How to cut the tubing? Please cut the tubing into two sections in proper length, make sure cut them squarely and cleanly. How to connect/disconnect the tubing? To connect: please push the tubing into the fitting and make sure it is fully inserted. Then put the blue lock clip on the fitting, it will lock the tubing in place. -
Page 7: Installation Steps
6. Installation Steps Precautions: Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection. Testing was performed under standard laboratory conditions, actual performance may vary. For cold water use only. This filter must be protected from freezing, which can cause cracking of the filter and water leakage. - Page 8 2). Connect the end of 3/8" tubing that has been softened into the 3-way feed water valve. Make sure push and squeeze the tubing to the very end. 3). Use a wrench to tighten the nut, please do not over tighten. Note: If the cold water pipe is 1/2", please connect one part of converter to the angle valve and connect another part of...
- Page 9 3). Connect cold water pipe onto the feed water valve. Valve installation complete. Step 4: Connect the "SUPPLY" water tubing 1). Except " DO NOT USE" one, remove all other three plugs by pressing the fitting sleeves. 2). Connect the other end of 3/8" tubing into "Supply" port on the back of the system, make sure to insert the tubing about 0.8 inch to the end of the fitting.
- Page 10 2). Choose a spot on the drain pipe that is convenient for installing the drain saddle. It is recommended to install the drain saddle on the vertical drain pipe. 3). Drill a 1/4" hole in the drain pipe. Make sure not to penetrate the opposite side of the pipe.
- Page 11 Install the drinking faucet Note: If the thickness of your counter is over 1.9”(4.8cm), please contact us at support@frizzlife.com to claim for longer stem. Note: If your counter top or granite does not have an existing hole, please drill one (1/2") before proceeding.
-
Page 12: First Time Usage
3). Connect the other end of 1/4" white tubing from the "FILTERED" port into the 1/4" quick fitting. Step 9: Connect the power cord 1). Turn on the angle valve and 3-way feed water valve. Check for leaks. 2). Insert the DC head of the power adapter into the "POWER"... -
Page 13: User Interface
Note: Please fully open the drinking faucet when dispensing water. Otherwise, it may cause system to malfunction. × 8. User Interface Power-on When the system is powered on, you will hear a beep. All indicators will be on for 3 seconds, and then the system will automatically flush for 30 seconds. -
Page 14: Automatic Flushing
Long-time operation reminder When the system keeps producing water continuously for 30 minutes, the system will enter into protection status and all the components stop working. The indicators will flash in red. In this condition, please unplug the power for 10 seconds then power on again. -
Page 15: Replacement Of Filter Cartridge
9. Replacement of Filter Cartridge The replacement filer cartridges are: PP+CB 2-in-1 filter, RO membrane and Post carbon filter. Please replace filter cartridges regularly according to the recommended replacement period shown below. Recommended Position Filter Model Number Replacement Period 6 months or cumulative water 1st stage PP+CB 2-in-1 filter ASR711... - Page 16 3). Remove the front cover of the filter. 4). Unscrew the cartridge needs to be replaced counter clockwise. Screw the new cartridge clockwise into the system. 5). Put back the front cover. 6). Connect the power code and turn on the water supply. Step 2: Reset the filter lifetime Long press the "Reset"...
-
Page 17: Hook Up To Your Refrigerator/Ice Maker
RO membrane, please do not use the water in the first 20 minutes. If you replace CP filter cartridges, please do not use the water in the first 10 minutes. 11. Hook Up to Your Refrigerator/Ice Maker The PX600 system can be connected with your refrigerator/lce-maker by utilizing an extra lMC-1 ice maker connection kit (not included). -
Page 18: Maintenance
Frizzlife now offer a perfect solution -- Frizzlife MWT3 mini water tank -- if you are encountering the following problems of tankless RO systems: 1.lf you consider the lagging outflow to be undesirable. 2.lf you are encountering the constant on and off issue of the system pumpdue to unstable/lack of water pressure. -
Page 19: Trouble Shooting
A. If the system has not been used for more than 2 days, please turn on the faucet and discharge the filtered water at least 5 minutes before usage. B. If the system will not be used for more than 1 week, please seal the filter cartridges and store them in the refrigerator but do not put them in the freezer. - Page 20 No water out of Connection of pipeline is Please check the pipelines and make faucet incorrect. sure the connection is correct. Please replace the filter according to Filter is blocked. the instruction. Water pressure is low, or water Please contact customer service team. Low water flow supply is insufficient.
-
Page 21: Frequently Asked Questions
After you put the water still for a while, all bubbles will be gone, the water is totally good for drinking. Why out TDS value of PX600 is higher than normal RO system? The first two stages of the system are able to eliminate more than 99.99% of all substances from your tap water, removing more than 94% of TDS value. -
Page 22: Limited Product Warranty
1 minute to get the water, since the whole system will not release any harmful substances to the water. The TDS removing rate for PX600 is about 94-95%, if your incoming TDS is high, the outlet TDS will be high too. - Page 23 1. Frizzlife is not liable for anything that we deem as abuse of the units, including but not limited to, misuse of product outside of intended use, equipment modifications, unauthorized repairs, improper installation, damage from freezing, hot water, fire or other acts of God outside of Frizzlife control.
- Page 24 150% Extended Warranty 1. Email us your order ID and full name at support@frizzlife.com 2. Scan the QR code below to register...
