- Page 1 OWNER'S MANUAL Model: PX500-A REVERSE OSMOSIS Water Filtration System Follow Frizzlife www.frizzlife.com...
-
Page 2: Table Of Contents
CONTENT 1. BEFORE INSTALLATION 2. PRODUCT INTRODUCTION 3. SAMPLE CONNECTION 4. INSTALLATION TIPS 5. INSTALLATION STEPS 6. FIRST TIME USAGE 7. USER INTERFACE 8. REPLACEMENT OF FILTER CARTRIDGE 9. FILTER REPLACEMENT INSTRUCTION 10.HOOK UP TO YOUR REFRIGERATOR/ICE MAKER 11.MINI TANK AVAILABLE NOW 12. -
Page 3: Before Installation
Model: PX500-A Thank you for purchasing Frizzlife PX500-A reverse osmosis undersink filter system with 500G RO membrane. If you have any questions or need any assistance, please contact: support@frizzlife.com Find the installation video Search "Frizzlife PX500-A installation" on www.youtube.com Register to get 150% warranty 1. -
Page 4: Product Introduction
Model: PX500-A 2. Product Introduction Front Back Accessories: Dedicated Faucet ASR312-500G (RO filter) Power supply Drain Saddle Feed Water Valve PX500-A Converter Set Connect to drinking faucet 1/4” White Tubing ASR313A (Alkaline filter) Connect to drain pipe 1/4” Red Tubing... -
Page 5: Installation Tips
Model: PX500-A 4. Installation Tips How to cut the tubing? Please cut the tubing into two sections in proper length, make sure cut them squarely and cleanly. How to connect/disconnect the tubing? To connect: please push the tubing into the fitting and make sure it is fully inserted. -
Page 6: Installation Steps
Model: PX500-A 5. Installation Steps Precautions: Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection. Testing was performed under standard laboratory conditions, actual performance may vary. For cold water use only. This filter must be protected from freezing, which can cause cracking of the filter and water leakage. - Page 7 Model: PX500-A Fig.3 Fig.4 Fig.5 Fig.6 Step 3: Connect the water supply (COLD WATER ONLY) Shut off the water supply. (Fig.7) Disconnect the cold water pipe from angle valve. Twist the feed water valve onto the angle valve and make sure the O ring is loaded.
- Page 8 Model: PX500-A Fig.10 Fig.11 Fig.12 Step 5： Install the drain saddle Disassemble the drain saddle, and peal off the black sticker and stick to saddle valve (Fig.13) Choose a spot on the drain pipe that is convenient for installing the drain saddle.
- Page 9 Step 8: Install the drinking faucet Note: If the thickness of your counter is over 1.5” (3.85cm), please contact us at support@frizzlife.com to claim for longer stem. Note: If your counter top or granite does not have an existing hole, please drill one (1/2") before proceeding.
- Page 10 Model: PX500-A Fig.24 Fig.21 Fig.22 Fig.23 Fig.28 Fig.27 Fig.25 Fig.26 Fig.29 Step 9: Connect the power cord Turn on the angle valve and 3-way feed water valve. Check for leaks. (Fig.30) Insert the DC head of the power adapter into the "POWER" port on the back of the system.
-
Page 11: First Time Usage
Model: PX500-A 6. First time usage The system will automatically flush for 30 seconds after the power supply is plugged Before first use or after filter replacement, please flush the filter system by turning on the faucet for 20 min. - Page 12 Model: PX500-A Power-on When the system is powered on, you will hear a beep. All indicators will be on for 3 seconds, and then the system will automatically flush for 30 seconds. After flushing, if there is no water production, it will turn into standby status.
-
Page 13: Replacement Of Filter Cartridge
Model: PX500-A Manual flushing When the system is in standby status, press the "Flush" button, the system will start flushing. Press the "Flush" button again to stop. Note: When the system is being flushed, the indicator will flash in blue. -
Page 14: Filter Replacement Instruction
Model: PX500-A Note: All the service life of the filter cartridge listed are based on actual laboratory test and the provided water. The actual service life of filter cartridge depends on source water quality and daily water usage. 9. Filter Replacement Instruction Step 1: Cut off the power and turn on the water faucet to release water pressure Cut off the water supply and power before replacement. -
Page 15: Hook Up To Your Refrigerator/Ice Maker
However, the essential elements such as calcium and magnesium may raise the TDS value of the water again. 10.Hook Up to Your Refrigerator/Ice Maker The PX500-A system can be connected with your refrigerator/Ice-maker by utilizing an extra IMC-1 ice maker connection kit (not included). -
Page 16: Mini Tank Available Now
2.If you are encountering the constant on and off issue of the system pump due to unstable/lack of water pressure. Simply search “Frizzlife MWT3” on Amazon, or frizzlife.com, or scan the QR code to purchase. Sample Pure Water Kitchen Faucet... -
Page 17: Maintenance
Model: PX500-A 12. Maintenance Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection. If you don't use the system for a long time: A. If the system has not been used for more than 2 days, please turn on the faucet and discharge the filtered water at least 5 minutes before usage. -
Page 18: Trouble Shooting
Model: PX500-A 13. Trouble Shooting Possible Cause Fault Solution The system is not connected Please check if the adapter is to the power adapter or the connected properly. connection is loose. No water Cold water valve, 3-way feed Please open the valves. - Page 19 Model: PX500-A Unchanged filter Electronic controller or Please contact customer service team. display panel is damaged. lifetime indicator The circuit board is boken. Please contact customer service team. The high pressure switch Please contact customer service team. is broken. System is unstoppable for The “FILTERED water”...
-
Page 20: Frequently Asked Questions
1 minute to get the water, since the whole system will not release any harmful substances to the water. The TDS removing rate for PX500-A is about 94-95%, if your incoming TDS is high, the outlet TDS will be high too. -
Page 21: Limited Product Warranty
1. Frizzlife is not liable for anything that we deem as abuse of the units, including but not limited to, misuse of product outside of intended use, equipment modifications, unauthorized repairs, improper installation, damage from freezing, hot water, fire or other acts of God outside of Frizzlife control. - Page 22 Do not use outdoors or in a location that is subjected to direct sunlight or freezing. This warranty will not be effective unless and until the Frizzlife is shown to have been used in accordance with the installation and maintenance instructions accompanying the product.
Need help?
Do you have a question about the PX500-A and is the answer not in the manual?
Questions and answers
The red indicater isn't reseting after filter change also other filters never indicated change after 5 years of use
The red indicator on the Frizzlife PX500-A may not be resetting after a filter change because the reset process was not performed correctly. After replacing the filter, you need to reset the system by pressing the reset button. If the red indicator persists, try unplugging the power for 10 seconds and then powering it on again. Ensure the filter is properly installed, as incorrect installation may also prevent the indicator from resetting.
This answer is automatically generated
