420W LED FOLLOWSPOT
Product
Updates:
V1
- FIRMWARE: V4.09
- RJ-LED2 FIRMWARE PLATFORM (Node Mode) full manual is
available for download at www.robertjuliat.com/LED/PDF_PAGE
DN41273400 (EN)
Released: 07/07/25
Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : +33 (0)3 44 26 51 89 - info@robertjuliat.fr
REF
www.robertjuliat.com
North American
Standard / CE
1176
1176C
Advertisement
Table of Contents
Related Manuals for Robert Juliat LEXIE 1176
Summary of Contents for Robert Juliat LEXIE 1176
- Page 1 - RJ-LED2 FIRMWARE PLATFORM (Node Mode) full manual is available for download at www.robertjuliat.com/LED/PDF_PAGE DN41273400 (EN) Released: 07/07/25 Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : +33 (0)3 44 26 51 89 - info@robertjuliat.fr www.robertjuliat.com...
-
Page 2: Table Of Contents
4.8 Optical filter ....................17 6.6 Selftest ......................42 4.8.1 Range ........................17 4.9 Colour........................17 4.9.1 Range ........................17 4.10 Gobo / Optical filter ..................18 Robert Juliat reserve the right to change or alter any of the items detailed on this page, to increase or improve manufacturing techniques without prior notice. -
Page 3: User's Instructions
Maybe harmful to the eye. 1.5 m (4.9 ft) 25 m (82 ft) Risk group 2. Luminaires should be positioned so that prolonged staring into luminaire at a distance closer than 11,4 m is not expected. EN - 1 - LEXIE 1176 Manual DN41273400... -
Page 4: Presentation
13. Zoom adjustment RJ45 network connector 14. Focus adjustment Handles 15. Colour changer Safety cable attachment point 16. Local display and controls Yoke 17. Identification plate Tilt locking handle Iris control 10. Gobo holder EN - 2 - LEXIE 1176 Manual DN41273400... -
Page 5: Identification Label
Universal "A" size gobo holder (metal, glass or frosted glass) IS750 Full closing iris with holder - Weight: 0.35 Kg PF1114 Ø165 mm metal filter holder M165TP 6 ways "push/pull" colour changer - Weight: 2.09 Kg DN41273300 Quick Start manual EN - 3 - LEXIE 1176 Manual DN41273400... -
Page 6: Accessories
Double slot front cassette for 180x180mm accessories - Weight: 0.43 Kg VD120 120 x 120 mm frosted glass PCP1716A 16A blue 2P+E 6h IEC60309 power connector DMXcat Bluetooth DMX/RDM Multifunction test tool - City Theatrical DMXcat® EN - 4 - LEXIE 1176 Manual DN41273400... -
Page 7: Set-Up
Maximum : Minimum 41°F 104°F IP20 - Indoor use only 3.1.4 Lifting Overhead view Net weight: 24 kg (52,8 lbs) 3.1.5 Safety cable • Safety cable attachment points Safety cable not supplied. EN - 5 - LEXIE 1176 Manual DN41273400... -
Page 8: Stand Set-Up
• Must be connected directly to AC power. Do not connect to dimmer power. • Automatic mains voltage detection. Daisy chain (with delivered power cable): Maximum : 5 units @ 230 V 2 units @ 120 V Power 2 units @ 100 V EN - 6 - LEXIE 1176 Manual DN41273400... -
Page 9: Data
2nd conductor of 1st twisted pair Not used 1st conductor of 2nd twisted pair Not used 2nd conductor of 2nd twisted pair DMX OUT DMX IN Daisy chain: Maximum : 31 units total DMX Console EN - 7 - LEXIE 1176 Manual DN41273400... -
Page 10: Art-Net / Sacn / Dual
(see Web Interface section of the manual). - Web interface is always available regardless of the protocol (Art-Net/sACN) selected. www.robertjuliat.com/LED/PDF_PAGE RJ-LED2 FIRMWARE PLATFORM (Node Mode) full manual is available for download at EN - 8 - LEXIE 1176 Manual DN41273400... -
Page 11: Accessories
3.4 Accessories 3.4.1 Iris 3.4.2 Gobo holder For gobo dimensions, see section 4.10 3.4.3 Colour changer unit: push-pull Clips (Parisien) For filter dimension, (3 pieces for each filter support) see section 4.9 EN - 9 - LEXIE 1176 Manual DN41273400... -
Page 12: Double Slot Front Cassette For Accessories
@ www.robertjuliat.com/ followspots/Accessories Caution: - Do not install the followspot sight on the lamp house to avoid blocking the ventilation vents. - Secure the sight with a suitable safety cable. EN - 10 - LEXIE 1176 Manual DN41273400... -
Page 13: Operations
Remotely with DMX / Art-Net /sACN / DUAL protocols DMX512-A T See 5.3 Home Values Default Home Values: - Dimmer @0 - Master dimmer @Full HTP mode (Highest Takes Precedence): Light output is the highest value Local control EN - 11 - LEXIE 1176 Manual DN41273400... -
Page 14: Parameters
T Set through RDM protocol, web interface or local control Mode Result Without PWM Flicker-Free, perfect for filming PWM 17 kHz Good dimming quality (Default Value) PWM 3,2 kHz Very good dimming EN - 12 - LEXIE 1176 Manual DN41273400... -
Page 15: Strobe
700 ms MEDIUM 470 ms MEDIUM 470 ms FAST 350 ms FAST 350 ms CUSTOM 0 - 4000 ms CUSTOM 0 - 4000 ms see 5.3 Home Values see 5.3 Home Values EN - 13 - LEXIE 1176 Manual DN41273400... -
Page 16: Beam Size Adjustment
4.4 Beam size adjustment 4.4.1 Range Beam angle Field angle Model Angles Minimum angle Maximum angle Beam angle 10.6° 15.5° 1176/C Field angle 11° 22.1° 4.4.2 Control FOCUS ZOOM FOCUS ZOOM EN - 14 - LEXIE 1176 Manual DN41273400... -
Page 17: Pan / Tilt
4.5 Pan / Tilt 4.5.1 Range Function Range 0 T 360° TILT 42° 42° 68° 60° Standard position Suspended position 4.5.2 Control Lock Unlock EN - 15 - LEXIE 1176 Manual DN41273400... -
Page 18: Iris
4.6 Iris 4.6.1 Range 100% Open iris Closed iris 4.6.2 Control 4.7 Gobo 4.7.1 Range For gobo dimensions, see section 4.10 EN - 16 - LEXIE 1176 Manual DN41273400... -
Page 19: Optical Filter
4.8 Optical filter 4.8.1 Range For filter dimension, see section 4.10 FO100-10 4.9 Colour 4.9.1 Range Type Coloured gel filter Ø165 mm Dimension See section 3.4.3 Installation Place dark colours towards the front end. EN - 17 - LEXIE 1176 Manual DN41273400... -
Page 20: Gobo / Optical Filter
4.10 Gobo / Optical filter Location Type Metal / Glass / frosted glass A-size Gobo installation Optical filter installation EN - 18 - LEXIE 1176 Manual DN41273400... -
Page 21: Controls And Parameters
000% Home Main display (home screen) STAND MASTER LOCAL 100% Diagnostic Nothing to report Diagnostics x1 push Link status : NOK DHCP : OFF 192.168.000.013 Network information MASK 255.255.255.000 192.168.000.001 x1 push EN - 19 - LEXIE 1176 Manual DN41273400... -
Page 22: Menus
FANS • VALUES (*) If availble for the fixture. POWER SUPPLY • VALUES LOCAL POTENTIOMETER • SETUP • ROTATION • CALIBRATION TEMPERATURES • VALUES COOLING • SILENT • NORMAL • FULL EXPERT EN - 20 - LEXIE 1176 Manual DN41273400... -
Page 23: Parameters
ON, select : SETUP DISPLAY AUTO OFF Always ON Always on Auto-OFF Auto OFF Timer without warning press OK Auto OFF only warnings to validate Main display turns OFF after 20 seconds EN - 21 - LEXIE 1176 Manual DN41273400... -
Page 24: Dmx512 - A Remote Control
Press OK PROFILE Start address: 00 1 to validate DMX address of the unit from 1 to 512 DATA MODE Personality Press OK PROTOCOL PERSONALITY DMX ADDI Press OK to validate to validate EN - 22 - LEXIE 1176 Manual DN41273400... -
Page 25: Parameters
– Once defined, the User ID is displayed on the Home screen. Example: Installation with 6 units Home screen ID1 @ 101 ID2 @ 123 ID3 @ 145 ID4 @ 167 ID5 @ 189 ID6 @ 211 information User ID DMX address EN - 23 - LEXIE 1176 Manual DN41273400... -
Page 26: Dmx Chart
Strobe ON - 1 ms T 20 ms 5.2.5.2 Strobe speed Range min Range max Function Frequency: 0,1 Hz T 10 Hz 5.2.5.3 Response time Range min Range max Function Response time: 0,1 s T 4 s EN - 24 - LEXIE 1176 Manual DN41273400... -
Page 27: Control Mode
Dimmer Curve Square Cooling mode: Silent Cooling mode: Normal Cooling mode: Full power Not used (*) Function activated after 5 seconds - needs to go back to zero to activate second function. EN - 25 - LEXIE 1176 Manual DN41273400... -
Page 28: Rdm Remote Control
✔ ✔ ✔ ✔ 04 00 04 01 LAMP_HOURS E1.20 ✔ ✔ ✔ ✔ ✔ ✔ Display Settings 05 01 DISPLAY_LEVEL E1.20 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ EN - 26 - LEXIE 1176 Manual DN41273400... - Page 29 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ 85 74 DMX_ERROR_COUNTER_DESCRIPTION E1.20 ✔ ✔ ✔ ✔ 85 75 DMX_ERROR_COUNTER E1.20 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ EN - 27 - LEXIE 1176 Manual DN41273400...
-
Page 30: Home Values & Standalone
- sACN - See section 5.4.2 - Dual: Sacn + Art-RDM (DMX512 data signal + RDM) - See section 5.4.3 From July 2024 the Robert Juliat equipment based on RJ LED2 platform is configured as follows: - DHCP (Dynamic Host Configuration Protocol - RFC1531) ON https://www.rfc-editor.org/rfc/rfc1531... - Page 31 Most personal computers are configured with DHCP and Zeroconf enabled, so the IP address defaults to 169.254.X.X with a subnet mask of 255.255.0.0. When connected to a Robert Juliat device, since the IP address/mask range are in the same class, network communication works seamlessly.
-
Page 32: Art-Net Remote Control
Set mode through RDM Local control (see 5.9 Web interface) protocol compatible device 1 - If necessary, change IP settings 2 - Set Art-Net Universe 3 - Set DMX address 4 - Set personality mode (see 5.2.4. DMX chart) EN - 30 - LEXIE 1176 Manual DN41273400... -
Page 33: Local Set-Up
DHCP: ON or OFF to validate IP address of the unit DATA MODE IP CONFIG IP-ADDRESS DATA MODE IP CONFIG Address 192.168.000.0 1 3 press OK press OK DHCP ADDRESS MASK to validate to validate EN - 31 - LEXIE 1176 Manual DN41273400... -
Page 34: Sacn Remote Control
Set mode through Web interface Set through local control (see 5.9 Web interface) 1 - If necessary, change IP settings 2 - Set sACN universe 3 - Set DMX address 4 - Set personality mode (see 5.2.4. DMX chart) EN - 32 - LEXIE 1176 Manual DN41273400... -
Page 35: Local Set-Up
DHCP: ON or OFF to validate IP address of the unit DATA MODE IP CONFIG IP-ADDRESS DATA MODE IP CONFIG Address 192.168.000.0 1 3 press OK DHCP ADDRESS MASK press OK to validate to validate EN - 33 - LEXIE 1176 Manual DN41273400... -
Page 36: Dual Remote Control
Set through local control Set mode through Web interface (see 5.9 Web interface) 1 - If necessary, change IP settings 2 - Set DUAL universe 3 - Set DMX address 4 - Set personality mode (see 5.2.4. DMX chart) EN - 34 - LEXIE 1176 Manual DN41273400... -
Page 37: Local Set-Up
DHCP: ON or OFF to validate IP address of the unit DATA MODE IP CONFIG IP-ADDRESS DATA MODE IP CONFIG Address 192.168.000.0 1 3 press OK press OK DHCP ADDRESS MASK to validate to validate EN - 35 - LEXIE 1176 Manual DN41273400... -
Page 38: Web Interface
SETUP Page EXPERT Page, password-protected (1280). NODE Page UID* list of devices detected by RDM on the DMX OUT link; (*) UID : RDM Unique Identifier the first UID is the fixture. EN - 36 - LEXIE 1176 Manual DN41273400... -
Page 39: Llrp (Low-Level Reader Protocol)
In summary, LLRP simplifies the process of identifying and configuring the IP addressing of LLRP-compatible devices on your network. All Robert Juliat equipment based on the RJ LED2 platform includes LLRP functionality. Two LLRP Manager software tools are available for free: DMXworkshop by Wayne Howell from Singularity (UK): https://singularity-uk.com/product/dmx-workshop/... -
Page 40: Fan Cooling Modes
FULL Maximum – constant speed Modes Silent Normal Full Cooling Ambiant temperature: 30°C 100% Brightness 5.5.2 Control DMX512-A Remotely by DMX512-A Locally T selection in Mode 3 – 4 SETUP / COOLING EN - 38 - LEXIE 1176 Manual DN41273400... -
Page 41: Service
• To clean the optical parts, use a soft cloth in combination with distilled water or isopropyl alcohol recommended for coated optics. Do not use any cleaning product that contains solvents or abrasives, as these can cause surface damage. • Dry with a soft lint-free cloth. EN - 39 - LEXIE 1176 Manual DN41273400... - Page 42 Dismantle the top lamp house cover (A) by removng the 16 screws B #1 & #2 + B #7 to #10 using a torx screwdriver with a TX20 bit. Then remove the plate (C). EN - 40 - LEXIE 1176 Manual DN41273400...
-
Page 43: Analysis
• Never type a zero (0) before the numbers XX or X (see 5.4.4) 7. Upload your firmware file (.upd2) In the “Update firmware” window, select the update file and click on “Submit firmware”. EN - 41 - LEXIE 1176 Manual DN41273400... -
Page 44: Factory Defaults
(SELFTEST). dmxo If the problem persists, please take a photo of the test result and send it either to your Robert Juliat dealer or to the Robert Juliat After-Sales Service, if requested (email: service@robertjuliat.fr) EN - 42 -...
