Important before assembly:
Read these instructions carefully before assembling or using the product.
■ Please check the contents of the boxes before attempting to assemble this product. The
instructions will have a checklist of parts and fittings.
■ It would be sensible to lay a rug or a carpet on the floor where you intend to assemble the
product, to avoid scratches and damaging the product or the floor.
■ Assemble the product as close to its intended final location/room as possible.
■ Do NOT use any power tools as this may damage the frame.
Health & Safety:
■ This product or some parts of this product will be heavy. Please use an assistant when lifting.
■ DO NOT jump on the product or any of its parts.
■ DO NOT use this product if any parts are missing, damaged or worn.
■ DO NOT use this product unless all fixings are secured.
■ Please keep small parts out of reach of children.
■ Always use on a level, even surface.
Please keep these instructions for future reference.
Assembly Instructions
Divan Beds
(Including Ottoman Beds & Build Your Own Bed)
5 - 10 mins
Assembly
Advertisement
Related Manuals for Happy Beds Divan Beds
Summary of Contents for Happy Beds Divan Beds
- Page 1 5 - 10 mins Assembly Assembly Instructions Divan Beds (Including Ottoman Beds & Build Your Own Bed) Important before assembly: Read these instructions carefully before assembling or using the product. ■ Please check the contents of the boxes before attempting to assemble this product. The instructions will have a checklist of parts and fittings.
- Page 2 These tools are not necessary, but may help to assemble certain parts of the product. Do NOT use any power tools as this may damage the frame. (Not metal) This product or some parts of this product will be heavy. Please use an assistant when lifting. Never drag or push the pieces across a hard or stone floor as this will cause damage to the joints.
- Page 3 Contents For Single Bases (2ft6, 3ft) For Double Bases (4ft, 4ft6) For King & Super King Bases (5ft, 6ft) Ottoman Bases: For Single Ottoman Bases (2ft6, 3ft) For Double Ottoman Bases (4ft, 4ft6, 5ft, 6ft) May 2023 - E&OE - V.4 www.happybeds.co.uk...
- Page 4 For Single Bases (2ft6, 3ft) (Skip to Page 7 for Double or Page 11 for King/Superking) Parts & Fittings Check List Headboard Bolts Gliders Base If headboard was ordered, the parts and fittings will be separate Instructions 1. Remove the outer packaging and cardboard corner protectors.
- Page 5 If you have a headboard to attach (or have an existing one)... 6. Locate the headboard stickers on either end of the base. 7. Decide which end the headboard will attach to and pierce the centre of the stickers. (Please Note: This action is irreversible, so please be sure of which end the headboard will attach.
- Page 6 (For Divan Beds with drawers) 11. The drawers are already installed within the Divan Bed base. Strips of fabric keep the drawers in place during transit and will need to be removed to allow access to the drawers. Remove these strips of fabric via pulling, tugging or cutting them off.
- Page 7 For Double Bases (4ft, 4ft6) (Go to Page 4 for Single or Page 11 for King/Superking) Parts & Fittings Check List Link Bars Headboard Bolts Bases Gliders Link Bar Screws If headboard was ordered, the parts and fittings will be separate Instructions 1.
- Page 8 6. Carefully flip the bases so that they are now resting atop the gliders, firmly pressing down on each corner of the bases to ensure that they are stable. 7. Locate the link bar holes where the two straight sides of the bases meet. They should be located near the top of the bases.
- Page 9 13. Press both headboard screws into the pierced holes until meeting resistance. Proceed to screw the headboard screws clockwise, leaving enough space for the headboard struts to fit into place. (for the headboard struts fixing, please follow the instructions that came separately with the headboard) 14.
- Page 10 (For Divan Beds with drawers) 16. The drawers are already installed within the Divan Bed base. Strips of fabric keep the drawers in place during transit and will need to be removed to allow access to the drawers. Remove these strips of fabric via pulling, tugging or cutting them off.
- Page 11 For King & Superking Bases (5ft, 6ft) (Go to Page 4 for Single or Page 7 for Double) Parts & Fittings Check List Link Bars Headboard Bolts Gliders Bases Link Bar Screws If headboard was ordered, the parts and fittings will be separate Instructions Remove the outer packaging and cardboard corner protectors.
- Page 12 6. Carefully flip the bases so that they are now resting atop the gliders, firmly pressing down on each corner of the bases to ensure that they are stable. 7. Locate the link bar holes where the two straight sides of the bases meet. They should be located near the top of the bases.
- Page 13 12. Press all 4 headboard screws into the pierced holes until meeting resistance. Proceed to screw the headboard screws clockwise, leaving enough space for the headboard struts to fit into place. (for the headboard struts fixing, please follow the instructions that came separately with the headboard) 13.
- Page 14 (For Divan Beds with drawers) 15. The drawers are already installed within the Divan Bed base. Strips of fabric keep the drawers in place during transit and will need to be removed to allow access to the drawers. Remove these strips of fabric via pulling, tugging or cutting them off.
- Page 15 Assembly Instructions Ottoman Beds Important before assembly: Read these instructions carefully before assembling or using the product. ■ Please check the contents of the boxes before attempting to assemble this product. The ■ ■ ■ Do NOT use any power tools as this may damage the frame. Health &...
- Page 16 Important for Ottoman and other gas lift beds Note: The bed base is in the upright position when first assembled as the gas lifts are fully extended during shipment for safety. After assembly a firm downward push will be required to overcome any resisitance in the gas lifts as these may initially stick.
- Page 17 Instructions 1. Remove the outer packaging and cardboard corner protectors. 2. Flip the divan base on its top so that the Gliders underside is accessible. 3. Locate the pre-drilled holes at each corner of the base. 4. Securely, but gently, insert the four gliders into the bottom of the base.
- Page 18 For Double Bases Step 3. Join the two lid-frames together with the bolt provided under the lid. Bolt Step 2. Join both halves of the base together using the two link clips provided. Ensure the square edges are adjacent. Space out each clip along the base.
- Page 19 headboard If you have a to attach (or have an existing one)... 7. Locate the headboard stickers on the end of the base. IMPORTANT: For Double or King bases, NOT ALL the stickers will be pierced, but only those that are required, aligning with the headboard struts on both bases.
- Page 20 Please dispose of all packaging safely. General Care & Maintenance Wipe clean with a slightly damp cloth. Avoid the use of all household cleaners and abrasives. Periodically check all screw & fixings to ensure they are secure. When moving your product, carefully lift into place. Never drag or push the product across the floor as this will cause damage to the joints.
