Control Panels
D9412GV4/D7412GV4/D7212GV4
en
Owner's Manual Supplement

Advertisement

loading
Need help?

Need help?

Do you have a question about the D9412GV4 and is the answer not in the manual?

Questions and answers

Related Manuals for Bosch D9412GV4

Summary of Contents for Bosch D9412GV4

  • Page 1 Control Panels D9412GV4/D7412GV4/D7212GV4 Owner's Manual Supplement...
  • Page 2 D9412GV4/D7412GV4/D7212GV4 | Owner's Manual Supplement System Requirements Minimum system requirements for Classification in accordance with ANSI/SIA CP-01-2007: • UL Listed and Classified control unit Model D9412GV4, D7412GV4, or D7212GV4 • UL Listed and Classified keypad Model D1256, D1257, D1260, D1255, D1255R, or D1255 RW •...
  • Page 3 User-Caused False Alarms, Arming the System User-Caused False Alarms, Disarming the System Arming and Disarming with Keyswitches Alarm Transmission Sequence – Alarm Abort Cancel Report and Cancel Window Duress Alarm Swinger Shutdown Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 4 4. Enter a second valid passcode with the authority to Passcode Disarm by pressing the passcode digits followed by the [ENTER] or [ENT] key. The second passcode must be different from the first passcode. The area is disarmed and ready for entry. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 5 The GV4 Series Control Panels change from one armed state to another armed state without disarming. The Easy Exit Control feature decreases the number of keystrokes and simplifies system operation. This feature is available by default and is always on. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 6 This feature causes no restrictions to the keypad scope as it pertains to any command or arming method other than Passcode Arming or Passcode Disarming. I have this feature. I do not have this feature. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 7 The system shows the user the menu options allowed according to their authority level, thereby providing users only pertinent commands and functions. I have this feature. I do not have this feature. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 8 Walk Tests 2.6.1 Description The D9412GV4, D7412GV4, and D7212GV4 have three Walk Test menus that allow the user to test various points that are within the scope of the keypad without sending a report to the central station. When performing a Walk Test, the Walk Test menu indicates that the menu is ready to time out, and clearly indicates on all keypads in the area of operation that a test is in progress.
  • Page 9 ### PTS UNTESTED. 7. Press the [NEXT] key to view the first point’s name. 8. Press the [ENT] key to view the point’s hardware state. Refer to Table 2. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 10 5. Press the View untested Pts softkey to see ### PTS UNTESTED. 6. Press the Next Pt softkey to view the first or next untested point: [Point Text] Area #, Pt # [Point State] HW Next PT> <Exit Prev PT> Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 11 Door Activated Custom Function 2.7.1 Description The D9412GV4 and D7412GV4 allow a custom function to be activated when user credentials are presented to a D9210C Door Controller Reader. The custom function executes as if the user performed a function at the keypad that is associated with the door controller.
  • Page 12 Dual Authentication Process The Dual Authentication process can be performed by entering a passcode followed by the [ENT] or [ENTER] key, then presenting valid access credentials to the associated Door Controller reader. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 13 6. If the access level is currently disabled, LEVEL # ENABLE? appears. If the access level is currently enabled, LEVEL # DISABLE? appears. Press [ENT] to accept the choice. 7. ENTER LEVEL appears again. Press [ESC]. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 14 2.10.2 Using Door Control? On a D1255 Keypad 1. Ensure that the display shows idle disarmed text. 2. Press the [COMMAND] key. The display shows SYSTEM COMMAND. 3. Press [4] and [6]. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 15 Table 3. Depending on your keypad, the operations in this section are the same, but the keypad display and keys are slightly different. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 16 For example, to unlock Door 4, at the following prompt, press [4], then press [ENT]. UNLOCK DOOR 1 2 3 4 5 6 7 8 Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 17 The display shows SECURE DOOR 1 2 3 4 X 6 7 8. This indicates that all doors are in a normal state, except for Door 5, which is secured. 4. Press [ESC] to leave this sub-function, or enter another door number to unlock. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 18 Press [ENT]. If this is not the user you wish to delete, press the [NEXT] or [PREV] key until the correct user name appears, then press [ENT]. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 19 Press [ENT] if the correct user number (or user name) appears. Press [ESC] if not. 6. ADD PASSCODE? appears. (If the user number already exists, CHANGE PASSCODE? Appears.) Press [ENT]. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 20 On a D1260 Keypad 14. Ensure that the display shows idle disarmed text. 15. Press the [COMMAND] key. The display shows *System Command*. 16. Press [5] and [6]. Enter passcode if necessary. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 21 [ENTER] to accept. Repeat Steps 26 and 27 until all authorized areas are set. 28. Level Added or Level Changed appears when all area assignments are made. Press [ENTER]. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 22 I have this feature. I do not have this feature. Enrolling a User Keyfob with RFID On a D1255 Keypad 1. Ensure that the display shows idle disarmed text. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 23 5. If successful, KEYFOB ADDED appears. KEYFOB USER: ### appears scrolling with AUTO-LEARNED. Press [ESC] to exit. 6. If not successful, an error message is displayed. KEYFOB USER: ### appears scrolling with NOT ASSIGNED. Press [ESC] to exit. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 24 5. If successful, Keyfob Added appears followed by Keyfob User (###) RFID: Auto-Learned. Press the Exit softkey. 6. If not successful, an error message is displayed followed by Keyfob User (###) RFID: Not Assigned. Press the Exit softkey. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 25 Keyfob User (###) RFID: Not Assigned. Press the Exit softkey. Remove a User Keyfob On a D1255 Keypad 1. At the USER KEYFOBS? prompt, press [ENT]. 2. ENTER RFID appears. Press [NEXT] until REPLACE KEYFOB appears. Press [ENT]. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 26 5. If successful, Keyfob Removed appears followed by Keyfob User (###) RFID: Not Assigned. Press the Exit softkey. 6. If not successful, an error message is displayed followed by Keyfob User (###) RFID: Not Assigned. Press the Exit softkey. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 27 This section of the user’s guide supplement will help to explain proper operation of your SIA CP-01 compliant Bosch Security Systems, Inc. D9412GV4, D7412GV4, or D7212GV4 Control Panel. Your installation company must configure all features necessary to provide SIA CP-01 compliance.
  • Page 28 Time, the control panel creates an “Exit Error” event as specified by the SIA standard: 1. An Exit Delay point remains faulted at the end of Exit Delay. 2. Entry Delay starts. Keypads show DISARM NOW and the Entry Tone sounds. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 29 No other keys are required. When the control panel is in Exit Delay or is armed, entry of a valid Passcode must be followed by an [ENTER] or [ENT] key. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 30 If a valid passcode is not entered, the alarm begins sounding again after a period of about 10 sec with no keypad activity. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 31 The maximum number of faults allowed on a point is called the Swinger Count. This value was set by the installer. Bosch Security Systems, Inc. | 9/11 | F01U245224-02...
  • Page 32 Bosch Security Systems, Inc. 130 Perinton Parkway Fairport, NY 14450 www.boschsecurity.com © Bosch Security Systems, Inc., 2011...
