Hitachi UTOPIA IVX Series Service Manual

Hide thumbs Also See for UTOPIA IVX Series:

Instruction manual (341 pages)

page of 413

/ 413
Bookmarks

Advertisement

Quick Links

Download this manual

UTOPIA IVX

SERIES

Service Manual

Outdoor Units: 8 ~ 12 HP

Indoor Units Type:

• 4-Way Cassette

• 2-Way Cassette

• Ceiling

• In-the-Ceiling

• Wall

• Floor

• Floor Concealed
