Secret Lab MAGNUS Assembly Manual And User Manual
Metal desk
Hide thumbs
Also See for MAGNUS:
- User manual ,
- Manual (84 pages) ,
- Assembly manual & user's manual (4 pages)
Related Manuals for Secret Lab MAGNUS
Summary of Contents for Secret Lab MAGNUS
- Page 1 Assembly Guide and User Manual Secretlab MAGNUS Metal Desk ® NUMBER OF PEOPLE PLEASE READ FIRST ASSEMBLY TIME 10 MINUTES 15 MINUTES...
- Page 2 Warnings and Caution Use and Liability Technical Specifications What’s In the Box Assembly Tool Kit Assembly Guide Assembling the Secretlab MAGNUS Installing the Secretlab MAGPAD™ Final Touches Usage Instructions Handling the Hinged Rear Cover Mounting a Monitor Arm Mounting the Tray Passthrough Cover...
- Page 3 Do not use attachments not recommended by the manufacturer. The Secretlab MAGNUS Metal Desk is designed for indoor use and dry work areas only. Do not use outdoors. Do not operate in environments with high heat, high humidity, high salinity or pollutant gases.
- Page 4 TECHNICAL SPECIFICATIONS 92mm/3.6” 585mm/23” 1500mm/59.0” 700mm/27.6” 1500mm/59.0” 735mm/29” 1380mm/54.3” Extendable up to 20mm/0.8”...
- Page 5 WHAT’S IN THE BOX FRONT LEG FRONT LEG REAR LEG REAR LEG Cable Tray + Tray Passthrough Cover Support Bar Hinged Rear Cover Rear Leg Metal Desk Top Front Leg Rear Leg Bracket Secretlab MAGPAD Desk Mat ™ (Optional) x1 ASSEMBLY TOOL KIT Cable Fastening Strap M3 Allen Key...
- Page 6 ASSEMBLY GUIDE Assembling the Secretlab MAGNUS TEAM LIFT With at least two people, lift the Metal Desk Top and place it upside down onto a debris-free area to protect the Metal Desk Top surface. REAR LEG SHORT FLAT HEAD SCREW (WITH NYLOK)
- Page 7 ASSEMBLY GUIDE REAR LEG LONG FLAT HEAD SCREW REAR LEG Align the Mounting Blocks onto the Rear Legs and screw in the fasteners. REAR LEG FRONT LEG SHORT FLAT HEAD SCREW Remove the straps and slot the Desk Legs into the Metal Desk Top and tighten the fasteners in a diagonal sequence.
- Page 8 ASSEMBLY GUIDE PAN HEAD SCREW Slot the Support Bar upward onto the Mounting Blocks and screw in the fasteners. Remove the Tray Passthrough Cover. Align and attach the back of the Cable Tray onto the Support Bar magnetically.
- Page 9 ASSEMBLY GUIDE SHORT FLAT HEAD SCREW Once the back of the Cable Tray is magnetically attached onto the Support Bar, screw in the fasteners at the front of the Cable Tray. With at least two people, lift and flip the desk without resting weight on TEAM LIFT the sides of the legs.
- Page 10 Hinged Rear Cover onto the Secretlab MAGNUS. Screw in the fasteners. Installing the Secretlab MAGPAD ™ Remove the Metal Sleeves from the inside of the rolled up Secretlab MAGPAD. Set them on the sides of the Secretlab MAGNUS. Unfasten the center strip.
- Page 11 flushed with the edge of your Secretlab MAGNUS. Align Pull the center strip to unroll the Secretlab MAGPAD. Take care to align the bottom edge of the desk mat with the Secretlab MAGNUS as you unroll it. Align Unroll...
- Page 12 Metal Sleeve onto the Secretlab MAGPAD. Ensure that the MAGPAD has been fully inserted into the sleeve. Slide the Metal Sleeve up to the edge of the Secretlab MAGNUS. Adjust to cover any visible gap. Align Final Touches - Adjusting the Desk Height...
- Page 13 fingers clear of this area. Mounting a Monitor Arm If you plan on using a monitor arm with the Secretlab MAGNUS, we recommend it to be mounted within the midsection of the desk. It will be easier to access the...
- Page 14 USAGE INSTRUCTIONS Mounting the Tray Passthrough Cover Place the Passthrough Cover back onto the Cable Tray and the Secretlab MAGNUS Metal Desk is now ready for your long hours of work or play! DISPOSAL OF YOUR OLD PRODUCT Please find out about your local collection system for the product. The correct disposal of your old...
- Page 15 Secretlab, the Secretlab logo and the Triangle logo are registered trade marks of Secretlab. Magnus is a registered trade mark of Secretlab in Singapore, New Zealand and the Phillipines. The Magnus logo is a registered trade mark of Secretlab in the EU.
