DeDietrich AMC PRO EVO 35 Installation And User Manual

DeDietrich AMC PRO EVO 35 Installation And User Manual

High-efficiency wall-hung gas boiler
Hide thumbs

Advertisement

Quick Links

Download this manual
en
Installation and user manual
High-efficiency wall-hung gas boiler
AMC PRO EVO
35
45
65
90
115

Advertisement

loading
Need help?

Need help?

Do you have a question about the AMC PRO EVO 35 and is the answer not in the manual?

Questions and answers

Related Manuals for DeDietrich AMC PRO EVO 35

Summary of Contents for DeDietrich AMC PRO EVO 35

  • Page 1 Installation and user manual High-efficiency wall-hung gas boiler AMC PRO EVO...
  • Page 2 Dear Customer, Thank you very much for buying this appliance. Please read through the manual carefully before using the product, and keep it in a safe place for later reference. In order to ensure continued safe and efficient operation we recommend that the product is serviced regularly.
  • Page 3 Contents Contents Safety ................... . 6 General safety instructions .
  • Page 4 Contents 6.1.3 Preparing the gas circuit ..............44 Control panel description .
  • Page 5 Contents 11.7.5 Increasing the domestic hot water temperature temporarily ........105 11.8 Switching the summer mode on or off .
  • Page 6 1 Safety Safety General safety instructions Danger Hazardous appliance Chance of injury for unqualified users. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 7 1 Safety Safety instructions for the installer Danger Gas leakage Chance of explosion. If you smell gas, always do the following: Do not use naked flames, do not smoke, and do not operate electrical contacts like a doorbell, light switch or lift button.
  • Page 8 1 Safety Caution Hot parts Burn hazard. Do not touch radiators for long periods. The temperature of the radiators can rise to over 60 °C. Caution Hot water Burn hazard. Be careful when using the domestic hot water. The temperature of domestic hot water can rise to over 65 °C. Caution Component wear Dangerous situations due to worn components.
  • Page 9 2 About this manual 1.4.3 User's liability To guarantee optimum operation of the system, you must abide by the following instructions: Read and follow the instructions given in the manuals for the product. Call on a qualified professional to carry out the installation and initial commissioning. Have your installer explain the installation to you.
  • Page 10 (1) Nominal output 50/30 °C. (2) Nominal output 80/60 °C. (3) This boiler type is a AMC PRO EVO 45 configured at 35 kW. Use the AMC PRO EVO 35 information given in this manual. Main components Fig.1 General AD-3002806-01...
  • Page 11 3 Description of the product Fig.2 Internal 1 Heat exchanger 2 Burner 3 Interior light 4 Ignition / ionisation electrode 5 Flame inspection glass 6 Non-return valve 7 Ignition / ionisation transformer 8 Automatic air vent AD-3002807-01 Fig.3 Gas - air unit 1 Front plate with mixing tube 2 Fan 3 Venturi...
  • Page 12 3 Description of the product Fig.4 Sensors and boxes 1 Flow temperature sensor 2 Flue gas temperature sensor 3 Water pressure sensor 4 Heat exchanger temperature sensor 5 Return temperature sensor 6 Control box 7 Expansion box AD-3002809-01 Introduction to the controls platform The AMC PRO EVO boiler is equipped with the controls platform.
  • Page 13 4 Before installation Item Description Function S-bus System Bus: Connection between appliances The system bus provides communication between appliances. R-bus Room unit Bus: Connection to a room unit The room unit bus provides communication to a room unit. Device A device is a PCB, control panel or a room unit. Appliance An appliance is a set of devices connected via the same L-bus System...
  • Page 14 4 Before installation Notice Insufficient support Damage to the product. Make sure the wall or construction can hold the weight of the appliance. Important An earthed electrical connection must be available close to the appliance. A connection to the drain must be available close to the appliance. When choosing the best installation location, consider: The regulations.
  • Page 15 4 Before installation We recommend to install a fill and drain valve in the return pipe to facilitate servicing work. Place it between the isolation valve and the appliance. We recommend to install an expansion vessel in the return pipe. Place it between the isolation valve and the appliance. We recommend to install a central heating filter in the return pipe to prevent clogging of internal components.
  • Page 16 4 Before installation Tab.5 Type of flue system: B Principle Description Recommended manufactur­ Room-ventilated version. Connection material: Without down-draught diverter. Cox Geelen Joint flue gas discharge via the roof, with guaranteed natural Poujoulat draft (at all times underpressure in the joint discharge duct). Ubbink Flue rinsed with air, air from the installation area (special con­...
  • Page 17 4 Before installation Tab.8 Type of flue system: C Principle Description Recommended manufactur­ Combined air inlet and flue system (common shared flue sys­ Connecting material to the tem) with overpressure. common shared flue system: Concentric (preferably). Cox Geelen Parallel (if concentric is not possible). Poujoulat Ubbink Minimum permitted pressure difference between the air inlet...
  • Page 18 4 Before installation Tab.11 Type of flue system: C 93(X) Principle Description Recommended manufactur­ Room-sealed version. Connection material and roof terminal: Air inlet and flue in shaft or duct: Concentric. Cox Geelen Air supply from existing shaft or duct. Poujoulat Flue gas discharge via the roof.
  • Page 19 4 Before installation Fig.8 Sample string 1 EN 14471 or EN 1856–1: The material is CE approved according to this standard. For plastic this is EN 14471, For aluminium and stainless steel this is EN 1856-1. 2 T120: The material has temperature class T120. A higher number EN 14471 - T120 P1 W 1 O50 LI E U0 is also allowed, but not lower.
  • Page 20 Calculation: L = L AD-3002009-01 Tab.16 Maximum length (L) Diameter 80 mm 80 mm 100 mm 100 mm AMC PRO EVO 35 29 m 40 m 40 m 40 m AMC PRO EVO 45 39 m 40 m 40 m...
  • Page 21 Calculation: L = L AD-3002011-01 Tab.18 Maximum length (L) Diameter 80/125 mm 80/125 mm 100/150 mm 100/150 mm AMC PRO EVO 35 18 m 20 m 20 m 20 m AMC PRO EVO 45 20 m 20 m 20 m...
  • Page 22 36 m. AD-3002013-01 Tab.20 Maximum length (L) Diameter 80 mm 80 mm 100 mm 100 mm AMC PRO EVO 35 16 m 40 m 40 m 40 m AMC PRO EVO 45 29 m 40 m 40 m...
  • Page 23 4 Before installation Condensation Direct connection of the flue gas outlet to structural ducts is not permitted because of condensation. If condensate from a plastic or stainless steel pipe section can flow back to an aluminium part in the flue gas outlet, this condensate must be discharged via a trap before it reaches the aluminium.
  • Page 24 4 Before installation Fig.16 Controllers 1 Room unit (thermostat) (R) 2 Controller (R) 3 Wall box (R) 4 Building management system (R) AD-6000163-01 Fig.17 Producers 1 Gas boiler (A) 2 Gas boiler with internal pump (A) 3 Heat pump (A) 4 Heat pump with internal pump (A) 5 Undefined producer (A) 6 Undefined producer with internal pump (A)
  • Page 25 4 Before installation Fig.23 Tubing 1 Flow pipe 2 Return pipe 3 Heating or cooling pipe 4 Flow to return pipe 5 Water supply 6 Flow collector pipe 7 Return collector pipe AD-6000160-01 4.9.2 Single boiler - 2 circuits (Direct circuit, Underfloor mixing circuit) - Domestic hot water cylinder with two sensors Fig.24 Diagram and components - 6000254...
  • Page 26 4 Before installation 4.9.3 Single boiler - 3 circuits (Underfloor mixing circuit, Fan coil unit (direct), Swimming pool (direct)) - Domestic hot water cylinder with two sensors Fig.26 Diagram and components - 6000255 CircA CircB CircC AD-6000255-01 CircA Circuit A (Underfloor mixing circuit) P12 Circuit C pump CircB Circuit B (Fan coil unit (direct)) P13 DHW charge pump...
  • Page 27 4 Before installation 4.9.4 Cascade of two boilers - 3 circuits (Mixing circuit, Mixing circuit, Mixing circuit) - Domestic hot water cylinder with two sensors Fig.28 Diagram and components - 6000256 CircA CircB CircC AD-6000256-01 CircA Circuit A (Mixing circuit) P12 Circuit C pump CircB Circuit B (Mixing circuit) P13 DHW charge pump...
  • Page 28 5 Installation Fig.31 S-Bus connections - Lead boiler A1 to Lag boiler A2 AD-6000157-01 N1 S-Bus terminator N2 S-Bus connection between appliances Tab.27 Parameter list Display text Set on device Set to Code CP020 Zone Function SCB-10 2 = Mixing Circuit CP021 Zone Function SCB-10...
  • Page 29 5 Installation Fig.34 Positioning the boiler 3. Lift and position the boiler: 3.1. Remove the other pieces of packaging. 3.2. Lift the boiler out of the lower tray. 3.3. Hang the boiler on the wall bracket. For the desired position of the boiler, you can move the boiler 30 mm to the left or right from the centre of the wall bracket.
  • Page 30 5 Installation Connecting the discharge Fig.37 Connecting the discharge 1. Remove the dust cap from the condensate connection 2. Fit the flexible condensate drain hose on the condensate outlet. 3. Lead this drain hose to a plastic drain pipe of Ø 32 mm or larger, terminating in the drain.
  • Page 31 5 Installation Fig.40 Advised positions 1/2 Z 1/2 H (min. 2,5 m) MW-8800N001-3 1/2 H (min. 2,5 m) 1 Optimum location H Inhabited height controlled by the sensor 2 Possible location Z Inhabited area controlled by the sensor Avoid placing the outdoor temperature sensor in a position with the following characteristics: Masked by part of the building (balcony, roof, etc.).
  • Page 32 5 Installation Fig.43 Quick connect location 1 L-Bus socket for a 4 pin Molex Micro-Fit plug 2 S-Bus socket for a RJ12 plug 3 S-Bus socket for a RJ12 plug Warning Cable quality Chance of electrical fire Only use original cables that are either available as an accessory, or are provided with an accessory.
  • Page 33 5 Installation Fig.47 PCB locations AD-3002824-01 Tab.28 Primary and optional locations Device Primary location Location option CU-GH22 CB-23 SCB-09 (optional) 3 / 4 SCB-10 AD249 (optional) GTW-08 Modbus (optional) GTW-21 BACNet (optional) 5.8.3 Access to the control box Fig.48 Tilt the control box forward 1.
  • Page 34 5 Installation Fig.49 Lift the cover 3. Gently pull forward the clips on the front side and back side the cover simultaneously. 4. Lift the cover. The connectors on the connection board are now accessible. You can also access the control unit. Repeat the steps with the clips on the front side and back side of the other cover.
