User's Manual

Purifier

PCR & Tissue Culture Enclosures

Models

3951400

3951420

3952400

3962420

www.labconco.com/productreg.html

or return the attached card and

receive FREE LabbyWear

Non-Ventilated

™

Labconco's Mascot,

Labby the LABster

LABCONCO CORPORATION

8811 PROSPECT AVENUE

KANSAS CITY, MO 64132-2696

800-821-5525, 816-333-8811

FAX 816-363-0130

E-MAIL labconco@labconco.com

HOME PAGE www.labconco.com

Need help?

Do you have a question about the Purifier 3951400 and is the answer not in the manual?

Questions and answers

Summary of Contents for Labconco Purifier 3951400

Page 1 3962420 Register your product online at www.labconco.com/productreg.html or return the attached card and receive FREE LabbyWear ™ Labconco’s Mascot, Labby the LABster LABCONCO CORPORATION 8811 PROSPECT AVENUE KANSAS CITY, MO 64132-2696 800-821-5525, 816-333-8811 FAX 816-363-0130 E-MAIL labconco@labconco.com HOME PAGE www.labconco.com...
Page 3 The warranty for all Labconco products will expire one year from date of installation or two years from date of shipment from Labconco, whichever is sooner, except the following: •...
Page 4 CHAPTER 1: INTRODUCTION Polymerase Chain Reaction® Definition (PCR) About This Manual Typographical Conventions CHAPTER 2: PREREQUISITES Support Requirements Location and Air Current Requirements Electrical Requirements Space Requirements CHAPTER 3: GETTING STARTED Unpacking Your Enclosure Installing the Enclosure on a Supporting Structure & Work Surface Connecting the Electrical Supply Sealing the Enclosure to the Work Surface...
Page 5 CHAPTER 7: ACCESSORIZING YOUR ENCLOSURE Work Surfaces Storage Cabinets Base Stands & Mobile Stands CHAPTER 8: TROUBLESHOOTING APPENDIX A: REPLACEMENT PARTS APPENDIX B: DIMENSIONS APPENDIX C: SPECIFICATIONS DECLARATION OF CONFORMITY...
Page 6 Congratulations on your purchase of a Labconco Purifier Passive PCR Enclosure or Purifier Tissue Culture Enclosure. Your non- ventilated enclosure is designed to reduce cross-contamination in laboratory applications. The Purifier Passive PCR Enclosure and Purifier Tissue Culture Enclosure offer a UV light for disinfecting the interior and an interior switched electrical outlet.
Page 7 Chapter 1: Introduction strands of the DNA. When the solution cools, the primers bind to the separated strands, and DNA polymerase quickly builds a new strand by joining the free nucleotide bases to the primers. When this process is repeated, a strand that was formed with one primer binds to the other primer, resulting in a new strand that is restricted solely to the desired segment.
Page 8 Chapter 1: Introduction Chapter 7: Accessorizing Your Enclosure explains acceptable modifications or how to add accessories. Chapter 8: Troubleshooting contains a table of problems you may encounter while using the product including the probable causes of the problems and suggested corrective actions. Appendix A: Components contains labeled diagrams of all of the components of the enclosures.
Page 9 Before you install the enclosure, carefully examine the location. You must be certain that the area is level and of solid construction. In addition, a dedicated source of electrical power should be located near the installation site to power the enclosure. Carefully read this chapter to learn the requirements for your installation site: •...
Page 10 Chapter 2: Prerequisites • High traffic areas where walking might cause an air disturbance. • Overhead or wall HVAC diffusers, fans, radiators or other lab equipment producing air currents. • Next to doorways or windows that may be opened. Electrical Requirements Standard duplex electrical receptacles should be nearby for connecting the non-ventilated Purifier Passive PCR Enclosure or Purifier Tissue Culture Enclosure.
Page 11 Now that the site for your non-ventilated Purifier PCR or Purifier Tissue Culture Enclosures is properly prepared, you are ready to unpack, inspect and install your non-ventilated enclosure. Read this chapter to learn how to: • Unpack and move the enclosure. •...
Page 12 The front of the non- ventilated enclosure should be aligned within 1/8" of the front of the work surface. Mounting holes are provided in the Labconco accessory work surfaces to secure the enclosure. Product Service 1-800-522-7658...
Page 13 Chapter 3: Getting Started Work Surface Specifications The work surface should be smooth, rigid, and durable, such as a chemically-resistant epoxy resin. The surface should be non-porous and resistant to the materials used in conjunction with the Purifier PCR or Purifier Tissue Culture Enclosures. The work surface should also contain a dished recessed area for containing primary spills.
Page 14 Chapter 3: Getting Started Connecting the Electrical Supply A grounded receptacle should be nearby for connecting the Purifier PCR or Purifier Tissue Culture Enclosures. Please review Chapter 2 for electrical prerequisites. All wiring for the building electrical outlets SHOULD be performed by a licensed electrician and conform to all local codes.
Page 15 Features: Labconco engineered the Purifier Passive PCR Enclosure and Purifier Tissue Culture Enclosure to provide a non-ventilated, circulation-free work area to reduce cross-contamination in laboratory applications. A spacious interior and convenience outlet give ample room for media preparation and equipment used for procedures.
Page 16 Chapter 4: Features and Safety Precautions 9, Internal 10, Not Shown Figure 4-1 Features 1. Ergonomic Slope and Front of 20° provides maximum visibility, and comfort, reduces glare, thereby minimizing operator fatigue. 2. Internal Depth of 23" and interior height of 22" provides necessary depth and height to support procedures and other auxiliary equipment without extending outside the non-ventilated enclosure.
Page 17 Chapter 4: Features and Safety Precautions 5. Fluorescent Light provides illumination for the interior of the enclosure. 6. Ultraviolet Germicidal Light provides surface decontamination and maintains sterility inside the enclosure. It is located above the work area. 7. Variable PCR Digital UV Light Timer (Purifier PCR Enclosure only) allows the operator to time the surface disinfection of the work area for PCR protocols.
Page 18 Chapter 4: Features and Safety Precautions The use of safety goggles, protective clothing, gloves and any other personal protective equipment recommended by your safety officer should be used. The sash should remain in the down position while using the enclosure. Ensure the enclosure is connected to an electrical service in accordance with local and national electrical codes.
Page 19 Planning • Thoroughly understand procedures and equipment required before beginning work. • Arrange for minimal disruptions, such as room traffic or entry into the room while the enclosure is in use. Start-up • Clean and surface disinfect the inside of the enclosure. Use UV light as required for protocol.
Page 20 Now that you have an understanding of how to work in the non- ventilated enclosure, we will review the suggested maintenance schedule and common service operations. Routine Maintenance Schedule Weekly • Clean the enclosure interior appropriate for the application. Monthly (or more often as required) •...
Page 21 Chapter 6: Maintaining Your Enclosure Fluorescent Light Replacement 1. Disconnect power. 2. Locate the two Phillips machine screws on top of the light and remove. Lift up the light assembly. 3. Rotate and remove the old fluorescent lamp. 4. Reinstall the new fluorescent lamp, light and screws in reverse order.
Page 22 There are several ways to accessorize the enclosure for your individual requirements. These include the addition of accessory work surfaces, storage cabinets, base stands and mobile stands. 1. Work Surfaces An optional dished work surface is available. Dished work surfaces are contoured to fit the enclosure to contain spills.
Page 23 Chapter 7: Accessorizing Your Non-Ventilated Enclosure 2. Storage Cabinets SOLVENT ACID Size/Description Dual Doors Right Hinge Left Hinge Dual Doors Right Hinge Left Hinge 48" 9902000 9901000 36" 9902100 9901100 30" 9902200 9901200 24" 9902300 9902400 9901300 9901500 18" 9901400 9901600 12"...
Page 24 Refer to the following table if your enclosure fails to operate properly. If the suggested corrective actions do not solve your problem, contact Labconco for additional assistance. PROBLEM CAUSE CORRECTIVE ACTION Circuit breaker(s) Reset or replace circuit breaker. tripped. Lamp not installed Inspect lamp installation.
Page 25 The following illustrations indicate the replacement parts. Product Service 1-800-522-7658...
Page 26 Appendix A: Replacement Parts Item Qty. Part Number Description 3906500 Glass, Side Short 3906102 Glass, Sash 4' Short 3905602 Lower Foil 4' 2.3 Ft. 6913700 Wiper, Sash 1927403 Spring, Compression Sash Latch 3906700 Latch Bracket 6916500 Latch Sash 1893206 Screw, #8-32 x .38 Phil, SS, Type F 3945200 Sash Assembly 4' 3907400...
Page 27 Appendix A: Replacement Parts 15, Interior Light (3 Pos.) Figure A-1 Interior Figure A-2 Product Service 1-800-522-7658...
Page 28 See the following dimensions. Product Service 1-800-522-7658...
Page 29 This appendix contains electrical specifications, environmental conditions and wiring diagrams. Electrical Specifications • 10 Amps, 115V, 60 Hz, or 5 Amps, 230V, 50/60 Hz, Purifier Passive PCR Enclosure or Purifier Tissue Culture Enclosure. The auxiliary outlet load is 8 Amps on 115V and 4 Amps on 230V.
Page 30 Appendix C: Specifications Product Service 1-800-522-7658...
Page 31 Appendix C: Specifications Product Service 1-800-522-7658...
Page 32 Product Service 1-800-522-7658...
Page 33 Tissue Culture Enclosure Model Number* ______________________Serial Number* __________________________Date of Installation __________ *Model and serial numbers are located on the top and on the back. Indicate Labconco accessories purchased with your enclosure. ❑ Work Surface ❑ Other ________________________________ ❑ Base Stand ❑...
Page 34 LabbyWear is the official uniform ™ of LABsters everywhere! Be a LABster! As a token of our thanks for returning your Product Registration Card, we would like to send you the LabbyWear of your choice. Please select from one of the three items listed or collect Labby Bucks and redeem for other LabbyWear merchandise.
