  • Page 1 DICENTIS Conference System Installation manual...

  • Page 3: Table Of Contents

    Using a cable coupler to insert power locally 5.1.5 Using a cable coupler to switch the system on DICENTIS System cable assemblies DCNM-CBCON Connectors for DICENTIS cable DCNM-CBTK System Network Cable Toolkit DCNM-CB250 System installation cable DCNM-IDESKINT On-air & teleph. DCNM-IDESK...
  • Page 4 DCNM-IDESK / DCNM-IDESKVID Interpreter desk DICENTIS Microphones DCNM-MMDSP Anti-reflection foil DICENTIS Card holders 7.7.1 DCNM-NCH Name Card Holder 7.7.2 DCNM-DICH ID card holder for DCNM-D DICENTIS Electronic name cards Installation Test 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 5: Safety

    (Safety_ML). These instructions are supplied together with all equipment that can be connected to the mains supply. Safety precautions Some of the DICENTIS Conference System products are designed to be connected to the public mains network. To avoid any risk of electric shock, all interventions must be carried out with disconnected mains supply.
  • Page 6 Note: The FCC and IC Wireless statement applies to: – DCNM-MMD2 – DCNM-DVT – DCNM-DSL – DCNM-DE – DCNM-IDESK – DCNM-IDESKVID – DCNM-FIDP 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 7: About This Manual

    DICENTIS About this manual | en About this manual The purpose of this manual is to provide information required for installing the DICENTIS Conference System. This installation manual is available as a digital document in the Adobe portable document format (PDF).

  • Page 8: Document History

    2024-01 V6.1 Update to the Safety chapter, DCNM-CBCPLR, and DCNM-FAI. 2025-02 V6.4 Update to the chapters: DICENTIS tabletop devices and DCNM-FSLP Flush language selection panel. 2025-03 V6.5 Update to the subchapters: Typical system setup and Redundant server PC. Added chapter: DICENTIS Electronic name cards.

  • Page 9: System Installation Overview

    System installation overview | en System installation overview It is advisable to participate in the DICENTIS Conference System training before you install, configure, prepare, and operate a DICENTIS Conference System. The DICENTIS Conference System is an IP based conference system which runs on an OMNEO compatible Ethernet network.

  • Page 10: Typical System Setup

    This system overview does not give information on redundant network options. For more information, refer to Redundancy options, page 27. Figure 3.1: Typical DICENTIS Conference System setup A typical DICENTIS Conference System consists of: Hall display of the conference room: –...
  • Page 11 This device allows for wireless language distribution. 11. Powering switch: – Used to increase the number of DICENTIS devices connected to the system. 12. Audio processor and powering switch: – Controls the system audio, routes audio from and to the system and supplies power to the DICENTIS devices.
  • Page 12 Sony, Panasonic) 5 DCNM-SERVER3 6 L3 Ethernet switch 7 DCNM-APS2 8 DCNM-MMD2, displaying the active speaker on the device ….. HD-SDI (coax cable) ----- Ethernet TCP/IP _____ DCNM-Cables 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 13: System Extension

    DICENTIS System installation overview | en System extension The DICENTIS Conference System is scalable from small to medium to large. This section describes what a small, medium and large system is and what the requirements are for these systems: A small to medium DICENTIS Conference System (see Typical system setup, page 10) consists of: –...
  • Page 14 ARNI‑S. Defining subnets and subnet masks A subnet is a logical, visible subdivision of an IP network. The number of DICENTIS devices that can be in the same subnet depends on the subnet mask. A standard class C subnet (255.255.255 or /24) can contain 254 IP addresses. Some DICENTIS devices have 2 IP addresses.
  • Page 15 DICENTIS System installation overview | en Multi subnet DICENTIS Conference System The following figure illustrates a typical multi subnet DICENTIS Conference System with a total of 1500 DICENTIS devices. – The system is divided over four (4) subnets, where two (2) subnets having a maximum of 450 DICENTIS nodes and an OMN-ARNIS are connected.

  • Page 16: System Installation Design And Planning

    Notice! Make sure that the cable lengths and power consumptions do not exceed the specifications. Not doing so will result in malfunctioning at any moment of the DICENTIS Conference System and products. Caution! When the relative humidity is below 40%, synthetic materials can cause static discharge and result in malfunctions.
  • Page 17 The calculation tool is on the DVD supplied with the Audio processor and powering switch and is part of the DICENTIS software DCNM.iso file. The DCNM.iso file can be downloaded from the Bosch website at: https://licensing.boschsecurity.com/software...

  • Page 18: Hardware Requirements

    TOS byte Switch (hex) Priority queue PTP sync, 0x38 0xE0 Highest delay req PTP follow- 0x2E 0xB8 High up, delay response, audio (reserved) 0x08 0x20 Control 0x00 Best effort 0x00 None 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...
  • Page 19 RSTP is used to allow the creation of loops for redundancy. The switch must support changing the following parameters to the listed values: – Hello_Time = 9 seconds – Forwarding_delay = 30 seconds – Max_age = 22 seconds Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 20 8‑port router). – Non-blocking backplane per switching port, i.e. 2 Gbit per port (e.g. 16 Gbps for an 8‑port router). – MAC address table of at least 1000 addresses per directly connected subnet. 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 21: Power Supply Capacity Calculation Plan

    It is advisable to use the power calculation tool. The calculation tool is on the DVD supplied with the Audio processor and powering switch and is also part of the DICENTIS software DCNM.iso file, which can be downloaded from the Bosch website at: https:// licensing.boschsecurity.com/software...
  • Page 22 *The DCNM-FSL is powered by PoE and not via the DCNM-APS or DCNM-PS. See Calculation using PoE switches, page 25 for more information. Ordering number Cable lengths DCNM-CB02-I 6.56 DCNM-CB05-I 16.40 DCNM-CB10-I 32.81 DCNM-CB25-I 82.02 Table 4.2: Cable types and lengths 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...
  • Page 23 Mains inlet, mains switch and fuse holder. Reset button. Ground switch (grounded or floating). Socket 1 without power. Socket 2 low power. 15, 17, 19 Socket 3, 4, 5 high power. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 24 For socket 2, the cable power consumption of the cable does not need to be counted if only one device is connected to this output. The shortest redundant cable does not need to be counted. Refer to – Calculation using PoE switches, page 25 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 25: Calculation Using Poe Switches

    System installation design and planning | en 4.3.2 Calculation using PoE switches Select one or more PoE Ethernet switches to supply power to the DICENTIS devices. Each DICENTIS device must be connected to an individual PoE enabled output of an Ethernet switch.
  • Page 26 | System installation design and planning DICENTIS Figure 4.6: Bottom view DICENTIS Interpreter devices (DCNM-IDESK / DCNM-IDESKVID) Figure 4.7: Topview view DICENTIS Flush base device (DCNM-FBD2) Item Description Network connector Network / PoE connector 2025-03 | 6.5 | Bosch Security Systems B.V.

  • Page 27: Redundancy Options

    Redundant cabling for DCNM-APS2/DCNM-PS2 units, page 28. – Redundant server PC, page 30. Notice! Rapid Spanning Tree Protocol (RSTP) must be enabled in the DICENTIS Conference System for these redundancy options to work correctly. Notice! Follow these steps when setting up redundancy options for your system: First, set up your system without cable redundancy and RSTP configuration in the system and DICENTIS.

  • Page 28: Redundant Cabling For Dcnm-Aps2/Dcnm-Ps2 Units

    The # sign shows the way the devices are counted. In the example below up to 19 (22 - 3 = 19) discussion devices can be connected. Figure 4.8: DICENTIS discussion devices connected with redundant cabling between DCNM-PS2 / DCNM-APS2 type units...
  • Page 29 DCNM-PS2 units. Notice! Rapid Spanning Tree Protocol (RSTP) must be enabled in the DICENTIS Conference System for these redundancy options to work correctly. Bosch Security Systems B.V. 2025-03 | 6.5 |...

  • Page 30: Redundant Server Pc

    3 DCNM-APS2 4 DCNM-PS2 5 DICENTIS cabling (redundant loop) For this option to work the DICENTIS Conference System has to be run in combination with EverRun Enterprise software from Stratus Technologies. For more information, refer to the Stratus Technologies website.

  • Page 31: Installation Material And Tools

    – to extend cables, – in a floor pod as break-out box, – as an interface between DICENTIS cable and “standard” CAT-5E cable combined with a separate power cable, – to insert power locally to the participant devices, – to switch the system on by using two cable couplers and a switch.

  • Page 32: Using A Cable Coupler To Extend A Cable

    Using a cable coupler as a break-out box The DICENTIS Cable coupler can be used in a floor pod as a break-out box, for example, if you want to connect temporary devices like a rostrum microphone. The cable coupler can be fixated using the screw holes (2.5 mm) or via a tie wrap through the recessed area.

  • Page 33: Using A Cable Coupler As An Interface Between Different Types Of Cable

    Using a cable coupler as an interface between different types of cable The cable coupler can be used as an interface between DICENTIS cable and “standard” CAT-5E cable, optionally combined with a separate power cable. This can be used, for example, when standard CAT-5E cabling coming from the technical room has to be connected with DICENTIS cable in the conference room.

  • Page 34: Using A Cable Coupler To Insert Power Locally

    Risk of electric shock. Exposed power cables are a potential hazard. Make sure all power cables are securely fastened by fixing them with a tie wrap on the inside of the box (see drawing ‘Creating a tension relief’). 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...
  • Page 35 – the ripple should be less than 200 mV pk-pk – maximum output current should not exceed 3.0 A (or limited to 3.0 A, because DICENTIS cables and devices have a maximum rating for this current) – Requirement for the power cable: – Use a 20 AWG (0.5 mm ) cable –...

  • Page 36: Using A Cable Coupler To Switch The System On

    DICENTIS 5.1.5 Using a cable coupler to switch the system on The DICENTIS system automatically goes into “standby” mode when: – the option to automatically switch off the system after a period of inactivity is configured in the Meeting Application, and –...
  • Page 37 S1 or powering down the system. When the high power trunks are powered up, the switch of relay R2 will power relay 1 to keep the switch closed. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...

  • Page 38: Dicentis System Cable Assemblies

    | Installation material and tools DICENTIS DICENTIS System cable assemblies The DICENTIS System Cable Assemblies, terminated with connectors on both ends, are available in different lengths and are used to connect DICENTIS devices to each other. Ordering number Cable lengths DCNM-CB02-I 6.56...

  • Page 39: Dcnm-Cbcon Connectors For Dicentis Cable

    Power contact cavity (2 places) Housing Locking latch Signal contact cavity (8 Places) Refer to – DICENTIS System cable assemblies, page 38 – DCNM-CB250 System installation cable, page 41 – DCNM-CBTK System Network Cable Toolkit, page 40 Bosch Security Systems B.V.

  • Page 40: Dcnm-Cbtk System Network Cable Toolkit

    DICENTIS DCNM-CBTK System Network Cable Toolkit The system network cable toolkit is used to connect the DCNM-CBCON Connectors for DICENTIS cable, page 39 to the DCNM-CB250 System installation cable, page 41 or DICENTIS System cable assemblies, page 38. Item Description Power wiring tool.

  • Page 41: Dcnm-Cb250 System Installation Cable

    Refer also to the sections DCNM-CBCON Connectors for DICENTIS cable, page 39 and DCNM-CBTK System Network Cable Toolkit, page The DCNM-CB250-I cable can be used to create cable assemblies and leader cables.

  • Page 42: Dcnm-Ideskint On-Air & Teleph. Dcnm-Idesk

    | Installation material and tools DICENTIS DCNM-IDESKINT On-air & teleph. DCNM-IDESK The DCNM-IDESKINT On-air & teleph. DCNM-IDESK is an accessory that is connected to the DICENTIS Interpreter desk. It has 3 functions: – to control a booth on-air indicator outside the booth, –...
  • Page 43 LED. The input of the connector is used for the external telephone system, while the output is used for the external booth on-air LED. See the image and table below for reference. Figure 5.14: 8-pin Phoenix connector Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 44 0.75 mm with ferrule with plastic sleeve max. Table 5.4: Connection data Ferrules without insulating collar Cross section: 0.22 mm to 1.5 mm (according to DIN 46228-1) Length: 5 mm to 10 mm Table 5.5: Specifications for ferrules 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...
  • Page 45 DICENTIS Installation material and tools | en Figure 5.15: Connection diagram Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...

  • Page 46: Mechanical Installation Of Central Equipment

    – to route audio signals to/from devices, – to supply power to devices, – as an Ethernet switch to connect the PC and the participant and interpreting DICENTIS devices. The Powering switch is used to: – supply power to devices.
  • Page 47 Mains inlet, mains switch and fuse holder. Reset button. Ground switch (grounded or floating). Socket 1 without power. Socket 2 low power. 15, 17, 19 Socket 3, 4, 5 high power. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 48 Item Description 14, 16, 18, 20 Overload LED for sockets 2‑5: Green: Power OK. Red: Overload. Remove cable and wait a few seconds for the system to reset the overload. 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...
  • Page 49 The unit extends 30 mm in front of the 19” mounting brackets when installed in a 19” rack system. Caution! Do not obstruct the airflow vents on the front side and rear left and right sides. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...

  • Page 50: System Server

    | Mechanical installation of Central Equipment DICENTIS System server The DICENTIS System server is provided with pre-installed and configured Windows Server® for Embedded Systems - Telecommunications (16 Core), pre-installed DICENTIS Conference System software, and pre-configured DHCP server. Note: please refer to the datasheet for the technical specifications.

  • Page 51: Dante Gateway

    Mechanical installation of Central Equipment | en How to install The DICENTIS System can be mounted under a desk, behind a display or in a rack. To install the system server: Connect the DICENTIS System to the DICENTIS system (i.e. DCNM-(A)PS2 or network switch) using a CAT-5E cable.
  • Page 52 DICENTIS Notice! In a large system (with over 450 DICENTIS nodes), the OMN-DANTEGTW must be installed in the VLAN where the OMN-ARNI-E is available. In large systems, the OMN-DANTEGTW becomes the clock master and the OMN-ARNI-E can distribute it to the other VLANs / OMN- ARNI-S devices.
  • Page 53 Dante controller to set the Dante gateway as preferred clock master. – If these tips do not solve the problem, the device is broken and needs to be exchanged. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 54 Connect the Dante network port in the OMN-DANTEGTW to a network port in the Dante network. Connect the OMNEO network port in the OMN-DANTEGTW to the OMNEO network. Connect the mains supply. 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 55: Mechanical Installation Of Contribution Devices

    (chairperson use, depending on the configuration). Connecting DICENTIS devices The DICENTIS Conference System can be quickly and easily configured as a daisy‑chain configuration or as a star configuration: – Daisy‑chain configuration: Uses dedicated cabling, consisting of CAT‑5e cables including two additional power conductors (see Typical system setup, page 10).

  • Page 56: Dicentis Tabletop Devices

    | Mechanical installation of Contribution Devices DICENTIS DICENTIS tabletop devices DCNM-MMD / DCNM-MMD2 Figure 7.1: Front, top, rear and side views Item Description 7” capacitive touch screen. LED strip. Two‑way loudspeaker. 3.5 mm stereo jack for headphone or headset with integrated microphone.
  • Page 57 Figure 7.2: Front, top, rear and side views Item Description Two‑way loudspeaker. Near Field Communication (NFC) reader. Chairperson priority button, microphone mute button, or microphone request button for second participant. Microphone request button. Voting buttons. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 58 Tightening torque 0.7 Nm Depth 5 mm To connect the system network cables to the DICENTIS devices (refer to the following figure): Insert the system network cable/connector (2). Lead the system network cable through the cable guides (3). 2025-03 | 6.5 | Bosch Security Systems B.V.
  • Page 59 DICENTIS Mechanical installation of Contribution Devices | en Installing DICENTIS devices Figure 7.3: Bottom view discussion DICENTIS devices (DCNM-MMD / DCNM-MMD2) Figure 7.4: Bottom view DICENTIS devices (DCNM-D / DCNM-DVT / DCNM-DSL / DCNM-DE) Item Description Screw insert for fixed installation. 2x RJ45 connection input/output for system power cable.
  • Page 60 | Mechanical installation of Contribution Devices DICENTIS Item Description Cable guides. USB connector, for future use (DCNM-MMD / DCNM-MMD2 only). 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 61: Dicentis Flush-Mounted Devices

    DICENTIS Mechanical installation of Contribution Devices | en DICENTIS flush-mounted devices The flush-mounted devices create individual participant positions. They are ideal for use in permanent installations, because they offer great flexibility due to their modular set-up. You can select different flush-mounted devices depending on the functionalities you require.
  • Page 62 | Mechanical installation of Contribution Devices DICENTIS DCNM-FPT >2 +0.5 R2.5 - 0.5 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...
  • Page 63 Notice! Install DCNM-FEC Flush end caps on the couple pieces at the two ends of the recess. Total NSF x (mm) 71.5 121.5 171.5 221.5 271.5 321.5 371.5 421.5 471.5 Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 64 DCNM-FPRIOB DCNM-FVP DCNM-FSLP DCNM-FIDP DCNM-FLSP DCNM-FSL DCNM-FBPS DCNM-FBPW Table 7.3: Number-size factors Removing a flush-mounted device To remove a flush-mounted device installed on a surface, use the DCNM-FET Flush extraction tools. 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...
  • Page 65 DICENTIS Mechanical installation of Contribution Devices | en DCNM-FET DCNM-FET DCNM-FET DCNM-FET DCNM-FET Removing a flush-mounted device Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...

  • Page 66: Dcnm-Fbd2 Flush Base Device

    The flush base device is at the center of the various possible setups with the flush range. Besides the ports to connect the other flush products, it has two connectors for you to daisy-chain with the DICENTIS cables. Refer to Connecting DICENTIS devices, page 55. Control connection The flush base device has RJ12 connectors to power and control the button panels DCNM- FMICB or DCNM-FPRIOB.
  • Page 67 Description The device is powered off. Steady green The device is ready or fully operational. Blinking green The device is not connected to DICENTIS services. Steady orange The device is booting. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 68 Flush priority button panel DCNM-FIDP Flush identification panel DCNM-FVP Flush voting panel DCNM-FAI Flush audio interface DCNM-FLSP Flush loudspeaker panel DCNM-FMCP Flush microphone connection panel DCNM-FSLP Flush language selection panel 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 69: Dcnm-Fmcp Flush Microphone Connection Panel

    The DCNM-FMCP also connects to one of the button panels, DCNM-FMICB or DCNM- FPRIOB, which allows for control of the microphone’s LED and for powering the microphone. For this connection, use the 30 cm cable that comes with the panel. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...

  • Page 70: Dcnm-Fmicb Flush Microphone Button Panel

    DICENTIS 1 Connect the DCNM-FMCP to the 2 Connect the DCNM-FMPC to the DCNM-MICSLS/DCNM-MICSLL, as DCNM-FMICB/DCNM-FPRIOB/DCNM- described in DICENTIS Microphones, FAI for power and control of the LEDs page 96 of the microphone and the DCNM- FMCP pre-amplifier 3 Connect the DCNM-FMCP to the DCNM-FBD2 for the audio 7.3.3...

  • Page 71: Dcnm-Fpriob Flush Priority Button Panel

    The DCNM-FBD2 has two ports for loudspeakers, creating two participant seats. The DCNM-FLSP can be active at the same time as the microphone, making sure the speech intelligibility is excellent. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 72 Use it as a template to draw the lines by which you need to cut: the outside of the tool is the maximum cut, the inside of the tool is the minimum. 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...
  • Page 73 To use the DCNM-FPT to create a new table cut for the DCNM-FLSP, position the coupling pieces and use them to draw the lines by which you need to cut. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...

  • Page 74: Dcnm-Fvp Flush Voting Panel

    Use the 30 cm cable to connect, through RJ12, to the DCNM-FBD2 or to daisy-chain to the other panels. Use the headphone connection cable to connect to the headphone connector of the DCNM-FBD2. 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...
  • Page 75 You can connect an external headphones socket to the language selector (e.g. a 3.5 mm headphones socket). The external headphones socket must be connected to a plug or to solder pads. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 76 To prevent the user from suffering an unpleasant ESD discharge while inserting the headphones into the connector, always use a headphone connector with a plastic front in combination with the external headphone connection. 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 77: Dcnm-Fai Flush Audio Interface

    The flush audio interface connects to the flush hand held microphones to create participant seats and floor-standing positions. It also makes it easy to install a microphone that requires phantom power to the DICENTIS System flush-mounted setups. You can use the DCNM-FAI for: –...
  • Page 78 | Mechanical installation of Contribution Devices DICENTIS – Connecting a third party microphone or line level audio source to DICENTIS. Note: In this setup, it can also provide phantom power. Figure 7.11: Connecting the DCNM-FMCP to the DCNM-FBD2 through the DCNM-FAI...
  • Page 79 To see how to connect the flush hand held microphones, refer to DCNM-FHH / DCNM-FHHC Flush hand held microphones, page 83. Slide switches The DCNM-FAI comes with the following preset from factory: Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 80 | Mechanical installation of Contribution Devices DICENTIS The DCNM-FAI has three slide switches to configure the audio settings: 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...
  • Page 81 The power settings supported are: Phantom power of 48 V. No power on audio signal lines. Mic bias. This power setting does not support balanced signals. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 82 The DCNM-FAI also has an 8-pin connector with the signals for unbalanced and balanced audio, LED power for the microphone, and RTS button control. 1 2 3 4 5 6 7 8 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 83: Dcnm-Fhh / Dcnm-Fhhc Flush Hand Held Microphones

    They can also create a floor-stand microphone position. Depending on your needs and preferences, choose the DCNM-FHH with a straight cable or the DCNM-FHHC with a coiled cable, both with 5 m. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 84 | Mechanical installation of Contribution Devices DICENTIS Figure 7.13: Connect the DCNM-FAI to the DCNM-FHH / DCNM-FHHC Figure 7.14: DCNM-FAI switch settings to connect the DCNM-FHH / DCNM-FHHC 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 85: Dcnm-Fidp Flush Identification Panel

    FIDP for continuous and reliable identification. Mount it on the left or right of the DCNM- FIDP, at the end of the panels. The DCNM-FICH replaces the DCNM-FEC on that side. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 86 | Mechanical installation of Contribution Devices DICENTIS Figure 7.16: Replace the DCNM-FEC by the DCNM-FICH 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 87: Flush Setups

    A participant or chairperson seat with two microphones (rostrum) with: – Optional voting. – Optional language selection. – Optional participant identification. Refer to the diagrams on how to set up a DICENTIS flush system. Two participant or chairperson seats FIDP FPRIOB FMCP FMICB FLSP...
  • Page 88 Note: Per side, there only can be four CAN connected panels. Refer to Panels per side in DCNM-FBD2 Flush base device, page 66 for more information on CAN connected panels. 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 89: Dcnm-Fsl Flush Language Selector

    For a simple mounting in an armrest or other areas with limited space, the DCNM-FSL is powered via PoE utilizing a CAT-5E cable. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 90 The DCNM-FSL display automatically turns off when it is not used for 10 seconds. It will turn on again once you touch the volume control or language selection buttons. Connect the language selector to a PoE switch in the DICENTIS network with a CAT-5e cable.
  • Page 91 External headphone connection When using an external headphone connector, please install it according to the electrical diagram below (wiring and jack connector). Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 92 GND, so that the device thinks that a headphone is connected. Please note that this will cause the buttons' LEDs to be always on, which results in a shortened lifetime of the buttons' LEDs. 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 93: Dcnm-Idesk / Dcnm-Ideskvid Interpreter Desk

    Press these 2 buttons (with a small raised dash) at the same time to enter the installation mode and assign the device to a booth and desk. Refer to the DICENTIS Configuration manual, chapter “Configuring an IDESK (directly on the device)” on how to configure the interpreter desk.
  • Page 94 Two RJ45 compatible connections for system communication and power are available for quick and easy connection of the interpreter desks. Loop-through cabling can be applied by using DICENTIS System cables or star cabling using standard CAT-5e cables and PoE switches.
  • Page 95 The HDMI outgoing current is limited at 60mA, while the official HDMI standard specifies 55 mA. Some HDMI to VGA converters may require more current, which may result in unexpected behavior or a non-working converter. Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...

  • Page 96: Dicentis Microphones

    | Mechanical installation of Contribution Devices DICENTIS DICENTIS Microphones The DICENTIS Microphones are the DCNM‑HDMIC High directive microphone, the DCNM- MICL/S Stem microphones, and the DCNM-MICSLL/LS Screw lock microphones. These are typically used with the DICENTIS devices. Figure 7.22: DCNM-FHH / DCNM-FHHC, DCNM‑HDMIC, DCNM‑MICS / DCNM‑MICL and DCNM- MICSLL / DCNM-MICSLS...
  • Page 97 DICENTIS Mechanical installation of Contribution Devices | en Figure 7.23: DCNM‑HDMIC or DCNM-MICS / DCNM-MICL connection Gently guide the connection guidance (4) into the DICENTIS device microphone connector (9). Gently push the connector plug (6) into the device microphone connector (9) until the connection lock (5) fits/click into place.

  • Page 98: Dcnm-Mmdsp Anti-Reflection Foil

    | Mechanical installation of Contribution Devices DICENTIS DCNM-MMDSP Anti-reflection foil The DICENTIS anti‑reflection foil can be used to protect the tempered glass screen of a DICENTIS multimedia Device. Installation procedure Use the included alcohol swab and the microfiber fabric to clean the device LCD screen before installation.

  • Page 99: Dicentis Card Holders

    The DCNM-DICH can be used with the DCNM-DE, the DCNM-DSL, and the DCNM-DVT. Fixate the ID card holder easily by removing the protective foil at the rear, position it at the left side of the DICENTIS Discussion device, and press it firmly down as shown in the picture below: Bosch Security Systems B.V.
  • Page 100 100 en | Mechanical installation of Contribution Devices DICENTIS 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...

  • Page 101: Dicentis Electronic Name Cards

    There are two types of electronic name cards: DCNM-ENCS Electronic name card single sided and DCNM-ENCD Electronic name card double sided. After being installed and integrated into the DICENTIS topology, the electronic name cards are easily managed and automatically updated by the DICENTIS system. For information on how to manage and configure the devices, refer to the DICENTIS configuration manual.

  • Page 102: Installation Test

    Not to do so could result in a system malfunctioning. Each DICENTIS device has its own built‑in diagnostics, which can be used for faultfinding. The diagnostics starts as soon the DICENTIS device is powered on. The DICENTIS Conference System does not have to be configured with, and connected to, the system controller PC.
  • Page 103 “Please download software”. Now the device can be downloaded: – Downloading devices is not covered in this manual. Refer to the DICENTIS configuration manual on how to download the devices. Customer service If a fault cannot be resolved, please contact your supplier or system integrator, or go directly to your Bosch representative.
  • Page 104 104 | Installation Test DICENTIS 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...
  • Page 105 DICENTIS Installation Test | 105 Bosch Security Systems B.V. 2025-03 | 6.5 | Installation manual...
  • Page 106 106 | Installation Test DICENTIS 2025-03 | 6.5 | Bosch Security Systems B.V. Installation manual...
  • Page 108 Bosch Security Systems B.V. Torenallee 49 5617 BA Eindhoven Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2025 Building solutions for a better life 202503261656...
