WASHING MACHINE USER MANUAL

Serena MBN/MSN/BXN/SXN/GXN 7012K

Elite BXN/MBN 7012HK

Senator MSN/MXN/BXN 8012K

Senator SXN/BXN/MXN 8014K

Executive SXN/MSN/BXN/VSN 9014K

Executive Plus MSN/BXN 1014K

UF421PKMAN790 C

Need help?

Do you have a question about the DeepClean Serena MBN 7012K and is the answer not in the manual?

Questions and answers

Summary of Contents for IFB DeepClean Serena MBN 7012K

Page 1 WASHING MACHINE USER MANUAL Serena MBN/MSN/BXN/SXN/GXN 7012K Elite BXN/MBN 7012HK Senator MSN/MXN/BXN 8012K Senator SXN/BXN/MXN 8014K Executive SXN/MSN/BXN/VSN 9014K Executive Plus MSN/BXN 1014K UF421PKMAN790 C...
Page 3 Welcome to the IFB Family Get ready to experience excellence in washing and long lasting peace of mind. Happy Laundry Days to you! Front Load Washer...
Page 4 Contents The A to Z of Your Washing Machine The Display Panel Safety Guidelines Installation Instructions Caution About eWaste Section 1 Getting Started With Your Washing Machine Installing Your Machine & Safety Guidelines Before You Start Section 2 Running Your Machine 6 Easy Steps For Doing Your Laundry Finishing Program Guide...
Page 5 PRECAUTIONS This appliance meets the required safety standards, but using it improperly could cause injury or property damage. Make sure to read this manual carefully—it covers safety, installation, use and maintenance. Use detergents with low foam to prevent any problems. Following these guidelines will help you get the most out of your new washing machine and keep it running smoothly while avoiding accidents or damage.
Page 6 The A to Z of Your Washing Machine Detergent Control Program Power Dispenser Panel Selector ON/OFF Drawer Door Handle Porthole Door Adjustable Feet Filter for Levelling Cabinet Door...
Page 7 The A to Z of Your Washing Machine Power LED Display Temperature Spin Steam TimeSaver Soak Start/Pause...
Page 8 The Display Panel TEMPERATURE/PRE WASH Touch this button to select/change wash Temperature. To select Pre wash option, touch this button till P-0C P30C P40C P60C P95C is seen on the display. SPIN/EXTRA RINSE To select/change Spin Speed use this button. Keep this button pressed for 3 secs to select the Extra Rinse option.
Page 9 The Display Panel SOAK/TUB CLEAN Touch this button to Select/Deselect Soak. Press the button for 3 secs to select Tub Clean program. The message “tUb Cln 00:58 tUb Cln…” on the display means that the Tub Clean program has been selected. START/PAUSE Touch this button one time to Start/Pause the machine.
Page 10 The Display Panel TIME STATUS Displays Program Time, Spin Speed, Temperature, Error codes and other status updates. OPTIONS The corresponding options will— GLOW when selected, FLASH if available for selection and remain OFF if not selectable. Glows if Pre wash option is selected. Glows if Extra Rinse option is selected.
Page 11 ﬁtters, electricians, or technicians. All washing machine installation work must be carried out only by authorised IFB Care Service Personnel. Use only the new hoses provided with the machine; old hoses should never be reused.
Page 12 Your machine comes with ventilating openings on the base. Always put it directly on the ﬂoor after removing any carpets. Keep your machine safe from direct sunlight and rainfall. Avoid installing the machine in damp areas or bathrooms exposed to direct showers Don’t put the machine on a sloping, uneven, or unstable surface.
Page 13 (like fusing, voltage and frequency) match your electricity supply. If you’re not sure, reach out to IFB Care for help. Avoid washing or drying articles contaminated with combustible or explosive substances, such as oil, paint, gasoline, or solvents, to prevent ﬁre or explosions.
Page 14 Caution A WORD OF WARNING The manufacturer isn’t responsible if there’s a problem with the earthing system. Make sure your machine is connected to a grounded outlet with a 16A Fuse or MCB. If you’re unsure whether the machine is properly grounded, get it checked by a qualiﬁed technician or licensed electrician.
Page 15 Only use a new hose kit to connect your machine to the water supply on site. Don’t try to reuse old hoses. If any parts need replacing, make sure to use genuine IFB spare parts. That way, you can be sure your machine meets safety standards.
Page 16 Caution Keep your machine dry to avoid corrosion/rusting. Don’t spill water on the machine. If spills occur, wipe it dry. Your machine should be kept away from ﬂoor cleaning chemicals. Don’t wash or spray water over the switch or control panel. Keep the machine dry to prevent corrosion and rusting.
Page 17 Caution Your machine has been built according to current safety requirements. During assembly, the machine is tested with water to make sure it performs correctly. Sometimes, a few water droplets may be left inside the drum. Replace the trolley immediately if excessive vibrations are observed, as it can affect the machine’s reliability and lifespan.
Page 18 About eWaste eWaste, or Waste Electrical and Electronic Equipment (WEET), refers to discarded appliances using electricity. To responsibly manage eWaste, follow the guidelines below. • Always dispose of end-of-lifecycle products by contacting an authorised local eWaste recycler. • Do drop off used electronic products, batteries, or accessories at authorised eWaste recyclers.
Page 19 Provisions of Hazardous Substances outlined in eWaste Management Rule, 2016. FOR DETAILED INFORMATION AND DISPOSAL REQUEST Contact IFB Care at 080 695 45678. Provide your details to our representative to arrange for proper product disposal.
Page 20 Getting started with your washing machine SECTION Installation and Safety Guidelines SELECTING THE RIGHT SPOT Place the machine on a level ﬂoor. Make sure the machine is close to both water and electrical connections. REMOVING TRANSIT BOLTS Use a spanner to remove the transit bolts.
Page 21 Getting started with your washing machine SECTION Installation and Safety Guidelines LEVELLING Level the machine by using adjustable screws, as shown. Make sure all 4 feet are grounded. Levelled Levelled Locked and Locked...
Page 22 Getting Started With Your Washing Machine SECTION Installation and Safety Guidelines CONNECTION TO WATER SUPPLY The water inlet of the machine has a collar with parallel internal threads. Water supply point with a ¾” external/parallel thread should be within 1 m of the machine. Don’t stretch the water supply hose.
Page 23 Getting Started With Your Washing Machine SECTION Installation and Safety Guidelines CONNECTION TO DRAIN HOSE (contd) Is the sink on the left side? Follow this diagram. 100 cm Is the sink on the right side? Follow this diagram. 140 cm...
Page 24 Getting Started With Your Washing Machine SECTION Installation and Safety Guidelines ELECTRICAL CONNECTION A 16 Amp, 3 pin 220-240 V AC, 50 Hz electrical point with a 16 Amp MCB within 1 m of the machine is mandatory. Make sure your home has proper earthing and the connection between the socket...
Page 25 Running Your Machine SECTION 6 Easy Steps for Doing Your Laundry SORT THE LAUNDRY Pre treat collars, cuffs and stains. Check for wash care symbols. Close zippers, hooks and strings. Empty the pockets of your clothes.
Page 26 Running Your Machine SECTION 6 Easy Steps for Doing Your Laundry LOAD THE LAUNDRY Make sure the laundry drum is empty. Load garments one by one. Close the door and press till you hear a click.
Page 27 Note To be used to dispense Fragrances (Sensora) only during Refresh cycle. If liquid detergent is used, use the liquid detergent Additives/Fragrances dispenser supplied in the (IFB Sensora) main wash chamber. Liquid Detergent Dispenser...
Page 28 Running Your Machine SECTION Note Always use detergents that are recommended for front load washing machines. Using the wrong detergent can cause laundry issues. Avoid using soap ﬂakes or granulated soap powders in your washing machine. When washing woollens or silk, make sure to use the detergent type recommended by the manufacturer.
Page 29 Running Your Machine SECTION 6 Easy Steps for Doing Your Laundry SELECT PROGRAM Switch ON the machine. Turn the Program Selector knob to the required program. Start/Pause LED will ﬂash. Choose Wash Option. To change/cancel the program during the wash, press the Power ON/OFF button and wait for 2 secs, then select...
Page 30 Running Your Machine SECTION 6 Easy Steps for Doing Your Laundry START WASHING (contd) Door status will be displayed after pressing the Start/Pause button. If the Water Level inside the drum is above the rubber or the temperature inside the drum is high, the door won’t open.
Page 31 Running Your Machine SECTION Finishing Remove the laundry and wipe the moisture from the door and door seal. Leave the door slightly open. Wipe the panel and cabinet with a dry cloth to remove the moisture. Turn OFF the tap.
Page 32 Running Your Machine SECTION Program Guide PROGRAM TYPE OF LAUNDRY Mix/Daily Cotton, synthetic and easy-care garments. Not recommended for special garments like silk/delicates, dark clothes, wool, duvets, curtains, etc. Cotton Cotton colour-fast garments. Uniform/Linen Shirts, pants, uniforms, bed and table linen, towels, night dresses, pyjamas, underwear, etc.
Page 33 Running Your Machine SECTION Program Guide PROGRAM TYPE OF LAUNDRY Synthetic Polyester, acrylic or polyamide daily wear garments. CradleWash® Hand wash and delicate wash garments. Silk, lingerie, satin, synthetic or sheer fabrics. Sports Wear Singlets, leggings, jogging clothes and running wear. Bulky/Bedding Machine washable cotton curtains.
Page 34 Running Your Machine SECTION Wash Options OPTIONS Details Temperature/Pre wash Temp You can change the default temperature in the given range. Press the Temperature button on the Pre wash control and select from Cold, 30°C, 40°C, 60°C, 95°C, P 0°C, P 30°C, P 40°C, P 60°C, P 95°C, Cold and Repeat.
Page 35 Running Your Machine SECTION Wash Options OPTIONS Details Steam/WiFi Reset When the Steam option is selected, steam is produced inside the drum—at the Select optimum wash time to enhance the wash. *WiFi Reset Touch the Steam button on the control panel to select Steam or Time Saver Option.
Page 36 Select button within 4 secs. It is advisable not to soak coloured garments as they may bleed colour. For cold wash programs, Soak can be selected only through the My IFB app. *Note Soak/Warm Soak can be selected only through The My IFB App.
Page 37 Running Your Machine SECTION Wash Options OPTIONS Details Tub Clean Run this program to eliminate impurities, scaling, bacteria and unpleasant smell from the washing machine. IMPORTANT Do not put laundry in the washing machine during Tub Clean. Before running the Tub Clean program, empty the washing machine drum.
Page 38 Running Your Machine SECTION Wash Options OPTIONS Details Tub Clean Reminder The Tub Clean program reminder will appear on your washing machine after every 40 wash cycles. You can run the Tub Clean program or skip. It is recommended to run the Tub Clean program after every 40 cycles to keep your washing machine clean.
Page 39 Running Your Machine SECTION Wash Options OPTIONS Details Rinse Hold If clothes are left unattended for a long time it Options may cause creasing. This option pauses the program during its ﬁnal rinse to prevent this. ‘rinS HOLd’ message will appear on the display. You can cancel the current program or input your desired Speed/Spin and continue.
Page 40 Running Your Machine SECTION EMERGENCY DOOR LOCK RELEASE Note Emergency door lock release should be used only during power OFF/power failure. Using this ends the current program. PRECAUTIONS TO BE TAKEN FOR THE ABOVE Let the wash water cool down if it is hot. Don’t remove laundry from the drum while it is rotating.
Page 41 Running Your Machine SECTION Washing Symbols—A Guide RESISTANT MATERIAL DELICATE FABRIC WASHABLE AT 95°C WASHABLE AT 60°C WASHABLE AT 40°C WASHABLE AT 30°C HAND WASH DRY CLEAN ONLY WOOL SEAL BLEACHABLE IN COLD WATER DON’T BLEACH DON’T DRY CLEAN DRY FLAT HANG TO DRY DRY ON CLOTHES HANGER TUMBLE DRY, NORMAL HEAT...
Page 42 Running Your Machine SECTION Wash Guide Map LAUNDRY WEIGHT in KG PROGRAM Daily Temperature °C Cold, 30, 40, 60 Spin Speed RPM 400–1200/No Final Spin Cotton 9 10 Temperature °C Cold, 30, 40, 60, 95, 40 E, 60E** Spin Speed RPM 400–1200/No Final Spin (7012/8012) Spin Speed RPM 400–1400/No Final Spin (8014/9014/1014) Synthetic Temperature °C Cold, 30, 40, 60...
Page 43 Running Your Machine SECTION Wash Guide Map LAUNDRY WEIGHT in KG PROGRAM Refresh items items items items Temperature °C | Spin Speed RPM 9 10 Spin Dry Rinse Temperature °C Spin Speed RPM 400–1200/No Final Spin (7012/8012) Spin Speed RPM 400–1400/No Final Spin (8014/9014/1014) Cradle Wash®...
Page 44 WEIGHT in KG PROGRAM Express 15’ Temperature °C Cold, 30, 40 Spin Speed RPM 400–1200/No Final Spin PROGRAMS VIA MY IFB APP Sports Wear Temperature °C Cold, 40 Spin Speed RPM 400–800/No Final Spin Express 30’ Temperature °C 40, 60 Spin Speed RPM 400–1200/No Final Spin...
Page 45 Running Your Machine SECTION Wash Guide Map LAUNDRY WEIGHT in KG PROGRAMS VIA MY IFB APP Wool Temperature °C Cold, 30, 40 Spin Speed RPM 400–800/No Final Spin Tub Clean Temperature °C Cold, 60, 95 Spin Speed RPM Dark Wash Temperature °C 40...
Page 46 Running Your Machine SECTION Wash Guide Map LAUNDRY WEIGHT in KG PROGRAMS VIA MY IFB APP Jeans Temperature °C 60 Spin Speed RPM 400–1200/No Final Spin (7012/8012) Spin Speed RPM 400–1400/No Final Spin (8014/9014/1014) Shirts /Blouses Temperature °C Cold, 30, 40, 60 Spin Speed RPM 400–800/No Final Spin...
Page 47 Machine SECTION Wash Guide Map LAUNDRY WEIGHT in KG PROGRAMS VIA MY IFB APP Linen Temperature °C Cold, 30, 40 Spin Speed RPM 400–600/No Final Spin Note With Cotton Eco 60** program, the actual wash temperature attained will be lower than 60°C, although the wash performance will be at par with the Cotton 60°C program.
Page 48 Running Your Machine SECTION Key Features ADVANCED WASH TECHNOLOGY Powered by Ai Available on selected models only The intuitive sensing logic in the machine detects two parameters important for fabric care during cleaning— · Type of fabric Cotton, Mixed or Synthetic ·...
Page 49 Running Your Machine SECTION Key Features ADVANCED WASH TECHNOLOGY Aqua Energie The technology that energises water to carry the detergent deep into the fabric. CradleWash® India’s ﬁrst wash program for the care of delicate fabrics. Crescent Moon Drum The crescent moon design of the drum allows the water to cushion the wash and protect the fabric.
Page 50 Running Your Machine SECTION Key Features WASH PROGRAMS AND OPTIONS More than 100 thoughtfully designed programs and options to give your clothes the ultimate wash experience. Time, Energy, Water Saving Cotton 40E/60E Express 15’ Time Saver Fabric Friendly Wash Cotton, Synthetic, CradleWash®, Wool, Mix/Daily, Linen Hygienic Wash...
Page 51 Running Your Machine SECTION Key Features MACHINE CARE Auto Tub Clean Automatically ensures tub hygiene after the wash. Auto Foam Control System Auto detection and control of excess foaming. High-Low Voltage Protection A microcontroller continuously monitors the voltage ﬂuctuations and stops the program if it goes below 150±...
Page 52 Running Your Machine SECTION Key Features USER CONVENIENCE Child Lock Prevents children from tampering with the machine settings. Laundry Add Lets you add laundry even after the cycle has started. Anti Crease Reduces wrinkling of clothes for easy ironing.
Page 53 Get More From Your Machine SECTION Tips for best results BEFORE WASHING Empty all pockets. Remove everything including coins, keys, pins, notes etc. Close all zips and fasten all hooks. Check the wash care label and avoid non-machine washable items. WHILE SORTING Separate polyester fabrics from cotton.
Page 54 Put the stained area face down on a paper towel or white cloth. Apply the stain remover You can also use to the back of the stain so IFB Fabo Stain Remover that the stain is forced for stubborn stains out of the cloth.
Page 55 Get More From Your Machine SECTION Stain Treatment...
Page 56 Get More From Your Machine SECTION Stain Treatment STAIN TREATMENT Use ice in a plastic bag to harden the gum. Chewing gum Adhesive Scrape off what you can and then sponge Tape with white spirits. Rubber Cement Blood Rinse and soak immediately in cold water with an enzyme pre wash.
Page 57 Get More From Your Machine SECTION Stain Treatment STAIN TREATMENT Treat as soon as possible by sponging with Fruit cold water. Rub a little detergent on the stain and wash. Grass Sponge with white spirits. Rub in an enzyme pre wash and then wash. Grease Sponge with white spirits or dry-cleaning ﬂuid and then wash.
Page 58 Get More From Your Machine SECTION Stain Treatment STAIN TREATMENT Treat while still wet. Rinse in warm water Water Based Paint and wash. Scorch Marks Dampen a cloth with hydrogen peroxide. Lay it over the affected area and press with a hot iron. Some inks are impossible to remove.
Page 59 Get More From Your Machine SECTION Maintenance and Cleaning CLEANING THE DETERGENT DISPENSER DRAWER Remove detergent residue regularly. Clean the detergent dispenser drawer with warm water. Remove and clean the siphon under running warm water. Detergent residue can build in the dispenser housing, clean it before reinstalling the dispenser.
Page 60 Get More From Your Machine SECTION Maintenance and Cleaning CLEANING THE WATER HOSE MESH FILTER Turn OFF taps and disconnect the power supply to the machine. Unscrew the inlet hose from the machine and tap the drain water from the hose. Remove the ﬁlter mesh from the tap end of the inlet hose and clean under...
Page 61 Get More From Your Machine SECTION Maintenance and Cleaning CLEANING THE FILTER The ﬁlter should be cleaned frequently in order to increase the life of the drain pump. Open the detachable bottom door with a coin or a key. Drain Plug Emergency Place a shallow container Lever...
Page 62 Get More From Your Machine SECTION Let’s make washing easier. Here is a list of clothes and their approximate weights to help you figure out a perfect wash load. CLOTHING WEIGHTS Bottoms Sheets Lungi/Dhoti 200 g Cotton (Double) 1 Kg Skirts 200 g Cotton (Single)
Page 63 Get More From Your Machine SECTION This table may help you plan a laundry load of 7, 8, 9, 10 Kg. LAUNDRY ITEMS 7 Kg 8 Kg 9 Kg 10 Kg Bath Towels Shirts Blouses Skirts Pair of Pants Pair of Jeans T-shirts Set of Pyjamas Tea Towels...
Page 64 Opening the door Check if the machine is not possible. is displaying the ‘dL Er’ message. Child Lock is active. Disable the Child Lock and wait until the Door display glows. If the problem persists, contact IFB Care.
Page 65 Machine door is not Close the machine securely closed. door properly. Inlet hose is bent, Straighten the inlet sieve, inlet valve or hose. Check; unclog the hose is clogged. the sieve, valve and hose. If the problem persists, contact IFB Care.
Page 66 Check and tighten the Inlet hose Water leakage inlet hose connection. connection is loose. in the machine. Filter is not securely Check and tighten tightened. the ﬁlter. Inlet hose is leaking. Contact IFB Care. If the problem persists, contact IFB Care.
Page 67 Filter is partially Clean and ensure that clogged. the ﬁlter is unclogged. Add a few clothes to Load is unbalanced. balance the load. Rearrange the load to allow proper spinning. If the problem persists, contact IFB Care.
Page 68 Select the Start/Pause is active. button at Rinse Hold stage. Filter is clogged. Clean and ensure that the ﬁlter is unclogged. Excessively foaming Use detergents detergent is used. recommended for Front Load Washing Machines only. If the problem persists, contact IFB Care.
Page 69 Use only the required Blue stains fabric additives. amount of fabric on clothes. additives. Do not pour additives directly on the fabric. Additives of inferior Use good quality fabric quality being used. additives. If the problem persists, contact IFB Care.
Page 70 Excessive use of Use proper amount detergent. of detergent. Cold wash program. Use hot wash program. Button not pressed All the buttons are Buttons not properly. sensitive and need working. to be pressed softly. If the problem persists, contact IFB Care.
Page 71 In case of a disbalance in load, the machine Balance time makes attempts to redistribute the clothes on display remains to minimise vibrations. This can extend the unchanged. duration of the program. If the problem persists, contact IFB Care.
Page 72 Useful Information About Your Washing Machine SECTION Display THE LED DISPLAY GIVES YOU COMPLETE INFORMATION • Program Selection • Wash Option Selection • Program Balance Time • Program Status • Problem/Fault Indications, if any • Child Lock Selection • Door Status •...
Page 73 SECTION Display Messages & Error Codes For any code displayed that is not present in the following list or if the suggested solution does not ﬁx the problem, contact IFB Care or an authorised dealer. DISPLAY PROBABLE CAUSE SOLUTION rinS HOLd—Indicates...
Page 74 After the water drains out, rearrange the clothes and restart the wash program. If the problem and/or the display persists, contact IFB Care.
Page 75 Useful Information About Your Washing Machine SECTION Display Messages & Error Codes DISPLAY PROBABLE CAUSE SOLUTION DP—Water not Touch Start/Pause drained. button to restart the Drain program. Filter is blocked. Switch OFF the appliance, drain out the water using the drain pump and then clean the ﬁlter.
Page 76 If the same message appears again, turn OFF the tap, switch OFF the appliance and contact IFB Care. For further assistance please download My IFB App for service registrations or you call us on our call centre number 08045845678/ 080 695 45678...
Page 77 ≤ 9 Ltr/Kg/cycle CONSUMPTION WATER PRESSURE 0.3 Bar - 10 Bar (3.5–10 Ltr/min) MAXIMUM POWER Refer to the product label CONSUMPTION DRAIN PUMP 30 W RATING HEATER RATING 2000 W DRUM Stainless Steel **12 programs available via the My IFB app.
Page 78 Senator SXN/BXN/MXN 8014K Executive SXN/MSN/BXN/VSN 9014K Executive PLUS MSN/BXN 1014K Characteristic Symbol Critical (Cc) Significant (Sc) MATERIAL MANUAL No Revision Paper UF421PKMAN790 IFB Industries Limited, Goa Rev Information Date Change Checked Date Approved Date New manual 09/02 2024 Updated for...
Page 79 +91 080 458 45678/080 695 45678 +91 92310 04321 www.ifbappliances.com...
