Barco F400 Quick Start Manual

Environment conditions
Environment
Ambient temperature
Humidity
Altitude
Air cleanness
Air clearance
Remote control & local keypad
1
2
3
4
5
6
7
1 Shutter close 7 Input selection
2 Shutter open 8 Power On/Off
3 Button pressed 9 OSD On/Off
4 Lens menu 10 Confirmation
5 Navigation 11 Menu enter/exit
6 Menu back 12 Test patterns
1. Equivalent with cleanroom standard ISO 14644-1 ISO Class 9. If not, an environment protection housing must be used.
R5914423 /05 | 2024-09-04
Operating
5°C (41°F) to 40°C (104°F) (0–1500 m)
10°C (50°F) to 35°C (95°F) (1500–3000 m)
10% RH to 80% RH Non-condensed
0 m (0 Ft) to 3000 m (9842 Ft)
Clean office environment
Air outlets: minimum 250 mm (10 in)
Air inlets: minimum 250 mm (10 in)
8
9
10
11
12
1 Navigation
2 Confirmation
3 Menu enter/exit
4 Menu back
5 Power On/Off
6 OSD On/Off
Quick Start Guide
Non-Operating
-20°C (-4°F) to 60°C (140°F)
10% RH to 90% RH Non-Condensed
-60 m (-197 Ft) to 10000 m (32810 Ft)
1 n.a.
n.a.
1
11 10
ENABLING BRIGHT OUTCOMES
F400
2 3 4 5 6
9 8 7
7 Input selection
8 Shutter open/close
9 Test patterns
10 Lens menu
11 LCD touch panel
