- Page 1 1473-1-8573 │14.08.2014 Technical Manual Sensor unit 1gang; 2gang 1gang (SU-F-1.0.PB.1) 2gang (SU-F-2.0.PB.1)
-
Page 2: Table Of Contents
® ABB-free@home Content Notes on the instruction manual ________________________________________________________ 3 Safety ____________________________________________________________________________ 4 Used symbols ________________________________________________________________________ 4 Intended use _________________________________________________________________________ 5 Improper use _________________________________________________________________________ 5 Target group / qualification of personnel ____________________________________________________ 5 Safety instructions _____________________________________________________________________ 6 Information on protection of the environment ______________________________________________ 7... -
Page 3: Notes On The Instruction Manual
® ABB-free@home Notes on the instruction manual Notes on the instruction manual Please read this manual through carefully and adhere to the information contained therein. This will assist you in preventing damage to persons and property and ensure reliable operation and long service life of the device. -
Page 4: Safety
® ABB-free@home Safety Safety The device has been constructed according to the latest valid regulations governing technology and is operationally reliable. It has been tested and left the factory in a technically safe and reliable state. However, residual hazards remain. Read and adhere to the safety instructions to pre- vent such hazards. -
Page 5: Intended Use
® ABB-free@home Safety Intended use This device is a sensor unit for decentralized flush-mounted installation. The sensor unit (with bus coupler) can be assigned to an available switch actuator. The devices serve for switching processes and are not pre-programmed. The device is intended for the following: »... -
Page 6: Safety Instructions
® ABB-free@home Safety Safety instructions Warning Electric voltage! Risk of death and fire due to electrical voltage of 230 V. Dangerous currents flow through the body when coming into direct or indirect contact with live components. This can result in electric shock, burns or even death. -
Page 7: Information On Protection Of The Environment
® ABB-free@home Information on protection of the environment Information on protection of the environment All packaging materials and devices bear the markings and test seals for proper disposal. The products meet the legal requirements, in particular the laws governing elec-... -
Page 8: Product Description
® ABB-free@home Product description Product description Fig. 1: Product overview [1] Flush-mounted insert, 1gang [2] Flush-mounted insert, 2gang [3] Support ring (not included in scope of delivery) [4] Cover frame (not included in scope of delivery) [5] Push-button (not included in scope of delivery) This device is a sensor unit for decentralized flush-mounted installation. -
Page 9: Type Overview
® ABB-free@home Product description Type overview Article no. Product name Sensor channels SU-F-1.0.PB.1 Sensor unit, 1gang SU-F-2.0.PB.1 Sensor unit, 2gang Table 1: Overview of types Function overview The following table provides an overview of the possible functions and applica- tions of the device:... -
Page 10: Device Overview Of Sensor Unit, 1Gang
® ABB-free@home Product description Device overview of sensor unit, 1gang Fig. 2: Device overview of sensor unit, 1gang [1] Mark TOP [2] Type plate [3] Bus connection terminal Device overview of sensor unit, 2gang Fig. 3: Device overview of sensor unit, 2gang... -
Page 11: Technical Data
® ABB-free@home Technical data Technical data Main overview Parameters Value Power Supply 24 V DC (via bus line) Bus subscribers 1 (12mA) Connection Bus connection terminal: 0.4-0.8 mm Line type J-Y(St)Y, 2 x 2x 0.8 mm Wire stripping 6-7 mm... -
Page 12: Mounting
® ABB-free@home Mounting Mounting Planning instructions Note... Planning and application instructions for the system are available in the free@home system manual. They can be downloaded at www.abb.com/freeathome. Safety instructions for mounting Warning - Risk of death due to electrical voltage Dangerous currents flow through the body when coming into di- rect or indirect contact with live components. -
Page 13: Mounting / Installation
® ABB-free@home Mounting Mounting / Installation » Turn the device into the correct installation position. The mark "TOP" [1] must be aligned toward the top. » Turn the support ring into the correct instal- lation position. The mark "TOP" [2] must be aligned toward the top. - Page 14 ® ABB-free@home Mounting » Insert the device into the flush-mounted box and screw it on. Technical Manual 1473-1-8573 │14...
-
Page 15: Commissioning
® ABB-free@home Commissioning Commissioning Commissioning is always carried out via the Web-based surface of the System Access Point. The System Access Point establishes the connection between the free@home participants and the smartphone, tablet or PC. It is used to identify and program the participants during commissioning. - Page 16 ® ABB-free@home Commissioning Adding device Fig. 6: Adding devices » In the "Add device" bar select the desired application and pull it via drag-and- drop onto the floor plan in the working area. Fig. 7: Allocation A pop-up window opens automatically which lists all the devices suitable for the application selected.
- Page 17 ® ABB-free@home Commissioning Identification via serial number Sensor Unit 1gang Sensor Unit flushm. ABB700000012 Fig. 8 Identification via serial number » Compare the short 3-digit number of the identity label, which should be glued to the device plan, with the numbers in the list and in this way identify the de- vice you are searching for and, if necessary, also the channel.
-
Page 18: Setting Options Per Channel
® ABB-free@home Commissioning Setting options per channel General settings and special parameter settings can be made for each channel. The settings are made via the placement function of the Web- based user interface of the System Access Point. Device selection Fig. - Page 19 ® ABB-free@home Commissioning 7.2.1 Settings of sensor unit, 1gang Sensor settings [1] Changing the name [2] Deleting the channel via 'X' Sensor Unit 1-gang [3] Selecting the push-button in the list view Push-button Push-button settings [1] Changing the name Push-button...
-
Page 20: Linking
® ABB-free@home Commissioning Linking The sensor units created via the allocation function can now be linked with actua- tors. This allows simple ON/OFF circuits or two-way circuits to be implemented. The linking in the list view is then made via the linking function of the Web-based user interface of the System Access Point. - Page 21 ® ABB-free@home Commissioning Connecting an actuator with an additional sensor Fig. 12: Connecting actuator and sensor » To connect the actuator with an additional sensor, first click on the second desired sensor [1] which is to operate the actuator and then on the actuator [2].
-
Page 22: Updating Options
® ABB-free@home Updating options Updating options A Firmware update is carried out via the Web-based user interface of the System Access Point. Technical Manual 1473-1-8573 │22... -
Page 23: Operation
® ABB-free@home Operation Operation Operation is carried out by pressing the individual push-buttons. Their function is fixed via the assigned application or its pre-programming and its parameter set- tings. Extensive applications are available for the push-buttons (control buttons). Note... The scope of delivery contains only the electronic insert. It must still be completed with a suitable push-button and a cover frame. -
Page 24: Maintenance
® ABB-free@home Maintenance Maintenance The unit is maintenance-free. In case of damage (e.g., during transport or stor- age), do not perform repairs. Once the device is opened, the warranty is void! Access to the device must be guaranteed for operation, testing, inspection, maintenance and repairs (according to DIN VDE 0100-520). - Page 25 ® ABB-free@home A member of the ABB Group Note We reserve the right to at all times Busch-Jaeger Elektro GmbH make technical changes as well as PO Box changes to the contents of this 58505 Lüdenscheid document without prior notice.
